Analysis and synthesis tools for OCCAM hPF simulations

Project description

OccamTools · Build Status Codacy Badge codecov License: GPL v3 PyPI version

Analysis and synthesis tools for OCCAM molecular dynamics/hybrid particle-field simulations.

Input to OCCAM consists mainly of three file types; fort.1 (simulation metadata), fort.3 (particle and bond parameters), and fort.5 (positions and bond structure). The output from the run is a fort.8 file, adhering to the .xyz file format. The occamtools python package provides a reader for these file formats (both input and output) and generates a single object containing all the information about the simulation, making analysis of simulation runs and comparison between runs easier.

Installation

Install by (requires python >= 3.6)

> pip install occamtools

Usage

Loading data · Loading simulation data is done by

import numpy as np
from occamtools import OccamData

data = OccamData('your/file/or/directory/here')

where the data object now holds all information about the simulation run, e.g. print what kinds of particles a simulation consists of

print('Simulation consists of...')
for type_name in data.type_dict:
    num_type = sum(data.type == data.type_dict[type_name])
    print(f'  - {num_type} particles of type {type_name}')

# Simulation consists of...
#   - 400 particles of type H
#   - 100 particles of type C
#   - 250 particles of type Ar
#   ...

or make a simple plot of particles in a section of the simulation box diffusing (requires pip install asciichartpy)

from asciichartpy import plot

indices = (data.x[0, :] > 20.0) & (data.x[0, :] < 25.0)
diffused = data.x[-1, indices]
bins, hist = np.histogram(diffused)
print(plot(bins.tolist(), hist.tolist()))

# 9.00  ┤  ╭─╮
# 8.00  ┤  │ ╰╮
# 7.00  ┤  │  │
# 6.00  ┤ ╭╯  ╰╮
# 5.00  ┤ │    ╰╮
# 4.00  ┤ │     │
# 3.00  ┤╭╯     │
# 2.00  ┤│      ╰╮
# 1.00  ┼╯       ╰

or plot the deviations of the total kinetic energy from the mean over the simulation run (again requires pip install asciichartpy)

kinetic_energy_deviations = data.kinetic_energy - np.mean(data.kinetic_energy)
print(plot(kinetic_energy_deviations.tolist()))

#  60.53  ┤            ╭╮
#  50.62  ┤            ││  ╭╮╭╮
#  40.71  ┤            ││  ││││              ╭╮
#  30.81  ┤            ││  ││││              ││     ╭╮    ╭─
#  20.90  ┤ ╭╮         ││  ││││    ╭─╮       ││     ││    │
#  10.99  ┤ ││ ╭─╮ ╭╮ ╭╯│  ││││╭╮  │ │ ╭╮    ││     ││    │
#  10.09  ┤ ││ │ │ ││ │ │  │││││╰╮ │ ╰╮││    ││ ╭╮  ││╭╮╭╮│
#   0.18  ┼╮││ │ │ ││ │ ╰╮ │││╰╯ │ │  ╰╯│╭╮  │╰╮││╭╮│││││││
# -00.73  ┤│││ │ │ ││ │  ╰─╯││   │╭╯    ││╰──╯ ╰╯││││││││││
# -10.64  ┤│││╭╯ │ ││╭╯     ││   ││     ╰╯       ││││││││╰╯
# -20.54  ┤││╰╯  │ │╰╯      ╰╯   ╰╯              ││││││╰╯
# -30.45  ┤╰╯    ╰─╯                             ││││╰╯
# -40.36  ┤                                      ││││
# -50.26  ┤                                      ││╰╯
# -60.17  ┤                                      ╰╯

File storage · Behind the scenes, .npy (for numpy arrays) and .json (for anything else) files are used to represent the simulation data. By default, loading a simulation run causes the saving of small (relative to the original fort.5/7/8) binary files containing the data. These are used to load from on subsequent calls. This means calls to OccamData.load('your/file/here') of OccamData('your/file/here') will be significantly faster after the first call. In this specific example, a 25x speedup is achieved (but your mileage may vary). load example

Running tests with tox

Assuming python 3.7 is already installed, install separate 3.6 and 3.8 instances using pyenv by

> brew install pyenv
> pyenv install 3.6.6
> pyenv install 3.8-dev

and then inside the occamtools directory do

> git clone git@github.com:mortele/OccamTools.git occamtools
> cd occamtools
> pyenv local 3.6.6 3.8-dev
> pip3 install tox-pyenv
> tox

which will run unit tests (using pytest) with python versions 3.6, 3.7, and the 3.8 development build.

OCCAM

OCCAM is a program for Molecular Dynamics Simulations able to perform Hybrid Particle-Field (PF) Theoretical Molecular Dynamics simulations. This recent PF technique combines molecular dynamics (MD) and self consistent field theory (SCF). Read more.

occam-website

Changelog

0.3.3: Add option to not save .npy files when loading OccamData objects. Fix a bug causing errors when reading very short .xyz files. Fix a bug causing the grid size to not correctly update when using replace_in_fort3.
0.3.2: Add testing with python alpha version 3.8-dev, stream line travis integration and coverage reporting.
0.3.1: Move the bins keyword argument to histogram from an explicit argument to **kwargs handled by np.histogram.
0.3.0: Add histogram computation capabilities.
0.2.7: Add the velocity_traj flag to fort1 file reader.
0.2.6: Add proper testing for python 3.6 and 3.7 using tox.
0.2.5: Change python version required to >=3.6 (from >=3.7).
0.2.4: Add functionality for reading .xyz files with additional velocity information, as output by OCCAM when the velocity_traj flag is set in fort.1.
0.2.3: Code clean-up.
0.2.2: Extend repace_in_fort3 to allow for changing compressibility and non-bonded interactions. Fix a bug causing new particle types added to break the chi matrix when writing fort.3 files.
0.2.1: Update the __all__ variable of __init__.py to reflect newly added classes and methods.
0.2.0: Add functionality for editing fort.3 files (in-place or creating new ones).
0.1.0: Add functionality for editing fort.1 files (in-place or creating new ones).
