asusrouter 1.21.3

API wrapper for communication with ASUSWRT-powered routers using HTTP protocol

AsusRouter

AsusRouter is an API wrapper for communication with ASUSWRT-powered routers using HTTP(S) protocols. The library supports both the stock AsusWRT firmware and AsusWRT-Merlin.

Up till now, it is mostly used for the custom AsusRouter Home Assistant integration and from recently by the core Home Assistant AsusWRT integration. But I am always open to making it suitable for any other use.

Installation

Installation of the latest release is available from PyPI:

pip install asusrouter

Usage

Once installed, you can import the AsusRouter class from the module. Example shows the default parameters except for host, username and password.

import aiohttp
import asyncio
from asusrouter import AsusRouter, AsusData

# Create a new event loop
loop = asyncio.new_event_loop()

# Create aiohttp session
session = aiohttp.ClientSession(loop=loop)

router = AsusRouter(                #required - both IP and URL supported
    hostname="router.my.address",   #required
    username="admin",               #required
    password="password",            #required
    use_ssl=True,                   #optional
    session=session,                #optional
)

# Connect to the router
loop.run_until_complete(router.async_connect())

# Now you can use the router object to call methods
data = loop.run_until_complete(router.async_get_data(AsusData.NETWORK))
print(data)

# Remember to disconnect and close the session when you're done
loop.run_until_complete(router.async_disconnect())
loop.run_until_complete(session.close())

Supported devices

AsusRouter supports virtually every AsusWRT-powered device.

[!TIP]
Version 388.10 of AsusWRT-Merlin firmware is officially NOT supported due to the issues with HTTP daemon crashes. Use versions >=388.10_2 or <=388.9_2.

WiFi 7 | 802.11be

Model	Status	Tested firmware	Find it on Amazon[^amazon]
GT-BE19000	💛 Expected to work		find it
GT-BE98	💚 Confirmed	Stock: 102_34372	find it
GT-BE98 Pro	💛 Expected to work		find it
RT-BE58U	💛 Expected to work		find it
RT-BE88U	💛 Expected to work		find it
RT-BE92U	💛 Expected to work		find it
RT-BE96U	💛 Expected to work		find it
TUF-BE3600	💛 Expected to work		find it
TUF-BE6500	💛 Expected to work		find it
ZenWiFi BD4	💛 Expected to work		find it
ZenWiFi BQ16	💛 Expected to work		find it
ZenWiFi BQ16 Pro	💛 Expected to work		find it
ZenWiFi BT10	💛 Expected to work		find it

WiFi 6e | 802.11axe

Model	Status	Tested firmware	Find it on Amazon[^amazon]
GT-AXE11000	💛 Expected to work		find it
GT-AXE16000	💚 Confirmed	Stock: 388.21617 Merlin: 388.7_beta1_rog 388.7_0_rog	find it
RT-AXE7800	💚 Confirmed	Stock: 388_22068	find it
ZenWiFi ET8	💚 Confirmed	Stock: 388.23759	find it
ZenWiFi ET9	💛 Expected to work		find it
ZenWiFi Pro ET12	💚 Confirmed	Stock: 388.23013	find it

