IcedPyGui 0.3.1

Python wrapper for Rust Iced

IcedPyGui (IPG)

Python wrapper for Rust Iced Gui

Iced + Python == IcedPyGui (IPG)

https://github.com/icedpygui/IcedPyGui/assets/163431522/4a30a7d3-d17e-4d90-bf34-320e9a5d8c5d

Python Examples

• Many Python examples are here.

Features

• Supported Iced widgets
  • Button
  • Checkbox
  • Canvas - Can add canvas widgets but dynamic drawing to follow
  • Column - a container holding widgets or other container in with horizontal positioning
  • ComboBox - Needs modification to work in IPG, but PicKList good substitute
  • Container - container, holds a single container or widget, used for alignment purposes
  • Events - keyboard, mouse, timer, and window
  • Fonts - Future release
  • Image - svg and png types
  • Modal - discontinued for now, use stack or open a small window
  • MouseArea - holds a widget and detect mouse movement and mouse button presses
  • PaneGrid - maybe a future release, will need to be modified for IPG
  • PickList - essentially a combobox
  • ProgressBar - a bar used to show progression of some action
  • QRCodes - future release
  • Radio buttons - multiple radios can be grouped, multiple groups allowed
  • Row - a container holding widgets or other containers with vertical positioning.
  • Rule - A widget line divider for readability
  • Scrollable - container which allows scrolling items
  • Slider - A widget for creating values by sliding a bar
  • Space - a widget for helping align content
  • Stack - a container that allows one to stack other containers
  • Styling - All widget now have styling
  • SVG - image type
  • TextEditor - Future release
  • TextInput - Allows one to input any text, numerical ones coming soon
  • Text - a text widget
  • Toggler - a widget for setting conditions like true/false on/off, etc
  • Tooltip - Only widget now, container ability future release
  • Windows multiple - many windows enabled
• Iced_aw widgets - are moved into IPG due to version conflicts
  • Card - a container with a header and footer
  • ColorPicker - future release
  • Menu - Dropdown menu items
  • Tabs - future release
• IPG widgets
  • DatePicker - compact and resizable
  • SelectableText - all mouse buttons supported
  • Table - Easily loaded with a list of py dictionaries, supports adding buttons, checkboxes, and togglers, continually updating code

Future Enhancements to the program

• Since upgrading to iced 0.13.1, I can now dispense with using a mutex to store some data. These work fine but a mutex cannot use anything with a lifetime since it is static. This will clear up some issues when trying to incorporated widgets such as the Editor, etc.
• Some optimization might be possible by not rebuilding the widgets unless they change. Not tested yet but hopefully it can happen.
• More widgets will be added see those mentioned above, along with any other I can find.
• Fonts is on the list for an upcoming release.

Python issues to be addressed

• Need to incorporate using the 'with' statement in python. Using with would allow one to not have to supply the window or parent id if those follow closely. For example:

      with window(...):
          with container(...):
              add_widget(...)


• @dataclass can be used but no IPG code in it until a later release

• @staticmethod future release

• Better error messages during callbacks. Currently an error in python code during the callback trigger a rust error which captures the python error but doesn't say where in the callback it happens.

Pyo3 Enhancements

• There are a number of future possible enhancements related to parallelism and async.

Installation (PiPy)

• Create and activate a virtual environment in your favorite IDE

pip install IcedPyGui

Installation (Rust)

• Install Rust
• Clone the repository and open in your favorite IDE
• Create and activate a virtual environment - The venv for this take a couple of minutes to create, be patient, sometimes a restart of vs code needed to recognize the venv
• Install maturin and compile the rust code
• Use maturin develop (~10 sec compile time on AMD Rizen 7700, stored in local venv)
• maturin build --release (~1.5 min compile time stored in target/wheels)
• Copy over one of the python examples (link above), use the below code, or the demo in the demo folder.

pip install maturin
maturin develop

• Open and run one of the python examples

Overview

• IcedPyGui is based on Rust Iced v0.12.1.
• Widgets for Iced_aw v0.8.0 are used too .
• Pyo3 is used as the python wrapper.
• Maturin is used to build and publish the module .
• The syntax and the design of the callbacks were inspired by the python wrapper of Dear ImGui, DearPyGui(DPG).
• The icon above was a merge of Python and Iced icons by Deep Dream Generator

Intro

Iced is a great GUI for Rust but it's still early in the development cycle, more good things will follow.

