dolphie 6.1.0

Your single pane of glass for real-time analytics into MySQL/MariaDB & ProxySQL

Dolphie

Your single pane of glass for real-time analytics into MySQL/MariaDB & ProxySQL

Installation

Requires Python 3.8.1+

Using PyPi

$ pip install dolphie

Using Poetry

$ curl -sSL https://install.python-poetry.org | python3 -

$ poetry install

Using Homebrew

If you are a Homebrew user, you can install dolphie via

$ brew install dolphie

Using Docker

$ docker pull ghcr.io/charles-001/dolphie:latest
$ docker run -dit --name dolphie ghcr.io/charles-001/dolphie:latest
$ docker exec -it dolphie dolphie -h host.docker.internal -u root --ask-pass

Usage

positional arguments:
  uri                   Use a URI string for credentials (mysql/proxysql) - format: mysql://user:password@host:port (port is optional with default 3306, or 6032 for ProxySQL)

options:
  --help                show this help message and exit
  --host-setup          Start Dolphie by showing the Host Setup modal instead of automatically connecting
  -C , --cred-profile   Credential profile to use. See below for more information
  -u , --user           Username
  -p , --password       Password
  -h , --host           Hostname/IP address
  -P , --port           Port (socket has precedence)
  -S , --socket         Socket file
  -c , --config-file    Dolphie's config file to use. Options are read from these files in the given order: ['/etc/dolphie.cnf', '/etc/dolphie/dolphie.cnf', '~/.dolphie.cnf']
  -m , --mycnf-file     MySQL config file path to use. This should use [client] section [default: ~/.my.cnf]
  -l , --login-path     Specify login path to use with mysql_config_editor's file ~/.mylogin.cnf for encrypted login credentials [default: client]
  -r , --refresh-interval
                        How much time to wait in seconds between each refresh [default: 1]
  --host-cache-file     Resolve IPs to hostnames when your DNS is unable to. Each IP/hostname pair should be on its own line using format ip=hostname [default: ~/dolphie_host_cache]
  --host-setup-file     Specify location of file that stores the available hosts to use in host setup modal [default: ~/dolphie_hosts]
  --heartbeat-table     (MySQL only) If your hosts use pt-heartbeat, specify table in format db.table to use the timestamp it has for replication lag instead of Seconds_Behind_Master from SHOW REPLICA STATUS
  --ssl-mode            Desired security state of the connection to the host. Supports: REQUIRED/VERIFY_CA/VERIFY_IDENTITY [default: OFF]
  --ssl-ca              Path to the file that contains a CA (certificate authority)
  --ssl-cert            Path to the file that contains a certificate
  --ssl-key             Path to the file that contains a private key for the certificate
  --panels              What panels to display on startup separated by a comma. Supports: dashboard,processlist,graphs,replication,metadata_locks,ddl,proxysql_hostgroup_summary,proxysql_mysql_query_rules,proxysql_command_stats [default: dashboard,processlist]
  --graph-marker        What marker to use for graphs (available options: https://tinyurl.com/dolphie-markers) [default: braille]
  --pypi-repo           What PyPi repository to use when checking for a new version default: [https://pypi.org/pypi/dolphie/json]
  -H , --hostgroup      This is used for creating tabs and connecting to them for hosts you specify in Dolphie's config file under a hostgroup section. As an example, you'll have a section called [cluster1] then below it you will list each host on a new line in the format key=host (keys have no meaning). Hosts support optional port (default is whatever port parameter is) in the format host:port. You can also name the tabs by suffixing ~tab_name to the host (i.e. 1=host~tab_name)
  -R, --record          Enables recording of Dolphie's data to a replay file. Note: This can use significant disk space. Monitor accordingly!
  -D, --daemon          Starts Dolphie in daemon mode. This will not show the TUI and is designed be put into the background with whatever solution you decide to use. Automatically enables --record. This mode is solely used for recording data to a replay file
  --daemon-log-file     Full path of the log file for daemon mode
  --replay-file         Specify the full path of the replay file to load and enable replay mode
  --replay-dir          Directory to store replay data files
  --replay-retention-hours
                        Number of hours to keep replay data. Data will be purged every hour [default: 48]
  --exclude-notify-vars
                        Dolphie will let you know when a global variable has been changed. If you have variables that change frequently and you don't want to see them, you can specify which ones with this option separated by a comma (i.e. --exclude-notify-vars=variable1,variable2)
  --show-trxs-only      (MySQL only) Start with only showing threads that have an active transaction
  --additional-columns  Start with additional columns in Processlist panel
  --debug-options       Display options that are set and what they're set by (command-line, dolphie config, etc) then exit. WARNING: This will show passwords and other sensitive information in plain text
  -V, --version         Display version and exit

