Project description
Piceli
Infrastructure management for python
Documentation: https://docs.piceli.pynenc.org
Source Code: https://github.com/pynenc/piceli
Piceli simplifies Kubernetes object management and deployment, streamlining the process of configuring and applying Kubernetes resources. With Piceli, developers can define Kubernetes objects using Python, manage configurations efficiently, and deploy them to clusters with ease.
Key Features
-
Effortless Kubernetes Object Management: Easily define Kubernetes resources in Python, with support for custom objects and configurations.
-
Simplified Deployment Workflow: Piceli provides tools for planning, detailing, and executing deployments directly from your terminal, offering clear insights into the deployment process.
-
Intuitive CLI: The Piceli CLI enhances your Kubernetes management experience, offering commands to list models, plan deployments, and more.
-
Extensive Documentation: Get up and running quickly with detailed guides and examples in the Piceli documentation.
Installation
To install Piceli, simply use pip:
pip install piceli
This will install Piceli and its dependencies, preparing you for your Kubernetes management tasks.
Quick Start Example
First define your kubernetes objects using piceli's templates:
from piceli.k8s import templates
my_cron_job = templates.CronJob(
name="example-cronjob",
schedule=templates.crontab.daily_at_x(hour=6, minute=0),
labels={"app": "myapp"},
backoff_limit=2,
)
Objects from the official kubernetes library:
from kubernetes import client
def create_service_example(name, labels, ports, selector):
# Define the Kubernetes Service
service = client.V1Service(
api_version="v1",
kind="Service",
metadata=client.V1ObjectMeta(
name=name,
labels=labels
),
spec=client.V1ServiceSpec(
ports=ports,
type="ClusterIP",
selector=selector
)
)
return service
Or a yaml or json file:
apiVersion: v1
kind: Service
metadata:
name: test-service
labels:
service: test-service
component: test-service
spec:
ports:
- name: test-service
port: 5432
targetPort: 5432
- name: test-service-2
port: 5433
targetPort: 5434
type: ClusterIP
selector:
pod_name: pod-to-select
Then explore the defined kubernetes object with the CLI:
piceli --folder-path=/folder/to/resources model list
╭───────────────────────────────── Command Execution ─────────────────────────────────╮
│ Running command: List Kubernetes Objects Model │
╰─────────────────────────────────────────────────────────────────────────────────────╯
╭───────────────────────── Context Options ─────────────────────────╮
│ Namespace: default │
│ Module Name: Not specified │
│ Module Path: Not specified │
│ Folder Path: /folder/to/resources │
│ Include Sub-elements: True │
╰───────────────────────────────────────────────────────────────────╯
┏━━━━━━━━━━━━━━━━━━┳━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ Name ┃ Kind ┃ Namespace ┃ Origin ┃
┡━━━━━━━━━━━━━━━━━━╇━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ some-scheduler │ Job │ Default │ OriginYAML(path='/folder/to/resources │
│ task-scheduler │ Job │ Default │ OriginYAML(path='/folder/to/resources │
│ task-worker │ Job │ Default │ OriginYAML(path='/folder/to/resources │
│ other-job │ Job │ Default │ OriginYAML(path='/folder/to/resources │
└──────────────────┴──────┴───────────┴───────────────────────────────────────────────┘
The automatic deployment plan with the different steps
PICELI__FOLDER_PATH=/folder/to/resources/tmp_cli PICELI__NAMESPACE=test-run piceli deploy plan
╭───────────────────────────────── Command Execution ─────────────────────────────────╮
│ Running command: Deployment Plan │
╰─────────────────────────────────────────────────────────────────────────────────────╯
╭────────────────────────────── Context Options ───────────────────────────────╮
│ Namespace: test-run │
│ Module Name: Not specified │
│ Module Path: Not specified │
│ Folder Path: /folder/to/resources/tmp_cli │
│ Include Sub-elements: True │
╰──────────────────────────────────────────────────────────────────────────────╯
Kubernetes Deployment Plan
┣━━ Step 1:
┃ ┣━━ Role example-role in namespace default
┃ ┣━━ ServiceAccount example-serviceaccount in namespace default
┃ ┗━━ StorageClass resizable in namespace default
┣━━ Step 2:
