Python scripts used by MISP to export MISP format into STIX and to import STIX into MISP format.

Project description

MISP-STIX - Python library to handle the conversion between MISP standard and STIX

Python version MISP-STIX version Github Actions License

MISP-STIX-converter is a Python library (>=3.8) to handle all the conversions between the MISP standard format and STIX formats.

The package is available as misp-stix in PyPI.

Features

This library is used by the MISP core software to perform STIX conversion and serving as a useful tool for anyone looking for a clean way of converting between the MISP standard format and various STIX versions (1.1.1, 1.2, 2.0, 2.1).

A complete documentation is available including the mappings between the different formats.

Install from pip

It is strongly recommended to use a virtual environment

If you want to know more about virtual environments, python has you covered

From the current repository:

pip3 install misp-stix

Package details at PyPI: misp-stix

Install the latest version from the repository for development purposes

Note: poetry is strongly recommended; e.g., pip3 install poetry

git clone https://github.com/MISP/misp-stix.git && cd misp-stix
git submodule update --init
poetry install

If you already have poetry face any issue with it while installing or updating misp-stix with it, you can try pip3 install -U poetry to make sure you have a version >= 1.2

Alternatively, you can set up a virtual environment with the following:

virtualenv -p python3 venv
source ./venv/bin/activate
pip install -U pip
# Manual install of setuptools to avoid some dependencies issues
pip install setuptools
pip install .

Running the tests

Tests for MISP format export as STIX 1.1.1 & 1.2:

poetry run pytest tests/test_stix1_export.py

Tests for MISP format export as STIX 2.0:

poetry run pytest tests/test_stix20_export.py

Tests for MISP format export as STIX 2.1:

poetry run pytest tests/test_stix21_export.py

Usage

Command-line Usage

If you are not already within your virtual environment, you can either choose to prefix all the following example commands with poetry run, or simply activate your python environment:

# If you chose to use the recommended option
poetry shell

# OR

# Another option that should work if you followed the example mentioned above with the install instructions
./venv/bin/activate

At this point, you should be able to use the command-line feature. Here are a few examples:

# Convert an Events collections to STIX 2.1
misp_stix_converter export --version 2.1 -f tests/test_events_collection_1.json

# Convert a MISP Event and set a specific name for the STIX 2.1 output file
misp_stix_converter export --version 2.1 -f tests/test_event.misp.json -o tests/test_event.stix21.json

# Convert a STIX 2 Bundle to MISP, and set specific distributions
misp_stix_converter import -f tmp/test_bundle.stix21.json -o tmp/test_bundle.misp.json -d 1 -cd 1
# This will set the distribution for the Event, Attributes and Galaxy Clusters to `this community`

# Convert multiple STIX 2 Bundles to MISP and directly push the results to MISP, knowing your authentication key
misp_stix_converter import -f tmp/*.stix21.json --url https://localhost --api_key _YOUR_AUTHENTICATION_KEY_
# This will create a MISP Event for each file

Parameters

For more details on the different options presented with the examples, here is the complete description.

usage: misp_stix_converter [-h] [--debug] {export,import} ...

Convert MISP <-> STIX

options:
  -h, --help       show this help message and exit
  --debug          Show errors and warnings

Main feature:
  {export,import}
    export         Export MISP to STIX - try `misp_stix_converter export -h` for more help.
    import         Import STIX to MISP - try `misp_stix_converter import -h` for more help.
Export parameters
usage: misp_stix_converter export [-h] -f FILE [FILE ...] -v {1.1.1,1.2,2.0,2.1} [-s] [-m] [--output_dir OUTPUT_DIR] [-o OUTPUT_NAME] [--level {attribute,event}] [--format {json,xml}] [-n NAMESPACE] [-org ORG]

options:
  -h, --help            show this help message and exit
  -f FILE [FILE ...], --file FILE [FILE ...]
                        Path to the file(s) to convert.
  -v {1.1.1,1.2,2.0,2.1}, --version {1.1.1,1.2,2.0,2.1}
                        STIX specific version.
  -s, --single_output   Produce only one result file (in case of multiple input file).
  -m, --in_memory       Store result in memory (in case of multiple result files) instead of storing it in tmp files.
  --output_dir OUTPUT_DIR
                        Output path - used in the case of multiple input files when the `single_output` argument is not used.
  -o OUTPUT_NAME, --output_name OUTPUT_NAME
                        Output file name - used in the case of a single input file or when the `single_output` argument is used.

