jhuki 0.1.0.dev11

Utilities to prepare Einstein Toolkit simulations

Writing parameter files for Cactus simulations is not easy. To achieve a successful evolution, one has to tune several parameters, which typically depend on the grid configuration or on other settings. Writing these par files by hand is tedious and error-prone. Jhuki is a Python library to prepare simulations for the Einstein Toolkit (or Cactus-based codes).

:warning: This package is currently under development. It may be full of bugs, and its interfaces might change without notice. It is also highly opinionated.

Features

• Generate parameter files from a template using configuration files or command-line arguments
• Take care of the grid configuration given the desired resolution at the finest level and other details
• Generate binary black hole configurations for quasi-circular mergers (automatically setting the linear momenta)
• Add dissipation

You can find the reference material at the website sbozzolo.github.io/Jhuki.

Examples

Integration with SimFactory

Jhuki integrates well with SimFactory. Assume you have the following simple test_sim.rpar file:

#!/usr/bin/env python3

from jhuki.simfactory import simfactory_option
from jhuki.simfactory import write_parfile

par_b = simfactory_option("@PARB@", 5)

m_plus = 0.5

lines="""
TwoPunctures::par_b      = $par_b
TwoPunctures::par_m_plus = $m_plus

# Rest of the parameter file

"""

write_parfile(lines)

SimFactory can execute this Python file to produce a .par file to run:

sim create-run test_sim.rpar

will run the parfile with content

TwoPunctures::par_b      = 5
TwoPunctures::par_m_plus = 0.5

The value for par_b is run-time adjustable:

sim create-run test_sim.rpar --define PARB 10

will produce

TwoPunctures::par_b      = 10
TwoPunctures::par_m_plus = 0.5

Since arbitrary Python code can be executed before the parfile is written, all the features of Jhuki presented below can be used directly. For instance, as discussed below, one can prepare quasi circular inspirals with the function prepare_quasicircular_inspiral, so one can add the entire parfile code for the two puncture with:

#!/usr/bin/env python3

from jhuki.simfactory import simfactory_option
from jhuki.simfactory import write_parfile
from jhuki.twopunctures import prepare_quasicircular_inspiral

par_b = simfactory_option("@PARB@", 5)

twopunctures = prepare_quasicircular_inspiral(mass_ratio=1,
                                              coordinate_distance=par_b)

lines="""

$twopunctures

# Rest of the parameter file
"""

write_parfile(lines)

This sets up a good fraction of the parfile needed to run quasi circular inspirals.

Working with grid structures

Problem: you want to generate the parfile code for a grid structure with two refinement centers, each with 8 levels and resolution at the finest level 0.001 and CFL factor of 0.4 (in the finest level). In this, you want to ensure that the maximum timestep on the grid never exceeds 1 to avoid numerical instability.

#!/usr/bin/env python3

from jhuki import grid as pg

refinement_radii = tuple(2**level for level in range(7))

center1 = pg.RefinementCenter(refinement_radii,
                              dx_fine=0.001,
                              cfl_fine=0.5,
                              center_num=1,
                              position=(10,0,0))

# Same but with different center_num and position
center2 = pg.RefinementCenter(refinement_radii,
                              dx_fine=0.001,
                              cfl_fine=0.5,
                              center_num=2,
                              position=(-10,0,0))

grid_not_synced = pg.Grid((center1, center2), outer_boundary=1000)
grid_synced = pg.set_dt_max_grid(grid_not_synced, dt_max=1)

print(grid_synced)

This will output something along the lines of

CartGrid3D::type = "coordbase"
Carpet::domain_from_coordbase = "yes"
CoordBase::domainsize = "minmax"

Driver::ghost_size = 3
CoordBase::boundary_size_x_lower = 3
CoordBase::boundary_size_y_lower = 3
CoordBase::boundary_size_z_lower = 3
CoordBase::boundary_size_x_upper = 3
CoordBase::boundary_size_y_upper = 3
CoordBase::boundary_size_z_upper = 3

