citronella 1.0.1

Webdriver Extension with Page Object Wrapper

Citronella

webdriver extension with a page object wrapper.

Example Tests

Selenium

import pytest
from Pages.contents_page import ContentsPage


class TestNavigationMenu:

    def test_help_page(self, web):
        web.driver.get('https://pypi.org/')
        web.page = ContentsPage

        web.page.home_page.help_button.click()
        assert 'Help' in web.driver.title

    def test_sponsors_page(self, web):
        web.page.help_page.sponsors_button.click()
        assert 'Sponsors' in web.driver.title

    def test_login_page(self, web):
        web.page.sponsors_page.login_button.click()
        assert 'Log' in web.driver.title

    def test_register_page(self, web):
        web.page.login_page.register_button.click()
        assert 'Create' in web.driver.title

Appium

import pytest
from Pages.contents_page import ContentsPage


class TestInput:

    def test_input(self, web):
        web.page = ContentsPage
        web.page.home_page.gallery_button.click()
        web.page.gallery_page.text_input.send_keys('citronella')
        web.page.gallery_page.add_button.click()
        elements = web.page.gallery_page.text_lists.get_elements()
        assert 'citronella' in [x.text for x in elements]

Even though this module is mainly designed for the page object model, it can also be used without it for quick prototyping or mockups, etc.

from selenium import webdriver
from selenium.webdriver.common.by import By
from citronella import WebPage


driver = webdriver.Chrome()

web = WebPage(driver, webdriver_wait=20, logger=False)
web.driver.get('https://pypi.org/')

web.locate(By.ID, 'search').get_element().send_keys('citronella')
web.locate(By.XPATH, '//button[@type="submit"]/i').get_element().click()

elements = web.locate(By.XPATH, '//span[@class="package-snippet__name"]')
if elements.ec_visibility_of_all_elements_located():
    results = elements.get_elements()
    text_lists = [x.text for x in results]

---

Install Package

pip install citronella

---

Documentation

There are only two modules import in this package:

• The first module is for conftest.py.

Selenium

import pytest
from selenium import webdriver
from citronella import WebPage


@pytest.fixture(autouse=True, scope='class')
def web(request):
    driver = webdriver.Chrome()
    yield WebPage(driver)
    driver.quit()

Appium

import pytest
import os
from appium import webdriver
from appium.options.android import UiAutomator2Options
from citronella import WebPage


@pytest.fixture(autouse='true', scope='class')
def web(request):
    options = UiAutomator2Options()
    options.platformName = 'Android'
    options.app = os.getcwd() + '/APK/ApiDemos-debug.apk.zip'
    driver = webdriver.Remote('http://127.0.0.1:4723/wd/hub', options=options)
    yield WebPage(driver)
    driver.quit()

• The second module are for the page object model.

Selenium

from selenium.webdriver.common.by import By
from citronella import ui
from Pages.components import Header


class HomePage(Header):

    def some_button(self):
        return ui(By.XPATH, '//a[@name="foo"]')

    def search_input(self):
        return ui(By.ID, 'search')

    def search_button(self):
        return ui(By.NAME, 'search-button')

Appium

from appium.webdriver.common.appiumby import AppiumBy
from citronella import ui
from Pages.components import Header


class HomePage(Header):

    def some_button(self):
        return ui(AppiumBy.XPATH, '//a[@name="foo"]')

    def search_input(self):
        return ui(AppiumBy.ACCESSIBILITY_ID, 'search')

    def search_button(self):
        return ui(AppiumBy.ID, 'search-button')

---

Page Object Design / Strategy

There's a two ways to create a page object for WebPage:

1. Straightforward approach: This method requires importing the page object for each test.

from selenium import webdriver
from selenium.webdriver.common.by import By
from citronella import WebPage, ui


class HomePage:
    def auth_buton(self):
        return ui(By.XPATH, '//a[@name="foo"]')

class LoginPage:
    def email_input(self):
        return ui(By.ID, 'email')

    def password_input(self):
        return ui(By.ID, 'password')

    def login_buton(self):
        return ui(By.ID, 'login')

driver = webdriver.Chrome()
web = WebPage(driver)
web.driver.get('https://foobarbaz.com/')
web.page = HomePage
web.page.auth_button.click()
web.page = LoginPage
web.page.email_input.send_keys('foo')
web.page.password_input.send_keys('bar')
web.page.login_button.click()

2. Lazy loading approach: This method is slightly more complex but offers the benefit of lazy loading. see ContentsPage example or this Page object example

from selenium import webdriver
from selenium.webdriver.common.by import By
from citronella import WebPage, ui


class ContentsPage:
    def home_page(self):
        return HomePage

    def login_page(self):
        return LoginPage

class HomePage:
    def auth_buton(self):
        return ui(By.XPATH, '//a[@name="foo"]')

class LoginPage:
    def email_input(self):
        return ui(By.ID, 'email')

    def password_input(self):
        return ui(By.ID, 'password')

    def login_buton(self):
        return ui(By.ID, 'login')

driver = webdriver.Chrome()
web = WebPage(driver)
web.driver.get('https://foobarbaz.com/')
web.page = ContentsPage
web.page.home_page.auth_button.click()
web.page.login_page.email_input.send_keys('foo')
web.page.login_page.password_input.send_keys('bar')
web.page.login_page.login_button.click()

---

Usage

citronella.WebPage

Args:

• driver / webdriver

Kwargs (optional):

• webdriver_wait number(seconds), default value is 10
• logger bool, default value is True

Method Lists:

Method Name	Args*	Kwargs**	Note
driver	-	-	return selenium webdriver object
locate	by, value	-	similar asdriver.get_element as input & return citronella.WebUi object
page	page object	-	setter
page	-	-	getter
webdriver_wait	number(sec)	-
ready_state	number(sec)	-	execute javascript document.readyState manually, default timeout is 30
sleep	number(sec)	-

citronella.ui / citronella.WebUi

Args:

• by
• value

Method Lists:

Method Name	Args*	Kwargs**	Note
send_keys	text	clear bool, return_key bool
click	-	-
get_element	-	-
get_elements	-	-
ec_element_to_be_clickable	-	-	wrapper of EC / excpected_condition
ec_presence_of_element_located	-	-	wrapper of EC / excpected_condition
ec_presence_of_all_elements_located	-	-	wrapper of EC / excpected_condition
ec_visibility_of_element_located	-	-	wrapper of EC / excpected_condition
ec_visibility_of_all_elements_located	-	-	wrapper of EC / excpected_condition
ec_visibility_of_any_elements_located	-	-	wrapper of EC / excpected_condition
ec_invisibility_of_element_located	-	-	wrapper of EC / excpected_condition
ec_element_located_to_be_selected	-	-	wrapper of EC / excpected_condition
