google-cloud-alloydb-connector 1.5.0

A Python client library for connecting securely to your Google Cloud AlloyDB instances.

AlloyDB Python Connector

The AlloyDB Python Connector is an AlloyDB Connector library designed for use with the Python language.

Using an AlloyDB Connector provides the following benefits:

• IAM Authorization: uses IAM permissions to control who/what can connect to your AlloyDB instances

• Improved Security: uses robust, updated TLS 1.3 encryption and identity verification between the client connector and the server-side proxy, independent of the database protocol.

• Convenience: removes the requirement to use and distribute SSL certificates, as well as manage firewalls or source/destination IP addresses.

• (optionally) IAM DB Authentication: provides support for AlloyDB’s automatic IAM DB AuthN feature.

The AlloyDB Python Connector is a package to be used alongside a database driver. Currently supported drivers are:

• pg8000
• asyncpg

Installation

You can install this library with pip install:

pg8000

pip install "google-cloud-alloydb-connector[pg8000]"

See Synchronous Driver Usage for details.

asyncpg

pip install "google-cloud-alloydb-connector[asyncpg]"

See Async Driver Usage for details.

APIs and Services

This package requires the following to connect successfully:

• IAM principal (user, service account, etc.) with the AlloyDB Client role or equivalent. Credentials for the IAM principal are used to authorize connections to an AlloyDB instance.

• The AlloyDB API to be enabled within your Google Cloud Project. By default, the API will be called in the project associated with the IAM principal.

Credentials

This library uses the Application Default Credentials (ADC) strategy for resolving credentials. Please see these instructions for how to set your ADC (Google Cloud Application vs Local Development, IAM user vs service account credentials), or consult the google.auth package.

Usage

This package provides several functions for authorizing and encrypting connections. These functions are used with your database driver to connect to your AlloyDB instance.

AlloyDB supports network connectivity through public IP addresses and private, internal IP addresses, as well as Private Service Connect (PSC). By default this package will attempt to connect over a private IP connection. When doing so, this package must be run in an environment that is connected to the VPC Network that hosts your AlloyDB private IP address.

Please see Configuring AlloyDB Connectivity for more details.

Synchronous Driver Usage

To connect to AlloyDB using the connector, inititalize a Connector object and call it's connect method with the proper input parameters.

The Connector itself creates database connection objects by calling its connect method but does not manage database connection pooling. For this reason, it is recommended to use the connector alongside a library that can create connection pools, such as SQLAlchemy. This will allow for connections to remain open and be reused, reducing connection overhead and the number of connections needed.

In the Connector's connect method below, input your AlloyDB instance URI as the first positional argument and the name of the database driver for the second positional argument. Insert the rest of your connection keyword arguments like user, password and db etc.

To use this connector with SQLAlchemy, use the creator argument for sqlalchemy.create_engine:

from google.cloud.alloydb.connector import Connector
import sqlalchemy

# initialize Connector object
connector = Connector()

# function to return the database connection
def getconn():
    conn = connector.connect(
        "projects/<YOUR_PROJECT>/locations/<YOUR_REGION>/clusters/<YOUR_CLUSTER>/instances/<YOUR_INSTANCE>",
        "pg8000",
        user="my-user",
        password="my-password",
        db="my-db-name"
        # NOTE: this assumes private IP by default.
        # Add the following keyword arg to use public IP:
        # ip_type="PUBLIC"
    )
    return conn

# create connection pool
pool = sqlalchemy.create_engine(
    "postgresql+pg8000://",
    creator=getconn,
)

The returned connection pool engine can then be used to query and modify the database.

# insert statement
insert_stmt = sqlalchemy.text(
    "INSERT INTO my_table (id, title) VALUES (:id, :title)",
)

with pool.connect() as db_conn:
    # insert into database
    db_conn.execute(insert_stmt, parameters={"id": "book1", "title": "Book One"})

    # query database
    result = db_conn.execute(sqlalchemy.text("SELECT * from my_table")).fetchall()

    # commit transaction (SQLAlchemy v2.X.X is commit as you go)
    db_conn.commit()

    # Do something with the results
    for row in result:
        print(row)

To close the Connector object's background resources, call it's close() method as follows:

connector.close()

Synchronous Context Manager

The Connector object can also be used as a context manager in order to automatically close and cleanup resources, removing the need for explicit calls to connector.close().

Connector as a context manager:

from google.cloud.alloydb.connector import Connector
import sqlalchemy

# helper function to return SQLAlchemy connection pool
def init_connection_pool(connector: Connector) -> sqlalchemy.engine.Engine:
    # function used to generate database connection
    def getconn():
        conn = connector.connect(
            "projects/<YOUR_PROJECT>/locations/<YOUR_REGION>/clusters/<YOUR_CLUSTER>/instances/<YOUR_INSTANCE>",
            "pg8000",
            user="my-user",
            password="my-password",
            db="my-db-name"
        )
        return conn

    # create connection pool
    pool = sqlalchemy.create_engine(
        "postgresql+pg8000://",
        creator=getconn,
    )
    return pool

# initialize Connector as context manager
with Connector() as connector:
    # initialize connection pool
    pool = init_connection_pool(connector)
    # insert statement
    insert_stmt = sqlalchemy.text(
        "INSERT INTO my_table (id, title) VALUES (:id, :title)",
    )

    # interact with AlloyDB database using connection pool
    with pool.connect() as db_conn:
        # insert into database
        db_conn.execute(insert_stmt, parameters={"id": "book1", "title": "Book One"})

        # commit transaction (SQLAlchemy v2.X.X is commit as you go)
        db_conn.commit()

        # query database
        result = db_conn.execute(sqlalchemy.text("SELECT * from my_table")).fetchall()

        # Do something with the results
        for row in result:
            print(row)

Async Driver Usage

The AlloyDB Connector is compatible with asyncio to improve the speed and efficiency of database connections through concurrency. The AsyncConnector currently supports the following asyncio database drivers:

• asyncpg

import asyncpg

import sqlalchemy
from sqlalchemy.ext.asyncio import AsyncEngine, create_async_engine

from google.cloud.alloydb.connector import AsyncConnector

async def init_connection_pool(connector: AsyncConnector) -> AsyncEngine:
    # initialize Connector object for connections to AlloyDB
    async def getconn() -> asyncpg.Connection:
        conn: asyncpg.Connection = await connector.connect(
            "projects/<YOUR_PROJECT>/locations/<YOUR_REGION>/clusters/<YOUR_CLUSTER>/instances/<YOUR_INSTANCE>",
            "asyncpg",
            user="my-user",
            password="my-password",
            db="my-db-name"
            # NOTE: this assumes private IP by default.
            # Add the following keyword arg to use public IP:
            # ip_type="PUBLIC"
            # ... additional database driver args
        )
        return conn

    # The AlloyDB Python Connector can be used along with SQLAlchemy using the
    # 'async_creator' argument to 'create_async_engine'
    pool = create_async_engine(
        "postgresql+asyncpg://",
        async_creator=getconn,
    )
    return pool

async def main():
    connector = AsyncConnector()

    # initialize connection pool
    pool = await init_connection_pool(connector)

    # example query
    async with pool.connect() as conn:
        await conn.execute(sqlalchemy.text("SELECT NOW()"))

    # dispose of connection pool
    await pool.dispose()

    # close Connector
    await connector.close()

For more details on additional arguments with an asyncpg.Connection, please visit the official documentation.

Async Context Manager

The AsyncConnector also may be used as an async context manager, removing the need for explicit calls to connector.close() to cleanup resources.

import asyncio
import asyncpg

import sqlalchemy
from sqlalchemy.ext.asyncio import AsyncEngine, create_async_engine

from google.cloud.alloydb.connector import AsyncConnector

async def init_connection_pool(connector: AsyncConnector) -> AsyncEngine:
    # initialize Connector object for connections to AlloyDB
    async def getconn() -> asyncpg.Connection:
            conn: asyncpg.Connection = await connector.connect(
                "projects/<YOUR_PROJECT>/locations/<YOUR_REGION>/clusters/<YOUR_CLUSTER>/instances/<YOUR_INSTANCE>",
                "asyncpg",
                user="my-user",
                password="my-password",
                db="my-db-name"
                # ... additional database driver args
            )
            return conn

    # The AlloyDB Python Connector can be used along with SQLAlchemy using the
    # 'async_creator' argument to 'create_async_engine'
    pool = create_async_engine(
        "postgresql+asyncpg://",
        async_creator=getconn,
    )
    return pool

async def main():
    # initialize Connector object for connections to AlloyDB
    async with AsyncConnector() as connector:
        # initialize connection pool
        pool = await init_connection_pool(connector)

        # example query
        async with pool.connect() as conn:
            await conn.execute(sqlalchemy.text("SELECT NOW()"))

        # dispose of connection pool
        await pool.dispose()

Automatic IAM Database Authentication

The Python Connector supports Automatic IAM database authentication.