STIX 1 specific arguments:
  --level {attribute,event}
                        MISP data structure level.
  --format {json,xml}   STIX 1 format.
  -n NAMESPACE, --namespace NAMESPACE
                        Namespace to be used in the STIX 1 header.
  -org ORG              Organisation name to be used in the STIX 1 header.
Import parameters
usage: misp_stix_converter import [-h] -f FILE [FILE ...] [-v {1,2}] [-s] [-o OUTPUT_NAME] [--output_dir OUTPUT_DIR] [-d {0,1,2,3,4}] [-sg SHARING_GROUP] [--galaxies_as_tags] [--org_uuid ORG_UUID] [-cd {0,1,2,3,4}]
                                  [-cg CLUSTER_SHARING_GROUP] [-p PRODUCER] [-c CONFIG] [-u URL] [-a API_KEY] [--skip_ssl]

options:
  -h, --help            show this help message and exit
  -f FILE [FILE ...], --file FILE [FILE ...]
                        Path to the file(s) to convert.
  -v {1,2}, --version {1,2}
                        STIX major version - default is 2
  -s, --single_event    Produce only one MISP event per STIX file(in case of multiple Report, Grouping or Incident objects).
  -o OUTPUT_NAME, --output_name OUTPUT_NAME
                        Output file name - used in the case of a single input file or when the `single_output` argument is used.
  --output_dir OUTPUT_DIR
                        Output path - used in the case of multiple input files when the `single_output` argument is not used.
  -d {0,1,2,3,4}, --distribution {0,1,2,3,4}
                        Distribution level for the imported MISP content - default is 0
  -sg SHARING_GROUP, --sharing_group SHARING_GROUP
                        Sharing group ID when distribution is 4.
  --galaxies_as_tags    Import MISP Galaxies as tag names instead of the standard Galaxy format.
  --org_uuid ORG_UUID   Organisation UUID to use when creating custom Galaxy clusters.
  -cd {0,1,2,3,4}, --cluster_distribution {0,1,2,3,4}
                        Galaxy Clusters distribution level in case of External STIX 2 content - default id 0
  -cg CLUSTER_SHARING_GROUP, --cluster_sharing_group CLUSTER_SHARING_GROUP
                        Galaxy Clusters sharing group ID in case of External STIX 2 content.
  -p PRODUCER, --producer PRODUCER
                        Producer of the imported content - Please make sure you use a name from the list of existing producer Galaxy Clusters.
  -c CONFIG, --config CONFIG
                        Config file containing the URL and the authentication key to connect to your MISP.
  -u URL, --url URL     URL to connect to your MISP instance.
  -a API_KEY, --api_key API_KEY
                        Authentication key to connect to your MISP instance.
  --skip_ssl            Skip SSL certificate checking when connecting to your MISP instance.

In Python scripts

Given a MISP Event (with its metadata fields, attributes, objects, galaxies and tags), declared in an event variable in Python dict format, you can get the result of a conversion into one of the supported STIX versions:

  • Convert a MISP Event in STIX1:
from misp_stix_converter import MISPtoSTIX1EventsParser

parser = MISPtoSTIX1EventsParser(
    'MISP-Project', # Example of Org name
    '1.1.1' # STIX1 version (1.1.1 or 1.2)
)
parser.parse_misp_event(event)

stix_package = parser.stix_package
  • Convert a MISP Event in STIX1 using directly its file name:
from misp_stix_converter import misp_to_stix1

response = misp_to_stix1(
    filename, # file name of the file containing a MISP Event
    'xml', # return format (XML or JSON)
    '1.1.1' # STIX1 version (1.1.1 or 1.2)
)
# if everything went well, response is a dictionary where `success` = 1

