bffl 0.3.2

A framework for structured bitfield processing

bffl

Bit Fields For Lumberjacks

bffl is a high-performance bit field protocol framework for working with packed binary data. It's ideal for scenarios requiring precise control of bit arrangements, such as verilog interfaces and arbitrary bitfield manipulations. Your protocol is expressed concisely using compositions of ints, structs, arrays, and user-defined types.

Quickstart

Standard installation:

pip install bffl

Development installation (if you want to work on bffl):

git clone [e-mail]:kenseehart/bffl.git
cd bffl
pip install -e .

Comparison to ctypes

While bffl and ctypes both handle binary data in Python, their primary purposes differ. ctypes maps to C structs, whereas bffl maps to bit vectors.

Tool	Model	Primary Purpose	Implementation
ctypes	C/C++ types	Interface with C/C++ code, model C/C++ datatypes	Python, C++
bffl	Bit fields	Model arbitrary bit-aligned datatypes and interfaces	Python

Use Cases:

• ctypes:

  • Interfacing with C/C++ libraries.
  • System-level programming.
  • Handling performance-critical applications using C/C++.
  • Optimal for compute-bound tasks where hardware-specific optimizations are beneficial.
  • Memory mapping optimized your hardware

• bffl:

  • Protocol implementation requiring precise bit-level control.
  • Verilog interface testing.
  • Custom binary data formats with exact bit alignment.
  • Consistent behavior across different hardware architectures.
  • Ideal for IO-bound tasks and memory transfers, where exact bit-level management is crucial.
  • Memory mapping is portable (independent of hardware architecture)

Comparison to Bitfields in C++

C++ typically controls bit allocation for optimal performance, respecting byte or word boundaries, which can hinder precise bit-level control. bffl offers explicit control over bit allocation, with no implicit padding. This is crucial for protocol implementations and verilog interfaces, where predictable bitwise allocation is required.

In bffl, a struct with a 5-bit integer and a 13-bit integer is exactly 18 bits, and an array of 5 such structs is 90 bits. Python's int type supports unbounded bit fields, allowing flexible manipulation without byte misalignment issues.

Ease of Use

@struct
class parrot_struct:
    status: uint(2, {'dead': 0, 'pining': 1, 'resting': 2})
    plumage_rgb: uint(5)[3]

@struct
class quest_struct:
    quest: uint(3, {'grail': 0, 'shrubbery': 1, 'meaning': 2, 'larch': 3, 'gourd': 4})
    knights: knight_struct[3]
    holy: uint[1]
    parrot: parrot_struct

def get_dead_parrot_quests(raw_data_source: Sequence[int]) -> Iterator[str]:
    data = quest_struct()
    status = data.parrot.status

    for data.n_ in raw_data_source:
        if status == 'dead':
            yield data.json_

for jstr in get_dead_parrot_quests(sequence_of_integers_from_somewhere()):
    print(jstr)

Interoperability

Fields in bffl have read/write properties exposing data:

Attribute	Description
n_	Raw bits as an int (unbounded size)
v_	Data value as basic types (int, float, str, list, dict)
json_	Data value as a JSON string

Performance

bffl achieves performance by performing symbolic processing during interface allocation, reducing runtime overhead. Bound field computations typically involve simple shift-and operations.

@struct
class MyRegister:
    rtype: uint(2, {'grail': 0, 'shrubbery': 1, 'meaning': 2, 'larch': 3})
    stuff: uint(3)
    junk: uint(1)

@struct
class MyProtocol:
    header: uint(5)
    a: MyRegister
    b: MyRegister
    c: MyRegister

def look_for_fives(datastream: Sequence[int]):
    buffer = MyProtocol()
    bstuff = buffer.b.stuff
    for n in datastream:
        buffer.n_ = n
        if bstuff == 5:
            handle_5()

Trailing Underscore Convention

Fields in bffl are marked with a trailing underscore to distinguish them from non-field attributes. This allows full use of the field namespace.

Metatypes, Field Types, and Fields

bffl uses metatypes to define complex datatypes. For example, uint(5) defines a 5-bit unsigned integer field type. Fields are instantiated and assigned values via the v_ or n_ attributes.

Struct Syntax

Inline Syntax

struct_name = struct('struct_name', [('field_name', field_type), ...])

Class Syntax

class struct_name(metaclass=metastruct):
    field_name: field_type
    ...

System Verilog Support

bffl includes an svreg type for System Verilog slice semantics.

r = svreg(28)(0xabadbee)
r2 = r[15:4]
assert r2 == 0xbad
r2.v_ = 0xead
r[3:0] = 0xd
assert r == 0xdeadbee

Related Projects

Here is a comparison grid of various bitfield-related libraries with verified licenses:

Library	Description	Primary Purpose
bitvector	Bit vector implementation with BitField descriptor for sub-byte bit addressing	Address and manipulate bits in integer words
bfield	Convenient bit fields for int subclasses	Define and manipulate bitfields
ctypes-bitfield	Bitfields with ctypes integration	Interface with C/C++ bitfields
sparsebitfield	Manage sparse sets of large integers	Efficiently manage large sets of bits
bitfield	Sparse sets of large integers optimized for sequential integers	Handle large, sparse integer sets
named_bitfield	Define named bitfields for easier access and manipulation	Named bitfields
bitstring	Supports slicing and manipulating bit strings	Handle and manipulate bit strings