┃ ┗━━ RoleBinding example-rolebinding in namespace default
┣━━ Step 3:
┃ ┣━━ Secret example-secret in namespace default
┃ ┗━━ ConfigMap example-configmap in namespace default
┣━━ Step 4:
┃ ┗━━ PersistentVolumeClaim example-persistentvolumeclaim in namespace default
┣━━ Step 5:
┃ ┗━━ Deployment example-deployment in namespace default
┣━━ Step 6:
┃ ┗━━ Service example-service in namespace default
┣━━ Step 7:
┃ ┗━━ CronJob example-cronjob in namespace default
┗━━ Step 8:
┗━━ HorizontalPodAutoscaler example-horizontalpodautoscaler in namespace default
A detail view of all the changes that the deployment will do in the cluster:
PICELI__FOLDER_PATH=/folder/to/resources/tmp_cli PICELI__NAMESPACE=test-run piceli deploy detail
╭───────────────────────────────── Command Execution ─────────────────────────────────╮
│ Running command: Deployment Detailed Analysis │
╰─────────────────────────────────────────────────────────────────────────────────────╯
╭────────────────────────────── Context Options ───────────────────────────────╮
│ Namespace: test-run │
│ Module Name: Not specified │
│ Module Path: Not specified │
│ Folder Path: /folder/to/resources/tmp_cli │
│ Include Sub-elements: True │
╰──────────────────────────────────────────────────────────────────────────────╯
New Kubernetes Objects
┏━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━┓
┃ Kind ┃ Name ┃ Version ┃ Group ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━┩
│ Role │ example-role │ v1 │ RbacAuthorization │
│ ServiceAccount │ example-serviceaccount │ v1 │ Core │
│ RoleBinding │ example-rolebinding │ v1 │ RbacAuthorization │
│ Secret │ example-secret │ v1 │ Core │
│ ConfigMap │ example-configmap │ v1 │ Core │
│ PersistentVolumeClaim │ example-persistentvolumecl… │ v1 │ Core │
│ Deployment │ example-deployment │ v1 │ Apps │
│ Service │ example-service │ v1 │ Core │
│ CronJob │ example-cronjob │ v1 │ Batch │
│ HorizontalPodAutoscaler │ example-horizontalpodautos… │ v2 │ Autoscaling │
└─────────────────────────┴─────────────────────────────┴─────────┴───────────────────┘
Kubernetes Objects Deployment Summary
┏━━━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━┓
┃ Kind ┃ Name ┃ Update Action ┃
┡━━━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━┩
│ StorageClass │ resizable │ No action needed │
└──────────────┴───────────┴──────────────────┘
───────────────────── StorageClass resizable - No action needed ──────────────────────
┏━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┓
┃ Existing Object ┃ Desired Object ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┩
│ { │ { │
│ "allowVolumeExpansion": true, │ "allowVolumeExpansion": true, │
│ "apiVersion": "storage.k8s.io/v1", │ "apiVersion": "storage.k8s.io/v1", │
│ "kind": "StorageClass", │ "kind": "StorageClass", │
│ "metadata": { │ "metadata": { │
│ "creationTimestamp": │ "name": "resizable" │
│ "2024-03-06T18:01:30+00:00", │ }, │
│ "managedFields": [ │ "provisioner": │
│ { │ "k8s.io/minikube-hostpath" │
│ "apiVersion": │ } │
│ "storage.k8s.io/v1", │ │
│ "fieldsType": "FieldsV1", │ │
│ "fieldsV1": { │ │
│ "f:allowVolumeExpansion": {}, │ │
│ "f:provisioner": {}, │ │
│ "f:reclaimPolicy": {}, │ │
│ "f:volumeBindingMode": {} │ │
│ }, │ │
│ "manager": "OpenAPI-Generator", │ │
│ "operation": "Update", │ │
│ "time": │ │
│ "2024-03-06T18:01:30+00:00" │ │
│ } │ │
│ ], │ │
│ "name": "resizable", │ │
│ "resourceVersion": "176636", │ │
│ "uid": │ │
│ "9ef7f7b7-8733-40b5-9e56-ee2f555823a5" │ │
│ }, │ │
│ "provisioner": │ │
│ "k8s.io/minikube-hostpath", │ │
│ "reclaimPolicy": "Delete", │ │
│ "volumeBindingMode": "Immediate" │ │
│ } │ │
└──────────────────────────────────────────┴──────────────────────────────────────────┘
Differences Summary
┏━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━━┳━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━┳━━━━━━━━━┓
┃ Path ┃ Type ┃ Existing ┃ Desired ┃
┡━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━━╇━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━╇━━━━━━━━━┩
│ metadata,creationTimestamp │ Ignored │ 2024-03-06T18:01:30+00:00 │ None │
├────────────────────────────┼──────────┼───────────────────────────────────┼─────────┤
│ metadata,managedFields │ Ignored │ [ │ None │
│ │ │ { │ │
│ │ │ "apiVersion": │ │
│ │ │ "storage.k8s.io/v1", │ │
│ │ │ "fieldsType": "FieldsV1", │ │