This project is the first I have published and so I expect I'll learn a lot and hopefully you can bare with me.

Rust's strict typing is mostly shielded from the python user but if you venture too far, you'll get burned with an error, so behave yourselves :)

Iced uses a messaging system which acts like a callback and no widget ids are used except for the containers and windows. This posed a bit of a problem in IPG but in most cases it was solved by mapping an id to the widget. In cases where this was not possible, the code was pull into IPG and an id was added in with fairly simple changes so it shouldn't be hard to keep those few items updated.

Iced doesn't use the concept of user data being passed around but when using DPG, sometimes the ability to send user data was very helpful. Therefore, this concept was added to IPG.

Each widget in IPG has a used data parameter which passes any additional information needed by the callback. The user data is special because it is only passed through to rust and back out as a PyObject or PyAny. Therefore any python data can be used since it is never extracted into a rust type.

Important rules

• Import IPG as indicated below in the demo code and any parameter class needed for the widgets.

• Instantiate the Rust structure then add your containers and widgets.

• The last line of code to execute must be ipg.start_session(). Any code after that will not be executed because Iced is now running. You can place it anywhere, just make sure its last executed. If you start your program and nothing happens, it might mean that you aren't executing start_session() or you forgot to add it in, been there, done that.

• Every widget needs to have a parent container previously defined and every container needs to have a window and optionally a parent container defined. If the container is placed into a window then no parent_id is required.

• Therefore at least one window needs to be added first and at least one container needs to be added to the window before any widgets are added. As long as you have defined a parent, you can add a widget.

Let's get started with out first program

Further below you'll find the full code to be tested in your IDE. Sometimes the these code snippets don't paste properly into the IDE if the parameter names are in them. But since these snippets are for learning, they need to be there for better understanding. So look further down for the full code to copy and paste.

First we import IPG from icedpygui. This is a Rust structure to be instantiated. We will be using a container and a column, these have alignment parameters so we need to import the parameters classes so that we don't have to type in strings which result in irritating typos. We'll also be updating a text widget to show some results, therefore the text parameter class is needed.

from icedpygui import IPG
from icedpygui import IpgAlignment, IpgTextParam

Let's instantiate the Rust structure and add some containers. Since this is a short program, we'll dispense with using a class. See the examples for cases where we used a class but nothing special pertains to IPG when they are used, except for a @dataclass and @staticmethod which will be supported in the near future.

ipg = IPG()

ipg.add_window(window_id="main", title="Demo Window",
               width=600, height=500,
               pos_centered=True)

# alignment defaults to centering
ipg.add_container("main", container_id="cont",
                  width_fill=True, height_fill=True)

# The column width will shrink to the size of the largest widget by default.
# If you were to use width_fill and height_fill here, the contents would be center
# vertically but placed on the left of the window.  Essentially, the container
# alignment would not be effective because they both would use all of the window space.
ipg.add_column(window_id="main", container_id="col",
                parent_id="cont",
                align_items=IpgAlignment.Center)

So, the window was added using an window_id, title, size and position, followed by a container and column. The ids are a key part of IPG and can be consider the glue that holds everything together. Each time there is an add command, a corresponding structure is initialized and stored in a Mutex using a HashMap with an integer id. Once Iced is started, a recursive routine is called to create the nested tree for all of the containers and widgets which is used by Iced to display them. Therefore, widgets can only be added during the add or construct phase. This might seem restrictive but if you have a widget that you need later, just add it with the show parameter as false. When the time comes for it's use, just change the parameter show to true and you now have it. You can modify all of the widgets during a callback procedure where the command update_item() is used. You can also move widgets from container to container very easily. You will see some of this in the demo code below.

Note how the ids are used. A container must have a window_id because Iced is a multi-window GUI, we need to know which window to put it in. In addition, if a container goes into another container, then the parent_id is needed.

A quick word on width_fill parameter. Almost all containers and widgets have a width and height. The parameter width and height take a float number. The width_fill and height_fill is bool and overrides the float. The fill parameters will cause the width of the container or widget to fill the available space. This works pretty good in most cases but there are some cases where there is a conflict as you'll see in some of the examples.

The column was added because the container holds only one widget and we need a container that holds more. We could have not used a container but only a column but then we would need to add spaces to get the column centered horizontally since a column only centers vertically. So the container made it easier.

To make things a little bit more exciting, let's add 3 widgets in a Column container.

