image-quantizer 0.0.2

Convert image into quantized image compatible with Waveshare epaper display

Image Quantizer

Simple Python package to convert an image into a quantized image using a customizable palette. Resulting image can be displayed by ePaper displays such as Waveshare displays.

Installation

It can be installed as a PyPi package

pip install --user image-quantizer

It can also be installed manually

git clone https://github.com/lobis/image-quantizer
cd image-quantizer
python3 setup.py install --user

Usage

from image_quantizer import quantize_image

with Image.open("tests/data/cliff.jpg") as image:
    quantized_image = quantize_image(image, palette=PALETTES["WAVESHARE-EPD-7COLOR"])
    quantized_image.save("cliffs-quantized.png")

Custom palette

from image_quantizer import quantize_image, PALETTES

# Existing palette names
print(PALETTES)

palette = [
    [0, 0, 0],  # white
    [255, 255, 255],  # black
    [0, 0, 255],  # blue
    [0, 255, 0],  # green
]

with Image.open("tests/data/cliff.jpg") as image:
    quantized_image_custom = quantize_image(image, palette=palette)
    quantized_image_custom.show()

Split by Palette

In some cases such as highlighted here, it might be useful to split an image into its colors. This is necessary to display the image in a waveshare RED-WHITE-BLACK display.

from image_quantizer import quantize_image, split_image_by_color

with Image.open("tests/data/cliff.jpg") as image:
    quantized_image = quantize_image(image, palette=PALETTES["BLACK-WHITE-RED"])
    split_images = split_image_by_color(image)
    for color, image in split_images:
        image.show()

Original image:

Single palette color images:
