Analytics ETL and collaboration tool for progressive campaigning

Project description

Project Keanu

Project Keanu constist of:

  • Handbook for analytic terms, metrics and their definitions
  • Common data model for campaign evaluation
  • Set of queries to visualize metrics and key indicators
  • ETL tool to transform data in CRM (Currently CiviCRM, Identity in the future)
  • Metabase setup tool (mainly import/export of questions, dashboards)

Keanu CLI

Keanu command lives in cli directory. It can (incrementally) load data from CiviCRM to keanu schema and delete it. With this functionality you can develop ETL SQL scripts with ease of rewinding and forwarding the state of keanu DB.

Setup

  1. Install Pipenv command in your system: sudo apt install pipenv
  2. Install dependencies in cli directory: pipenv install

Configuration

  1. Copy the .env.sample file to .env and change it to taste.
  • DATABASE_URL - must use schema understood by SQLAlchemy library, required only for SQL related commands
  • SOURCE - is a name of CiviCRM database (also called schema), required only for SQL related commands
  • METABASE_ENDPOINT, METABASE_AUTH_EMAIL, METABASE_AUTH_PASSWORD - Metabase credentials, required only metabase commands

Usage

Keanu commands has a set of subcommands, similar to git or heroku. You need to enable the Pipenv, by running pipenv shell.

Package building

To build the package use python setup.py bdist_wheel.

To upload it to PyPI:

  1. Create a ~/.pypirc file:
[distutils]
index-servers=pypi
[pypi]
repository = https://upload.pypi.org/legacy/
username = pypi-username

To install the package locally:

pip install --upgrade dist/keanu-0.1-py3-none-any.whl

  1. Use python -m twine upload dist/*.

SQL commands

These are the commands related to creating and filling in the Keanu schema (from CiviCRM DB).

schema: manipulating database schema

  • keanu.py schema -L FILENAME - loads SQL schema file.
  • keanu.py schema -D - drops all tables from the database.

load: loading data

keanu.py load SQLDIR loads data from CiviCRM to keanu db in ordered steps. Every SQL file in SQLDIR directory has -- ORDER: 12 comment which specifies an order. The default order is 100.

Options:

  • -o 10: - order, start from SQL file with order 10 (also see order spec)
  • -n - dry run, do not execute the SQL. Usefull to see the order of scripts
  • -i - incremental, also run the incremental parts of the SQL, normally deleted (they are marked by -- BEGIN INCREMENTAL and -- END INCREMENTAL comments)
  • -d - display a whole SQL statement instead of abbreviation of first line

delete: deleting data

keanu.py delete SQLDIR will go through the SQL scripts in reverse order and execute the commented DELETE and TRUNCATE statements in the scripts.

Options:

  • -n - dry run, do not execute the SQL. Usefull to see the order of scripts
  • -o 10: - delete data until the SQL file order (inclusive) and stop
  • -d - display a whole SQL statement instead of abbreviation of first line

Order spec

You can provide just a number to order (-o) option, but you can also provide:

  • a list of numbers such as 10,11,50 and scripts with respective order will be run
  • a range in python format such as 10:16 equal to 10,11,12,13,14,15 (excluding 16)
  • a mix of them: 10:13,31,50:52

SQL file reference:

We add metadata to SQL files in SQL comments. This is usefull because you can still work with the SQL files using tools like MySQL Workbench, or mysql command - the commands will be ignored.

Supported commands are:

-- ORDER: arg - arg should be a 3 digit number. It specifies the order this script will be run. -- DELETE FROM .. - a DELETE statement will be saved to revert this script, so to remove all the data it has added. Must start with all caps DELETE. -- TRUNCATE - similar to above. Please note: TRUNCATE will fail if any other table has reference to this table, even when it's empty. -- IGNORE - the rest of the file will be ignored.

Blocks are also supported. They are marked by a pair of lines:

-- BEGIN keyword
 .. some SQL code here..
-- END keyword

They should be properly nested.

Supported blocks are:

  • BEGIN INCREMENTAL / END INCREMENTAL - marks part of the SQL that will normally be removed, and will be only used if -i (incremental flag) is used while loading. You can have many INCREMENTAL blocks. Example use:
-- this scripts inserts into cookie jar
-- ORDER: 10
-- DELETE FROM jar

INSERT INTO jar (colour, size, external_id)
SELECT
  cd.name,
  c.size,
  c.id
FROM cookie c
JOIN colour_dictionary cd ON c.colour_id = cd.id

-- when we do incremental, we exclude external_id's we already have:
-- BEGIN INCREMENTAL
WHERE c.id NOT IN (SELECT external_id FROM jar)
-- END INCREMENTAL
  • BEGIN INITIAL / END INITIAL - marks part of the SQL that will be removed in incremental -i mode.

Enviroment variable interpolation. Similar to shell, simple variable interpolation is supported. ${FOO} will be interpolated into value of FOO environment variable. This is currently used to insert the source schema name with ${SOURCE}.

Metabase commands

These are the commands to export / import Metabase questions and dashboards that are related to the Keanu schema

Export

keanu.py metabase export generates a JSON dump of all the data required to import the collections / dashboards / questions given in options.

The generated JSON is printed on standard output. It contains a property items with the list of objects that got exported, as well as a property mappings with information to translate ids that make sense only in the context of a Metabase instance (table ids, card ids, etc).

Options:

  • -c "Some collection" - Exports all the questions and dashboards contained in the named collection and its child collections. You should ensure that the dashboards refer only to questions contained within that collection, unless you plan to import the data within the same Metabase instance. The collection must exist.

Import

keanu.py metabase import reads a JSON dump generated by the export command and import the object into a Metabase instance.

Options:

  • -c "Some collection" - The name of the collection into which the objects should be imported. The collection must exist and be empty (no support for overwrite / merge at the moment).
  • -j /path/to/file.json - The JSON file to import.

Product vision

Right now during initial development, we run keanu command from the source directory cli, and the SQL scripts are kept in sql. The vision for the future product is the following:

Keanu will be a command installed gloablly into the system, with pip install keanu. It will work like git or heroku, a multi-tool to do everything conntected to common DB model, ETL, running AI logic, installing dashboards in Metabase (this last function fits this command least, but let's see).

It will download a repository of SQL files, properly divided between general use, CiviCRM users, Identity users, etc, and be able to configure itself with keanu setup - saving information about source and target DBs. It will be able also to upload SQL files that were changed and verion manage them somehow, to help in collaboration (this could be done using git).

Similarly, it will enable import and export of Metabase questions (called cards) and dashboards. Not only their SQL, but also their JSON configuration (using python Metabase API client library).
