caterpillar-hls 1.1

Hardened HLS merger

Caterpillar

caterpillar is a hardened HLS merger. It takes an HTTP Live Streaming VOD URL (typically an .m3u8 URL), downloads the video segments, and attempts to merge them into a single, coherent file. It is specially designed to combat timestamp discontinuities (symptom: a naive FFmpeg run spews tons of "Non-monotonous DTS in output stream" warning messages and ends up with a useless file with completely broken timestamps).

caterpillar supports up to version 3 of the HTTP Live Streaming protocol (VOD only; non-VOD playlists are treated as VOD, and may result in unexpected consequences).

Contents

• Dependencies
• Installation
  • For end users
  • For developers and beta testers
  • For application developers
• Usage
• Batch mode
• Configuration
• Notes and limitations
• Etymology
• Copyright

Dependencies

A recent version of FFmpeg. FFmpeg 3.3.4 is known to work with caterpillar; FFmpeg 3.2.4 is known to NOT work.

Installation

Python 3.6 or later is required.

If in doubt, check out the detailed "Installation Guide for Novices".

For end users

To install,

pip install caterpillar-hls

To upgrade to the latest version,

pip install -U caterpillar-hls

For developers and beta testers

To install from the master branch,

git clone https://github.com/zmwangx/caterpillar.git
cd caterpillar
python setup.py develop
caterpillar -h

To update to the latest master,

cd /path/to/caterpillar
git pull origin master

For application developers

Short of calling caterpillar.caterpillar.main with sys.argv set appropriately, you can access caterpillar's functionality through caterpillar.caterpillar.process_entry and caterpillar.caterpillar.process_batch. Warning: there's no stability guarantee to these interfaces, although I won't break compatibility without a very compelling reason.

process_entry and process_batch additionally support event hooks (a feature not exposed to end users). See caterpillar.caterpillar.events for types of events emitted and associated data attributes.

Usage

$ caterpillar -h
usage: caterpillar [-h] [-b] [-e] [-f] [-j JOBS] [-k]
                   [-m {concat_demuxer,concat_protocol,0,1}] [-r RETRIES]
                   [--remove-manifest-on-success] [--workdir WORKDIR]
                   [--workroot WORKROOT] [--wipe] [-v] [--progress]
                   [--no-progress] [-q] [--debug] [-V]
                   m3u8_url [output]

positional arguments:
  m3u8_url              the VOD URL, or the batch mode manifest file
  output                path to the final output file (default is a .ts file
                        in the current directory with the basename of the VOD
                        URL)

optional arguments:
  -h, --help            show this help message and exit
  -b, --batch           run in batch mode (see the "Batch Mode" section in
                        docs)
  -e, --exist-ok        skip existing targets (only works in batch mode)
  -f, --force           overwrite the output file if it already exists
  -j JOBS, --jobs JOBS  maximum number of concurrent downloads (default is
                        twice the number of CPU cores, including virtual
                        cores)
  -k, --keep            keep intermediate files even after a successful merge
  -m {concat_demuxer,concat_protocol,0,1}, --concat-method {concat_demuxer,concat_protocol,0,1}
                        method for concatenating intermediate files (default
                        is 'concat_demuxer'); see
                        https://github.com/zmwangx/caterpillar/#notes-and-limitations
                        for details
  -r RETRIES, --retries RETRIES
                        number of times to retry when a possibly recoverable
                        error (e.g. download issue) occurs; default is 2, and
                        0 turns off retries
  --remove-manifest-on-success
                        remove manifest file if all downloads are successful
                        (only works in batch mode)
  --workdir WORKDIR     working directory to store downloaded segments and
                        other intermediate files (default is automatically
                        determined based on URL and output file)
  --workroot WORKROOT   if nonempty, this path is used as the root directory
                        for all processing, under which both the working
                        directory and final destination are mapped; after
                        merging is done, the artifact is eventually moved to
                        the destination (use cases: destination on a slow HDD
                        with workroot on a fast SSD; destination on a
                        networked drive with workroot on a local drive)
  --wipe                wipe all downloaded files (if any) and start over
  -v, --verbose         increase logging verbosity (can be specified multiple
                        times)
  --progress            show download progress bar regardless of verbosity
                        level
  --no-progress         suppress download progress bar regardless of verbosity
                        level
  -q, --quiet           decrease logging verbosity (can be specified multiple
                        times)
  --debug               output debugging information (also implies highest
                        verbosity)
  -V, --version         show program's version number and exit

