BaSiCPy 1.2.0

A python package for background and shading correction of optical microscopy images

BaSiCPy

A python package for background and shading correction of optical microscopy images

BaSiCPy is a python package for background and shading correction of optical microscopy images. It is developed based on the Matlab version of BaSiC tool with major improvements in the algorithm.

Reference:

• BaSiCPy: A robust and scalable shadow correction tool for optical microscopy images (in prep.)
• A BaSiC Tool for Background and Shading Correction of Optical Microscopy Images by Tingying Peng, Kurt Thorn, Timm Schroeder, Lichao Wang, Fabian J Theis, Carsten Marr*, Nassir Navab*, Nature Communication 8:14836 (2017). doi: 10.1038/ncomms14836.

Simple examples

Notebook	Description	Colab Link
timelapse_brightfield	100 continuous brightfield frames of a time-lapse movie of differentiating mouse hematopoietic stem cells.
timelapse_nanog	189 continuous fluorescence frames of a time-lapse movie of differentiating mouse embryonic stem cells, which move much more slower compared to the fast moving hematopoietic stem cells, resulting in a much larger correlation between frames. Note that in this challenging case, the automatic parameters are no longer optimal, so we use the manual parameter setting (larger smooth regularization on both flat-field and dark-field) to improve BaSiC’s performance.
WSI_brain	you can stitch image tiles together to view the effect of shading correction

You can also find examples of running the package at notebooks folder. Data used in the examples and a description can be downloaded from Zenodo.

---

Usage

See Read the Docs for the detailed usage.

Installation

For Mac (Intel chip), Linux or WSL2 users

Install from PyPI

pip install basicpy

or install the latest development version

git clone https://github.com/peng-lab/BaSiCPy.git
cd BaSiCPy
pip install .

For Mac users with M1 / M2 chip

BaSiCPy requires jax, which has potential build issue with M1 chips. One easiest solution is using Miniforge as explained here. In the Miniforge environment, please try the following:

conda install -c conda-forge jax jaxlib
pip install basicpy

For Windows users

BaSiCPy requires jax which does not support Windows officially. However, thanks to cloudhan/jax-windows-builder, we can install BaSiCPy as follows:

pip install "jax[cpu]==0.4.11" -f https://whls.blob.core.windows.net/unstable/index.html --use-deprecated legacy-resolver
pip install ml-dtypes==0.2.0
pip install basicpy

One may need to add

import jax
jax.config.update('jax_platform_name', 'cpu')

at the top of the script to ensure that JAX uses CPU.

For details and latest updates, see this issue.

Install with dev dependencies

git clone https://github.com/peng-lab/BaSiCPy.git
cd BaSiCPy
python -m venv venv
source venv/bin/activate
pip install -e '.[dev]'

Development

bump2version

This repository uses bump2version to manage dependencies. New releases are pushed to PyPi in the CI pipeline when a new version is committed with a version tag and pushed to the repo.

The development flow should use the following process:

1. New features and bug fixes should be pushed to dev
2. When tests have passed a new development version is ready to be release, use bump2version major|minor|patch. This will commit and create a new version tag with the -dev suffix.
3. Additional fixes/features can be added to the current development release by using bump2version build.
4. Once the new bugs/features have been tested and a main release is ready, use bump2version release to remove the -dev suffix.

After creating a new tagged version, push to Github and the version will be built and pushed to PyPi.

All-contributors

This repository uses All Contributors to manage the contributor list. Please execute the following to add/update contributors.

yarn
yarn all-contributors add username contribution
yarn all-contributors generate # to reflect the changes to README.md

For the possible contribution types, see the All Contributors documentation.

Contributors

Current version

Nicholas-Schaub 📆 👀 🚇 ⚠️ 💻 🤔

Tim Morello 💻 📖 👀 ⚠️ 🤔 🚇

Tingying Peng 🔣 💵 📆 📢 💻

Yohsuke T. Fukai 🔬 💻 🤔 👀 ⚠️ 💬 🚇

YuLiu-web 📖 📓

For details on the contribution roles, see the documentation.

Old version (f3fcf19), used as the reference implementation to check the approximate algorithm

• Lorenz Lamm (@LorenzLamm)
• Mohammad Mirkazemi (@Mirkazemi)