Order of precedence for methods that pass options to Dolphie:
	1. Command-line
	2. Credential profile (set by --cred-profile)
	3. Environment variables
	4. Dolphie's config (set by --config-file)
	5. ~/.mylogin.cnf (mysql_config_editor)
	6. ~/.my.cnf (set by --mycnf-file)

Credential profiles can be defined in Dolphie's config file as a way to store credentials for easy access.
A profile can be created by adding a section in the config file with the format: [credential_profile_<name>]
The following options are supported in credential profiles:
	user
	password
	socket
	ssl_mode REQUIRED/VERIFY_CA/VERIFY_IDENTITY
	ssl_ca
	ssl_cert
	ssl_key
	mycnf_file
	login_path

MySQL my.cnf file supports these options under [client] section:
	host
	user
	password
	port
	socket
	ssl_mode REQUIRED/VERIFY_CA/VERIFY_IDENTITY
	ssl_ca
	ssl_cert
	ssl_key

Login path file supports these options:
	host
	user
	password
	port
	socket

Environment variables support these options:
	DOLPHIE_USER
	DOLPHIE_PASSWORD
	DOLPHIE_HOST
	DOLPHIE_PORT
	DOLPHIE_SOCKET
	DOLPHIE_SSL_MODE REQUIRED/VERIFY_CA/VERIFY_IDENTITY
	DOLPHIE_SSL_CA
	DOLPHIE_SSL_CERT
	DOLPHIE_SSL_KEY

Dolphie's config supports these options under [dolphie] section:
	(bool) host_setup
	(str) credential_profile
	(str) user
	(str) password
	(str) host
	(int) port
	(str) socket
	(str) ssl_mode
	(str) ssl_ca
	(str) ssl_cert
	(str) ssl_key
	(str) mycnf_file
	(str) login_path
	(str) host_cache_file
	(str) host_setup_file
	(int) refresh_interval
	(str) heartbeat_table
	(str) startup_panels
	(str) graph_marker
	(str) pypi_repository
	(str) hostgroup
	(bool) show_trxs_only
	(bool) show_additional_query_columns
	(bool) record_for_replay
	(bool) daemon_mode
	(str) daemon_mode_log_file
	(str) replay_file
	(str) replay_dir
	(int) replay_retention_hours
	(str) exclude_notify_global_vars

Supported ProxySQL versions

• ProxySQL 2.6+ (could work on previous versions but not tested)

Note: Use admin user instead of stats user so you can use all features

Supported MariaDB versions

• MariaDB 5.5/10.0/11.0+
• RDS MariaDB

Supported MySQL versions

• MySQL/Percona Server 5.6/5.7/8.x/9.x
• RDS MySQL & Aurora/Azure

MySQL Grants required

Least privilege

1. PROCESS (only if you switch to using processlist via P command)
2. SELECT to performance_schema + pt-heartbeat table (if used)
3. REPLICATION CLIENT/REPLICATION SLAVE

Recommended

1. PROCESS (only if you switch to using processlist via P command)
2. Global SELECT access (good for explaining queries, listing all databases, etc)
3. REPLICATION CLIENT/REPLICATION SLAVE
4. SUPER (required if you want to kill queries)

Record & Replay

Have you ever wished you could view the process list and various other related statistics from a specific moment in time? Perhaps during a database stall that led to an incident, and your monitoring tools failed to identify the root cause? Well, you're in luck! Dolphie has a Replay system that lets you do just that.