│ │ │ "fieldsV1": { │ │
│ │ │ "f:allowVolumeExpansion": │ │
│ │ │ {}, │ │
│ │ │ "f:provisioner": {}, │ │
│ │ │ "f:reclaimPolicy": {}, │ │
│ │ │ "f:volumeBindingMode": {} │ │
│ │ │ }, │ │
│ │ │ "manager": │ │
│ │ │ "OpenAPI-Generator", │ │
│ │ │ "operation": "Update", │ │
│ │ │ "time": │ │
│ │ │ "2024-03-06T18:01:30+00:00" │ │
│ │ │ } │ │
│ │ │ ] │ │
├────────────────────────────┼──────────┼───────────────────────────────────┼─────────┤
│ metadata,uid │ Ignored │ 9ef7f7b7-8733-40b5-9e56-ee2f5558… │ None │
├────────────────────────────┼──────────┼───────────────────────────────────┼─────────┤
│ metadata,resourceVersion │ Ignored │ 176636 │ None │
├────────────────────────────┼──────────┼───────────────────────────────────┼─────────┤
│ volumeBindingMode │ Defaults │ Immediate │ None │
├────────────────────────────┼──────────┼───────────────────────────────────┼─────────┤
│ reclaimPolicy │ Defaults │ Delete │ None │
└────────────────────────────┴──────────┴───────────────────────────────────┴─────────┘
And finally run the deployment and follow the step by step process, that will rollback to the previous state if anything unexpected happens.
PICELI__FOLDER_PATH=/folder/to/resources/tmp_cli PICELI__NAMESPACE=test-run piceli deploy run
╭───────────────────────────────── Command Execution ─────────────────────────────────╮
│ Running command: Running Deployment │
╰─────────────────────────────────────────────────────────────────────────────────────╯
Namespace 'test-run' created successfully.
╭───────────────────────────── Execution Status: PENDING ─────────────────────────────╮
│ Starting the deployment process. │
╰─────────────────────────────────────────────────────────────────────────────────────╯
────────────────────────────────── Starting Level 0 ──────────────────────────────────
Applying Level 0
───────────────────────────────────────────────────────────────────────
Name Kind Group Version
───────────────────────────────────────────────────────────────────────
example-role Role RbacAuthorization v1
example-serviceaccount ServiceAccount Core v1
resizable StorageClass Storage v1
───────────────────────────────────────────────────────────────────────
╭───────────────────────────── Execution Status: PENDING ─────────────────────────────╮
│ Starting the deployment process. │
╰─────────────────────────────────────────────────────────────────────────────────────╯
────────────────────────────────── Starting Level 0 ──────────────────────────────────
Applying Level 0
───────────────────────────────────────────────────────────────────────
Name Kind Group Version
───────────────────────────────────────────────────────────────────────
example-role Role RbacAuthorization v1
example-serviceaccount ServiceAccount Core v1
resizable StorageClass Storage v1
───────────────────────────────────────────────────────────────────────
Role example-role - Applying object
Role example-role - New object, will be created.
Role example-role - Application completed.
ServiceAccount example-serviceaccount - Applying object
ServiceAccount example-serviceaccount - New object, will be created.
ServiceAccount example-serviceaccount - Application completed.
StorageClass resizable - Applying object
StorageClass resizable - Comparing existing object...
Existing object matches the desired spec; no action needed.
StorageClass resizable - Application completed.
Completed Level 0
─────────────────────────────────────────────────────
Name Kind Status
─────────────────────────────────────────────────────
example-role Role Completed
example-serviceaccount ServiceAccount Completed
resizable StorageClass Completed
─────────────────────────────────────────────────────
──────────────────────────── Level Completed Successfully ────────────────────────────
────────────────────────────────── Starting Level 1 ──────────────────────────────────
Applying Level 1
─────────────────────────────────────────────────────────────────
Name Kind Group Version
─────────────────────────────────────────────────────────────────
example-rolebinding RoleBinding RbacAuthorization v1
─────────────────────────────────────────────────────────────────
RoleBinding example-rolebinding - Applying object
RoleBinding example-rolebinding - New object, will be created.