CoordBase::xmin = 1000
CoordBase::ymin = 1000
CoordBase::zmin = 1000
CoordBase::xmax = 1000
CoordBase::ymax = 1000
CoordBase::zmax = 1000
CoordBase::dx = 0.64
CoordBase::dy = 0.64
CoordBase::dz = 0.64
Carpet::max_refinement_levels = 8
Carpet::time_refinement_factors = "[1,1,2,4,8,16,32,64]"
CarpetRegrid2::num_levels_1 = 8
CarpetRegrid2::position_x_1 = 10
CarpetRegrid2::position_y_1 = 0
CarpetRegrid2::position_z_1 = 0
CarpetRegrid2::radius_1[1] = 64
CarpetRegrid2::radius_1[2] = 32
CarpetRegrid2::radius_1[3] = 16
CarpetRegrid2::radius_1[4] = 8
CarpetRegrid2::radius_1[5] = 4
CarpetRegrid2::radius_1[6] = 2
CarpetRegrid2::radius_1[7] = 1
CarpetRegrid2::num_levels_2 = 8
CarpetRegrid2::position_x_2 = -10
CarpetRegrid2::position_y_2 = 0
CarpetRegrid2::position_z_2 = 0
CarpetRegrid2::radius_2[1] = 64
CarpetRegrid2::radius_2[2] = 32
CarpetRegrid2::radius_2[3] = 16
CarpetRegrid2::radius_2[4] = 8
CarpetRegrid2::radius_2[5] = 4
CarpetRegrid2::radius_2[6] = 2
CarpetRegrid2::radius_2[7] = 1

You can also add a small shift to the grid so that the origin is not on (0,0,0) passing the tiny_shift argument to Grid.

Another useful method is rl_synced_every, which returns the number of iterations at which all the refinement levels are at the same time.

Working with binary black holes

Problem: you want to simulate a binary black quasi-circular merger. This can be tricky because you have to provide the correct linear momenta. With Juhki, this is trivial:

#!/usr/bin/env python3

from jhuki.twopunctures import prepare_quasicircular_inspiral

mass_ratio = 1
coordinate_distance = 12
dimensionless_spin_plus = (0.1, 0.2, 0.3)
dimensionless_spin_minus = (0.4, -0.1, -0.2)

twopunctures = prepare_quasicircular_inspiral(mass_ratio,
                                              coordinate_distance,
                                              chi_plus=dimensionless_spin_plus,
                                              chi_minus=dimensionless_spin_minus)
print(twopunctures)

This will produce an output similar to the following:

ADMBase::initial_data = twopunctures
ADMBase::initial_lapse = twopunctures-averaged
ADMBase::initial_shift = zero
ADMBase::initial_dtlapse = zero
ADMBase::initial_dtshift = zero
TwoPunctures::give_bare_mass = no
TwoPunctures::par_b = 6.0
TwoPunctures::target_m_plus = 0.5
TwoPunctures::target_m_minus = 0.5
TwoPunctures::par_P_plus[0] = -0.000531433937072403
TwoPunctures::par_P_plus[1] = 0.0848055056299618
TwoPunctures::par_P_plus[2] = 0
TwoPunctures::par_P_minus[0] = 0.000531433937072403
TwoPunctures::par_P_minus[1] = -0.0848055056299618
TwoPunctures::par_P_minus[2] = 0
TwoPunctures::par_S_plus[0] = 0.025
TwoPunctures::par_S_plus[1] = 0.05
TwoPunctures::par_S_plus[2] = 0.075
TwoPunctures::par_S_minus[0] = 0.1
TwoPunctures::par_S_minus[1] = -0.025
TwoPunctures::par_S_minus[2] = -0.05
TwoPunctures::center_offset[0] = 0.0
TwoPunctures::center_offset[1] = 0.0
TwoPunctures::center_offset[2] = 0.0

This module should be used along with the Grid one.

Installation

The best way to install Jhuki is by cloning this repo and using poetry. If you have poetry install, just run poetry install in the folder where you cloned the repo to install Jhuki. Alternatively, Jhuki is available on PyPI.

Tests

Jhuki comes with a suite of unit tests. To run the tests,

poetry run pytest --cov=./ --cov-report=term

Tests are automatically run after each commit by GitHub Actions. This will also tell you what is the test coverage.

Code style

• We lint the code with black -l 79.
• We work only with immutable structures.

What does jhuki mean?

The word jhuki belongs to the Tohono O'odham vocabulary and means rain. If kuibit is the tool you use to collect the fruit of your Cactus simulations, then jhuki is what allowed that fruit to be there in the first place.

Credits

The logo contains elements designed by pngtree.com.

The computation of the momenta for quasi-circular mergers of binary black holes uses NRPyPN. If you use this module, please follow the citation guidelines as specified by the documentation in the NRPyPN repo.
