anjana 1.0.0

ANJANA is an open source framework for applying different anonymity techniques.

ANJANA

Anonymity as major assurance of personal data privacy:

ANJANA is a Python library for anonymizing sensitive data.

The following anonymity techniques are implemented, based on the Python library pyCANON:

• k-anonymity.
• (α,k)-anonymity.
• ℓ-diversity.
• Entropy ℓ-diversity.
• Recursive (c,ℓ)-diversity.
• t-closeness.
• Basic β-likeness.
• Enhanced β-likeness.
• δ-disclosure privacy.

Installation

First, we strongly recommend the use of a virtual environment. In linux:

virtualenv .venv -p python3
source .venv/bin/activate

Using pip:

Install anjana (linux and windows):

pip install anjana

Using git:

Install the most updated version of anjana (linux and windows):

pip install git+https://github.com/IFCA-Advanced-Computing/anjana.git

Getting started

For anonymizing your data you need to introduce:

• The pandas dataframe with the data to be anonymized. Each column can contain: identifiers, quasi-indentifiers or sensitive attributes.
• The list with the names of the identifiers in the dataframe, in order to suppress them.
• The list with the names of the quasi-identifiers in the dataframe.
• The sentive attribute (only one) in case of applying other techniques than k-anonymity.
• The level of anonymity to be applied, e.g. k (for k-anonymity), ℓ (for ℓ-diversity), t (for t-closeness), β (for basic or enhanced β-likeness), etc.
• Maximum level of record suppression allowed (from 0 to 100, acting as the percentage of suppressed records).
• Dictionary containing one dictionary for each quasi-identifier with the hierarchies and the levels.

Example: apply k-anonymity, ℓ-diversity and t-closeness to the adult dataset with some predefined hierarchies:

import pandas as pd
import anjana
from anjana.anonymity import k_anonymity, l_diversity, t_closeness

# Read and process the data
data = pd.read_csv("adult.csv")
data.columns = data.columns.str.strip()
cols = [
    "workclass",
    "education",
    "marital-status",
    "occupation",
    "sex",
    "native-country",
]
for col in cols:
    data[col] = data[col].str.strip()

# Define the identifiers, quasi-identifiers and the sensitive attribute
quasi_ident = [
    "age",
    "education",
    "marital-status",
    "occupation",
    "sex",
    "native-country",
]
ident = ["race"]
sens_att = "salary-class"

# Select the desired level of k, l and t
k = 10
l_div = 2
t = 0.5

# Select the suppression limit allowed
supp_level = 50

# Import the hierarquies for each quasi-identifier. Define a dictionary containing them
hierarchies = {
    "age": dict(pd.read_csv("hierarchies/age.csv", header=None)),
    "education": dict(pd.read_csv("hierarchies/education.csv", header=None)),
    "marital-status": dict(pd.read_csv("hierarchies/marital.csv", header=None)),
    "occupation": dict(pd.read_csv("hierarchies/occupation.csv", header=None)),
    "sex": dict(pd.read_csv("hierarchies/sex.csv", header=None)),
    "native-country": dict(pd.read_csv("hierarchies/country.csv", header=None)),
}

# Apply the three functions: k-anonymity, l-diversity and t-closeness
data_anon = k_anonymity(data, ident, quasi_ident, k, supp_level, hierarchies)
data_anon = l_diversity(
    data_anon, ident, quasi_ident, sens_att, k, l_div, supp_level, hierarchies
)
data_anon = t_closeness(
    data_anon, ident, quasi_ident, sens_att, k, t, supp_level, hierarchies
)

The previous code can be executed in less than 4 seconds for the more than 30,000 records of the original dataset.

Define your own hierarchies

All the anonymity functions available in ANJANA receive a dictionary with the hierarchies to be applied to the quasi-identifiers. In particular, this dictionary has as key the names of the columns that are quasi-identifiers to which a hierarchy is to be applied (it may happen that you do not want to generalize some QIs and therefore no hierarchy is to be applied to them, just do not include them in this dictionary). The value for each key (QI) is formed by a dictionary in such a way that the value 0 has as value the raw column (as it is in the original dataset), the value 1 corresponds to the first level of transformation to be applied, in relation to the values of the original column, and so on with as many keys as levels of hierarchies have been established.

For a better understanding, let's look at the following example. Supose that we have the following simulated dataset (extracted from the hospital_extended.csv dataset used for testing purposes) with age, gender and city as quasi-identifiers, name as identifier and disease as sensitive attribute. Regarding the QI, we want to apply the following hierarquies: interval of 5 years (first level) and 10 years (second level) for the age. Suppression as first level for both gender and city.

name	age	gender	city	disease
Ramsha	29	Female	Tamil Nadu	Cancer
Yadu	24	Female	Kerala	Viralinfection
Salima	28	Female	Tamil Nadu	TB
Sunny	27	Male	Karnataka	No illness
Joan	24	Female	Kerala	Heart-related
Bahuksana	23	Male	Karnataka	TB
Rambha	19	Male	Kerala	Cancer
Kishor	29	Male	Karnataka	Heart-related
Johnson	17	Male	Kerala	Heart-related
John	19	Male	Kerala	Viralinfection

Then, in order to create the hierarquies we can define the following dictionary:

import numpy as np

age = data['age'].values
# Values: [29 24 28 27 24 23 19 29 17 19] (note that the following can be automatized)
age_5years = ['[25, 30)', '[20, 25)', '[25, 30)',
              '[25, 30)', '[20, 25)', '[20, 25)',
              '[15, 20)', '[25, 30)', '[15, 20)', '[15, 20)']

age_10years = ['[20, 30)', '[20, 30)', '[20, 30)',
               '[20, 30)', '[20, 30)', '[20, 30)',
               '[10, 20)', '[20, 30)', '[10, 20)', '[10, 20)']

hierarchies = {
    "age": {0: age,
            1: age_5years,
            2: age_10years},
    "gender": {
        0: data["gender"].values,
        1: np.array(["*"] * len(data["gender"].values)) # Suppression
    },
    "city": {0: data["city"].values,
             1: np.array(["*"] * len(data["city"].values))} # Suppression
}

You can also use the function generate_intervals() from utils for creating the interval-based hierarchy as follows:

import numpy as np
from anjana.anonymity import utils

age = data['age'].values

hierarchies = {
    "age": {
        0: data["age"].values,
        1: utils.generate_intervals(data["age"].values, 0, 100, 5),
        2: utils.generate_intervals(data["age"].values, 0, 100, 10),
    },
    "gender": {
        0: data["gender"].values,
        1: np.array(["*"] * len(data["gender"].values)) # Suppression
    },
    "city": {0: data["city"].values,
             1: np.array(["*"] * len(data["city"].values))} # Suppression
}

License

This project is licensed under the Apache 2.0 license.

Project status

This project is under active development.

Funding and acknowledgments

This work is funded by European Union through the SIESTA project (Horizon Europe) under Grant number 101131957.

---