Adding widgets

ipg.add_button(parent_id="col", label="Press Me!", on_press=button_pressed)

ipg.add_checkbox(parent_id="col", label="Check Me!!!", on_toggle=checked)

checked_text_id = ipg.add_text(parent_id="col",
                               content="This will change when I'm checked")

The button and checkbox widgets were next added and given a parent_id, which is the container_id that you want to put the widget in. The callbacks are functions you want to execute when, for example, a button is pressed. So in the case above, we have callback functions, button_pressed and checked. Note, some IDE's automatically insert a () after a function name is typed in. This will give you an error because these are references to the function and are not to be executed at this time. So make sure the () is not present.

As you may have noted, widgets don't get an id but are assigned an id during the construction of the Rust structure which returns an integer. The text widget which was added last is an example where the id of the widget is needed for updating the text widget with some new content.

Defining callbacks

Below we defined two callbacks, button_pressed and checked, All callbacks have from 1 to 3 parameters based on the output of the widget. The button has only one (2 if user_data used) and the checkbox has a minimum of 2, id and a bool to indicate if checked or not and a 3rd if user_data used. You can look at the docs to determine the returning values, but they are mostly obvious based on what the widget does.

def button_pressed(btn_id):
    print(btn_id)

def checked(_chk_id: int, checked: bool):
    if checked:
        ipg.update_item(wid=checked_text_id,
                        param=IpgTextParam.Content,
                        value="I'm checked")

    else:
        ipg.update_item(wid=checked_text_id,
                        param=IpgTextParam.Content,
                        value="I'm not checked")

The button is simple because it only returns the id of itself. So in most cases, you'll be doing something else like processing some data or changing some other widget. In this case, we'll just print out the id number.

We have used the term btn_id above versus id because id is used by python and it's good to indicate what the id is coming from so that you can remember which id to use in your function, like in the checkbox callback. You are not using the checkbox id but the text id.

Another note on naming the callback parameters. They can be named anything, order is most important.

For the checkbox callback, we could just print the checked status but that really never happens in a real programs so let's display the info in a text widget by using the command update_item().

The update_item is going to be your goto function to change the way the gui looks and to process your data while Iced is running. The update_item function takes 3 arguments, an integer id of the widget you want to update, the class name of the parameter you want to change, and the value you want to set it too. Unless you are updating the calling widget, you'll need the id of the widget you want to update. The class name is the same as the parameter name of the widget so you can look at the docs for which to select.

So in the checked function, we do an if else statement for the boolean and change the text accordingly. The user_data is not covered here but the are many in the examples and they are straight forward to use.

Finally, we're ready to start the engine on the gui with one last line of code, the magic.

ipg.start_session()

Let's put it all together to cut down on the cutting a pasting.

from icedpygui import IPG
from icedpygui import IpgAlignment, IpgTextParam


def button_pressed(btn_id):
    print(btn_id)


def checked(_chk_id: int, checked: bool):
    if checked:
        ipg.update_item(checked_text_id,
                        IpgTextParam.Content,
                        "I'm checked")

    else:
        ipg.update_item(checked_text_id,
                        IpgTextParam.Content,
                        "I'm not checked")


ipg = IPG()

ipg.add_window(window_id="main", title="Demo Window",
               width=600, height=500,
               pos_centered=True)

# container alignment defaults to centering
ipg.add_container("main", container_id="cont",
                  width_fill=True, height_fill=True)

# The column width will shrink to the size of the largest widget by default.
ipg.add_column(window_id="main", container_id="col", parent_id="cont",
               align_items=IpgAlignment.Center)

ipg.add_button(parent_id="col", label="Press Me!", on_press=button_pressed)

ipg.add_checkbox(parent_id="col", label="Check Me!!!", on_toggle=checked)

checked_text_id = ipg.add_text(parent_id="col",
                               content="This will change when I'm checked")

ipg.start_session()

Hopefully you were able to run the program successfully. If not, try one of the examples and see if it will work. All of the examples are run before publishing to make sure the code works.

The examples are found in a separate repository as indicated above and here https://github.com/icedpygui/IcedPyGui-Python-Examples

Issues / Questions / Feedback / Contributing

Feedback/Discussions/Questions are welcomed! You can come chat in the Discord server.

If you have errors not cleared up in questions, click on the issues tab and create a new one. Follow the template.

Code contributions are welcomed. See guidelines
