cotproxy 1.0.0

Cursor-On-Target Transform Proxy

Cursor on Target Transformation Proxy

COTProxy is an in-line Cursor-on-Target (CoT) transformation proxy for TAK Products. CoT can be modified as it travels from one TAK Product to another over a network.

How does it work?

Given a matching UID & Transform, CoT Event characteristics can be changed, including Callsign, Type, Icon, Video, et al. COTProxy’s transform configurations are managed via the COTProxyWeb front-end, installed separately.

Concept of Operations CONOPS:

Support This Project

Help: Email [e-mail] or Signal/WhatsApp: [phone]

This project has been developed for the Disaster Response, Public Safety and Frontline Healthcare community. All contributions further project development and ensure ongoing support.

Configuration

COTProxy can be configured using an INI-style config file, or using Environment Variables. Configuration Parameters are as follows:

• CPAPI_URL: URL of COTProxyWeb API. Default = http://localhost:10415/

• LISTEN_URL: Protocol, Local IP & Port to listen for CoT Events. Default = udp://0.0.0.0:8087.

• PASS_ALL: If True, will pass everything, Transformed or not. Default = False.

• AUTO_ADD: If True, will automatically create Transforms and Objects for all COT Events. Default = False.

Optional special parameters for importing legacy known_craft.csv files:

• KNOWN_CRAFT_FILE: [optional] Path to existing Known Craft file to use when seeding COTProxyWeb database. Default = known_craft.csv.

• SEED_FAA_REG: [optional] If True, will set Tail/N-Number on seeded ICAO Hexs from FAA database. Default = True.

TLS & other configuration options, see: PyTAK.

Example Config

To use any of these example configurations, save the indented code block to the file /etc/config.ini and start COTProxy with cotproxy -c /etc/config.ini.

Example - Send modified CoT to a TAK Server using TLS:

[cotproxy]
; ^-- [cotproxy] must always the the first line of config file.

; Listen for CoT at TCP Port 8087 on all network interfaces:
LISTEN_URL=tcp://0.0.0.0:8087

; Send modified CoT to our TAK Server using TLS:
COT_URL=tls://takserver.example.com:8089

; TLS Cert & Key
PYTAK_TLS_CLIENT_CERT=/etc/cotproxy.cert.pem
PYTAK_TLS_CLIENT_KEY=/etc/cotproxy.key.pem

Example - Send modified CoT to ATAK Mesh Multicast:

[cotproxy]
; ^-- [cotproxy] must always the the first line of config file.

; Listen for CoT at TCP Port 8087 on all network interfaces:
LISTEN_URL=tcp://0.0.0.0:8087

; ATAK Multicast Group & Port:
COT_URL=udp://239.2.3.1:6969

Running

COTProxy should be started as a background sevice (‘run forever’, daemon, etc). Most modern Linux-based operating systems use the systemd System and Service Manager.

CentOS, Debian, Ubuntu, RaspberryOS, Raspbian

These instructions will create, enable and start a service on Linux.

1. Download the example cotproxy systemd service definition:

   $ sudo wget --output-document=/etc/systemd/system/cotproxy.service https://raw.githubusercontent.com/ampledata/cotproxy/main/cotproxy.service

2. Create the /etc/config.ini file and add an appropriate configuration, see Configuration section of the README for config examples:

$ sudo nano /etc/config.ini

3. Enable cotproxy systemd service:

   $ sudo systemctl daemon-reload
   $ sudo systemctl enable cotproxy
   $ sudo systemctl start cotproxy

4. You can view cotproxy logs with: $ sudo journalctl -xef

Installation

Debian, Ubuntu, RaspberryOS, Raspbian

COTProxy is available as a .deb package:

$ sudo apt update
$ wget https://github.com/ampledata/pytak/releases/latest/download/python3-pytak_latest_all.deb
$ sudo apt install -f ./python3-pytak_latest_all.deb
$ wget https://github.com/ampledata/cotproxy/releases/latest/download/python3-cotproxy_latest_all.deb
$ sudo apt install -f ./python3-cotproxy_latest_all.deb

CentOS, RedHat

Install from the Python Package Index (PyPI):

$ python3 -m pip install cotproxy

Developers

Install from GitHub source:

$ git clone https://github.com/ampledata/cotproxy.git
$ cd cotproxy/
$ python3 setup.py install

Install with PyEnv

PyEnv is an alternative installation method that bypasses the system built-in Python environment on Linux & MacOS. PyEnv works by installing its own Python binary & libraries, and keeping installed modules isolated from system modules. This is the authors preferred method of installation.

