michelson-kernel 0.1.6

Jupyter kernel for the Michelson language

Michelson kernel

Jupyter kernel for the Michelson language

Features

• Custom interpreter with runtime type checker
• Syntax highlighter
• Autocomplete by Tab
• Inplace docstrings by Shift+Tab
• Macros support
• Verbose execution logging
• Debug helpers

How to install

Option 1: try online!

Powered by awesome Binder: https://mybinder.org/v2/gh/baking-bad/michelson-kernel/binder?filepath=michelson_quickstart.ipynb

Option 2: run in docker

1. Get the latest image from dockerhub (only when new releases are published)

docker pull bakingbad/michelson-kernel

2. Create container using verified docker image:

docker run --rm -it -p 127.0.0.1:8888:8888 -v $(pwd):/home/jupyter/notebooks bakingbad/michelson-kernel

3. Open the link from container output in your browser
4. Save notebooks in the mapped folder in order not to loose them

Option 3: install python package

1. Requires Python 3.5+. The recomended way to install it (especially if you plan to use multiple versions) is pyenv. Make sure you have all necessary packets installed. After that:

pyenv install 3.7.0
pyenv local 3.7.0   # per folder
pyenv global 3.7.9  # per system

2. Ensure you have several crypto libraries installed (see pytezos docs):

sudo apt install libsodium-dev libsecp256k1-dev libgmp-dev

3. Install the package using pip

pip install michelson-kernel

4. Install Jupyter

pip install jupyter

5. Check that Jupyter is now supporting Michelson kernel

jupyter kernelspec list

6. Run jupyter

jupyter notebook

Open the link from the command output, create new notebook with Michelson kernel.

Option 4: install from sources

1. Follow steps 1-2 from "Option 3" to ensure you have correct Python version and packets required for the PyTezos library
2. Ensure the following packages are installed: libssl-dev zlib1g-dev uuid-dev
3. Get the sources, build and install

git clone https://github.com/baking-bad/michelson-kernel
cd michelson-kernel
make

4. Follow steps 4-6 from "Option 3"

How to uninstall

1. Run the following command

jupyter kernelspec uninstall michelson -f

2. Check that Jupyter is no longer supporting Michelson kernel

jupyter kernelspec list

3. Uninstall Python package

pip uninstall michelson-kernel

How it works

• Technical details of the REPL implementation
  https://forum.tezosagora.org/t/michelson-repl-in-a-jupyter-notebook/1749
• Interactive tutorial demonstrating REPL features
  https://mybinder.org/v2/gh/baking-bad/michelson-kernel/binder?filepath=michelson_quickstart.ipynb
• Same, but a rendered version
  https://nbviewer.jupyter.org/github/baking-bad/michelson-kernel/blob/binder/michelson_quickstart.ipynb

Sample notebooks

Located in the current repository in a separate branch:
https://github.com/baking-bad/michelson-kernel/tree/binder

List of helpers

These instructions are not Michelson primitives and thus cannot be used outside of the Jupyter.
In the Jupyter editor helpers are highlighted in blue.

DUMP

Returns the whole stack with values, types, and annotations if any.

DUMP n

Returns top n items from the stack.

PRINT "fmt"

Prints a formatted string to the stdout, referencing arbitrary stack elements is allowed:
PRINT "This is the top element {0}, and this is the second {1}"

DROP_ALL

Clears the stack.

EXPAND { code }

Expands Michelson macros:
EXPAND { PAPAIIR }

INCLUDE path

Loads Michelson source from the filesystem (absolute or relative path) INCLUDE "test.tz", or from one of the Tezos networks INCLUDE "mainnet:KT1VG2WtYdSWz5E7chTeAdDPZNy2MpP8pTfL". Initializes parameter, storage, and code sections. If loaded from the network, current storage is also written to the STORAGE variable and can be accessed later.

PATCH prim value

Sets value for on of the context-dependent Michelson instructions: AMOUNT, BALANCE, NOW, SOURCE, SENDER, CHAIN_ID.

DEBUG bool

Enables or disables verbose output: DEBUG False or DEBUG True.

BIG_MAP_DIFF

Takes the top of the stack, searches for temporary big_map instances in that element, and displays what the big_map_diff would be like if it was a contract execution ending.

BEGIN %entrypoint (param_expr) (storage_expr)

Simulates the contract execution beginning. Requires parameter and storage sections initialized. Also, clears the stack.
The %entrypoint argument can be omitted, %default will be used in that case.
This helper also allocates temporary big_map instances if any in parameters or storage.
You can use STORAGE variable for the storage_expr, in case you have previously loaded it from the network.

COMMIT

Simulates the contract execution ending. Requires a Pair of operation list and valid storage on top of the stack. Returns a list of internal operations, new storage, and big_map_diff.

RESET

Clears the stack, deletes all big_map instances.

RESET "network"

Does the same as the version without parameters, but also initializes NETWORK and CHAIN_ID variables.
Can be used to set real network context in order to access blockchain data.

RUN %entrypoint (param_expr) (storage_expr)

Requires code section initializes. Internally calls BEGIN, then executes code, and finishes with COMMIT.

Check out the articles and tutorial for more technical details, also you can take a look at the implementation.

Contact

• Telegram chat: @baking_bad_chat
• Slack channel: #baking-bad

Credits

• This project is supported by Tezos Foundation
• Michelson test set from the Tezos repo is used to ensure the interpreter workability
• Michelson structured documentation by Nomadic Labs is used for inline help