environment variables:
  CATERPILLAR_USER_CONFIG_DIR
                        custom directory for caterpillar.conf
  CATERPILLAR_USER_DATA_DIR
                        custom directory for certain data cached by
                        caterpillar
  CATERPILLAR_NO_USER_CONFIG
                        when set to a non-empty value, do not load
                        options from user config file
  CATERPILLAR_NO_CACHE  when set to a non-empty value, do not read or
                        write caterpillar's cache

configuration file:
  <an operating system and user-dependent path>

See the wiki page for usage examples.

Batch mode

In normal mode, caterpillar deals with only one stream. There is also a batch mode for downloading multiple streams at once. In this mode, you specify a manifest file on the command line in the place of the VOD URL, where the manifest file contains a VOD URL and a filename (or path) seperated by a tab on each line, e.g., caterpillar manifest.txt, where manifest.txt contains

https://example.com/hls/1.m3u8	1.mp4
https://example.com/hls/2.m3u8	2.mp4
https://example.com/hls/3.m3u8	3.mp4

The filenames (or paths) are relative to the parent directory of the manifest file. The tab character is not allowed in the filenames (or paths).

Comments that start with # are allowed in the manifest file.

Most options for normal mode are also allowed in the batch mode, as are options set in the configuration file.

Configuration

To save some retyping, caterpillar supports the configuration of default options in an operating system and user-dependent configuration file. The path is usually ~/Library/Application Support/caterpillar/caterpillar.conf on macOS, %AppData%\org.zhimingwang\caterpillar\caterpillar.conf on Windows, and ~/.config/caterpillar/caterpillar.conf on Linux. Run caterpillar -h to view the actual path.

The syntax of the configuration file is documented in the template (automatically created for you if possible), duplicated below:

# You may configure default options here so that you don't need to
# specify the same options on the command line every time.
#
# Each option, along with its argument (if any), should be on a separate
# line; unlike on the command line, you don't need to quote or escape
# whitespace or other special characters in an argument, e.g., a line
#
#     --workdir Temporary Directory
#
# is interpreted as two command line arguments "--workdir" and
# "Temporary Directory".
#
# Positional arguments are not allowed, i.e., option lines must begin
# with -.
#
# Blank lines and lines starting with a pound (#) are ignored.
#
# You can always override the default options here on the command line.
#
# Examples:
#
#     --jobs 32
#     --concat-method concat_protocol

Notes and limitations

• EXT-X-MEDIA for alternative renditions are not supported since multiple playlists need to be downloaded, merged, and muxed, which is beyond the current scope of this tool.

• EXT-X-STREAM-INF variant streams are only partially supported: when two or more variant streams are present, the best one (selected based on higher resolution, higher average bandwidth, and higher bandwidth, in that order) is automatically selected; there is no mechanism for users to select another variant at the moment. In addition, AUDIO, VIDEO, SUBTITLES or CLOSED-CAPTIONS attributes referencing EXT-X-MEDIA tags are not supported.

  Efforts could be made to extract the variant streams and show them to the user, and it is even feasible to proceed with the download if only one variant stream is present. Contribution is welcome for this feature.

• A note on -m, --concat-method: The final step of caterpillar is concatenating one or more parts (generated from splitted playlists with FFmpeg's hls demuxer) into a single output file. In this step we provide two methods of choice: the concat demuxer and the concat protocol (the former is the default). To pick the non-default concat_protocol, specify --concat-method concat_protocol on the command line, or as a shortcut, -m 1 (0 is an alias for concat_demuxer, and 1 is an alias for concat_protocol).

