chilife 1.0.2

A package for modeling non-canonical amino acid side chain ensembles.

UPDATES
2024.8.15 : chiLife 1.0 released!
2024.8.15 : chiLife can now be used to create arbitrary peptides with natural and NCAAs. Checkout the make_peptide function.
2024.8.15 : chiLife can make NCAA structures from smiles. Checkout smiles2residue. Note: Requires RDKit to be installed.
chiLife now supports arbitrary backbone attachments including DNA and RNA labels and more!

chiLife

chiLife is a Python package for modeling non-canonical amino acid side chain ensembles and using those ensembles to predict experimental observables. Currently, it is focused primarily on site-directed spin labels (SDSLs). The goal of chiLife is to provide a simple, flexible and interoperable Python interface to protein side chain ensemble modeling, allowing for rapid development of custom analysis and modeling pipelines. This is facilitated by the use of RotamerEnsemble and SpinLabel objects with standard interfaces for all supported side chain types, side chain modeling methods and protein modeling methods. Flexibility is achieved by allowing users to create and use custom RotamerEnsemble and SpinLabel objects as well as custom side chain modeling methods. Interoperability sought by interactions with other Python-based molecular modeling packages. This enables the use of experimental data, like double electron-electron resonance (DEER), in other standalone protein modeling applications that allow user-defined restraints, such as PyRosetta and NIH-Xplor.

Getting Started

Stable distributions of chiLife can be installed using pip.

pip install chiLife

Alternatively, the development version can be installed by downloading and unpacking the GitHub repository, or using git clone followed by a standard Python setuptools installation.

git clone https://github.com/StollLab/chiLife.git
cd chiLife
pip install -e .   # Install as editable and update using `git pull origin main`

---

chiLife Module

The central entity of chiLife is the SpinLabel object, which inherits from the more abstract RotamerEnsemble object. While most people will primarily use SpinLabel objects, be aware that most properties and functions discussed are also functional on RotamerLibrary objects as well. SpinLabel objects can be created and "attached" to protein models easily and quickly, allowing for scriptable analysis or on-the-fly simulation of distance distributions while modeling. Attaching a SpinLabel to a protein does not alter the protein in any way, allowing the protein model to retain the native amino acid.

Simple rotamer-library based SpinLabel modeling

import numpy as np
import matplotlib.pyplot as plt
import chilife as xl

# Download protein structure from PDB
MBP = xl.fetch('1omp', save=True)

# Create Spin lables
SL1 = xl.SpinLabel('R1M', site=20, chain='A', protein=MBP)
SL2 = xl.SpinLabel('R1M', site=238, chain='A', protein=MBP)

# Calculate distribution
r = np.linspace(0, 100, 256)
P = xl.distance_distribution(SL1, SL2, r=r)

# Plot distribution
fig, ax = plt.subplots(figsize=(6, 3))
ax.plot(r, P)
ax.set_yticks([])
ax.set_xlabel('Distance ($\AA$)')
for spine in ['left', 'top', 'right']:
    ax.spines[spine].set_visible(False)
plt.show()

The side chain ensembles can then be saved using a simple save function that accepts an arbitrary number of RotamerEnsemble, SpinLabel, MDAnalyisis.Universe and MDAnalyiss.AtomGroup objects. Because RotamerEnsemble/SpinLabel objects do not mutate the underlying protein, they are saved as separate multi-state objects and can be visualized with applications like PyMOL. If you do wish to permanently alter the underlying protein structure, you can use the mutate function described below.

# Save structure
xl.save('MBP_L20R1_S238R1.pdb', SL1, SL2, MBP)

Off-rotamer sampling and local repacking

One of the benefits of chiLife is the variety and customizable nature of spin label modeling methods. This includes methods to sample side chain conformations that deviate from canonical dihedral angles and fixed rotamer libraries (off-rotamer sampling) and methods to repack a SpinLabel and its neighboring amino acids.

import chilife as xl

MBP = xl.fetch('1omp')

# Create a SpinLabel object using the MTSSLWizard 'Accessible Volume' Approach
SL1 = xl.SpinLabel.from_wizard('R1M', site=20, chain='A', protein=MBP)

# Create a SpinLabel object by sampling off-rotamer dihedral conformations using the rotamer library as a prior
SL2 = xl.SpinLabel('R1M', site=238, chain='A', sample=2000, protein=MBP)

# Create a SpinLabel object from a ProEPR.repack trajectory
traj, de = xl.repack(SL1, SL2, protein=MBP)

The repack function performs a Markov chain Monte Carlo sampling (MCMC) repack of the spin labels, SL1 and SL2 and neighboring side chains, returning an MDAnalysis.Universe object containing all accepted structures of the MCMC trajectory, the energy function changes at each acceptance step and new SpinLabel objects attached to the lowest-energy structure of the trajectory.

SpinLabel objects and neighboring side chains can be repacked using off-rotamer sampling by using the off_rotamer=True option. In the event off-rotamer sampling is being used for repacking, it is likely that the desired SpinLabel object is not the default rotamer ensemble attached to the lowest-energy structure, but instead the ensemble of side chains created in the MCMC sampling trajectory. This can be done using the from_trajectory class method.

