neatplan 0.3.0

nginx-style network configuration

neatplan

nginx-style network configuration

...pretty neat, huh?

Why, for the love of integrated circuits why you ask? Because I can.

Dependencies

• Python >= 3.6
• crossplane
• iproute2
• dhclient (optional)

Features

• Boot-time configuration
• IPv4/IPv6 support
• Loopback interface up by default (ip link set lo up)
• Set link up for a given interface (ip link set <iface> up)
• Set IP address for a given interface (ip addr add <ip/mask> dev <iface>)
• Set IP route for a given interface (ip ro add <ip> dev <iface>)
• Set default IP route for a given interface (ip ro add default via <ip> dev <iface>)
• Set via IP route for a given interface (ip ro add <ip> via <ip> dev <iface>)
• Set nameservers (/etc/resolv.conf)
• DHCP configuration (dhclient)
• Firewall configuration (iptables-restore, ip6tables-restore)
• Custom commands to run before and after for advanced and custom configuration
• Configured interfaces are being stored in /run/neatplan

Installation

Neatplan is intended for people who know what they are doing, or at least for those aware that this may result in the loss of access to the server over the network. If you're afraid of breaking things, pick something else. Although, returning to the previous network configuration method is trivial because neatplan does not introduce any invasive changes to the system. But before you start destroying your network configuration, however enjoyable it is, make sure you have access to some kind of remote (or local) console that will allow you to debug without direct SSH access.

All the scripts must be run with root privileges, as it is necessary to interact with network configuration.

PyPI

pip install neatplan

Github

git clone https://github.com/c0m4r/neatplan.git /opt/neatplan
cd /opt/neatplan
./deploy.sh

The script will:

• create the Python venv
• create a symlink to the wrapper in /usr/local/bin/neatplan
• copy the respective init script if it's available
• create a config file in /etc/neatplan/default.conf

Alpine Linux

To replace networking with neatplan at boot time:

rc-update del networking boot
rc-update add neatplan boot

Void Linux

To start neatplan as a runit service:

ln -s /etc/sv/neatplan /var/service/

Usage

Simply running neatplan will immediately set the network using default config (if present).

Dry-run

If you would like to test your configuration before actually executing it, use the dry-run mode:

neatplan --dry-run

Neatplan will only print a parsed configuration, so you can verify it before execution.

Custom config path

You can also point neatplan to a different config file using --config option:

neatplan --config /path/to/file.conf

Help

Run with --help to see this help message:

usage: neatplan [-h] [-c CONFIG] [-v] [--dry-run]

nginx-style network configuration

options:
  -h, --help            show this help message and exit
  -c CONFIG, --config CONFIG
                        Config file absolute path
  -v, --version         Show version and exit
  --dry-run             Don't execute, only show what you've got

Configuration

Config path

/etc/neatplan/default.conf

Quick example

• IPv4 using DHCP
• Static IPv6 address
• IPv6-only CloudFlare DNS

network {
    backend iproute2;
    ethernet {
        eth0 {
            dhcp4 {
                enable true;
            }
            addresses {
                address fe80:ffff:eeee:dddd::1/64;
            }
            routes {
                route fe80::1 default;
            }
        }
    }
    dns {
        nameserver 2606:4700:4700::1111;
        nameserver 2606:4700:4700::1001;
    }
}

Note that

Full feature showcase

network {
    backend iproute2;
    before {
        command "touch /tmp/neatplan";
    }
    firewall {
        iptables /etc/iptables/iptables.rules;
        ip6tables /etc/iptables/ip6tables.rules;
    }
    ethernet {
        eth0 {
            dhcp4 {
                enable true;
            }
            dhcp6 {
                enable false;
            }
            addresses {
                address fe80:ffff:eeee:dddd::1/64;
                address fe80:ffff:eeee:dddd::2/64;
                address 192.168.0.10;
                address 192.168.100.50/24;
            }
            routes {
                route fe80::1 default;
                route 192.168.0.1;
                route 1.1.1.1 via 192.168.0.1;
            }
        }
    }
    dns {
        nameserver 2606:4700:4700::1111;
        nameserver 2606:4700:4700::1001;
    }
    after {
        command "echo I\'m so custom, wow";
        command "ip link add link eth0 name eth0.1337 type vlan id 1337";
    }
}

Note that dhcp6 { enable: false; } isn't actually necessary. It's not being run by default if not enabled explicitly.

Additionally, the ability to execute custom commands within the before and after contexts can be used to run arbitrary code. Make sure only root has write access to the configuration.

Writing init scripts

• Neatplan saves all configured interfaces (including lo) at boot time to /run/neatplan. You can iterate through them or do whatever the hell you want with that information.
• When starting neatplan make sure it is started before services that rely on the network, preferably within boot runlevel (thank you captain obvious)
• If you're about to use IPv6 you have to make sure that tentative states are gone before ending a start job
• When stopping neatplan make sure to rm /run/neatplan at the end.
• Handle Python venv before executing neatplan with . /opt/neatplan/.venv/bin/activate or set the PATH=/opt/neatplan/.venv:$PATH.

See example OpenRC and runit init scripts.

Documentation

I'm not saying it's the worst documentation I wrote, but it's the worst documentation I wrote.

Contexts

name	context	description
network		root of network configuration
before	network	list of commands to run before network configuration
firewall	network	firewall configuration
ethernet	network	ethernet configuration
<iface>	network → ethernet	network interface configuration
dhcp4	network → ethernet → <iface>	DHCP v4 settings
dhcp6	network → ethernet → <iface>	DHCP v6 settings
addresses	network → ethernet → <iface>	IP addresses configuration
routes	network → ethernet → <iface>	IP routes configuration
dns	network	list of nameservers
before	network	list of commands to run after network configuration

Directives

name	context	syntax	description
backend	network	backend <name>;	IP configuration backend
command	before, after	command "<command> <args>";	Custom shell command
iptables	firewall	iptables <filepath>;	Path to iptables rules
ip6tables	firewall	ip6tables <filepath>;	Path to ip6tables rules
enable	dhcp4, dhcp6	option true | false;	Enable or disable option
address	<iface>	address <ip/mask>;	IPv4 or IPv6 address
route	<iface>	route <ip> [default | via <ip>];	IP route
nameserver	dns	nameserver <ip>;	Nameserver address