  Each of these two methods may work better in certain cases. For instance, for this stream, the concat demuxer simply fails with loads of error messages like "Application provided duration: 7980637472 / timestamp: 7994129672 is out of range for mov/mp4 format", whereas the concat protocol works fine. However, for this stream, the concat protocol dumps a bunch of worrisome warnings like "DTS out of order" or "Non-monotonous DTS in output stream", whereas the concat demuxer doesn't.

  In short, if the default fails you (either doesn't work outright, or the generated video is bad in some way), try -m 1.

• Encoding-related issues. caterpillar, since version 1.0, reads and writes every on-disk file in UTF-8 encoding, period. In particular, user config file and batch mode manifests need to be in UTF-8. Legacy config file might need to be migrated to UTF-8.

  If you're unfamiliar with the concept of character encodings, you may find the classic Joel on Software article on charsets and Unicode informative (gosh, it's fifteen years old now). On Unix-like systems, uchardet is my go-to tool for encoding detection; it's not readily packaged on Windows, and it's not officially supported and a royal pain to compile by yourself (to a non-Windows developer like me, and probably to whomever is reading this note). I don't know a good alternative on Windows, but I have a small web app that does encoding detection entirely in the browser: https://chardet.tcl.sh/.

  Converting a file to UTF-8, once you know its contents, is actually pretty easy. Any text editor worth its salt (and still afloat) should be able to save as UTF-8; heck, even Windows Notepad can do this (it even appears to be the default).

  This note is mostly only relevant to Windows. I can't overstate how I absolutely fucking detest dealing with encodings surrounding Microsoft products. If you ever saw �'s on web pages in places where there should be quotation marks — that's Latin-1, or Windows-1252, being decoded as UTF-8. That's just the tip of the iceberg. If you ever deal with CJK, or another alphabet other than Latin, oh baby, you're in for a world of pain. I can't count the number of times I opened a file or unzipped an archive from a Windows user, only to find garbage filenames or garbage content or both, and had to guess the encoding to restore the meaning. Also, meet Windows cmd or PowerShell; you have to fucking chcp 65001 just to work with Unicode, and even then for whatever fucking reason I still get ??? for Chinese characters in input commands – oh and I use Cmder, which allows a secondary font for CJK, an infinite improvement over stock cmd or PowerShell already, but still no luck. You may also want to meet the latest and greatest Office for Mac, where you still can't import a UTF-8-encoded CSV file with non-ASCII characters (I know a workaround, for fuck's sake). Not sure about the Windows version, and not enthusiastic enough to find out. (In all fairness, Apple's HFS+ with its infamous NFD-based UTF-8-MAC encoding in filenames was hell, but other than that Mac OS X and its successors have been pretty good encoding-wise; and APFS is finally rid of the pseudo-NFD garbage — it might have had its own problems at first, but I've yet to run into any. HFS+ encoding problems are peanuts compared to Microsoft's encoding problems, by the way. I'm not even bringing fonts into the mix.)

  In addition, if you ever have Chinese filenames in the English version of Windows — gosh, they're so ugly they almost bring tears to my eyes. I had to swap the entire fucking system UI font via a registry hack to keep tears at bay. Last I heard there are plenty of Chinese folks working in Redmond — hell, I even have acquitances there. How they managed to tolerate this shit for so many years is beyond me.

  Pretty sure I can tell you a lot more if I spent more time with Microsoft products (which is close to zero at the moment).

  Windows is more than thirty years old now, and the UN is more than seventy years old. Yet Redmond still hasn't got the memo on globalization.

  This dissolved into another Microsoft rant. Oh well.

Etymology

The word "caterpillar" starts with cat(1), and the body of a caterpillar is segmented.

Copyright

Copyright © 2017 Zhiming Wang

This project is licensed under the MIT license. See COPYING for details.
