heiDPI 1.3.0

nDPId consumer implementation

---

nDPId Docker Image for deep packet inspection. As described in nDPId, we split the image into producer and consumer image for a more generic purpose. For the producer, the image starts the UNIX and UDP socket and nDPId respectively. Via environment variables, users can adapt the nDPId daemon and nDPIsrvd. As by now, we support all current nDPId parameters.

Live Notebook
Latest Release
Supported Versions
Project License
Continuous Integration

Getting Started

Install using PyPi:

pip install heiDPI

Use the CLI for quick usage:

> heiDPI -h
usage: heiDPI [-h] [--host HOST | --unix UNIX] [--port PORT] [--write WRITE] [--config CONFIG] [--show-daemon-events SHOW_DAEMON_EVENTS] [--show-packet-events SHOW_PACKET_EVENTS] [--show-error-events SHOW_ERROR_EVENTS] [--show-flow-events SHOW_FLOW_EVENTS]

heiDPI Python Interface

options:
  -h, --help            show this help message and exit
  --host HOST           nDPIsrvd host IP (default: None)
  --unix UNIX           nDPIsrvd unix socket path (default: None)
  --port PORT           nDPIsrvd TCP port (default: 7000)
  --write WRITE         heiDPI write path for logs (default: /var/log)
  --config CONFIG       heiDPI write path for logs (default: /home/smachmeier/projects/emcl/heiDPI/config.yml)
  --show-daemon-events SHOW_DAEMON_EVENTS
                        heiDPI shows daemon events (default: 0)
  --show-packet-events SHOW_PACKET_EVENTS
                        heiDPI shows packet events (default: 0)
  --show-error-events SHOW_ERROR_EVENTS
                        heiDPI shows error events (default: 0)
  --show-flow-events SHOW_FLOW_EVENTS
                        heiDPI shows flow events (default: 0)

Prerequisities

In order to run this container you'll need docker installed.

• Windows
• OS X
• Linux

Usage

Pull images:

docker pull stefan96/heidpi-producer:main
docker pull stefan96/heidpi-consumer:main

Run producer and consumer separately from each other using UDP socket:

docker run -p 127.0.0.1:7000:7000 --net host stefan96/heidpi-producer:main
docker run -e HOST=127.0.0.1 --net host stefan96/heidpi-consumer:main

or use the docker-compose.yml:

docker-compose up

Additionally, you use a UNIX socket:

docker run -v ${PWD}/heidpi-data:/tmp/ --net host stefan96/heidpi-producer:main
docker run -v ${PWD}/heidpi-data:/tmp/ -v ${PWD}/heidpi-logs:/var/log -e UNIX=/tmp/nDPIsrvd-daemon-distributor.sock --net host stefan96/heidpi-consumer:main

Environment Variables

Consumer

Variable	Type	Default
UNIX	string
HOST	string
PORT	int	7000
JSON_PATH	string	/var/log/nDPIdsrvd.json
SHOW_ERROR_EVENTS	int	0
SHOW_DAEMON_EVENTS	int	0
SHOW_PACKET_EVENTS	int	0
SHOW_FLOW_EVENTS	int	1
MAX_BUFFERED_LINES	int	1024

Config file

You can change the default configuration by mounting a config file /usr/src/app/config.yml:

flow_event:
  ignore_fields: []
  flow_event_name:
    - update
    - end
    - idle
    - detected
  filename: flow_event
  threads: 25

License

This project is licensed under the GPL-3.0 license - see the LICENSE.md file for details.