WiFi 6 | 802.11ax

Model	Status	Tested firmware	Find it on Amazon[^amazon]
DSL-AX82U	💚 Confirmed	Merlin: 386.07_0-gnuton0_beta2	find it
GT-AX11000	💚 Confirmed	Merlin: 386.7_2 388.1_0 388.4_0 388.7_0_rog	find it
GT-AX11000 Pro	💚 Confirmed	Stock: 388.24198 Merlin: 388.7_0_rog	find it
GT-AX6000	💛 Expected to work	Merlin: 388.7_beta1	find it
GT6	💛 Expected to work		find it
RP-AX56	💚 Confirmed		find it
RT-AX3000P	💛 Expected to work		find it
RT-AX52	💛 Expected to work		find it
RT-AX53U	💚 Confirmed	Stock: 386.69061	find it
RT-AX5400	💛 Expected to work		find it
RT-AX55	💚 Confirmed	Stock: 386.50410 386.52041	find it
RT-AX56U	💚 Confirmed	Merlin: 386.7_2 388.1_0 388.2_2	find it
RT-AX57	💛 Expected to work		find it
RT-AX57 Go	💛 Expected to work		find it
RT-AX57M	💛 Expected to work		find it
RT-AX58U	💚 Confirmed	Stock: 386.49674 388.22237 Merlin: 386.7_2 388.1_0 388.4_0 388.7.0	find it
RT-AX59U	💛 Expected to work		find it
RT-AX68U	💚 Confirmed	Stock: 388.21732	find it
RT-AX82U	💚 Confirmed	Stock: 386.48664 386.49674 Merlin: 388.8_4-gnuton1	find it
RT-AX86S	💚 Confirmed	Stock: 386.46061 386.48260 386.49447 388.22525 Merlin: 386.7_2	find it
RT-AX86U	💚 Confirmed	Stock: 386.46061 386.48260 386.49447 388.22525 Merlin: 386.7_2 388.4_0 388.7_beta1	find it
RT-AX86U Pro	💚 Confirmed	Stock: 388.23565	find it
RT-AX88U	💚 Confirmed	Stock: 386.45934 386.48631 388.24198 Merlin: 386.5_2 386.8_0 388.1_0 388.2_0 388.4_0 388.7_0	find it
RT-AX88U Pro	💚 Confirmed	Merlin: 388.4_0	find it
RT-AX89X	💚 Confirmed		find it
RT-AX92U	💚 Confirmed	Stock: 386.46061	find it
TUF-AX3000 V2	💚 Confirmed	Stock: 388.23785	find it
TUF-AX4200	💛 Expected to work		find it
TUF-AX5400	💚 Confirmed	Stock: 386.50224 388.21224 388.22525 388.23285 388.24121 Merlin: 388.4_0	find it
TUF-AX6000	💚 Confirmed	Stock: 388.32432	find it
ZenWiFi AX (XT8)	💚 Confirmed	Stock: 386.48706 388.23285 Merlin: 386.7_2-gnuton1	find it
ZenWiFi AX Hybrid (XP4)	💛 Expected to work		find it
ZenWiFi AX Mini (XD4)	💚 Confirmed	Stock: 386.48790 386.49599	find it
ZenWiFi Pro XT12	💚 Confirmed	Stock: 388.22127	find it
ZenWiFi XD4 Plus	💛 Expected to work		find it
ZenWiFi XD4S	💛 Expected to work		find it
ZenWiFi XD5	💚 Confirmed	Stock: 388.23949	find it
ZenWiFi XD6	💚 Confirmed	Stock: 388.21380	find it
ZenWiFi XD6S	💚 Confirmed	Stock: 388.21380	find it
ZenWiFi XT9	💚 Confirmed	Stock: 388_23285	find it

WiFi 5 | 802.11ac

Model	Status	Tested firmware	Find it on Amazon[^amazon]
4G-AC55U	💚 Confirmed	Stock: 380.8102	find it
BRT-AC828	💚 Confirmed	Stock: 382_70348	find it
DSL-AC68U	💚 Confirmed	Stock: 386.47534 386.50117 Merlin: 386.4-gnuton2 386.7_2-gnuton1	find it
RT-AC51U	💚 Confirmed	Stock: 380.8591	find it
RT-AC52U B1	💚 Confirmed		find it
RT-AC5300	💚 Confirmed	Merlin: 386.7_2	find it
RT-AC57U V3	💚 Confirmed	Stock: 386.21649	find it
RT-AC58U	💚 Confirmed		find it
RT-AC66U	💚 Confirmed	Merlin: 380.70_0	find it
RT-AC66U B1	💚 Confirmed	Stock: 386.51255	find it
RT-AC68U	💚 Confirmed	Stock: 386.49703 Merlin: 386.5_2 386.7_0	find it
RT-AC85P	💚 Confirmed	Stock: 382.52516	find it
RT-AC86U	💚 Confirmed	Stock: 386.48260 386.49709 Merlin: 386.7_0 386.7_2 386.9_0	find it
RT-AC87U	💚 Confirmed	Merlin: 384.13_10	find it
RT-AC88U	💚 Confirmed	Stock: 386.48260 Merlin: 386.5_0 386.7_beta1 386.12_2	find it
RT-ACRH17	💚 Confirmed	Stock: 382.52517	find it
ZenWiFi AC Mini(CD6)	💛 Expected to work		find it

WiFi 4 | 802.11n

Model	Status	Tested firmware	Find it on Amazon[^amazon]
RT-N66U	💚 Confirmed		find it

Support the library

Issues and Pull requests

If you have found an issue working with the library or just want to ask for a new feature, please fill in a new issue.

You are also welcome to submit pull requests to the repository!

Check it with your device

Testing the library with different devices would help a lot in the development process. Unfortunately, currently, I have only one device available, so your help would be much appreciated.