Make sure to configure your AlloyDB Instance to allow IAM authentication and add an IAM database user.

A Connector or AsyncConnector can be configured to connect to an AlloyDB instance using automatic IAM database authentication with the enable_iam_auth argument set to True.

When configuring the connector.connect call for IAM authentication, the password field can be omitted and the user field should be formatted as follows:

• For an IAM user account, this is the user's email address.
• For a service account, it is the service account's email without the .gserviceaccount.com domain suffix.

For example, to connect with IAM authentication using the [e-mail] service account:

connector.connect(
    "projects/<YOUR_PROJECT>/locations/<YOUR_REGION>/clusters/<YOUR_CLUSTER>/instances/<YOUR_INSTANCE>",
    "pg8000",  # asyncpg for AsyncConnector
    user="[e-mail]",
    db="my-db-name",
    enable_iam_auth=True,
)

Configuring a Lazy Refresh (Cloud Run, Cloud Functions etc.)

The Connector's refresh_strategy argument can be set to "lazy" to configure the Python Connector to retrieve connection info lazily and as-needed. Otherwise, a background refresh cycle runs to retrive the connection info periodically. This setting is useful in environments where the CPU may be throttled outside of a request context, e.g., Cloud Run, Cloud Functions, etc.

To set the refresh strategy, set the refresh_strategy keyword argument when initializing a Connector:

connector = Connector(refresh_strategy="lazy")

Specifying IP Address Type

The AlloyDB Python Connector by default will attempt to establish connections to your instance's private IP. To change this, such as connecting to AlloyDB over a public IP address or Private Service Connect (PSC), set the ip_type keyword argument when initializing a Connector() or when calling connector.connect().

Possible values for ip_type are "PRIVATE" (default value), "PUBLIC", and "PSC".

Example:

from google.cloud.alloydb.connector import Connector

import sqlalchemy

# initialize Connector object
connector = Connector()

# function to return the database connection
def getconn():
  return connector.connect(
    "projects/<YOUR_PROJECT>/locations/<YOUR_REGION>/clusters/<YOUR_CLUSTER>/instances/<YOUR_INSTANCE>",
    "pg8000",
    user="my-user",
    password="my-password",
    db="my-db-name",
    ip_type="PUBLIC",  # use public IP
  )

# create connection pool
pool = sqlalchemy.create_engine(
    "postgresql+pg8000://",
    creator=getconn,
)

# use connection pool...
connector.close()

Debug Logging

The AlloyDB Python Connector uses the standard Python logging module for debug logging support.

Add the below code to your application to enable debug logging with the AlloyDB Python Connector:

import logging

logging.basicConfig(format="%(asctime)s [%(levelname)s]: %(message)s")
logger = logging.getLogger(name="google.cloud.alloydb.connector")
logger.setLevel(logging.DEBUG)

For more details on configuring logging, please refer to the Python logging docs.

Support policy

Major version lifecycle

This project uses semantic versioning, and uses the following lifecycle regarding support for a major version:

Active - Active versions get all new features and security fixes (that wouldn’t otherwise introduce a breaking change). New major versions are guaranteed to be "active" for a minimum of 1 year. Deprecated - Deprecated versions continue to receive security and critical bug fixes, but do not receive new features. Deprecated versions will be publicly supported for 1 year. Unsupported - Any major version that has been deprecated for >=1 year is considered publicly unsupported.

Supported Python Versions

We follow the Python Version Support Policy used by Google Cloud Libraries for Python. Changes in supported Python versions will be considered a minor change, and will be listed in the release notes.

Release cadence

This project aims for a minimum monthly release cadence. If no new features or fixes have been added, a new PATCH version with the latest dependencies is released.

Contributing

We welcome outside contributions. Please see our Contributing Guide for details on how best to contribute.
