Project description

aghast

Build Status Binder

Aghast is a histogramming library that does not fill histograms and does not plot them. Its role is behind the scenes, to provide better communication between histogramming libraries.

Specifically, it is a structured representation of aggregated, histogram-like statistics as sharable "ghasts." It has all of the "bells and whistles" often associated with plain histograms, such as number of entries, unbinned mean and standard deviation, bin errors, associated fit functions, profile plots, and even simple ntuples (needed for unbinned fits or machine learning applications). ROOT has all of these features; Numpy has none of them.

The purpose of aghast is to be an intermediate when converting ROOT histograms into Numpy, or vice-versa, or both of these into Boost.Histogram, Physt, Pandas, etc. Without an intermediate representation, converting between N libraries (to get the advantages of all) would equire N(N ‒ 1)/2 conversion routines; with an intermediate representation, we only need N, and the mapping of feature to feature can be made explicit in terms of a common language.

Furthermore, aghast is a Flatbuffers schema, so it can be deciphered in many languages, with lazy, random-access, and uses a small amount of memory. A collection of histograms, functions, and ntuples can be shared among processes as shared memory, used in remote procedure calls, processed incrementally in a memory-mapped file, or saved in files with future-proof schema evolution.

Installation from packages

Install aghast like any other Python package:

pip install aghast                        # maybe with sudo or --user, or in virtualenv

(Not on conda yet.)

Manual installation

After you git-clone this GitHub repository and ensure that numpy is installed, somehow:

pip install "flatbuffers>=1.8.0"          # for the flatbuffers runtime (with Numpy)
cd python                                 # only implementation so far is in Python
python setup.py install                   # to use it outside of this directory

Now you should be able to import aghast or from aghast import * in Python.

If you need to change flatbuffers/aghast.fbs, you'll need to additionally:

  1. Get flatc to generate Python sources from flatbuffers/aghast.fbs. I use conda install -c conda-forge flatbuffers. (The flatc executable is not included in the pip flatbuffers package, and the Python runtime is not included in the conda flatbuffers package. They're disjoint.)
  2. In the python directory, run ./generate_flatbuffers.py (which calls flatc and does some post-processing).

Every time you change flatbuffers/aghast.fbs, re-run ./generate_flatbuffers.py.

Documentation

Full specification:

Tutorial examples

Run this tutorial on Binder.

Conversions

The main purpose of aghast is to move aggregated, histogram-like statistics (called "ghasts") from one framework to the next. This requires a conversion of high-level domain concepts.

Consider the following example: in Numpy, a histogram is simply a 2-tuple of arrays with special meaning—bin contents, then bin edges.

import numpy

numpy_hist = numpy.histogram(numpy.random.normal(0, 1, int(10e6)), bins=80, range=(-5, 5))
numpy_hist

(array([     2,      5,      9,     15,     29,     49,     80,    104,
           237,    352,    555,    867,   1447,   2046,   3037,   4562,
          6805,   9540,  13529,  18584,  25593,  35000,  46024,  59103,
         76492,  96441, 119873, 146159, 177533, 210628, 246316, 283292,
        321377, 359314, 393857, 426446, 453031, 474806, 489846, 496646,
        497922, 490499, 473200, 453527, 425650, 393297, 358537, 321099,
        282519, 246469, 211181, 177550, 147417, 120322,  96592,  76665,
         59587,  45776,  34459,  25900,  18876,  13576,   9571,   6662,
          4629,   3161,   2069,   1334,    878,    581,    332,    220,
           135,     65,     39,     26,     19,     15,      4,      4]),
 array([-5.   , -4.875, -4.75 , -4.625, -4.5  , -4.375, -4.25 , -4.125,
        -4.   , -3.875, -3.75 , -3.625, -3.5  , -3.375, -3.25 , -3.125,
        -3.   , -2.875, -2.75 , -2.625, -2.5  , -2.375, -2.25 , -2.125,
        -2.   , -1.875, -1.75 , -1.625, -1.5  , -1.375, -1.25 , -1.125,
        -1.   , -0.875, -0.75 , -0.625, -0.5  , -0.375, -0.25 , -0.125,
         0.   ,  0.125,  0.25 ,  0.375,  0.5  ,  0.625,  0.75 ,  0.875,
         1.   ,  1.125,  1.25 ,  1.375,  1.5  ,  1.625,  1.75 ,  1.875,
         2.   ,  2.125,  2.25 ,  2.375,  2.5  ,  2.625,  2.75 ,  2.875,
         3.   ,  3.125,  3.25 ,  3.375,  3.5  ,  3.625,  3.75 ,  3.875,
         4.   ,  4.125,  4.25 ,  4.375,  4.5  ,  4.625,  4.75 ,  4.875,
         5.   ]))

We convert that into the aghast equivalent (a "ghast") with a connector (two functions: from_numpy and to_numpy).

import aghast

ghastly_hist = aghast.from_numpy(numpy_hist)
ghastly_hist

<Histogram at 0x7f0dc88a9b38>

This object is instantiated from a class structure built from simple pieces.

ghastly_hist.dump()

Histogram(
  axis=[
    Axis(binning=RegularBinning(num=80, interval=RealInterval(low=-5.0, high=5.0)))
  ],
  counts=
    UnweightedCounts(
      counts=
        InterpretedInlineInt64Buffer(
          buffer=
              [     2      5      9     15     29     49     80    104    237    352
                  555    867   1447   2046   3037   4562   6805   9540  13529  18584
                25593  35000  46024  59103  76492  96441 119873 146159 177533 210628
               246316 283292 321377 359314 393857 426446 453031 474806 489846 496646
               497922 490499 473200 453527 425650 393297 358537 321099 282519 246469
               211181 177550 147417 120322  96592  76665  59587  45776  34459  25900
                18876  13576   9571   6662   4629   3161   2069   1334    878    581
                  332    220    135     65     39     26     19     15      4      4])))

Now it can be converted to a ROOT histogram with another connector.

root_hist = aghast.to_root(ghastly_hist, "root_hist")
root_hist

<ROOT.TH1D object ("root_hist") at 0x55555e208ef0>

import ROOT
canvas = ROOT.TCanvas()
root_hist.Draw()
canvas.Draw()

png

And Pandas with yet another connector.

pandas_hist = aghast.to_pandas(ghastly_hist)
pandas_hist
unweighted
[-5.0, -4.875) 2
[-4.875, -4.75) 5
[-4.75, -4.625) 9
[-4.625, -4.5) 15
[-4.5, -4.375) 29
[-4.375, -4.25) 49
[-4.25, -4.125) 80
[-4.125, -4.0) 104
[-4.0, -3.875) 237
[-3.875, -3.75) 352
[-3.75, -3.625) 555
[-3.625, -3.5) 867
[-3.5, -3.375) 1447
[-3.375, -3.25) 2046
[-3.25, -3.125) 3037
[-3.125, -3.0) 4562
[-3.0, -2.875) 6805
[-2.875, -2.75) 9540
[-2.75, -2.625) 13529
[-2.625, -2.5) 18584
[-2.5, -2.375) 25593
[-2.375, -2.25) 35000
[-2.25, -2.125) 46024
[-2.125, -2.0) 59103
[-2.0, -1.875) 76492
[-1.875, -1.75) 96441
[-1.75, -1.625) 119873
[-1.625, -1.5) 146159
[-1.5, -1.375) 177533
[-1.375, -1.25) 210628
... ...
[1.25, 1.375) 211181
[1.375, 1.5) 177550
[1.5, 1.625) 147417
[1.625, 1.75) 120322
[1.75, 1.875) 96592
[1.875, 2.0) 76665
[2.0, 2.125) 59587
[2.125, 2.25) 45776
[2.25, 2.375) 34459
[2.375, 2.5) 25900
[2.5, 2.625) 18876
[2.625, 2.75) 13576
[2.75, 2.875) 9571
[2.875, 3.0) 6662
[3.0, 3.125) 4629
[3.125, 3.25) 3161
[3.25, 3.375) 2069
[3.375, 3.5) 1334
[3.5, 3.625) 878
[3.625, 3.75) 581
[3.75, 3.875) 332
[3.875, 4.0) 220
[4.0, 4.125) 135
[4.125, 4.25) 65
[4.25, 4.375) 39
[4.375, 4.5) 26
[4.5, 4.625) 19
[4.625, 4.75) 15
[4.75, 4.875) 4
[4.875, 5.0) 4

80 rows × 1 columns

Serialization

A ghast is also a Flatbuffers object, which has a multi-lingual, random-access, small-footprint serialization:

ghastly_hist.tobuffer()

bytearray("\x04\x00\x00\x00\x90\xff\xff\xff\x10\x00\x00\x00\x00\x01\n\x00\x10\x00\x0c\x00\x0b\x00\x04
           \x00\n\x00\x00\x00`\x00\x00\x00\x00\x00\x00\x01\x04\x00\x00\x00\x01\x00\x00\x00\x0c\x00\x00
           \x00\x08\x00\x0c\x00\x0b\x00\x04\x00\x08\x00\x00\x00\x10\x00\x00\x00\x00\x00\x00\x02\x08\x00
           (\x00\x1c\x00\x04\x00\x08\x00\x00\x00\x00\x00\x00\x00\x00\x00\x14\xc0\x00\x00\x00\x00\x00
           \x00\x14@\x01\x00\x00\x00\x00\x00\x00\x00P\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x08
           \x00\n\x00\t\x00\x04\x00\x08\x00\x00\x00\x0c\x00\x00\x00\x00\x02\x06\x00\x08\x00\x04\x00\x06
           \x00\x00\x00\x04\x00\x00\x00\x80\x02\x00\x00\x02\x00\x00\x00\x00\x00\x00\x00\x05\x00\x00\x00
           \x00\x00\x00\x00\t\x00\x00\x00\x00\x00\x00\x00\x0f\x00\x00\x00\x00\x00\x00\x00\x1d\x00\x00
           \x00\x00\x00\x00\x001\x00\x00\x00\x00\x00\x00\x00P\x00\x00\x00\x00\x00\x00\x00h\x00\x00\x00
           \x00\x00\x00\x00\xed\x00\x00\x00\x00\x00\x00\x00`\x01\x00\x00\x00\x00\x00\x00+\x02\x00\x00
           \x00\x00\x00\x00c\x03\x00\x00\x00\x00\x00\x00\xa7\x05\x00\x00\x00\x00\x00\x00\xfe\x07\x00
           \x00\x00\x00\x00\x00\xdd\x0b\x00\x00\x00\x00\x00\x00\xd2\x11\x00\x00\x00\x00\x00\x00\x95\x1a
           \x00\x00\x00\x00\x00\x00D%\x00\x00\x00\x00\x00\x00\xd94\x00\x00\x00\x00\x00\x00\x98H\x00\x00
           \x00\x00\x00\x00\xf9c\x00\x00\x00\x00\x00\x00\xb8\x88\x00\x00\x00\x00\x00\x00\xc8\xb3\x00\x00
           \x00\x00\x00\x00\xdf\xe6\x00\x00\x00\x00\x00\x00\xcc*\x01\x00\x00\x00\x00\x00\xb9x\x01\x00
           \x00\x00\x00\x00A\xd4\x01\x00\x00\x00\x00\x00\xef:\x02\x00\x00\x00\x00\x00}\xb5\x02\x00\x00
           \x00\x00\x00\xc46\x03\x00\x00\x00\x00\x00,\xc2\x03\x00\x00\x00\x00\x00\x9cR\x04\x00\x00\x00
           \x00\x00a\xe7\x04\x00\x00\x00\x00\x00\x92{\x05\x00\x00\x00\x00\x00\x81\x02\x06\x00\x00\x00
           \x00\x00\xce\x81\x06\x00\x00\x00\x00\x00\xa7\xe9\x06\x00\x00\x00\x00\x00\xb6>\x07\x00\x00
           \x00\x00\x00vy\x07\x00\x00\x00\x00\x00\x06\x94\x07\x00\x00\x00\x00\x00\x02\x99\x07\x00\x00
           \x00\x00\x00\x03|\x07\x00\x00\x00\x00\x00p8\x07\x00\x00\x00\x00\x00\x97\xeb\x06\x00\x00\x00
           \x00\x00\xb2~\x06\x00\x00\x00\x00\x00Q\x00\x06\x00\x00\x00\x00\x00\x89x\x05\x00\x00\x00\x00
           \x00K\xe6\x04\x00\x00\x00\x00\x00\x97O\x04\x00\x00\x00\x00\x00\xc5\xc2\x03\x00\x00\x00\x00
           \x00\xed8\x03\x00\x00\x00\x00\x00\x8e\xb5\x02\x00\x00\x00\x00\x00\xd9?\x02\x00\x00\x00\x00
           \x00\x02\xd6\x01\x00\x00\x00\x00\x00Py\x01\x00\x00\x00\x00\x00y+\x01\x00\x00\x00\x00\x00\xc3
           \xe8\x00\x00\x00\x00\x00\x00\xd0\xb2\x00\x00\x00\x00\x00\x00\x9b\x86\x00\x00\x00\x00\x00\x00
           ,e\x00\x00\x00\x00\x00\x00\xbcI\x00\x00\x00\x00\x00\x00\x085\x00\x00\x00\x00\x00\x00c%\x00
           \x00\x00\x00\x00\x00\x06\x1a\x00\x00\x00\x00\x00\x00\x15\x12\x00\x00\x00\x00\x00\x00Y\x0c
           \x00\x00\x00\x00\x00\x00\x15\x08\x00\x00\x00\x00\x00\x006\x05\x00\x00\x00\x00\x00\x00n\x03
           \x00\x00\x00\x00\x00\x00E\x02\x00\x00\x00\x00\x00\x00L\x01\x00\x00\x00\x00\x00\x00\xdc\x00
           \x00\x00\x00\x00\x00\x00\x87\x00\x00\x00\x00\x00\x00\x00A\x00\x00\x00\x00\x00\x00\x00\'\x00
           \x00\x00\x00\x00\x00\x00\x1a\x00\x00\x00\x00\x00\x00\x00\x13\x00\x00\x00\x00\x00\x00\x00\x0f
           \x00\x00\x00\x00\x00\x00\x00\x04\x00\x00\x00\x00\x00\x00\x00\x04\x00\x00\x00\x00\x00\x00\x00")

print("Numpy size: ", numpy_hist[0].nbytes + numpy_hist[1].nbytes)

tmessage = ROOT.TMessage()
tmessage.WriteObject(root_hist)
print("ROOT size:  ", tmessage.Length())

import pickle
print("Pandas size:", len(pickle.dumps(pandas_hist)))

print("Aghast size: ", len(ghastly_hist.tobuffer()))

Numpy size:  1288
ROOT size:   1962
Pandas size: 2984
Aghast size:  792

Aghast is generally forseen as a memory format, like Apache Arrow, but for statistical aggregations. Like Arrow, it reduces the need to implement $N(N - 1)/2$ conversion functions among $N$ statistical libraries to just $N$ conversion functions. (See the figure on Arrow's website.)

Translation of conventions

Aghast also intends to be as close to zero-copy as possible. This means that it must make graceful translations among conventions. Different histogramming libraries handle overflow bins in different ways:

fromroot = aghast.from_root(root_hist)
fromroot.axis[0].binning.dump()
print("Bin contents length:", len(fromroot.counts.array))

RegularBinning(
  num=80,
  interval=RealInterval(low=-5.0, high=5.0),
  overflow=RealOverflow(loc_underflow=BinLocation.below1, loc_overflow=BinLocation.above1))
Bin contents length: 82

ghastly_hist.axis[0].binning.dump()
print("Bin contents length:", len(ghastly_hist.counts.array))

RegularBinning(num=80, interval=RealInterval(low=-5.0, high=5.0))
Bin contents length: 80

And yet we want to be able to manipulate them as though these differences did not exist.

sum_hist = fromroot + ghastly_hist

sum_hist.axis[0].binning.dump()
print("Bin contents length:", len(sum_hist.counts.array))

RegularBinning(
  num=80,
  interval=RealInterval(low=-5.0, high=5.0),
  overflow=RealOverflow(loc_underflow=BinLocation.above1, loc_overflow=BinLocation.above2))
Bin contents length: 82

The binning structure keeps track of the existence of underflow/overflow bins and where they are located.

  • ROOT's convention is to put underflow before the normal bins (below1) and overflow after (above1), so that the normal bins are effectively 1-indexed.
  • Boost.Histogram's convention is to put overflow after the normal bins (above1) and underflow after that (above2), so that underflow is accessed via myhist[-1] in Numpy.
  • Numpy histograms don't have underflow/overflow bins.
  • Pandas could have Intervals that extend to infinity.

Aghast accepts all of these, so that it doesn't have to manipulate the bin contents buffer it receives, but knows how to deal with them if it has to combine histograms that follow different conventions.

Binning types

All the different axis types have an equivalent in aghast (and not all are single-dimensional).

aghast.IntegerBinning(5, 10).dump()
aghast.RegularBinning(100, aghast.RealInterval(-5, 5)).dump()
aghast.HexagonalBinning(0, 100, 0, 100, aghast.HexagonalBinning.cube_xy).dump()
aghast.EdgesBinning([0.01, 0.05, 0.1, 0.5, 1, 5, 10, 50, 100]).dump()
aghast.IrregularBinning([aghast.RealInterval(0, 5),
                         aghast.RealInterval(10, 100),
                         aghast.RealInterval(-10, 10)],
                       overlapping_fill=aghast.IrregularBinning.all).dump()
aghast.CategoryBinning(["one", "two", "three"]).dump()
aghast.SparseRegularBinning([5, 3, -2, 8, -100], 10).dump()
aghast.FractionBinning(error_method=aghast.FractionBinning.clopper_pearson).dump()
aghast.PredicateBinning(["signal region", "control region"]).dump()
aghast.VariationBinning([aghast.Variation([aghast.Assignment("x", "nominal")]),
                         aghast.Variation([aghast.Assignment("x", "nominal + sigma")]),
                         aghast.Variation([aghast.Assignment("x", "nominal - sigma")])]).dump()

IntegerBinning(min=5, max=10)
RegularBinning(num=100, interval=RealInterval(low=-5.0, high=5.0))
HexagonalBinning(qmin=0, qmax=100, rmin=0, rmax=100, coordinates=HexagonalBinning.cube_xy)
EdgesBinning(edges=[0.01 0.05 0.1 0.5 1 5 10 50 100])
IrregularBinning(
  intervals=[
    RealInterval(low=0.0, high=5.0),
    RealInterval(low=10.0, high=100.0),
    RealInterval(low=-10.0, high=10.0)
  ],
  overlapping_fill=IrregularBinning.all)
CategoryBinning(categories=['one', 'two', 'three'])
SparseRegularBinning(bins=[5 3 -2 8 -100], bin_width=10.0)
FractionBinning(error_method=FractionBinning.clopper_pearson)
PredicateBinning(predicates=['signal region', 'control region'])
VariationBinning(
  variations=[
    Variation(assignments=[
        Assignment(identifier='x', expression='nominal')
      ]),
    Variation(
      assignments=[
        Assignment(identifier='x', expression='nominal + sigma')
      ]),
    Variation(
      assignments=[
        Assignment(identifier='x', expression='nominal - sigma')
      ])
  ])

The meanings of these binning classes are given in the specification, but many of them can be converted into one another, and converting to CategoryBinning (strings) often makes the intent clear.

aghast.IntegerBinning(5, 10).toCategoryBinning().dump()
aghast.RegularBinning(10, aghast.RealInterval(-5, 5)).toCategoryBinning().dump()
aghast.EdgesBinning([0.01, 0.05, 0.1, 0.5, 1, 5, 10, 50, 100]).toCategoryBinning().dump()
aghast.IrregularBinning([aghast.RealInterval(0, 5),
                         aghast.RealInterval(10, 100),
                         aghast.RealInterval(-10, 10)],
                       overlapping_fill=aghast.IrregularBinning.all).toCategoryBinning().dump()
aghast.SparseRegularBinning([5, 3, -2, 8, -100], 10).toCategoryBinning().dump()
aghast.FractionBinning(error_method=aghast.FractionBinning.clopper_pearson).toCategoryBinning().dump()
aghast.PredicateBinning(["signal region", "control region"]).toCategoryBinning().dump()
aghast.VariationBinning([aghast.Variation([aghast.Assignment("x", "nominal")]),
                         aghast.Variation([aghast.Assignment("x", "nominal + sigma")]),
                         aghast.Variation([aghast.Assignment("x", "nominal - sigma")])]
                        ).toCategoryBinning().dump()

CategoryBinning(categories=['5', '6', '7', '8', '9', '10'])
CategoryBinning(
  categories=['[-5, -4)', '[-4, -3)', '[-3, -2)', '[-2, -1)', '[-1, 0)', '[0, 1)', '[1, 2)', '[2, 3)',
              '[3, 4)', '[4, 5)'])
CategoryBinning(
  categories=['[0.01, 0.05)', '[0.05, 0.1)', '[0.1, 0.5)', '[0.5, 1)', '[1, 5)', '[5, 10)', '[10, 50)',
              '[50, 100)'])
CategoryBinning(categories=['[0, 5)', '[10, 100)', '[-10, 10)'])
CategoryBinning(categories=['[50, 60)', '[30, 40)', '[-20, -10)', '[80, 90)', '[-1000, -990)'])
CategoryBinning(categories=['pass', 'all'])
CategoryBinning(categories=['signal region', 'control region'])
CategoryBinning(categories=['x := nominal', 'x := nominal + sigma', 'x := nominal - sigma'])

This technique can also clear up confusion about overflow bins.

aghast.RegularBinning(5, aghast.RealInterval(-5, 5), aghast.RealOverflow(
    loc_underflow=aghast.BinLocation.above2,
    loc_overflow=aghast.BinLocation.above1,
    loc_nanflow=aghast.BinLocation.below1
    )).toCategoryBinning().dump()

CategoryBinning(
  categories=['{nan}', '[-5, -3)', '[-3, -1)', '[-1, 1)', '[1, 3)', '[3, 5)', '[5, +inf]',
              '[-inf, -5)'])

Fancy binning types

You might also be wondering about FractionBinning, PredicateBinning, and VariationBinning.

FractionBinning is an axis of two bins: #passing and #total, #failing and #total, or #passing and #failing. Adding it to another axis effectively makes an "efficiency plot."

h = aghast.Histogram([aghast.Axis(aghast.FractionBinning()),
                      aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5)))],
                    aghast.UnweightedCounts(
                        aghast.InterpretedInlineBuffer.fromarray(
                            numpy.array([[  9,  25,  29,  35,  54,  67,  60,  84,  80,  94],
                                         [ 99, 119, 109, 109,  95, 104, 102, 106, 112, 122]]))))
df = aghast.to_pandas(h)
df
unweighted
pass [-5.0, -4.0) 9
[-4.0, -3.0) 25
[-3.0, -2.0) 29
[-2.0, -1.0) 35
[-1.0, 0.0) 54
[0.0, 1.0) 67
[1.0, 2.0) 60
[2.0, 3.0) 84
[3.0, 4.0) 80
[4.0, 5.0) 94
all [-5.0, -4.0) 99
[-4.0, -3.0) 119
[-3.0, -2.0) 109
[-2.0, -1.0) 109
[-1.0, 0.0) 95
[0.0, 1.0) 104
[1.0, 2.0) 102
[2.0, 3.0) 106
[3.0, 4.0) 112
[4.0, 5.0) 122
df = df.unstack(level=0)
df
unweighted
all pass
[-5.0, -4.0) 99 9
[-4.0, -3.0) 119 25
[-3.0, -2.0) 109 29
[-2.0, -1.0) 109 35
[-1.0, 0.0) 95 54
[0.0, 1.0) 104 67
[1.0, 2.0) 102 60
[2.0, 3.0) 106 84
[3.0, 4.0) 112 80
[4.0, 5.0) 122 94
df["unweighted", "pass"] / df["unweighted", "all"]

[-5.0, -4.0)    0.090909
[-4.0, -3.0)    0.210084
[-3.0, -2.0)    0.266055
[-2.0, -1.0)    0.321101
[-1.0, 0.0)     0.568421
[0.0, 1.0)      0.644231
[1.0, 2.0)      0.588235
[2.0, 3.0)      0.792453
[3.0, 4.0)      0.714286
[4.0, 5.0)      0.770492
dtype: float64

PredicateBinning means that each bin represents a predicate (if-then rule) in the filling procedure. Aghast doesn't have a filling procedure, but filling-libraries can use this to encode relationships among histograms that a fitting-library can take advantage of, for combined signal-control region fits, for instance. It's possible for those regions to overlap: an input datum might satisfy more than one predicate, and overlapping_fill determines which bin(s) were chosen: first, last, or all.

VariationBinning means that each bin represents a variation of one of the paramters used to calculate the fill-variables. This is used to determine sensitivity to systematic effects, by varying them and re-filling. In this kind of binning, the same input datum enters every bin.

xdata = numpy.random.normal(0, 1, int(1e6))
sigma = numpy.random.uniform(-0.1, 0.8, int(1e6))

h = aghast.Histogram([aghast.Axis(aghast.VariationBinning([
                         aghast.Variation([aghast.Assignment("x", "nominal")]),
                         aghast.Variation([aghast.Assignment("x", "nominal + sigma")])])),
                     aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5)))],
                    aghast.UnweightedCounts(
                        aghast.InterpretedInlineBuffer.fromarray(
                            numpy.concatenate([
                                numpy.histogram(xdata, bins=10, range=(-5, 5))[0],
                                numpy.histogram(xdata + sigma, bins=10, range=(-5, 5))[0]]))))
df = aghast.to_pandas(h)
df
unweighted
x := nominal [-5.0, -4.0) 31
[-4.0, -3.0) 1309
[-3.0, -2.0) 21624
[-2.0, -1.0) 135279
[-1.0, 0.0) 341683
[0.0, 1.0) 341761
[1.0, 2.0) 135675
[2.0, 3.0) 21334
[3.0, 4.0) 1273
[4.0, 5.0) 31
x := nominal + sigma [-5.0, -4.0) 14
[-4.0, -3.0) 559
[-3.0, -2.0) 10814
[-2.0, -1.0) 84176
[-1.0, 0.0) 271999
[0.0, 1.0) 367950
[1.0, 2.0) 209479
[2.0, 3.0) 49997
[3.0, 4.0) 4815
[4.0, 5.0) 193
df.unstack(level=0)
unweighted
x := nominal x := nominal + sigma
[-5.0, -4.0) 31 14
[-4.0, -3.0) 1309 559
[-3.0, -2.0) 21624 10814
[-2.0, -1.0) 135279 84176
[-1.0, 0.0) 341683 271999
[0.0, 1.0) 341761 367950
[1.0, 2.0) 135675 209479
[2.0, 3.0) 21334 49997
[3.0, 4.0) 1273 4815
[4.0, 5.0) 31 193

Collections

You can gather many objects (histograms, functions, ntuples) into a Collection, partly for convenience of encapsulating all of them in one object.

aghast.Collection({"one": fromroot, "two": ghastly_hist}).dump()

Collection(
  objects={
    'one': Histogram(
      axis=[
        Axis(
          binning=
            RegularBinning(
              num=80,
              interval=RealInterval(low=-5.0, high=5.0),
              overflow=RealOverflow(loc_underflow=BinLocation.below1, loc_overflow=BinLocation.above1)),
          statistics=[
            Statistics(
              moments=[
                Moments(sumwxn=InterpretedInlineInt64Buffer(buffer=[1e+07]), n=0),
                Moments(sumwxn=InterpretedInlineFloat64Buffer(buffer=[1e+07]), n=0, weightpower=1),
                Moments(sumwxn=InterpretedInlineFloat64Buffer(buffer=[1e+07]), n=0, weightpower=2),
                Moments(sumwxn=InterpretedInlineFloat64Buffer(buffer=[2468.31]), n=1, weightpower=1),
                Moments(
                  sumwxn=InterpretedInlineFloat64Buffer(buffer=[1.00118e+07]),
                  n=2,
                  weightpower=1)
              ])
          ])
      ],
      counts=
        UnweightedCounts(
          counts=
            InterpretedInlineFloat64Buffer(
              buffer=
                  [0.00000e+00 2.00000e+00 5.00000e+00 9.00000e+00 1.50000e+01 2.90000e+01
                   4.90000e+01 8.00000e+01 1.04000e+02 2.37000e+02 3.52000e+02 5.55000e+02
                   8.67000e+02 1.44700e+03 2.04600e+03 3.03700e+03 4.56200e+03 6.80500e+03
                   9.54000e+03 1.35290e+04 1.85840e+04 2.55930e+04 3.50000e+04 4.60240e+04
                   5.91030e+04 7.64920e+04 9.64410e+04 1.19873e+05 1.46159e+05 1.77533e+05
                   2.10628e+05 2.46316e+05 2.83292e+05 3.21377e+05 3.59314e+05 3.93857e+05
                   4.26446e+05 4.53031e+05 4.74806e+05 4.89846e+05 4.96646e+05 4.97922e+05
                   4.90499e+05 4.73200e+05 4.53527e+05 4.25650e+05 3.93297e+05 3.58537e+05
                   3.21099e+05 2.82519e+05 2.46469e+05 2.11181e+05 1.77550e+05 1.47417e+05
                   1.20322e+05 9.65920e+04 7.66650e+04 5.95870e+04 4.57760e+04 3.44590e+04
                   2.59000e+04 1.88760e+04 1.35760e+04 9.57100e+03 6.66200e+03 4.62900e+03
                   3.16100e+03 2.06900e+03 1.33400e+03 8.78000e+02 5.81000e+02 3.32000e+02
                   2.20000e+02 1.35000e+02 6.50000e+01 3.90000e+01 2.60000e+01 1.90000e+01
                   1.50000e+01 4.00000e+00 4.00000e+00 0.00000e+00]))),
    'two': Histogram(
      axis=[
        Axis(binning=RegularBinning(num=80, interval=RealInterval(low=-5.0, high=5.0)))
      ],
      counts=
        UnweightedCounts(
          counts=
            InterpretedInlineInt64Buffer(
              buffer=
                  [     2      5      9     15     29     49     80    104    237    352
                      555    867   1447   2046   3037   4562   6805   9540  13529  18584
                    25593  35000  46024  59103  76492  96441 119873 146159 177533 210628
                   246316 283292 321377 359314 393857 426446 453031 474806 489846 496646
                   497922 490499 473200 453527 425650 393297 358537 321099 282519 246469
                   211181 177550 147417 120322  96592  76665  59587  45776  34459  25900
                    18876  13576   9571   6662   4629   3161   2069   1334    878    581
                      332    220    135     65     39     26     19     15      4      4])))
  })

