avmp 0.1.1

Command line vulnerability program manager.

Automated Vulnerability Management Program (AVMP)

A collection of tools for managing and automating vulnerability management.

Streamline the way vulnerability management programs are created and run. This project is made to be modular so automation can be put into place at any program level.

---

Table of Contents

• Things to Note
• Intallation
• Running the tests
• Deployment
• How to use
  • Folder Structure
  • Main configuration file "config.json"
  • Dynamic process config "dynamic_process_config.json
  • Static process config "static_process_config.json"
• TO-DO
• Authors
• License

---

Things to Note

1. API keys for both Tenable IO and Jira are required.

2. I developed this tool using Jira on-prem and assume it would work for the cloud version as well however am unable to verify that.

3. There is a bit of setup to use the tool as it is in development, I am planning on creating a quick start script but until then please see How to use.

Installation

pip install git+https://github.com/RackReaver/AVMP

Running the tests

Check code coverage

>>> coverage run -m pytest
>>>
>>> coverage report

Deployment

At this time the tool can only be deployed locally.

How to use

$ avmp --help
      __      ____  __ _____
     /\ \    / /  \/  |  __ \
    /  \ \  / /| \  / | |__) |
   / /\ \ \/ / | |\/| |  ___/
  / ____ \  /  | |  | | |
 /_/    \_\/   |_|  |_|_|

A collection of tools for managing and automating vulnerability management.

Usage:
    avmp run [--config filepath] <process_config>
    avmp update [--config filepath] <ticket_db_filepath>
    avmp -h | --help
    avmp --version

Options:
    -h --help           Show this screen.
    --version           Show version.
    --config=filepath   AVMP configuration file [default: config.json]

Folder Structure vuln_manager:

vuln_manager
|
+-- process_configs
|  |
|  +-- dynamic/     # Configurations for generating vulnerability tickets
|  +-- static/      # Configurations for generating repetitive project/task tickets
|
+-- config.json
+-- tickets.db      # This is generated automatically and is mapped to in the process_configs

Main configuration file config.json:

{
    "creds": {
        "tenable": {
            "access_key": "",
            "secret_key": ""
        },
        "jira": {
            "server": "",
            "username": "",
            "password": ""
        }
    },
    "types": {
        "JIRA_PROJECT_ID": ["JIRA_FIELD_1", "JIRA_FIELD_2", "JIRA_FIELD_3"]
    },
    "due_dates": {
        "Critical": "DAYS_TO_PATCH",
        "High": "DAYS_TO_PATCH",
        "Medium": "DAYS_TO_PATCH",
        "Low": "DAYS_TO_PATCH",
    },
    "priorities": {
        "Critical": "JIRA_ID",
        "High": "JIRA_ID",
        "Medium": "JIRA_ID",
        "Low": "JIRA_ID"
}

Field	Required	Description
creds	yes	Data required from APIs to run package
types	no	List of required fields for a given Jira project (not required, but a good idea to ensure process_configs contain all required fields before making an API request).
due_dates	yes	Used to set Jira due date based on Tenable's severity rating.
priorities	yes	Mapping Tenable severity rating to Jira priorities (defaults to Low if others are unavailable).

Dynamic process config dynamic_process_config.json:

See examples for context on use cases.

{
  "process_type": "dynamic",
  "allow_ticket_duplication": "False",
  "scan_name": "TENABLE_SCAN_NAME",
  "max_tickets": 10,
  "assignee": "",
  "min_cvss_score": 6.0,
  "ticket_db_filepath": "tickets.db",
  "default_ticket_status": "Open",
  "time_saved_per_ticket": "10m",
  "root_ticket": "",
  "comments": [],
  "data": {
    "project": { "key": "JIRA_PROJECT_KEY" },
    "summary": "Vuln: ",
    "description": "",
    "issuetype": { "id": "JIRA_ISSUE_TYPE_ID" },
    "priority": { "id": "" },
    "duedate": ""
  }
}

Field	Required	Description
process_type	yes	Must be dynamic
allow_ticket_duplication	no	[default: false] Prevent multiple tickets for same plugin_id to be generated (This is based on the ticket_db_filepath provided).
scan_name	yes	Name of scan inside of Tenable IO
max_tickets	no	Number of tickets to be created each time this configuration is used (optional - will create all if value is blank).
assignee	no	Username to assign all created tickets to (optional).
min_cvss_score	yes	This is based on the CVSS Base Score provided by Tenable IO, allows for configurations based on severity.
ticket_db_filepath	yes	Location of SQLite database file for tracking tickets (DB will be created if ones doesn't already exist on the path provided).
default_ticket_status	yes	First status for database entry, this will change when the auto updater is run.
time_saved_per_ticket	yes	Jira time value to log work for calculating time saved.
root_ticket	no	If unable to log work against newly created ticket this value will provide a ticket that allows work to be logged against it.
comments	no	A list of strings that will generate comments.
data	yes	API values required to generate a Jira ticket (issue).

Static process config static_process_config.json:

See examples for context on use cases.

{
  "process_type": "static",
  "time_saved_per_ticket": "5m",
  "time_saved_comment": "Time saved through automation",
  "parent_ticket": {
    "project": { "key": "JIRA_PROJECT_KEY" },
    "summary": "SUMMARY",
    "description": "DESCRIPTION",
    "issuetype": { "name": "ISSUE_TYPE_NAME" },
    "assignee": { "name": "" },
    "priority": { "id": "PRIORITY_ID" }
  },
  "sub_tasks": {
    "sub_task_1": {
      "project": { "key": "JIRA_PROJECT_KEY" },
      "summary": "SUMMARY",
      "description": "DESCRIPTION",
      "issuetype": { "name": "Sub-task" },
      "assignee": { "name": "" }
    },
    "sub_task_2": {
      "project": { "key": "JIRA_PROJECT_KEY" },
      "summary": "SUMMARY",
      "description": "DESCRIPTION",
      "issuetype": { "name": "Sub-task" },
      "assignee": { "name": "" }
    }
  }
}

Field Name	Required	Description
process_name	yes	Must be static
time_saved_per_ticket	no	Jira time value to log work for calculating time saved.
time_saved_comment	no	Comment for Jira work log for time saved.
parent_ticket	yes	API values required to generate a Jira ticket (issue).
sub_tasks	no	JSON container for any sub tasks that should be created under parent ticket.

TO-DO

• Add persistent logging to wrapper.main() as a return value
• Add ticket reference table to database
  • Track project and process ticket numbers for automated linking
• Add support for SecurityScorecard
• Build tests for code base
• [x]Add example dynamic and static process configs
• Add database tracking of static_process tickets

Authors

• Matt Ferreira - Developer - RackReaver

License

This project is licensed under the Apache License - see the LICENSE file for details