PyEnv - Debian

1. Install required packages:

   $ sudo apt-get install make build-essential libssl-dev zlib1g-dev \
       libbz2-dev libreadline-dev libsqlite3-dev wget curl llvm \
       libncursesw5-dev xz-utils tk-dev libxml2-dev libxmlsec1-dev \
       libffi-dev liblzma-dev git
   $ curl https://pyenv.run | bash

2. Add the following to your ~/.bashrc and restart your shell:

   export PYENV_ROOT="$HOME/.pyenv"
   command -v pyenv >/dev/null || export PATH="$PYENV_ROOT/bin:$PATH"
   eval "$(pyenv init -)"
   eval "$(pyenv virtualenv-init -)"

Once back in:

$ pyenv install 3.9.13
...Catch up on your expense reports, have a snack, stay hydrated...
$ pyenv shell 3.9.13
$ pyenv virtualenv pytakenv
$ pyenv activate pytakenv
$ python3 -m pip install --upgrade pip
$ mkdir ~/src
$ cd ~/src
$ git clone https://github.com/ampledata/cotproxy.git
$ cd cotproxy
$ python3 setup.py install
$ cd ~/src
$ git clone https://github.com/ampledata/cotproxyweb.git
$ cd cotproxyweb
$ python3 -m pip install -r requirements.txt
$ bash setup.sh
... When prompted, select an admin password. ...

You should now be able to connect to port :8000/admin from a web browser.

Seed COTProxy Transforms frome existing Known Craft file, given a Known Craft file named known_ps.csv:

$ CPAPI_URL="http://localhost:8000/" KNOWN_CRAFT=known_ps.csv cotproxy-seed

PyEnv - CentOS 7

1. Update packages:

   sudo yum update
   sudo yum check-update

2. Install required packages:

   sudo yum groupinstall -y "Development Tools"
   sudo yum install -y zlib zlib-devel bzip2-devel openssl-devel sqlite-devel \
       readline-devel libffi-devel lzma-sdk-devel ncurses-devel gdbm-devel \
       db4-devel expat-devel libpcap-devel xz-devel pcre-devel wget

3. Install updated SQLite:

   mkdir -p ~/src
   cd ~/src
   wget https://www.sqlite.org/2019/sqlite-autoconf-3290000.tar.gz
   tar zxvf sqlite-autoconf-3290000.tar.gz
   cd sqlite-autoconf-3290000
   ./configure
   make
   sudo make install

3. Install PyEnv:

   curl https://pyenv.run | bash

4. Update ~/.bash_profile:

The following chunk of code should be appended to the end of your ~/.bash_profile, either using a text editor like vi, vim, nano or pico. Once added, reload your environment by running: source ~/.bash_profile:

export PYENV_ROOT="$HOME/.pyenv"
command -v pyenv >/dev/null || export PATH="$PYENV_ROOT/bin:$PATH"
eval "$(pyenv init -)"
eval "$(pyenv virtualenv-init -)"
export PATH=/opt/sqlite/bin:$PATH
export LD_LIBRARY_PATH=/opt/sqlite/lib
export LD_RUN_PATH=/opt/sqlite/lib
export C_INCLUDE_PATH=/opt/sqlite/include
export CPLUS_INCLUDE_PATH=/opt/sqlite/include

5. Install Python 3.9 environment:

   pyenv install 3.9.13
   pyenv shell 3.9.13
   pyenv virtualenv cpenv

6. Install cotproxy:

   mkdir -p ~/src
   cd ~/src
   wget https://github.com/ampledata/cotproxy/archive/refs/tags/v1.0.0b2.tar.gz
   tar -zvxf v1.0.0b2.tar.gz
   cd cotproxy-1.0.0b2/
   python3 setup.py install

7. Install & Initialize cotproxyweb:

   mkdir -p ~/src
   cd ~/src
   git clone https://github.com/ampledata/cotproxyweb.git
   cd cotproxyweb/
   python3 -m pip install -r requirements.txt
   python3 manage.py migrate
   python3 manage.py createsuperuser \
   --username admin --email [e-mail]
   python3 manage.py runserver 0:8000

8. From here follow the Running section of the README.

Source

Github: https://github.com/ampledata/cotproxy

Author

Greg Albrecht W2GMD [e-mail]

https://ampledata.org/

Copyright

COTProxy is Copyright 2022 Greg Albrecht

License

COTProxy is licensed under the Apache License, Version 2.0. See LICENSE for details.