Starting with version 6.0.0, you can instruct Dolphie to record its data (via --record) into a local SQLite database file that's compressed with ZSTD. When you're ready to replay this data, simply pass the --replay-file option, and you can interact with it as if you were watching it live! Within the Replay interface, you can navigate with the controls: back, forward, play/pause, or seek to a specific datetime. While some features are disabled during replay, the essential functionalities remain intact. For a complete list of available commands, press ? to access the help menu.

Note that this feature can incur a significant amount of disk space depending on how busy your server is and what you set --replay-retention-hours + --refresh-interval. Adjust these values to suit your needs and monitor the disk space usage accordingly. You can also not mix Dolphie versions with a replay file. If you try to, it will rename the current replay file and create a new one to prevent any potential version conflicts.

Daemon Mode

Also introduced in version 6.0.0 is the ability to run Dolphie in daemon mode (via --daemon option). It's designed to run in the background continuously recording data for future replay. It’s more resource-efficient than running Dolphie live, transforming it into a passive, always-on monitoring service. It eliminates Textual's TUI and creates a log file for messages while also displaying them in the console.

You have flexibility in how you run Dolphie in the background; personally, I prefer using systemctl, but alternatives like nohup or tmux can be viable options.

Here's some examples of log messages you might see:

[INFO] Starting Dolphie v6.0.0 in daemon mode with a refresh interval of 1s
[INFO] Log file: /var/log/dolphie/dolphie.log
[INFO] Connected to MySQL with Process ID 324
[INFO] Replay SQLite file: /var/lib/dolphie/replays/localhost/daemon.db (24 hours retention)
[INFO] Connected to SQLite
[INFO] Replay database metadata - Host: localhost:3306, Version: 8.0.34 (Percona Server), Dolphie: 6.0.0
[INFO] ZSTD compression dictionary trained with 10 samples (size: 52.56KB)
[WARNING] Read-only mode changed: R/W -> RO
[INFO] Global variable innodb_io_capacity changed: 1000 -> 2000

Credential Profiles

Credential profiles can be defined in Dolphie's config file as a way to store credentials for easy access. A profile can be created by adding a section in the config file with the format: [credential_profile_<name>] The following options are supported in credential profiles:

• user
• password
• socket
• ssl_mode REQUIRED/VERIFY_CA/VERIFY_IDENTITY
• ssl_ca
• ssl_cert
• ssl_key
• mycnf_file
• login_path

Example:

[credential_profile_dev]
user = dev_user
password = dev_password

[credential_profile_prod]
mycnf_file = /secure/path/to/prod.cnf

To use a credential profile, you can specify it with the -C or --cred-profile option when starting Dolphie. Hostgroups can also use credential profiles (see below)

Hostgroups

Hostgroups are a way to easily connect to multiple hosts at once. To set this up, you will create a section in Dolphie's config file with the name you want the hostgroup to be and list each host on a new line in the format key=<json> (keys have no meaning). Hosts support optional port (default is whatever port parameter is) in the format host:port. Once ready, you will use the parameter hostgroup or Host Setup modal to see it in action!

Note: Colors can be used in the tab name by using the format [color]text[/color] (i.e. [red]production[/red]). You can also use emojis supported by Rich (can see them by running python -m rich.emoji) by using the format :emoji: (i.e. :ghost:). Rich supports the normal emoji shortcodes.

Example:

[cluster1]
1={"host": "host1", "tab_title": "[yellow]host1[/yellow] :ghost:", "credential_profile": "dev"}
2={"host": "host2", "tab_title": "[blue]host2[/blue] :ghost:", "credential_profile": "dev"}
3={"host": "host3:3307", "tab_title": "[red]production[/red]", "credential_profile": "prod"}
4={"host": "host4"}

Feedback

I welcome all questions, bug reports, and requests. If you enjoy Dolphie, please let me know! I'd love to hear from you :dolphin:
