aja-pose 0.0.1

Animal pose estimation using Vision Transformers and HRNet(VHR)

Welcome to our module!

Aja-pose

AJA-pose helps you train, validate and test your animal pose estimation model. Check out how we have done it in Google Colab. We have evaluated our model (PCK@0.05) and the mean accuracy for the 23 keypoints for our model is 93.073%
We recommend using at least Nvidia V100 GPU for faster inferencing but T4 GPUs will still work.

Getting Started

git clone https://github.com/Antony-gitau/AJA-pose.git
cd AJA-pose
pip install -e .

Getting our model and the dataset. We have made our model public and can be downloaded here

import urllib.request

# # Get the dataset
url = "https://storage.googleapis.com/figures-gp/animal-kingdom/dataset.zip"
destination = "dataset.zip"

urllib.request.urlretrieve(url, destination)

# Unzip the file
!unzip dataset.zip

# The model file
url = "https://storage.googleapis.com/figures-gp/animal-kingdom/all_animals_no_pretrain_106.pth"
destination = "all_animals_no_pretrain_60.pth"

urllib.request.urlretrieve(url, destination)

Test our model
We require the path to the test images directory and the test.json file in MPII format

from aja_pose import Model

# path to the images directory and annotation in mpii json format
images_directory = '' # Path to the images directory
mpii_json = '' # Path to the test.json file
model_file = 'all_animals_no_pretrain_60.pth' # Path to the model file

# Initialize the class
model = Model()
# Test the model on Protocol 1
model.test(images_directory, protocol='P1', model=model_file)
# Test the model on Protocol 2
model.test(images_directory, protocol='P2', model=model_file)
# Test the model on birds class Protocol 3
model.test(images_directory, protocol='P3', model=model_file, animal_class='bird')
# Test the model on reptiles class Protocol 3
model.test(images_directory, protocol='P3', model=model_file, animal_class='reptile')
# Test the model on mammals class Protocol 3
model.test(images_directory, protocol='P3', model=model_file, animal_class='mammal')
# Test the model on fish class Protocol 3
model.test(images_directory, protocol='P3', model=model_file, animal_class='fish')
# Test the model on amphibian class Protocol 3
model.test(images_directory, protocol='P3', model=model_file, animal_class='amphibian')

You can also start to train your model or pretrain on top of ours

# train a VHR model
train_json = '' # labels for the train set (train.json)
valid_json = '' # Labels for the validation set (test.json)
model_file = '' # A pytorch model file to pretrain on.
model.train(images_directory, train_json, valid_json, pretrained=model_file)

# Train a model on a particular class e.g (Ampibian)
model.train(images_directory, protocol='P3', animal_class='amphibian', model=model_file)

Results

A sanity check on our model.

Ground Truth
Predictions

Performance

The performance of our model on the different animal classes is as shown below.

Animal Class	Samples		Head	Shoulder	Elbow	Wrist	Hip	Knee	Ankle	Mouth	Tail	Mean
Birds	1705		95.756	93.637	89.774	88.179	98.975	97.582	94.326	98.447	95.112	95.164
Reptiles	1209		91.538	85.291	84.662	85.587	90.457	88.097	85.239	96.723	83.925	89.553
Mammals	1496		90.641	89.269	88.509	89.927	90.263	88.655	89.535	93.622	82.161	90.038
Fish	918		96.468	96.249	98.643	96.058	98.403	96.743	95.775	97.564	98.256	96.467
Amphibian	1279		98.128	94.342	97.948	98.508	95.491	94.957	94.319	98.702	99.568	95.493

The model performance on Protocol 1 and Protocol 2 is as shown below.

Protocol	Samples		Head	Shoulder	Elbow	Wrist	Hip	Knee	Ankle	Mouth	Tail	Mean
P1	6620		94.230	91.054	90.806	90.920	94.414	93.233	92.094	96.867	92.346	93.073
P2	2883		88.683	75.815	80.223	81.136	85.568	83.840	82.028	94.799	72.506	83.711
