This module attempts to enhance contrast of a given image by equalizing its two dimensional histogram.
This module attempts to enhance contrast of a given image by equalizing its two dimensional histogram. An easy way to enhance quality of a given image is to just equalize its histogram, but despite using minimum resources and a very short process time, there are a lot of drawbacks to it.
One of the ways to tackle drawbacks of
histogram equalization method is to instead equalize the image's
two dimensional histogram, as one dimensional histogram of a given image does not contain the image's contextual information. Tests on a multitude of images has shown, by taking contextual information of an image in addition to the image's histogram into account when attempting to enhance contrast, output images are significantly better in quality in compare to histogram equalizaion and a handful of other known methods.
You can access the article that came up with this method here.
Two Dimensional Histogram
Here is the source code for the im2dhist python library with a short description on how it's done.
Run the following to install:
pip install im2dhisteq
import numpy as np import cv2 from im2dhisteq import im2dhisteq def imresize(img, wr=500, hr=None): # This is just for imshow-ing images with titles [ h, w] = img.shape hr = (h*wr)//w if not hr else hr img_resized = cv2.resize(img, dsize=(wr, hr)) return img_resized def main(): fullname = 'cloudy-day.jpg' image = cv2.imread(fullname) gray_image = cv2.cvtColor(image, cv2.COLOR_BGR2GRAY) # w_neighboring=6 is generally an adequate value, drived by a lot of experimenting. # w_neighboring=6 corresponds to a 13*13 square gray_image_2DHisteq = im2dhisteq(gray_image, w_neighboring=6) # This is just for imshow-ing images with titles gray_Image_resized = imresize(gray_image) gray_Image_2DHisteq_resized = imresize(gray_image_2DHisteq) cv2.imshow('Original Image', gray_Image_resized) cv2.imshow('2DHeq Image', gray_Image_2DHisteq_resized) cv2.waitKey(0) if __name__ == '__main__': main()
im2dhisteq --input 'cloudy-day.jpg' --output 'assets/cloudy-day-2dhisteq.jpg' --w 6
- A one minute comparative video: https://youtu.be/tX1KbJ2ugdE
- This is a sample image and its corresponding 2d-histogram equalized image.
