modelbaker 3.1.1

The full model baker core

modelbaker - the library

The modelbaker library is a package containing two main areas:

• Wrapper for ili2db iliwrapper
• Modules to generate a QGIS project from it's database source and interacting with this source

This Library is the backend of the QGIS Plugin QGIS Model Baker.

Installation

pip install modelbaker

Structure

.
├── __init__.py
├── iliwrapper
│   ├── __init__.py
│   ├── globals.py
│   ├── ili2dbargs.py
│   ├── ili2dbconfig.py
│   ├── ili2dbtools.py
│   ├── ili2dbutils.py
│   ├── ilicache.py
│   ├── iliexecutable.py
│   ├── iliexporter.py
│   ├── iliimporter.py
│   ├── iliupdater.py
│   └── ilivalidator.py
├── dataobjects
│   ├── __init__.py
│   ├── fields.py
│   ├── form.py
│   ├── layers.py
│   ├── legend.py
│   ├── project.py
│   └── relations.py
├── dbconnector
│   ├── __init__.py
│   ├── config.py
│   ├── db_connector.py
│   ├── gpkg_connector.py
│   ├── mssql_connector.py
│   └── pg_connector.py
├── db_factory
│   ├── __init__.py
│   ├── db_command_config_manager.py
│   ├── db_factory.py
│   ├── db_simple_factory.py
│   ├── gpkg_command_config_manager.py
│   ├── gpkg_factory.py
│   ├── gpkg_layer_uri.py
│   ├── layer_uri.py
│   ├── mssql_command_config_manager.py
│   ├── mssql_factory.py
│   ├── mssql_layer_uri.py
│   ├── pg_command_config_manager.py
│   ├── pg_factory.py
│   └── pg_layer_uri.py
├── generator
│   ├── __init__.py
│   ├── config.py
│   ├── domain_relations_generator.py
│   └── generator.py
├── ilitoppingmaker
│   ├── __init__.py
│   ├── ili2dbsettings.py
│   ├── ilidata.py
│   ├── iliprojecttopping.py
│   ├── ilitarget.py
│   ├── metaconfig.py
└── utils
    ├── __init__.py
    ├── db_utils.py
    ├── globals.py
    ├── qgis_utils.py
    └── qt_utils.py

ili2db

In the current release we use ili2db version 4.10

Infos for Devs

Code style

Is enforced with pre-commit. To use, make:

pip install pre-commit
pre-commit install

And to run it over all the files (with infile changes):

pre-commit run --color=always --all-file

Needed packages from PyPI

Needed packages from PyPI are downloaded and packaged on deployment to the plugin's libs folder.

Run the script to download and unpack them or install them to your system.

Script:

./scripts/package_pip_packages.sh
