memori 0.3.6

A python library for creating memoized data and code for neuroimaging pipelines

memori

A python library for creating memoized data and code for neuroimaging pipelines

Table of Contents

1. Installation
2. Command-Line Usage
   1. memori
   2. pathman
3. Python Usage
   1. The Stage Object
   2. The Pipeline Object
   3. Stage Aliases and Complex Pipelines
   4. Hashing external functions
   5. Path Management

Installation

To install, use pip:

pip install memori

Command-Line Usage

memori can be used to memoize the running of command-line scripts. It is designed to check the inputs and sha256 integrity of the calling script and determines whether the running of that calling script should be run or not. It accomplishes this through 3 checks:

1. Check against the stored cache that input arguments are all the same.
2. Check that the sha256 hash of the calling script (and dependents) are the same.
3. (Optional) Check that the desired outputs match the hashes stored in the cache.

If at least one of these conditions is not met, memori will re-run the script.

memori

The main command-line script to use memori is simply called memori on the command-line:

memori -h [any command/script here]

The above command will let you view the help of the memori script.

To call memori on a script simply add memori before the command you want to call. For example:

# wrapping echo in memori
memori echo "this echo command has been wrapped in memori"

This will call the echo command with memori. To cache the running of the command, you need to specify the -d/--hash_output flag:

# same command but with cached run
memori -d /path/to/cache echo 1
# the first call will print 1
memori -d /path/to/cache echo 1
# running this a second time will not print anything to the screen
# since the inputs/command is the same, so execution is skipped!

Since memori determines if a calling script has changed through hashing, you may want to determine script execution if the calling script depends on another script. This can occur if calling script 1 calls script 2 and changes are made to script 2. This can be accomplished through the -c/--dependents flag.

# script execution of script1.sh is now sensitive to changes in script2.sh
memori -c script2.sh -d /path/to/cache script1.sh arg0 arg1...

If we are expecting certain files to be written from a calling script, we can inform memori of their existence through the -o/--outputs flag. memori will re-run the calling script if the files are missing/modified.

memori -o /path/to/an/expected/output -d /path/to/cache script.sh arg0 arg1...

The -k/--kill flag can be used to kill the parent process, if the calling script returns an error code. This can be useful to halt a parent script if execution has failed.

Use the --verbose flag for under the hood logging info!

pathman

pathman is a script that allows for the convenient management of file path manipulations.

pathman -h

To view the full help.

Python Usage

memori uses a directed acyclic graph (DAG) approach to constructing pipelines. Nodes of the the graph represent a "logical unit of processing" (up to the user to define) that can be encomposed in a function. The edges of the graph transfers data between these nodes to create a pipeline. To represent this memori employs the use of the Stage and Pipeline objects.

The Stage object

A Stage is a wrapper around a python function and is the conceptual equivalent of a node of our graph. A Stage object can take input/output from/to other Stage objects, but can also be run in isolation. Here is an example of a Stage wrapped around a python function:

# our example function
def test_function(a, b, c):
    # Do some stuff
    d = a + b
    e = b + c

    # and return stuff
    return d, e

We can wrap this function in a Stage object and run it:

from memori import Stage

# any values a function returns need to be labeled with the `stage_outputs` parameter
my_test_stage = Stage(test_function, stage_outputs=["d", "e"])

# we can run this stage with the run method and store the results
result = my_test_stage.run(1, 2, 3)
# result will return a dictionary containing: {"d": 3, "e": 5}

# running it again with different parameters
result = my_test_stage.run(2, 3, 4)
# result will return a dictionary containing: {"d": 5, "e": 7}

Now lets write a 2nd function that can take input from our test_function. Note that the input arguments for this function should match the key names of the stage outputs for the test_function.

# new test function with input arguments matching previous stage
# function stage_output names
def test_function2(d, e):
    return d + e

# and wrap this in a Stage
my_test_stage2 = Stage(test_function2, stage_outputs=["f"])

# to run this we just merely need to **results (kwarg unpacking) to pass information
# from my_test_stage to my_test_stage2
result2 = my_test_stage2.run(**results)
# result2 will return a dictionary containing: {"f": 12}

# or running the entire pipeline from the beginning
result2 = my_test_stage2.run(**my_test_stage.run(1, 2, 3))
# result2 will return a dictionary containing: {"f": 8}

# The previous two lines is the equivalent to running
test_function2(**test_function(1, 2, 3))

We can create static values in our Stage object that ignores inputs from other stages that are passed into the run method.

# Stage will take the same params as test_function
# and use them as static values
my_test_stage = Stage(
    test_function,
    stage_outputs=["d", "e"],
    a=1,
    b=2,
    c=3
)

# when we run the stage, we will see that it does not change with the input (2, 3, 4)
result = my_test_stage.run(2, 3, 4)
# result will return a dictionary containing: {"d": 3, "e": 5}
# if static values weren't used this should return {"d": 5, "e": 7}

Now we know how to wrap the functions we write into a Stage object, but what benefit does this provide? The main feature of memori is to memoize the inputs to each stage and recall the outputs if they are the same. This can enable long running functions to be skipped if the results are going to be the same!

# To enable memoization feature, we need to add the hash_output
# parameter when constructing a Stage object. hash_output is
# just some directory to where the memoization files can be
# written to.
my_test_stage = Stage(test_function, stage_output=["d", "e"], hash_output="/test/directory")

# run the stage
my_test_stage.run(1, 2, 3)

This will write 3 files: test_function.inputs, test_function.stage, and test_function.outputs at the location: /test/directory These 3 files record the important states of the Stage for memoization, after it has been run.

The .stage file contains information about the function that was run. It contains some rudimentary static analysis to check whether and code wrapped by a Stage has changed in a way that will affect the result. If it has detected this, it will rerun the stage. Note that this file contains binary data is mostly non-human readable (unlike the .inputs and .outputs files).

The .inputs and .outputs files contain information about the inputs and outputs of the stage. These files are simply JSON files and upon opening them in a text editor you should see the following:

test_function.inputs

{
    "a": 1,
    "b": 2,
    "c": 3
}

test_function.outputs

{
    "d": 3,
    "e": 5
}

memori checks the .inputs file on each run to determine if the stage needs to be run (assuming it has also passed the .stage file check). If the stage is skipped, the .outputs file is used to load the results into the stage.

By default, memori uses the name of the function as the name for the hash files. If you would like to use a different name for these files, you can set the name of the Stage object with the stage_name parameter in the constructor:

# Stage with a custom stage name
Stage(...
    stage_name="my_stage_name"
...)

When passing path/file strings between Stage objects, memori has a special behavior: if it determines the string to be a valid file on the disk, it will hash it with the SHA256 algorithm. For files, this gives memoization results that can reflect changes in data integrity:

# now we specify the input and output to be files on the disk
file0 = "/Some/file/path"
file1 = "/Some/second/file/path"

# define our simple test_function that outputs a file path
def test_function3(f0):
    # always return file1
    return file1

# Now we wrap it in a stage
my_test_stage3 = Stage(test_function3, stage_outputs=["file1"], hash_output="/test/directory")

# and run the stage with file0 as the input
results3 = my_test_stage3.run(file0)

Now if you examine the test_function3.inputs and test_function3.outputs you will see the following:

test_function3.inputs

{
    "file0": {
        "file": "/Some/file/path",
        "hash": "f0e4c2f76c58916ec258f246851bea091d14d4247a2fc3e18694461b1816e13b"
    }
}

test_function3.outputs

{
    "file1": {
        "file": "/Some/second/file/path",
        "hash": "f91c3b6b3ec826aca3dfaf46d47a32cc627d2ba92e2d63d945fbd98b87b2b002"
    }
}

As shown above memori replaces a valid file path with a dictionary entry containing the "file" and "hash" keys. Valid files are compared by hash values rather than path/filename ensuring data integrity.

NOTE: Since "file" and "hash" are keywords used to hash valid files. These are reserved keywords that should NOT be used when returning an output from a stage using a dictionary. Doing so could lead to catastrophic results!

CAUTION: memori uses JSON to memoize and pass information between Stage objects. This means that the inputs/outputs of your function MUST be JSON serializable or you will get a serialization error. You can also get data conversion effects if you don't use the proper data types. For example, python always converts a Tuple to a List when serializing a dictionary to JSON. This will lead to hash check fail each time you run the Stage! Since whenever memori loads the stage output data from the .outputs file, the Tuple in the code will never match against list it was converted to in the JSON. So take care to use only JSON compatible data types (This means None, integers, floats, strings, bools, lists, and dictionaries are the only valid input/output data types in memori).

For data that is not JSON serializable, the typical workaround is to save it to a file and pass the file location between the Stage objects. This also allows you to take advantage of the SHA256 file hashing features of memori.

The Pipeline object

What happens when you have more complex pipelines? Maybe you have a Stage that needs to provide input to two different Stage objects.

This is where the Pipeline object comes in. A Pipeline is a collection of Stage objects with their input/output connections defined. A Pipeline object represents the conceptual DAG that was mentioned above.

from memori import Stage, Pipeline

# create some stages (see the last section on Stages for details)
stage0 = Stage(some params go here...)
stage1 = Stage(some params go here...)
stage2 = Stage(some params go here...)
stage3 = Stage(some params go here...)

# Now we create a Pipeline object, a pipeline takes a definition list during construction
# the definition list is a list of tuples specifying the connection between stages
#
# The "start" keyword is a special instruction that the Pipeline object can read
# it specifies that a particular stage has not precedent Stage and should be a Stage
# that is run first in the Pipeline.
p = Pipeline([
    ("start", stage0),  # stage0 takes no input from other stages, so it should run first
    (stage0, stage1),  # stage0 passes it's output to stage1
    (stage0, stage2),  # and also to stage2
    ((stage1, stage2), stage3)  # stage3 needs inputs from stage1 and stage2, so we use a
                                # special tuple-in-tuple so that it can get outputs from both
                                # NOTE: if stage1 and stage2 have stage_outputs with the same
                                # name, the last stage (right-most) stage will have precedence
                                # for it's output
])

# we can run the Pipeline with the run method, and get it's result
result = p.run(some input parameters here...)

Running the pipeline has the effect of invoking the run method of each Stage object individually, and passing the result of the stage onto the next stage as defined by the Pipeline definition passed in during Pipeline initialization.

Stage Aliases and Complex Pipelines

When building a complicated pipleine, sometimes the functions that you write will have input argument names that are different from the stage_output names that you have defined in a Stage. Consider the following example:

def test_function(a, b):
    return a + b

def test_function2(c):
    # this might represent some complicated processing
    c += 1
    return c

def test_function3(d):
    # this might be another function with some more complocated processing
    d += 2
    return d

Now let's say I want to pass the result of test_function to both test_function2 and test_function3. This presents an issue because test_function2 and test_function3 have different input argument names. So if I define the stage_output of the wrapped test_function to be stage_outputs=["c"] this won't work for test_function3 and if I define it to be stage_outputs=["d"] it won't work for test_function2.

One way of solving this issue would be to rewrite the test_function2 and test_function3 functions to have the same argument name, this may not always be possible (particularly when wrapping a function call from a third-party library). Another option would be to wrap the call of either test_function2 or test_function3 to take in the same input. For example:

# this is necessary hashing external function calls
# more about the hashable wrapper in the next section
from memori import hashable

# we wrap the call of test_function3
def test_function3_mod(c):
    return hashable(test_function3)(c)

Now when we create the Stage for each function, test_function2 and test_function3_mod now have the same input argument names and can take in input from test_function.

While this solution works (and indeed this was how it used to be done), memori provides a more convienent solution through Stage aliases. Aliases can map the name of one of the stage outputs to another name. When creating a Stage object, you can define this through the aliases parameter.

# We wrap test_function in a Stage, and specify an alias from d -> c
test_stage = Stage(test_function, stage_outputs=["c"], aliases=["d": "c"])

# Now I can construct stages around test_function2 and test_function3 without
# writing extra code
test_stage2 = Stage(test_function2, stage_outputs=["e"])
test_stage3 = Stage(test_function3, stage_outputs=["f"])

# now definte the pipeline
my_pipeline = Pipeline(
    [
        ("start", test_stage),
        (test_stage, test_stage2),
        (test_stage, test_stage3), # because we mapped d -> c, memori know where to pass the result to
    ]
)

Stage aliases reduces the need for extra boilerplate code, and adding on an extra stage the feeds from test_stage is as simple as adding another alias.

Hashing external functions

In the last section, we saw the use of the hashable wrapper when trying to wrap a function call in another function. But what does it actually do? Consider the following example:

def test_function(a, b)
    c = a + b
    d = test_function2(c)
    return d

def test_function2(c)
    return c + 1

stage0 = Stage(test_function, stage_outputs=["d"], hash_output="test")
result = stage0.run(1, 2)
# this will return the result {"d": 4}

Now, what if we change the code of test_function to:

# change up test_function!
def test_function(a, b)
    c = a + b + 1
    d = test_function2(c)
    return d

Rebuilding the stage on this function and invoking the run method it will cause the .stage hash to mismatch (since the function signature is different with the added + 1 in the code), and the function will rerun instead of loading from cache (this should return the result {"d": 5}).

So the function hashing feature of memori works! but what happens when we modify test_function2 and rerun our stage.

# will memori see this change?
def test_function2(c):
    return c + 2

Rerunning the stage with the updated test_function2, you will see that after invoking run, the Stage object simply loads the result from the .output file and ignores the difference in the updated test_function2 (this will still return {"d": 5} rather than {"d": 6}.

This occurs because memori function hashing only occurs one call deep. Meaning that only the instructions of the wrapped callable are the only thing that is hashed. Function calls inside a function are simply recorded as constants, meaning that only the name test_function2 is memoized, not the actual instructions!

To correct this issue, memori provides the hashable wrapper. This wrapper marks a function so that memori knows to try and hash it.

# wrap test_funtion2 in hashable
def test_function(a, b)
    c = a + b + 1
    d = hashable(test_function2)(c)
    return d

Alternatively, you can add the hashable wrapper a decorator.

# this is the same as calling hashable(test_function2)
# but makes everything transparent
@hashable
def test_function2(c)
    return c + 1

This allows you to simply call test_function2 without worrying about calling the hashable wrapper each time.

Path Management

memori also provides a path management utility called PathManager. It is useful for manipulating file paths as well as suffixes and extensions. If is derived from a Path object from the pathlib library, and so can use any of the parent methods as well.

Here are a few useful examples:

from memori import PathManager as PathMan

# a string to a path I want PathManager to manage
my_file_path_pm = PathMan("/my/path/to/a/file.ext.ext2")

# get only the file prefix
prefix = my_file_path_pm.get_prefix()
# prefix contains "file"

# get the path and file prefix
path_and_prefix = my_file_path_pm.get_path_and_prefix()
# path_and_prefix contains "/my/path/to/a/file"

# change path of the file, keeping the filename the same
repathed = my_file_path_pm.repath("/new/path")
# repathed contains "/new/path/file.ext.ext2"

# append a suffix (following the BIDS standard, suffixes should always have _)
suffixed = my_file_path_pm.append_suffix("_newsuffix")
# suffixed contains "/my/path/to/a/file_newsuffix.ext.ext2"

# replace last suffix
replaced = suffixed.replace_suffix("_newsuffix2")
# replaced contains "/my/path/to/a/file_newsuffix2.ext.ext2"

# delete last suffix
deleted = replaced.delete_suffix()
# deleted contains "/my/path/to/a/file.ext.ext2"

# methods can be chained together
chained = my_file_path_pm.repath("/new").append_suffix("_test").get_path_and_prefix()
# chained contains /new/file_test

# return as a string
my_file_path = my_file_path_pm.path
# /new/file_test