Not only for convenience: you can also define an Axis in the Collection to subdivide all contents by that Axis. For instance, you can make a collection of qualitatively different histograms all have a signal and control region with PredicateBinning, or all have systematic variations with VariationBinning.

It is not necessary to rely on naming conventions to communicate this information from filler to fitter.

Histogram → histogram conversions

I said in the introduction that aghast does not fill histograms and does not plot histograms—the two things data analysts are expecting to do. These would be done by user-facing libraries.

Aghast does, however, transform histograms into other histograms, and not just among formats. You can combine histograms with +. In addition to adding histogram counts, it combines auxiliary statistics appropriately (if possible).

h1 = aghast.Histogram([
    aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5)),
        statistics=[aghast.Statistics(
            moments=[
                aghast.Moments(aghast.InterpretedInlineBuffer.fromarray(numpy.array([10])), n=1),
                aghast.Moments(aghast.InterpretedInlineBuffer.fromarray(numpy.array([20])), n=2)],
            quantiles=[
                aghast.Quantiles(aghast.InterpretedInlineBuffer.fromarray(numpy.array([30])), p=0.5)],
            mode=aghast.Modes(aghast.InterpretedInlineBuffer.fromarray(numpy.array([40]))),
            min=aghast.Extremes(aghast.InterpretedInlineBuffer.fromarray(numpy.array([50]))),
            max=aghast.Extremes(aghast.InterpretedInlineBuffer.fromarray(numpy.array([60]))))])],
    aghast.UnweightedCounts(aghast.InterpretedInlineBuffer.fromarray(numpy.arange(10))))
h2 = aghast.Histogram([
    aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5)),
        statistics=[aghast.Statistics(
            moments=[
                aghast.Moments(aghast.InterpretedInlineBuffer.fromarray(numpy.array([100])), n=1),
                aghast.Moments(aghast.InterpretedInlineBuffer.fromarray(numpy.array([200])), n=2)],
            quantiles=[
                aghast.Quantiles(aghast.InterpretedInlineBuffer.fromarray(numpy.array([300])), p=0.5)],
            mode=aghast.Modes(aghast.InterpretedInlineBuffer.fromarray(numpy.array([400]))),
            min=aghast.Extremes(aghast.InterpretedInlineBuffer.fromarray(numpy.array([500]))),
            max=aghast.Extremes(aghast.InterpretedInlineBuffer.fromarray(numpy.array([600]))))])],
    aghast.UnweightedCounts(aghast.InterpretedInlineBuffer.fromarray(numpy.arange(100, 200, 10))))

(h1 + h2).dump()

Histogram(
  axis=[
    Axis(
      binning=RegularBinning(num=10, interval=RealInterval(low=-5.0, high=5.0)),
      statistics=[
        Statistics(
          moments=[
            Moments(sumwxn=InterpretedInlineInt64Buffer(buffer=[110]), n=1),
            Moments(sumwxn=InterpretedInlineInt64Buffer(buffer=[220]), n=2)
          ],
          min=Extremes(values=InterpretedInlineInt64Buffer(buffer=[50])),
          max=Extremes(values=InterpretedInlineInt64Buffer(buffer=[600])))
      ])
  ],
  counts=
    UnweightedCounts(
      counts=InterpretedInlineInt64Buffer(buffer=[100 111 122 133 144 155 166 177 188 199])))

The corresponding moments of h1 and h2 were matched and added, quantiles and modes were dropped (no way to combine them), and the correct minimum and maximum were picked; the histogram contents were added as well.

Another important histogram → histogram conversion is axis-reduction, which can take three forms:

  • slicing an axis, either dropping the eliminated bins or adding them to underflow/overflow (if possible, depends on binning type);
  • rebinning by combining neighboring bins;
  • projecting out an axis, removing it entirely, summing over all existing bins.

All of these operations use a Pandas-inspired loc/iloc syntax.

h = aghast.Histogram(
    [aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5)))],
    aghast.UnweightedCounts(
        aghast.InterpretedInlineBuffer.fromarray(numpy.array([0, 10, 20, 30, 40, 50, 60, 70, 80, 90]))))

loc slices in the data's coordinate system. 1.5 rounds up to bin index 6. The first five bins get combined into an overflow bin: 150 = 10 + 20 + 30 + 40 + 50.

h.loc[1.5:].dump()

Histogram(
  axis=[
    Axis(
      binning=
        RegularBinning(
          num=4,
          interval=RealInterval(low=1.0, high=5.0),
          overflow=
            RealOverflow(
              loc_underflow=BinLocation.above1,
              minf_mapping=RealOverflow.missing,
              pinf_mapping=RealOverflow.missing,
              nan_mapping=RealOverflow.missing)))
  ],
  counts=UnweightedCounts(counts=InterpretedInlineInt64Buffer(buffer=[60 70 80 90 150])))

iloc slices by bin index number.

h.iloc[6:].dump()

Histogram(
  axis=[
    Axis(
      binning=
        RegularBinning(
          num=4,
          interval=RealInterval(low=1.0, high=5.0),
          overflow=
            RealOverflow(
              loc_underflow=BinLocation.above1,
              minf_mapping=RealOverflow.missing,
              pinf_mapping=RealOverflow.missing,
              nan_mapping=RealOverflow.missing)))
  ],
  counts=UnweightedCounts(counts=InterpretedInlineInt64Buffer(buffer=[60 70 80 90 150])))

Slices have a start, stop, and step (start:stop:step). The step parameter rebins:

h.iloc[::2].dump()

Histogram(
  axis=[
    Axis(binning=RegularBinning(num=5, interval=RealInterval(low=-5.0, high=5.0)))
  ],
  counts=UnweightedCounts(counts=InterpretedInlineInt64Buffer(buffer=[10 50 90 130 170])))

Thus, you can slice and rebin as part of the same operation.

Projecting uses the same mechanism, except that None passed as an axis's slice projects it.

h2 = aghast.Histogram(
    [aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5))),
     aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5)))],
    aghast.UnweightedCounts(
        aghast.InterpretedInlineBuffer.fromarray(numpy.arange(100))))

h2.iloc[:, None].dump()

Histogram(
  axis=[
    Axis(binning=RegularBinning(num=10, interval=RealInterval(low=-5.0, high=5.0)))
  ],
  counts=
    UnweightedCounts(
      counts=InterpretedInlineInt64Buffer(buffer=[45 145 245 345 445 545 645 745 845 945])))

Thus, all three axis reduction operations can be performed in a single syntax.

In general, an n-dimensional ghastly histogram can be sliced like an n-dimensional Numpy array. This includes integer and boolean indexing (though that necessarily changes the binning to IrregularBinning).

h.iloc[[4, 3, 6, 7, 1]].dump()

Histogram(
  axis=[
    Axis(
      binning=
        IrregularBinning(
          intervals=[
            RealInterval(low=-1.0, high=0.0),
            RealInterval(low=-2.0, high=-1.0),
            RealInterval(low=1.0, high=2.0),
            RealInterval(low=2.0, high=3.0),
            RealInterval(low=-4.0, high=-3.0)
          ]))
  ],
  counts=UnweightedCounts(counts=InterpretedInlineInt64Buffer(buffer=[40 30 60 70 10])))

h.iloc[[True, False, True, False, True, False, True, False, True, False]].dump()

Histogram(
  axis=[
    Axis(
      binning=
        IrregularBinning(
          intervals=[
            RealInterval(low=-5.0, high=-4.0),
            RealInterval(low=-3.0, high=-2.0),
            RealInterval(low=-1.0, high=0.0),
            RealInterval(low=1.0, high=2.0),
            RealInterval(low=3.0, high=4.0)
          ]))
  ],
  counts=UnweightedCounts(counts=InterpretedInlineInt64Buffer(buffer=[0 20 40 60 80])))

loc for numerical binnings accepts

  • a real number
  • a real-valued slice
  • None for projection
  • ellipsis (...)

loc for categorical binnings accepts

  • a string
  • an iterable of strings
  • an empty slice
  • None for projection
  • ellipsis (...)

iloc accepts

  • an integer
  • an integer-valued slice
  • None for projection
  • integer-valued array-like
  • boolean-valued array-like
  • ellipsis (...)

Bin counts → Numpy

Frequently, one wants to extract bin counts from a histogram. The loc/iloc syntax above creates histograms from histograms, not bin counts.

A histogram's counts property has a slice syntax.

allcounts = numpy.arange(12) * numpy.arange(12)[:, None]   # multiplication table
allcounts[10, :] = -999   # underflows
allcounts[11, :] = 999    # overflows
allcounts[:, 0]  = -999   # underflows
allcounts[:, 1]  = 999    # overflows
print(allcounts)

[[-999  999    0    0    0    0    0    0    0    0    0    0]
 [-999  999    2    3    4    5    6    7    8    9   10   11]
 [-999  999    4    6    8   10   12   14   16   18   20   22]
 [-999  999    6    9   12   15   18   21   24   27   30   33]
 [-999  999    8   12   16   20   24   28   32   36   40   44]
 [-999  999   10   15   20   25   30   35   40   45   50   55]
 [-999  999   12   18   24   30   36   42   48   54   60   66]
 [-999  999   14   21   28   35   42   49   56   63   70   77]
 [-999  999   16   24   32   40   48   56   64   72   80   88]
 [-999  999   18   27   36   45   54   63   72   81   90   99]
 [-999  999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999]
 [-999  999  999  999  999  999  999  999  999  999  999  999]]

h2 = aghast.Histogram(
    [aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5),
                     aghast.RealOverflow(loc_underflow=aghast.RealOverflow.above1,
                                       loc_overflow=aghast.RealOverflow.above2))),
     aghast.Axis(aghast.RegularBinning(10, aghast.RealInterval(-5, 5),
                     aghast.RealOverflow(loc_underflow=aghast.RealOverflow.below2,
                                       loc_overflow=aghast.RealOverflow.below1)))],
    aghast.UnweightedCounts(
        aghast.InterpretedInlineBuffer.fromarray(allcounts)))

print(h2.counts[:, :])

