Emerging technologies Management and Risk evaluation on distributions Grid Evolution

Project description

EMeRGE

EMeRGE (Emerging technologies Management and Risk evaluation on distribution Grids Evolution) is a collection of mini-tools to help users develop openDSS feeder model from GIS (.shp) file and perform risk analysis at various PV scenarios and visulize results in an interactive dashboard made using Dash.

Releases

Installation

Run the following command to install:

pip install EMeRGE

Usage

csvextractor package (converts .shp files into CSV files)

  1. Requirements
    1. All .shp files stored in a folder
    2. QGIS, an open source tool (3.8 version) installed
    3. Open QGIS python shell, copy and paste the code from csvextractor/converter.py
    4. Pass input_path and output_path to GIS2CSV class instance

csvconverter package (converts CSVs exported from csvextractor into standard formats)

  1. Requirements
    1. Store all extracted CSV files from QGIS in a folder name 'GISCSVs'
    2. Store extra CSV files containing load profile data, solar profile data, linecode and wiredata (sample files available in github) in a folder names 'ExtraCSVs'

Creating a project skeleton for CSV formatting

    from csvconverter.formatter import Convert
    instance = Convert()
    instance.create_skeleton(<project_path>)

Converting CSVs into a standard format

Using config.json file

    from csvconverter.formatter import Convert
    instance = Convert('config.json')

Using python dict

    from csvconverter.formatter import Convert
    intance = Convert({'project_path':r'.\Project_formatter','feeder_name':'Test'})

dssgenerator package (generates dss files from CSV files)

  1. Requirements:
    1. Standard CSV files generated using csvconverter stored in a folder name same as feeder name
    2. Extra CSV files containing load profile, voltage profile and solar profile data in a folder named 'ExtraCSVs'

Creating a project skeleon for generating DSS files

    from dssgenerator.generator import CSV2DSS
    intance = CSV2DSS()
    instance.create_skeleton(<project_path>,<feeder_name>)

Converting CSV files into DSS files

Using config.json file

    from dssgenerator.generator import CSV2DSS
    instance = CSV2DSS('config.json')

Using using python dict

    from dssgenerator.generator import CSV2DSS
    instance = CSV2DSS({'project_path':".",'feeder_name':'test'})

dssmetrics package (Compute metrics)

Exporting metrics for a single scenario

  1. Requirements:
    1. OpenDSS files of distribution system
    2. Three pickle files (each file should contain python dictionary with element name as key and array of downward customer name as value) for 'Tranformer', 'Line' and 'Node'. Use pickle files generated by module CSV2DSS.
    3. Temperature data in the same resolution as simulation time period. (Optional)
    4. Transformer life parameters (Optional)
    5. Data from 4.2, 4.3 and 4.4 can be stored in a single folder and path can be specified in config.json

using config.json file

    from dssmetrics.opendss import OpenDSS
    instance = OpenDSS('config.json')
    instance.qsts_powerflow()

How to get config.json file for computing metrics for a single scenario

    from dssmetrics.opendss import OpenDSS
    instance = OpenDSS()

Exporting metrics for a multiple PV scenarios

  1. Requirements
    1. For each scenario create a folder inside DSSScenarios and copy dss files inside that folder
    2. Copy pickle files, temperature data (optional) and transformer life parameters (optional) inside ExtraData folder
    3. Inside Category folder create a new folder, copy and paste the config.json inside a new folder. Note before running code you have to do few edits on config.json

Create a project skeleton for computing metrics for multiple PV Scenarios

    from dssmetrics.main import MultipleOpenDSS
    a = MultipleOpenDSS()
    a.create_skeleton(<project_path>,<project_name>)

Computing metrics for multiple scenarios

using config.json file

    from dssmetrics.main import MultipleOpenDSS
    instance = MultipleOpenDSS()
    instance.simulate('config.json')

dssdashboard package (Visuallize data in dashboard)

  1. Requirements
    1. Coordinates folder should contain coordinate csv files for line,node,customers and transformers
    2. PVMetrics folder should contain results after computing metrics for various PV scenarios using dssmetrics package (without volt/var)
    3. AdvancedPVMetrics folder should contain results after computing metrics for various PV scenarios using dssmetrics package (with volt/var)
    4. Profile folder should contain profile for all consumer classes along with solar profil
    5. PVConnection folder - should have two folders : 'Base' containing all dss files and 'ExtraData' containing pickle files and csv files (requirement same as dssmetric package)

Creating a project skeleton for creating dashboard

    from dssdashboard.dashboard import AppServer
    instance = AppServer()
    instance.create_skeleton(<project_path>,<feeder_name>)

Launching a dashboard

using config.json file

    from dssdashboard.dashboard import AppServer
    instance = AppServer('config.json')
    instance.launch(port=8060)

JSON format of config.json file (csvconverter package)

{
    "project_path" : "",
    "feeder_name" : "",
    "log_settings": {
        "save_in_file": false,
        "log_folder": "",
        "log_filename":"",
        "clear_old_log_file": true
        },
    "MVA_to_KVA_conversion_for_PT"  : "yes",
    "force_lt_be_three_phase" : "yes",
    "PTrow" :  0,
    "three_phase" : "RYB",
    "single_phase" : ["R","Y","B"],
    "height_of_top_conductor_ht" : 9,
    "height_of_top_conductor_lt" : 8,
    "ht_spacing" : 1,
    "lt_spacing" : 0.47,
    "geomtry_units" : "m",
    "Service_wire_single_phase" : {
        "conductor_spacing" : 0.47,
        "num_of_cond" : 2,
        "num_of_phases" : 1,
        "height_of_top_conductor": 8,
        "phase_conductor":"AAAC_4.0",
        "neutral_conductor" : "AAAC_4.0",
        "units": "m",
        "spacing": "vertical"
    },
    "Service_wire_three_phase": {
        "conductor_spacing" : 0.47,
        "num_of_cond" : 4,
        "num_of_phases" : 3,
        "height_of_top_conductor": 8,
        "phase_conductor": "AAAC_4.0",
        "neutral_conductor" : "AAAC_4.0",
        "units": "m",
        "spacing": "vertical"
    },
    "ht_three_phase" : {
        "conductor_spacing" : 1,
        "num_of_cond" : 3,
        "num_of_phases" : 3,
        "height_of_top_conductor": 9,
        "phase_conductor": "RABBIT_7/3.35",
        "neutral_conductor" : "RABBIT_7/3.35",
        "units": "m",
        "spacing":"vertical"
    },
    "Consumer_kv": {
        "ht_consumer_ll" : 11.0,
        "ht_consumer_phase" : 6.6,
        "lt_consumer_ll" : 0.44,
        "lt_consumer_phase" : 0.23
    },
    "load_type": {
        "lt_consumer" : "wye",
        "ht_consumer" : "delta"
    },
    "ht_line": {
        "node_file_name" : "Asset_HT_Line_node.csv",
        "attribute_file_name" : "Asset_HT_Line_attribute.csv"
    },
    "ht_cable": {
        "node_file_name" : "Asset_HT_Line_Cable_node.csv",