The resulting STIX1 Package is then available in a filename.out file

  • Convert a MISP Event in STIX2:
# for STIX 2.0
from misp_stix_converter import MISPtoSTIX20Parser
# for STIX 2.1
from misp_stix_converter import MISPtoSTIX21Parser

parser20 = MISPtoSTIX20Parser()
parser20.parse_misp_event(event)

parser21 = MISPtoSTIX21Parser()
parser21.parse_misp_event(event)

# To get the list of parsed STIX objects
stix_20_objects = parser20.stix_objects
stix_21_objects = parser21.stix_objects

# To get the list of parser STIX objects within a STIX 2.0 or 2.1 Bundle
bundle20 = parser20.bundle
bundle21 = parser21.bundle
  • Convert a MISP Event in STIX2 using directly its file name:
from misp_stix_converter import misp_to_stix2

response_20 = misp_to_stix2(filename, version='2.0')
response_21 = misp_to_stix2(filename, version='2.1')
# Again response_20 & response_21 have a `success` field equal to 1 if everything went well

The resulting STIX2 Bundle is the available in a filename.out file, or you can define the output name with the output_name argument.

If you get some MISP collection of data, it is also possible to convert it straight into some STIX format:

from misp_stix_converter import MISPtoSTIX1EventsParser, MISPtoSTIX20Parser, MISPtoSTIX21Parser

filename = _PATH_TO_YOUR_FILE_CONTAINING_MISP_FORMAT_

parser1 = MISPtoSTIX1EventsParser('MISP', '1.1.1')
parser1.parse_json_content(filename)
stix_package = parser1.stix_package

parser20 = MISPtoSTIX20Parser()
parser20.parse_json_content(filename)
stix_20_objects = parser20.stix_objects
bundle20 = parser20.bundle

parser21 = MISPtoSTIX21Parser()
parser21.parse_json_content(filename)
stix_21_objects = parser21.stix_objects
bundle21 = parser21.bundle

But in order to parse multiple data collections, you can also use the following helpers:

from misp_stix_converter import misp_event_collection_to_stix1, misp_event_collection_to_stix2

input_filenames = [filename for filename in Path(_PATH_TO_YOUR_MISP_FILES_).glob('*.json')]

stix1_response = misp_event_collection_to_stix1(
    *input_filenames,
    output_name=output_filename, # path to the file where the results are going to be written
    return_format='xml', # STIX1 return format (XML or JSON)
    version='1.1.1' # STIX1 version (1.1.1 or 1.2)
)

stix20_response = misp_event_collection_to_stix2(
    *input_filenames,
    version='2.0' # STIX 2 version
)

stix21_response = misp_event_collection_to_stix2_1(
    *input_filenames,
    version='2.1',
    single_output=True, # For a single resulting file
    output_name=output_file_name, # path to the file where the results are going to be written
    in_memory=True # To keep results in memory before writing the full converted content at the end in the result file
)

Again, all the responses should have a success field equal to 1 and the resulting STIX1 Package and STIX 2.0 & 2.1 Bundles are available in the specific output file names.

Samples and examples

Various examples are provided and used by the different tests scripts in the tests directory. Those example files are showing the results of MISP format exported in the various supported STIX formats.

MISP <--> STIX Mapping

A specific documentation concerning the mapping between MISP and the various supported STIX versions is also provided in the documentation directory. You can find there all the different cases illustrated with examples.

License

misp-stix is released under a BSD 2-Clause "Simplified" License allow easy reuse with other libraries.

Copyright 2019-2023 Christian Studer
Copyright 2019-2023 CIRCL - Computer Incident Response Center Luxembourg c/o "security made in Lëtzebuerg" (SMILE) g.i.e.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