[[ 0  0  0  0  0  0  0  0  0  0]
 [ 2  3  4  5  6  7  8  9 10 11]
 [ 4  6  8 10 12 14 16 18 20 22]
 [ 6  9 12 15 18 21 24 27 30 33]
 [ 8 12 16 20 24 28 32 36 40 44]
 [10 15 20 25 30 35 40 45 50 55]
 [12 18 24 30 36 42 48 54 60 66]
 [14 21 28 35 42 49 56 63 70 77]
 [16 24 32 40 48 56 64 72 80 88]
 [18 27 36 45 54 63 72 81 90 99]]

To get the underflows and overflows, set the slice extremes to -inf and +inf.

print(h2.counts[-numpy.inf:numpy.inf, :])

[[-999 -999 -999 -999 -999 -999 -999 -999 -999 -999]
 [   0    0    0    0    0    0    0    0    0    0]
 [   2    3    4    5    6    7    8    9   10   11]
 [   4    6    8   10   12   14   16   18   20   22]
 [   6    9   12   15   18   21   24   27   30   33]
 [   8   12   16   20   24   28   32   36   40   44]
 [  10   15   20   25   30   35   40   45   50   55]
 [  12   18   24   30   36   42   48   54   60   66]
 [  14   21   28   35   42   49   56   63   70   77]
 [  16   24   32   40   48   56   64   72   80   88]
 [  18   27   36   45   54   63   72   81   90   99]
 [ 999  999  999  999  999  999  999  999  999  999]]

print(h2.counts[:, -numpy.inf:numpy.inf])

[[-999    0    0    0    0    0    0    0    0    0    0  999]
 [-999    2    3    4    5    6    7    8    9   10   11  999]
 [-999    4    6    8   10   12   14   16   18   20   22  999]
 [-999    6    9   12   15   18   21   24   27   30   33  999]
 [-999    8   12   16   20   24   28   32   36   40   44  999]
 [-999   10   15   20   25   30   35   40   45   50   55  999]
 [-999   12   18   24   30   36   42   48   54   60   66  999]
 [-999   14   21   28   35   42   49   56   63   70   77  999]
 [-999   16   24   32   40   48   56   64   72   80   88  999]
 [-999   18   27   36   45   54   63   72   81   90   99  999]]

Also note that the underflows are now all below the normal bins and overflows are now all above the normal bins, regardless of how they were arranged in the ghast. This allows analysis code to be independent of histogram source.

Other types

Aghast can attach fit functions to histograms, can store standalone functions, such as lookup tables, and can store ntuples for unweighted fits or machine learning.

Acknowledgements

Support for this work was provided by NSF cooperative agreement OAC-1836650 (IRIS-HEP), grant OAC-1450377 (DIANA/HEP) and PHY-1520942 (US-CMS LHC Ops).

Thanks especially to the gracious help of aghast contributors!

Project details

Verified details

These details have been verified by PyPI
Maintainers
Avatar for pivarski from gravatar.com pivarski

Unverified details

These details have not been verified by PyPI
Project links
Meta
Classifiers

Release history Release notifications | RSS feed

This version

0.2.1

0.2.0

0.1.0

0.1.0rc4 pre-release

0.1.0rc3 pre-release

0.1.0rc2 pre-release

0.1.0rc1 pre-release

Download files

Download the file for your platform. If you're not sure which to choose, learn more about installing packages.

Source Distribution

aghast-0.2.1.tar.gz (137.7 kB view details)

Uploaded Source

Built Distribution

aghast-0.2.1-py2.py3-none-any.whl (136.0 kB view details)

Uploaded Python 2 Python 3

File details

Details for the file aghast-0.2.1.tar.gz.

File metadata

  • Download URL: aghast-0.2.1.tar.gz
  • Upload date:
  • Size: 137.7 kB
  • Tags: Source
  • Uploaded using Trusted Publishing? No
  • Uploaded via: twine/1.13.0 pkginfo/1.5.0.1 requests/2.21.0 setuptools/41.0.0 requests-toolbelt/0.9.1 tqdm/4.31.1 CPython/3.7.1

File hashes

Hashes for aghast-0.2.1.tar.gz
Algorithm Hash digest
SHA256 5a60f84d8ecb1b5d56368d6eb839fdae93496d9d96b2a1ead8f820732679ccb4
MD5 47671b75afe7e3406ebed22ac0aaff1f
BLAKE2b-256 fdd9cfbc5921f2fa64648b3aeff0a5f02a7db1287dca0a38e560896a3e805671

See more details on using hashes here.

File details

Details for the file aghast-0.2.1-py2.py3-none-any.whl.

File metadata

  • Download URL: aghast-0.2.1-py2.py3-none-any.whl
  • Upload date:
  • Size: 136.0 kB
  • Tags: Python 2, Python 3
  • Uploaded using Trusted Publishing? No
  • Uploaded via: twine/1.13.0 pkginfo/1.5.0.1 requests/2.21.0 setuptools/41.0.0 requests-toolbelt/0.9.1 tqdm/4.31.1 CPython/3.7.1

File hashes

Hashes for aghast-0.2.1-py2.py3-none-any.whl
Algorithm Hash digest
SHA256 d945d3adb55dea3a1cd465730c49110a8667651d9d2ae1ff6643900b0d3e65c8
MD5 bfca193395dfd928cac5b22e24abb77c
BLAKE2b-256 9a15b67a8f15912dbfbbf4ae6025c4284c287a6be67e580d618afb38701af7a2

See more details on using hashes here.

Supported by

AWS AWS Cloud computing and Security Sponsor Datadog Datadog Monitoring Fastly Fastly CDN Google Google Download Analytics Microsoft Microsoft PSF Sponsor Pingdom Pingdom Monitoring Sentry Sentry Error logging StatusPage StatusPage Status page