        "attribute_file_name" : "Asset_HT_Line_Cable_attribute.csv"
    },
    "lt_line":{
        "node_file_name" : "Asset_LT_Line_node.csv",
        "attribute_file_name" : "Asset_LT_Line_attribute.csv"
    },
    "lt_cable":{
        "node_file_name" : "Asset_LT_Line_Cable_node.csv",
        "attribute_file_name" : "Asset_LT_Line_Cable_attribute.csv"
    },
    "line_column_mapper": {
        "length" : ["SHAPE_Leng"],
        "phase" :  ["force","RYB"],
        "four_conductor_system" : ["3Ph Five wire system","3Ph Four wire system"],
        "three_conductor_system" : ["3Ph Three wire system"],
        "two_conductor_system" : ["1Ph Three wire system","1Ph Two wire system","2Ph Three wire system"],
        "phase_system" : ["HTL_PWS","HTLC_PWS","LTL_PWS","LTLC_PWS"],
        "csize" : ["HTL_CSIZE_","HTLC_CBL_S","LTL_CSIZE","LTLC_CBL_S"],
        "cname" : ["HTL_CNAME","HTLC_CBL_T","LTL_CNAME","LTLC_CBL_T"],
        "nsize" : ["LTL_N_CSIZ"],
        "nname" : ["LTL_N_CNAM"],
        "units" : ["force","m"],
        "spacing" : ["force","vertical"]
    },
    "distribution_transformer":{"file_name" : "Asset_Distribution_Transformer.csv"},
    "power_transformer":{"file_name" : "Asset_Power_Transformer.csv"},
    "transformer_column_mapper": {
        "ID"  : ["DT_ID","PTR_ID"],
        "KVA_cap" : ["DT_CC_KVA","PTR_CAP_MV"],
        "HV_KV" : ["DT_HVSV_KV","PTR_PRY_VO"],
        "LV_KV" : ["DT_LVSV_KV","PTR_SEC_VO"],
        "maxtap" : ["force","1.1"],
        "mintap" : ["force","0.9"],
        "tap" : ["force","1.0"],
        "numtaps" : ["force","10"],
        "prim_con" : ["force","delta"],
        "sec_con" : ["force","wye"],
        "vector_group" : ["force","Dyn11"],
        "%resistance" : ["force","0.75"],
        "%reactance" : ["force","7.5"],
        "%noloadloss" : ["force","0"],
        "phase" : ["force","RYB"],
        "x" : ["x"],
        "y" : ["y"]
    },
    "lt_consumer": {"file_name" : "Consumer_LT.csv"},
    "ht_consumer":{"file_name" : "Consumer_HT.csv"},
    "consumer_column_mapper": {
        "pf" : ["LTC_PF","HTC_PF"],
        "tariff_type" : ["LTC_TCODE","HTC_TCODE"],
        "phase": ["LTC_PHASE","HTC_PHASE"],
        "Sanctioned_load" : ["LTC_SLOAD_","HTC_SDEMAN"],
        "x" : ["x"],
        "y" : ["y"],
        "PeakMWload" :  1.2,
        "estimate_consumer_peakkw" : "yes"
    },
    "consumer_class_by_tariff":{
        "residential" : ["LT Tariff IA","LT Tariff I B","LT Tariff VI"],
        "commercial" : ["LT Tariff II-A","LT Tariff II-B(1)","LT Tariff II-C", "LT Tariff V","LT Tariff II-B(2"],
        "industrial" : ["LT Tariff III-A (1)", "LT Tariff III-B","TARIFF III"],
        "agricultural" : ["LT Tariff IV"]
    },
    "peak_contribution": {
        "residential" : 0.867,
        "commercial" : 0.105,
        "industrial" : 0.017,
        "agricultural" : 0.011
    },
    "tec_per_kw_by_consumer_type":{
        "residential" : 5937.831,
        "commercial" : 6168.84,
        "industrial" : 6206.385,
        "agricultural" : 6102.5
    }
}

