levitydash 0.1.0b10

A lightweight, desktop native, multi-source, modulear dashboard for macOS, Windows and Linux

LevityDash

A lightweight, desktop native, multisource dashboard for macOS, Windows and Linux

LevityDash aims to be a lightweight, desktop native, multisource dashboard without a required web frontend. The current version only supports PySide2/Qt. However, a key goal of this project is to support multiple frontends and platforms, including embedded.

Note: This project is very much in the proof of concept stage – it functions, but it is far from the goal of a lightweight dashboard.

Current Features

Backend

• Plugin system for adding new sources
• Scheduling API pulls
• Data/key maps for automatically parsing ingested data
• Unit library for automatic localization/conversion
• Conditional value updates. i.e. if wind speed is zero do not log the wind direction

Data Sources

• REST API Pull
• Sockets (UDP, websocket, socket.io)
• BLE Advertisements

Builtin Plugins

• Open-Meteo [REST]
• WeatherFlow Tempest [REST, UDP, Websocket(incomplete)]
• Govee BLE Thermometers/Hygrometers [GVH5102]

Frontend

• Drag and drop dashboard design (This can be a little funky at times)
• YAML based dashboard specifications with support for both absolute and relative size/positioning
• Module grouping
• Editable Margins for text modules
• Resizable graph figures
• Custom, value mapped, gradients for figure items
• Text filters (i.e. lower, title, upper, digit to ordinal, etc.)

Current Modules

• Realtime single line text with support for showing units and titles and mapping glyphs/emojis to values
• Timeseries Graph
• Customizable Clock
• Moon Phase
• Submodule Group for organizing modules

Planned Modules

• Gauges [nearly complete]
• Weather Radar
• Multiline Text
• RSS Feeds
• Calendar
• Mini Graphs
• More plot types