RoleBinding example-rolebinding - Application completed.
Completed Level 1
───────────────────────────────────────────────
Name Kind Status
───────────────────────────────────────────────
example-rolebinding RoleBinding Completed
───────────────────────────────────────────────
──────────────────────────── Level Completed Successfully ────────────────────────────
────────────────────────────────── Starting Level 2 ──────────────────────────────────
Applying Level 2
─────────────────────────────────────────────────
Name Kind Group Version
─────────────────────────────────────────────────
example-secret Secret Core v1
example-configmap ConfigMap Core v1
─────────────────────────────────────────────────
Secret example-secret - Applying object
ConfigMap example-configmap - Applying object
Secret example-secret - New object, will be created.
Secret example-secret - Application completed.
ConfigMap example-configmap - New object, will be created.
ConfigMap example-configmap - Application completed.
Completed Level 2
───────────────────────────────────────────
Name Kind Status
───────────────────────────────────────────
example-secret Secret Completed
example-configmap ConfigMap Completed
───────────────────────────────────────────
──────────────────────────── Level Completed Successfully ────────────────────────────
────────────────────────────────── Starting Level 3 ──────────────────────────────────
Applying Level 3
─────────────────────────────────────────────────────────────────────────
Name Kind Group Version
─────────────────────────────────────────────────────────────────────────
example-persistentvolumeclaim PersistentVolumeClaim Core v1
─────────────────────────────────────────────────────────────────────────
PersistentVolumeClaim example-persistentvolumeclaim - Applying object
PersistentVolumeClaim example-persistentvolumeclaim - New object, will be created.
PersistentVolumeClaim example-persistentvolumeclaim - Application completed.
Completed Level 3
───────────────────────────────────────────────────────────────────
Name Kind Status
───────────────────────────────────────────────────────────────────
example-persistentvolumeclaim PersistentVolumeClaim Completed
───────────────────────────────────────────────────────────────────
──────────────────────────── Level Completed Successfully ────────────────────────────
────────────────────────────────── Starting Level 4 ──────────────────────────────────
Applying Level 4
───────────────────────────────────────────────────
Name Kind Group Version
───────────────────────────────────────────────────
example-deployment Deployment Apps v1
───────────────────────────────────────────────────
Deployment example-deployment - Applying object
Deployment example-deployment - New object, will be created.
Deployment example-deployment - Application completed.
Completed Level 4
─────────────────────────────────────────────
Name Kind Status
─────────────────────────────────────────────
example-deployment Deployment Completed
─────────────────────────────────────────────
──────────────────────────── Level Completed Successfully ────────────────────────────
────────────────────────────────── Starting Level 5 ──────────────────────────────────
Applying Level 5
─────────────────────────────────────────────
Name Kind Group Version
─────────────────────────────────────────────
example-service Service Core v1
─────────────────────────────────────────────
Service example-service - Applying object
Service example-service - New object, will be created.
Service example-service - Application completed.
Completed Level 5
───────────────────────────────────────
Name Kind Status
───────────────────────────────────────
example-service Service Completed
───────────────────────────────────────
──────────────────────────── Level Completed Successfully ────────────────────────────
────────────────────────────────── Starting Level 6 ──────────────────────────────────
Applying Level 6
─────────────────────────────────────────────
Name Kind Group Version
─────────────────────────────────────────────
example-cronjob CronJob Batch v1
─────────────────────────────────────────────
CronJob example-cronjob - Applying object
CronJob example-cronjob - New object, will be created.
CronJob example-cronjob - Application completed.
╭───────────────────────────────────╮
│ Deployment completed successfully │
╰───────────────────────────────────╯
Deployment ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 100% 0:00:00
For more information and detailed guides, check out the Piceli Documentation.
Requirements
Piceli aims to work seamlessly with your existing Kubernetes setup. Ensure you have kubectl configured and access to a Kubernetes cluster.
Contributing
We welcome contributions and feedback to help improve Piceli! Whether it's feature requests, bug reports, or code contributions, please feel free to reach out through our GitHub Issues page.
License
Piceli is made available under the MIT License.
Release history Release notifications | RSS feed
Download files
Download the file for your platform. If you're not sure which to choose, learn more about installing packages.
Source Distribution
piceli-0.0.4.tar.gz
(72.1 kB
view hashes)
Built Distribution
piceli-0.0.4-py3-none-any.whl
(98.0 kB
view hashes)