Arguments

  1. Definitions
    1. project_path - str, path to a project folder
    2. feeder_name - str, CSVs will be stored in this folder
    3. log_settings - dict, settings for logging
      1. save_in_file - bool, set to true if you want to save log info in a file
      2. log_folder - str, folder path for saving log file
      3. log_filename- str, log file name, must end with '.log'
      4. clear_old_log_file- bool, set to true if you want to clear old log file
    4. MVA_to_KVA_conversion_for_PT - str, set to "yes" if conversion is necessary
    5. force_lt_be_three_phase - str, set to 'yes' if you want to force lt lines to be three phase
    6. PTrow - int, in case of multiple PTs define which row number in CSV file
    7. three_phase - str, e.g. "RYB"
    8. single_phase - list, e.g. ['R', 'Y', 'B']
    9. height_of_top_conductor_ht - float
    10. height_of_top_conductor_lt - float
    11. ht_spacing - float
    12. lt_spacing - float
    13. geomtry_units - str, e.g. "m"
    14. Service_wire_single_phase - dict, service wire info
      1. conductor_spacing - float,
      2. num_of_cond - int
      3. num_of_phases - int
      4. height_of_top_conductor- int
      5. phase_conductor- str
      6. neutral_conductor - str 7 units - str
      7. spacing- str, can be only 'vertical' or 'horizontal'
    15. Service_wire_three_phase - dict, service wire info (three phase)
      1. conductor_spacing - float
      2. num_of_cond - int
      3. num_of_phases - int
      4. height_of_top_conductor- float
      5. phase_conductor- str
      6. neutral_conductor - str
      7. units- str, e.g. 'm'
      8. spacing- str, can only be 'vertical' or 'horizontal'
    16. ht_three_phase - dict, ht conductor info
      1. conductor_spacing - float
      2. num_of_cond - int
      3. num_of_phases - int
      4. height_of_top_conductor- float
      5. phase_conductor- str
      6. neutral_conductor - str
      7. units- str
      8. spacing- str
    17. Consumer_kv- dict
      1. ht_consumer_ll - float
      2. ht_consumer_phase - float
      3. lt_consumer_ll - float
      4. lt_consumer_phase - float
    18. load_type- dict
      1. lt_consumer - str, can be either 'wye' or 'delta'
      2. ht_consumer - tr, can be either 'wye' or 'delta'
    19. ht_line- dict
      1. node_file_name - str
      2. attribute_file_name - str
    20. ht_cable- dict
      1. node_file_name - str
      2. attribute_file_name - str
    21. lt_line- dict
      1. node_file_name - str
      2. attribute_file_name - str
    22. lt_cable- dict
      1. node_file_name - str
      2. attribute_file_name - str
    23. line_column_mapper- dict
      1. length - list
      2. phase - list
      3. four_conductor_system - list
      4. three_conductor_system - list
      5. two_conductor_system - list
      6. phase_system - list
      7. csize - list
      8. cname - list
      9. nsize - list
      10. nname - list
      11. units - list
      12. spacing - list
    24. distribution_transformer- dict
      1. file_name - str
    25. power_transformer- dict
      1. file_name - str
    26. transformer_column_mapper- dict
      1. ID - list
      2. KVA_cap - list
      3. HV_KV - list
      4. LV_KV - list
      5. maxtap - list
      6. mintap - list
      7. tap - list
      8. numtaps - list
      9. prim_con - list
      10. sec_con - list
      11. vector_group - list
      12. %resistance - list
      13. %reactance - list
      14. %noloadloss - list
      15. phase - list
      16. x - list
      17. y - list
    27. lt_consumer- dict
      1. file_name - str
    28. ht_consumer- dict
      1. file_name - str
    29. consumer_column_mapper- dict
      1. pf - list
      2. tariff_type - list
      3. phase- list
      4. Sanctioned_load - list
      5. x - list
      6. y - list
      7. PeakMWload - float
      8. estimate_consumer_peakkw - str, either 'yes' or 'no'
    30. consumer_class_by_tariff- dict
      1. residential - list
      2. commercial - list
      3. industrial - list
      4. agricultural - list
    31. peak_contribution- dict
      1. residential - float,
      2. commercial - float,
      3. industrial - float,
      4. agricultural - float
    32. tec_per_kw_by_consumer_type-{
      1. residential - float,
      2. commercial - float,
      3. industrial - float,
      4. agricultural - float

JSON format of configuration file for dss conversion (dssgenerator package)

{
    "project_path" : "",
    "feeder_name" : "",
    "log_settings": {
        "save_in_file": false,
        "log_folder": "",
        "log_filename":"",
        "clear_old_log_file": true
        },
    "PV_customers_step" : 10,
    "PV_capacity_step" : 1,
    "number_of_monte_carlo_run" : 1,
    "export_pickle_for_risk_analysis" : "yes",
    "time_series_pf" : "yes",
    "num_of_data_points" : 35040,
    "minute-interval" : 15,
    "time_series_voltage_profile" : "yes",
    "voltage_csv_name" : "voltagemult.csv",
    "sourcebasekv" : 33.0,
    "sourcebasefreq" : 50,
    "sourcepu" : 1.0,
    "sourcezeroseq_impedance" : [0.001,0.001],
    "sourceposseq_impedance" : [0.001,0.001],
    "source_num_of_phase" : 3,
    "include_PV" : "yes",
    "PV_volt_label" : [0.44,0.23],
    "annual_PV_capacity_factor" : 0.25,
    "inverter_oversize_factor" : 0.9,
    "max_pu_irradiance" : 0.98,
    "no_reactive_support_from_PV" : "yes",
    "PV_cutin" : 0.05,
    "PV_cutout" : 0.05,
    "solar_csvname" : "solarmult.csv",
    "three_phase" : "RYB",
    "single_phase" : ["R","Y","B"],
    "random_phase_allocation" : "yes",
    "multi_threephase_for_lt" : "yes",
    "num_of_parallel_three_phase" : 3,
    "servicewire_phase_conductor_type" : "AAAC",
    "servicewire_phase_conductor_size" : "4.0",
    "phase_conductor_type_ht_consumer" : "RABBIT",
    "phase_conductor_size_ht_consumer" : "7/3.35",
    "service_wire_spacing" : "vertical",
    "ht_consumer_conductor_spacing" : "vertical",
    "units_for_coordinate" : "m",
    "service_wire_num_of_cond" : {
        "single_phase" : 2,
        "three_phase" : 4
    },
    "ht_consumer_conductor_num_of_cond": {"three_phase" : 3},
    "phase2num" :{"R" : 1,"Y" : 2,"B" : 3}
}

Arguments

  1. Definitions
    1. project_path - str, folder path containing data
    2. feeder_name - str, feeder name
    3. log_settings- dict, settings for logging
      1. save_in_file - bool, set to true if want to save in file
      2. log_folder - str, folder where you want to save log file
      3. log_filename - str, log file name
      4. clear_old_log_file- bool, set to true if you want to clear the ol log file
    4. PV_customers_step - int, number of scenarios with unique percentage customers 5 PV_capacity_step - int, number of scenarios with unique percentage pv capacity
    5. number_of_monte_carlo_run - int, must be greater than or equlal to 1
    6. export_pickle_for_risk_analysis - str, either "yes" or "no"
    7. time_series_pf - str, "yes" or "no", specifying no will generate dss files for snapshot powerflow only
    8. num_of_data_points - int, number of data-point in time series
    9. minute-interval - int, simulation time step
    10. time_series_voltage_profile - str, "yes" or "no" - whether to include voltage profile or not
    11. voltage_csv_name - str, csv file name of voltage profile
    12. sourcebasekv - float, voltage in kV
    13. sourcebasefreq - int, can be either 50 or 60
    14. sourcepu - float, pu voltage of swing bus
    15. sourcezeroseq_impedance - list, e.g. [0.001, 0.001]
    16. sourceposseq_impedance - list e.g. [0.001, 0.001],
    17. source_num_of_phase - int, number of phases of swing bus
    18. include_PV - str, either "yes" or "no" include PV or not
    19. PV_volt_label - list, voltage level at which PV is to be connected [0.44, 0.23]
    20. annual_PV_capacity_factor - float, PV annual capacity factor
    21. inverter_oversize_factor - float, inverter size over PV size
    22. max_pu_irradiance - float, maximum pu irradiance
    23. no_reactive_support_from_PV - str, either "yes" or "no"
    24. PV_cutin - float, pv cutin as defined in opendss
    25. PV_cutout - float, pv cutout as defined in opendss
    26. solar_csvname - str, csv filename of solar profile
    27. three_phase - str, e.g. "RYB"
    28. single_phase - list, e.g. ['R', 'Y', 'B']
    29. random_phase_allocation - str, either "yes" or "no" random phase allocation for customers
    30. multi_threephase_for_lt - str, either "yes" or "no"
    31. num_of_parallel_three_phase - int, number of parallel three phases
    32. servicewire_phase_conductor_type - str, name of conductor to be used as service conductor e.g. "AAAC"
    33. servicewire_phase_conductor_size - str
    34. phase_conductor_type_ht_consumer - str
    35. phase_conductor_size_ht_consumer - str
    36. service_wire_spacing - str, either 'vertical' or 'horizontal'
    37. ht_consumer_conductor_spacing - str, either 'vertical' or 'horizontal'
    38. units_for_coordinate - str, e.g. "m"
    39. service_wire_num_of_cond - dict
      1. single_phase - int, number of conductors
      2. three_phase - int, number of conductors
    40. ht_consumer_conductor_num_of_cond - dict
      1. three_phase - int, number of conductors
    41. phase2num - dict
      1. R - int e.g 1
      2. Y - int e.g 2
      3. B - int e.g 3

