open source panorama viewer for the web. Built using HTML5, CSS3, JavaScript, and WebGL, it is plug-in free.

Project description

Dash Pannellum

Dash Pannellum is a Dash component that integrates the Pannellum panorama viewer into your Dash applications. It allows you to display interactive 360° panoramas, including equirectangular images, cube maps, and 360° videos.

Github Repo

https://github.com/pip-install-python/dash_pannellum

⭐️ Star this component on GitHub! Stay up to date on new releases and browse the codebase.

Features:

  • Display equirectangular panoramas
  • Support for multi-resolution panoramas
  • 360° video playback
  • Tour mode with multiple scenes and hotspots
  • Customizable controls
  • Center dot option for orientation
  • pinpoint location of where the user is within the component
  • autoload feature
  • adjustable props
  • supports keyboard controls [left arrow] [right arrow] [up arrow] [down arrow] to move, [shift] zoom in and [control] to zoom out

Installation

pip install dash-pannellum

Interactive Docs

View the interactive docs

Usage

Here's a simple example of how to use the DashPannellum component:

import dash
from dash import html
import dash_pannellum

app = dash.Dash(__name__)

app.layout = html.Div([
    dash_pannellum.DashPannellum(
        id='panorama',
        tour={
            "default": {
                "firstScene": "scene1",
                "sceneFadeDuration": 1000
            },
            "scenes": {
                "scene1": {
                    "title": "Example Panorama",
                    "hfov": 110,
                    "pitch": -3,
                    "yaw": 117,
                    "type": "equirectangular",
                    "panorama": "https://pannellum.org/images/from-tree.jpg"
                }
            }
        },
        width='100%',
        height='400px',
    )
])

if __name__ == '__main__':
    app.run_server(debug=True)

Component Properties

  • id (string): The ID used to identify this component in Dash callbacks.
  • width (string): The width of the panorama viewer.
  • height (string): The height of the panorama viewer.
  • tour (dict): Configuration object for the tour mode.
  • multiRes (dict): Configuration object for multi-resolution panoramas.
  • video (dict): Configuration object for video panoramas.
  • customControls (boolean): If true, enables custom controls for the panorama viewer.
  • showCenterDot (boolean): If true, displays a center dot in the panorama viewer.
  • loaded (boolean; read-only): Indicates whether the panorama has been loaded.
  • pitch (number; read-only): The current pitch of the panorama view.
  • yaw (number; read-only): The current yaw of the panorama view.
  • currentScene (string; read-only): The ID of the current scene in tour mode.

Examples


Tour Mode

tour_config = {
    "default": {
        "firstScene": "scene1",
        "sceneFadeDuration": 1000
    },
    "scenes": {
        "scene1": {
            "title": "First Scene",
            "hfov": 110,
            "pitch": -3,
            "yaw": 117,
            "type": "equirectangular",
            "panorama": "https://pannellum.org/images/from-tree.jpg",
            "hotSpots": [
                {
                    "pitch": -2.1,
                    "yaw": 132.9,
                    "type": "scene",
                    "text": "Go to Second Scene",
                    "sceneId": "scene2"
                }
            ]
        },
        "scene2": {
            "title": "Second Scene",
            "hfov": 110,
            "yaw": 5,
            "type": "equirectangular",
            "panorama": "https://pannellum.org/images/bma-0.jpg",
            "hotSpots": [
                {
                    "pitch": -0.6,
                    "yaw": 37.1,
                    "type": "scene",
                    "text": "Go to First Scene",
                    "sceneId": "scene1",
                    "targetYaw": -23,
                    "targetPitch": 2
                }
            ]
        }
    }
}

dash_pannellum.DashPannellum(
    id='tour-component',
    tour=tour_config,
    width='100%',
    height='400px',
)

Partial Panorama

Partial panoramas can be displayed by specifying the extents of the equirectangular panorama using the haov, vaov, and vOffset parameters. These parameters define the horizontal angle of view, vertical angle of view, and vertical offset, respectively.

partial_panorama_config = {
    "type": "equirectangular",
    "panorama": "https://pannellum.org/images/charles-street.jpg",
    "haov": 149.87,
    "vaov": 54.15,
    "vOffset": 1.17
}

dash_pannellum.DashPannellum(
    id='partial-panorama-component',
    tour={"default": {"firstScene": "scene1"}, "scenes": {"scene1": partial_panorama_config}},
    width='100%',
    height='400px',
)

In this example:

  • haov: 149.87 degrees - Specifies the horizontal angle of view.
  • vaov: 54.15 degrees - Specifies the vertical angle of view.
  • vOffset: 1.17 degrees - Specifies the vertical offset of the panorama.

These parameters allow you to display panoramas that don't cover a full 360° horizontally or 180° vertically. The vOffset parameter is particularly useful when the panorama is not centered vertically.

Multi-resolution Panorama

multiRes_config = {
    "basePath": "https://pannellum.org/images/multires/library",
    "path": "/%l/%s%y_%x",
    "fallbackPath": "/fallback/%s",
    "extension": "jpg",
    "tileResolution": 512,
    "maxLevel": 6,
    "cubeResolution": 8432
}

dash_pannellum.DashPannellum(
    id='multires-component',
    multiRes=multiRes_config,
    width='100%',
    height='400px',
)

Video Panorama

video_config = {
    "sources": [
        {"src": "https://bitmovin-a.akamaihd.net/content/playhouse-vr/progressive.mp4", "type": "video/mp4"},
    ],
    "poster": "https://bitmovin-a.akamaihd.net/content/playhouse-vr/poster.jpg"
}

dash_pannellum.DashPannellum(
    id='video-component',
    video=video_config,
    width='100%',
    height='400px',
)

Callbacks

You can use Dash callbacks to interact with the component. Here's an example that updates an output based on the panorama's current state: python

from dash.dependencies import Input, Output

@app.callback(
    Output('output-div', 'children'),
    Input('panorama', 'loaded'),
    Input('panorama', 'pitch'),
    Input('panorama', 'yaw'),
    Input('panorama', 'currentScene')
)
def update_output(loaded, pitch, yaw, current_scene):
    if loaded and pitch is not None and yaw is not None:
        return f'Current Scene: {current_scene}, Pitch: {pitch:.2f}, Yaw: {yaw:.2f}'
    return 'Loading panorama...'

Contributing

Contributions to dash-pannellum are welcome! Please refer to the project's issues on GitHub for any feature requests or bug reports.

License

This project is licensed under the MIT License.
