db-analytics-tools 0.2

Databases Tools for Data Analytics

DB Analytics Tools

Databases Analytics Tools is a Python open source micro framework for data analytics. DB Analytics Tools is built on top of Psycopg2, Pyodbc, Pandas, Matplotlib and Scikit-learn. It helps data analysts to interact with data warehouses as traditional databases clients.

Why adopt DB Analytics Tools ?

• Easy to learn : It is high level API and doesn't require any special effort to learn.
• Real problems solver : It is designed to solve real life problems of the Data Analyst
• All in One : Support queries, Data Integration, Analysis, Visualization and Machine Learning

Core Components

#	Component	Description	How to import
0	db	Database Interactions (Client)	import db_analytics_tools as db
1	dbi	Data Integration & Data Engineering	import db_analytics_tools.integration as dbi
2	dba	Data Analysis	import db_analytics_tools.analytics as dba
3	dbviz	Data Visualization	import db_analytics_tools.plotting as dbviz
4	dbml	Machine Learning & MLOps	import db_analytics_tools.learning as dbml

Install DB Analytics Tools

Dependencies

DB Analytics Tools requires

• Python
• Psycopg2
• Pyodbc
• Pandas
• SQLAlchemy
• Streamlit

DB Analytics Tools can easily installed using pip

pip install db-analytics-tools

Get Started

Setup client

As traditional databases clients, we need to provide database server ip address and port and credentials. DB Analytics Tools supports Postgres and SQL Server.

# Import DB Analytics Tools
import db_analytics_tools as db

# Database Infos & Credentials
ENGINE = "postgres"
HOST = "localhost"
PORT = "5432"
DATABASE = "postgres"
USER = "postgres"
PASSWORD = "Password123"

# SQL Server Example
ENGINE = "mssql"
HOST = "localhost"
PORT = "1433"
DATABASE = "master"
USER = "sa"
PASSWORD = "Password123"

# Setup client
client = db.Client(host=HOST, port=PORT, database=DATABASE, username=USER, password=PASSWORD, engine=ENGINE)

Data Definition Language

query = """
----- CREATE TABLE -----
drop table if exists public.transactions;
create table public.transactions (
    transaction_id integer primary key,
    client_id integer,
    product_name varchar(255),
    product_category varchar(255),
    quantity integer,
    unitary_price numeric,
    amount numeric
);
"""

client.execute(query=query)

Data Manipulation Language

query = """
----- POPULATE TABLE -----
insert into public.transactions (transaction_id, client_id, product_name, product_category, quantity, unitary_price, amount)
values
	(1,101,'Product A','Category 1',5,100,500),
	(2,102,'Product B','Category 2',3,50,150),
	(3,103,'Product C','Category 1',2,200,400),
	(4,102,'Product A','Category 1',7,100,700),
	(5,105,'Product B','Category 2',4,50,200),
	(6,101,'Product C','Category 1',1,200,200),
	(7,104,'Product A','Category 1',6,100,600),
	(8,103,'Product B','Category 2',2,50,100),
	(9,103,'Product C','Category 1',8,200,1600),
	(10,105,'Product A','Category 1',3,100,300);
"""

client.execute(query=query)

Data Query Language

query = """
----- GET DATA -----
select *
from public.transactions
order by transaction_id;
"""

dataframe = client.read_sql(query=query)
print(dataframe.head())

   transaction_id  client_id product_name product_category  quantity  unitary_price  amount
0               1        101    Product A       Category 1         5          100.0   500.0
1               2        102    Product B       Category 2         3           50.0   150.0
2               3        103    Product C       Category 1         2          200.0   400.0
3               4        102    Product A       Category 1         7          100.0   700.0
4               5        105    Product B       Category 2         4           50.0   200.0

Show current queries

You can simply show current queries for current user.

client.show_sessions()

You can cancel query by its session_id.

client.cancel_query(10284)

You can go further cancelling on lock

client.cancel_locked_queries()

This will canceled all current lockes queries.

Implement SQL based ETL

ETL API is in the integration module db_analytics_tools.integration. Let's import it ans create an ETL object.

# Import Integration module
import db_analytics_tools.integration as dbi

# Setup ETL
etl = dbi.ETL(client=client)

ETLs for DB Analytics Tools consists in functions with date parameters. Everything is done in one place i.e on the database. So first create a function on the database like this :

query = """
----- CREATE FUNCTION ON DB -----
create or replace function public.fn_test(rundt date) returns integer
language plpgsql
as
$$
begin
	--- DEBUG MESSAGE ---
	raise notice 'rundt : %', rundt;

	--- EXTRACT ---

	--- TRANSFORM ---

	--- LOAD ---

	return 0;
end;
$$;
"""

client.execute(query=query)

Run a function

Then ETL function can easily be run using the ETL class via the method ETL.run()

# ETL Function
FUNCTION = "public.fn_test"

## Dates to run
START = "2023-08-01"
STOP = "2023-08-05"

# Run ETL
etl.run(function=FUNCTION, start_date=START, stop_date=STOP, freq="d", reverse=False)

Function    : public.fn_test
Date Range  : From 2023-08-01 to 2023-08-05
Iterations  : 5
[Runing Date: 2023-08-01] [Function: public.fn_test] Execution time: 0:00:00.122600
[Runing Date: 2023-08-02] [Function: public.fn_test] Execution time: 0:00:00.049324
[Runing Date: 2023-08-03] [Function: public.fn_test] Execution time: 0:00:00.049409
[Runing Date: 2023-08-04] [Function: public.fn_test] Execution time: 0:00:00.050019
[Runing Date: 2023-08-05] [Function: public.fn_test] Execution time: 0:00:00.108267

Run several functions

Most of time, several ETL must be run and DB Analytics Tools supports running functions as pipelines.

## ETL Functions
FUNCTIONS = [
    "public.fn_test",
    "public.fn_test_long",
    "public.fn_test_very_long"
]

## Dates to run
START = "2023-08-01"
STOP = "2023-08-05"

# Run ETLs
etl.run_multiple(functions=FUNCTIONS, start_date=START, stop_date=STOP, freq="d", reverse=False)

Functions   : ['public.fn_test', 'public.fn_test_long', 'public.fn_test_very_long']
Date Range  : From 2023-08-01 to 2023-08-05
Iterations  : 5
*********************************************************************************************
[Runing Date: 2023-08-01] [Function: public.fn_test..........] Execution time: 0:00:00.110408
[Runing Date: 2023-08-01] [Function: public.fn_test_long.....] Execution time: 0:00:00.112078
[Runing Date: 2023-08-01] [Function: public.fn_test_very_long] Execution time: 0:00:00.092423
*********************************************************************************************
[Runing Date: 2023-08-02] [Function: public.fn_test..........] Execution time: 0:00:00.111153
[Runing Date: 2023-08-02] [Function: public.fn_test_long.....] Execution time: 0:00:00.111395
[Runing Date: 2023-08-02] [Function: public.fn_test_very_long] Execution time: 0:00:00.110814
*********************************************************************************************
[Runing Date: 2023-08-03] [Function: public.fn_test..........] Execution time: 0:00:00.111044
[Runing Date: 2023-08-03] [Function: public.fn_test_long.....] Execution time: 0:00:00.123229
[Runing Date: 2023-08-03] [Function: public.fn_test_very_long] Execution time: 0:00:00.078432
*********************************************************************************************
[Runing Date: 2023-08-04] [Function: public.fn_test..........] Execution time: 0:00:00.127839
[Runing Date: 2023-08-04] [Function: public.fn_test_long.....] Execution time: 0:00:00.111339
[Runing Date: 2023-08-04] [Function: public.fn_test_very_long] Execution time: 0:00:00.140669
*********************************************************************************************
[Runing Date: 2023-08-05] [Function: public.fn_test..........] Execution time: 0:00:00.138380
[Runing Date: 2023-08-05] [Function: public.fn_test_long.....] Execution time: 0:00:00.111157
[Runing Date: 2023-08-05] [Function: public.fn_test_very_long] Execution time: 0:00:00.077731
*********************************************************************************************

Get started with the UI

DB Analytics Tools UI is a web-based GUI (db_analytics_tools.webapp.DBAnalyticsUI). No need to code, all you need is a JSON config file. Run the command below :

db_tools start --config config.json --address 127.0.0.1 --port 8050

Get started with the CLI

DB Analytics Tools CLI is a command line interface (db_analytics_tools.cli) that allows you to run ETL pipelines and interact with the database without writing any code. Run the command below :

db_cli --engine greenplum --host localhost --port 5432 --database cdrfw --user joekakone --password mypassword --start 3 --stop 1 --freq m --functions prod.fn_preprocess_sales prod.fn_agregate_sales

Possible to redirect output to a log file

db_cli --engine greenplum --host localhost --port 5432 --database cdrfw --user joekakone --password mypassword --start 3 --stop 1 --freq m --functions prod.fn_preprocess_sales prod.fn_agregate_sales >> /app/01.log

Interact with Airflow

We also provide a class for interacting with the Apache Airflow REST API.

# Import Airflow class
from db_analytics_tools.airflow import AirflowRESTAPI

# Airflow Config
AIRFLOW_BASE_URL = "http://localhost:8080"
AIRFLOW_API_ENDPOINT = "api/v2/"
AIRFLOW_USERNAME = "airflow"
AIRFLOW_PASSWORD = "airflow"

# Create an instance
airflow = AirflowRESTAPI(AIRFLOW_BASE_URL, AIRFLOW_API_ENDPOINT, AIRFLOW_USERNAME, AIRFLOW_PASSWORD)

# Get list of DAGs
airflow.get_dags_list(include_all=False).head(10)

# Get a DAG details
airflow.get_dag_details(dag_id="my_airflow_pipeline", include_tasks=False)

# Get list of tasks of a DAG
airflow.get_dag_tasks(dag_id="my_airflow_pipeline").head(10)

# Trigger a DAG
airflow.trigger_dag(dag_id="my_airflow_pipeline", start_date='2025-03-11', end_date='2025-03-12')

# Backfill a DAG
airflow.backfill_dag(dag_id="my_airflow_pipeline", start_date='2025-03-01', end_date='2025-03-12', reprocess_behavior="failed")

Forecasting

# Import Forecast class
from db_analytics_tools.learning import ForecastKPI

# Create an instance
forecast = ForecastKPI(historical_data=df, date_column="dt")

# Summary
print(forecast.describe())

# Decomposition
decomposition_result = forecast.decompose_time_series(kpi_name='active_1d', period=7, model='additive', plot=True)
print(decomposition_result.trend.head())
print(decomposition_result.seasonal.head())

Documentation

Documentation available on https://joekakone.github.io/db-analytics-tools.

Help and Support

If you need help on DB Analytics Tools, please send me an message on Whatsapp or send me a mail.

Contributing

Please see the contributing docs.

Maintainer

DB Analytics Tools is maintained by Joseph Konka. Joseph is a Data Science Professional with a focus on Python based tools. He developed the base code while working at Togocom to automate his daily tasks. He packages the code into a Python package called SQL ETL Runner which becomes Databases Analytics Tools. For more about Joseph Konka, please visit www.josephkonkathedataguy.com.