JSON format (Exporting metric for a multiple scenarios - dssmetrics package)

{
    "project_path": "",
    "active_project":"",
	"active_scenario": "",
	"dss_filename":"",
    "start_time":"2018-1-1 0:0:0",
    "end_time":"2018-1-2 23:30:0",
    "simulation_time_step (minute)": 60,
    "parallel_simulation":true,
    "parallel_process": 2,
    "frequency": 50,
    "upper_voltage": 1.1,
    "lower_voltage":0.9,
    "record_every": 4,
    "export_voltages": false,
    "export_lineloadings": false,
    "export_transloadings":false,
    "export_start_date": "2018-1-1 0:0:0",
    "export_end_date": "2018-1-2 0:0:0",
    "volt_var": {
                "enabled": false,
                "yarray": [0.44,0.44,0,0,-0.44,-0.44],
                "xarray": [0.7,0.90,0.95,1.05,1.10,1.3]
                },
    "log_settings": {
                    "save_in_file": true,
                    "log_filename":"system",
                    "clear_old_log_file": true
                    }
}

Arguments

  1. Definitions
    1. project_path - str, path to a project folder
    2. active_project - str, name of feeder or project inside project folder
    3. active_scenario - str, name of scenario
    4. dss_filename - str, master dss filename
    5. start_time - str, simulation start time
    6. end_time - str, simulation end time
    7. simulation_time_step (minute) - int or float, simulation resolution
    8. frequency - int, can be either 50 or 60
    9. upper_voltage - float, must be >1.0 and represents overvoltage threshold
    10. lower_voltage - float, must be <1.0 and represents undervoltage threshold
    11. record_every - int, multiple of simulation time-step
    12. export_voltages: bool, set to true if you want to export voltges
    13. export_lineloadings: bool, set to true if you want to export line loadings
    14. export_transloadings: bool, set to true if toy want to export transformer loadings
    15. export_start_date: str, start date for export results ((must be in format "2018-1-1 0:0:0"))
    16. export_end_date: str, end date for export results (must be in format "2018-1-1 0:0:0"),
    17. volt_var: dict, volt/var parameters
      1. enabled: bool, set to true to enable volt var
      2. yarray: list, refer to opendss manual for volt-var yarray
      3. xarray: list, refer to opendss manual for volt-var xarray
    18. log_setting - dict, settings for logging
      1. save_in_file - bool, true if logs to be saved in file else false
      2. log_folder - str, folder path where you want to save log file
      3. log_filename - str, name of the log file
      4. clear_old_log_file - bool, clears old log file if exists

JSON format (Exporting metric for a single scenario - dssmetrics package)

{
    "dss_filepath": "",
    "dss_filename":"",
    "extra_data_path": "",
    "export_folder":"",
    "start_time":"2018-1-1 0:0:0",
    "end_time":"2018-6-1 0:0:0",
    "simulation_time_step (minute)": 15,
    "frequency": 50,
    "upper_voltage": 1.1,
    "lower_voltage":0.9,
    "record_every": 96,
    "export_voltages": false,
    "export_lineloadings": false,
    "export_transloadings":false,
    "export_start_date": "2018-1-1 0:0:0",
    "export_end_date": "2018-1-2 0:0:0",
    "volt_var": {
                "enabled": false,
                "yarray": [0.44,0.44,0,0,-0.44,-0.44],
                "xarray": [0.7,0.90,0.95,1.05,1.10,1.3]
                },
    "log_settings": {
                    "save_in_file": false,
                    "log_folder": "",
                    "log_filename":"",
                    "clear_old_log_file": true
                    }
}

Arguments

  1. Definitions
    1. dss_filepath - str, folder path containing all .dss files
    2. dss_filename - str, master dss filename
    3. extra_data_path - str, folder path containing pickle files and .csv input files
    4. start_time - str, simulation start time
    5. end_time - str, simulation end time
    6. simulation_time_step (minute) - int or float, simulation resolution
    7. frequency - int, can be either 50 or 60
    8. upper_voltage - float, must be >1.0 and represents overvoltage threshold
    9. lower_voltage - float, must be <1.0 and represents undervoltage threshold
    10. record_every - int, multiple of simulation time-step
    11. export_voltages: bool, set to true if you want to export voltges
    12. export_lineloadings: bool, set to true if you want to export line loadings
    13. export_transloadings: bool, set to true if toy want to export transformer loadings
    14. export_start_date: str, start date for export results ((must be in format "2018-1-1 0:0:0"))
    15. export_end_date: str, end date for export results (must be in format "2018-1-1 0:0:0"),
    16. volt_var: dict, volt/var parameters 16.1. enabled: bool, set to true to enable volt var 16.2. yarray: list, refer to opendss manual for volt-var yarray 16.3. xarray: list, refer to opendss manual for volt-var xarray
    17. log_setting - dict, settings for logging 17.1. save_in_file - bool, true if logs to be saved in file else false 17.2. log_folder - str, folder path where you want to save log file 17.3. log_filename - str, name of the log file 17.4. clear_old_log_file - bool, clears old log file if exists

JSON format for creating dashboard (dssdashboard package)

    {
    "project_path": "",
    "active_project":"",
    "time_step(min)":"",
    "year": 2018,
    "log_filename":"log.log",
    "pv_connection": {
        "dss_filename": "",
        "simulation_time_step (minute)": 15,
        "frequency": 50,
        "upper_voltage": 1.1,
        "lower_voltage":0.9
    }
    }

Arguments

  1. Definitions
    1. project_path - str, path to project folder
    2. active_project - str, name of project of folder inside project folder
    3. time_step(min) - str, time resolution in minute, same as simulatio time period
    4. year - int, set the year for load profile analysis
    5. log_filename - str, path to log file, if not log will be displayed on the screen
    6. pv_connection - dict, settings for running powerflow
      1. dss_filename: str, dss file name
      2. simulation_time_step (minute): int, simulation resolution in minute,
      3. frequency: int, frequency can be only 50 or 60
      4. upper_voltage: float, upper voltage limit
      5. lower_voltage: float, lower voltage limit

Project details


Download files

Download the file for your platform. If you're not sure which to choose, learn more about installing packages.

Files for EMeRGE, version 1.5.1
Filename, size File type Python version Upload date Hashes
Filename, size EMeRGE-1.5.1-py3-none-any.whl (70.1 kB) File type Wheel Python version py3 Upload date Hashes View
Filename, size EMeRGE-1.5.1.tar.gz (284.2 kB) File type Source Python version None Upload date Hashes View

Supported by

AWS AWS Cloud computing Datadog Datadog Monitoring Facebook / Instagram Facebook / Instagram PSF Sponsor Fastly Fastly CDN Google Google Object Storage and Download Analytics Microsoft Microsoft PSF Sponsor Pingdom Pingdom Monitoring Salesforce Salesforce PSF Sponsor Sentry Sentry Error logging StatusPage StatusPage Status page