# Create a SpinLabel object from a xl.repack trajectory with off-rotamer sampling
traj, de = xl.repack(SL1, SL2, protein=MBP, off_rotamer=True)
SL1 = xl.SpinLabel.from_trajectory(traj, site=238)

Note: if you are creating a SpinLabel object from a label that is unknown to chilife you will have to specify which atoms the spin density primarily resides on. this is done with the spin_atoms kwarg, e.g.

SL1 = xl.SpinLabel.from_trajectory(traj, site=238, spin_atoms=['N1', 'O1'])

When repacking, off-rotamer sampling can be controlled for each dihedral angle separately by passing a list of bools to the off_rotamer keyword. For example, passing off_rotamer = [False, False, False, True, True] will allow for off-rotamer sampling of only χ₄ and χ₅.

Mutating protein structures

Sometimes you don't want an entire rotamer ensemble, but just a protein structure mutated at a particular site with the most probable spin label conformer. This can be done easily with the mutate function.

import chilife as xl

MBP = xl.fetch('1omp')
SL = xl.SpinLabel('R1M', 238, protein=MBP)
MBP_S238R1 = xl.mutate(MBP, SL)
xl.save('MBP_S238R1.pdb', MBP_S238R1)

chiLife can mutate several sites at once, and it can mutate canonical amino acids as well.

SL1 = xl.SpinLabel('R1M', 20, protein=MBP)
SL2 = xl.SpinLabel('R1M', 238, protein=MBP)
L284V = xl.RotamerEnsemble('VAL', 284, protein=MBP)

Mutating adjacent sites is best done with the repack function to avoid clashes between SpinLabels/RotamerEnsembles. This returns a trajectory which can be used to pick the last or lowest-energy frame as the mutated protein.

MBP_L284V_L20R1_S238R1, _, _ = xl.repack(SL1, SL2, L284V, protein=MBP)

Adding user defined spin labels

Site-directed spin labels, and other non-canonical amino acids, are constantly being developed. Additionally, rotamer libraries for existing labels continuously undergo incremental improvements or modification to suit particular needs, e.g. a rotamer library specifically for transmembrane residues. In fact chiLife itself can be used to develop new and improved, or application-specific rotamer libraries. To this end, chiLife makes it easy to create user-defined spin labels and custom rotamer libraries. To create a custom rotamer library, all that is needed is (1) a pdb file of the spin label, (2) a list of the rotatable dihedral bonds, and (3) a list of the atoms that carry spin density.

xl.create_library(name='TRT_1.0',
                  resname='TRT',
                  pdb='test_data/trt.pdb',
                  dihedral_atoms=[['N', 'CA', 'CB', 'SG'],
                                  ['CA', 'CB', 'SG', 'SD'],
                                  ['CB', 'SG', 'SD', 'CAD'],
                                  ['SG', 'SD', 'CAD', 'CAE'],
                                  ['SD', 'CAD', 'CAE', 'OAC']],
                  spin_atoms='CAQ')

This function creates a portable TRT_1.0_rotlib.npz file that can be provided when creating a SpinLabel object.

xl.SpinLabel('TRT', site=238, protein=MBP, rotlib='TRT_1.0', sample=5000)

Thus, the file can be easily shared with coworkers, collaborators or with other chiLife users.

NOTE: In the above example, the rotlib keyword is only used for demonstration purposes. chiLife always searches the current working directory for rotamer library files first. If there is a XYZ_rotlib.npz in the working directory and you specify xl.SpinLabel('XYZ', ...), chiLife will assume you want to use the XYZ_rotlib.npz rotamer library.

User-defined labels can be constructed from a single-state pdb file or a multi-state PDB file. If constructed from a single-state pdb file, a list of dihedral angles and weights can be passed via the dihedrals and weigts keyword arguments. For each set of dihedral angles, chiLife create a rotamer and store the whole library using the specified name. Alternatively, using a multi-state PDB file can add some additional information, such as isomeric heterogeneity of the rotamer library.

For more information on how to use chiLife see examples and the workshop repository.

References

When you are using chiLife in your work, please cite:

Tessmer, M.H.; Stoll, S. chiLife: An open-source Python package for in silico spin labeling and integrative protein modeling. Plos Comput Biol. 2023, 19:e1010834. https://doi.org/10.1371/journal.pcbi.1010834

If you are using off-rotamer sampling, please cite:

Tessmer, M.H.; Canarie, E.R.; Stoll, S. Comparative evaluation of spin label modeling methods for protein structural studies. Biophys J. 2022, 121, 3508-3519. https://doi.org/10.1016/j.bpj.2022.08.002

When using bifunctional label modeling, please cite:

Tessmer, M.H.; Stoll, S. A Rotamer Library Approach to Modeling Side Chain Ensembles of the Bifunctional Spin Label RX. Appl. Magn. Reson. 2023, 55, 127–140. https://doi.org/10.1007/s00723-023-01576-1

Hasanbasri, Z.; Tessmer, M.H.; Stoll, S.; Saxena, S. Modeling of Cu(ii)-based protein spin labels using rotamer libraries. Phys. Chem. Chem. Phys. 2024, 26, 6806-6816. https://doi.org/10.1039/D3CP05951K

Note than many rotamer libraries have their own references. Please use the chilfe.rotlib_info() function on the rotamer libraries to check if there are any additional citations that should be referenced.
