Pacote Open Source desenvolvido no Brasil para modelar e simular Sistemas Elétricos de Potência. Open Source Package developed in Brazil to model and simulate Electric Power Systems

Project description

pySEP

PyPI PyPI - Python Version PyPI - License PyPI - Status PyPI - Downloads GitHub followers


A ideia principal deste pacote é fornecer, em livre licença, uma série de ferramentas capazes de modelar e simular Sistemas Elétricos de Potência.

Para isso, a presente versão possibilita a seguinte operação:

  • Cálculo do Fluxo de Potência pelo método de Newton-Raphson de um sistema com n barras.

Uma série de novas ferramentas serão disponibilizadas em novas versões, tais como:

  • Cálculo de curto-circuitos entre barras.
  • Cálculo de curto-circuito em linhas.
  • Cálculos relacionados a Sistemas de Transmissão.
  • Cálculos relacionados a Sistemas de Distribuição.

Entre outras ferramentas.

This package, pySEP, is a package created to assist in the Electric Power Systems learning, modelling and simulating.

The application of the Newton-Raphson method for the calculation of power flow in electrical power systems is an example of how it works.


Youtube

Uma playlist foi criada no YouTube para mostrar a ideia básica de modelagem do código do fluxo de potência pelo método de Newton-Raphson. Está disponível no link a seguir.

A playlist was created to show how the code of the Power Flow by Newton-Raphson method was created. It is available in:

enter image description here

FLUXO DE POTÊNCIA POR NEWTON-RAPHSON EM PYTHON


Getting Started

Para a correta execução deste pacote, recomenda-se que seja utilizada uma versão 3.x do Python.

For the correct working of this library, it is only required that, on the machine where this package is installed, the Python interpreter is also installed, with versions 3.x onwards being recommended.

Installing

A step-by-step guide on how to install this package is described below.

First, using the python pip, just type the following command.

pip install pySEP

After that, the package is installed where you configured the installation of it. Therefore, to use the circuit modeling tool to perform the calculations, write this command in the program in which the calculation will be created.

import pySEP

For example

import pySEP as psp

c = psp.circuit_cmd(sBase=100e6)

c.addBarra(1, 1, 1.05, 0, 0 + 0 * 1j, 0 + 0 * 1j)
c.addBarra(2, 2, 1.00, 0, 256.6e6 + 110.2e6 * 1j, 0 + 0 * 1j)
c.addBarra(3, 2, 1.00, 0, 138.6e6 + 45.2e6 * 1j, 0 + 0 * 1j)

c.addLinha(1, 2, z_ij=0.02 + 0.04j)
c.addLinha(1, 3, z_ij=0.01 + 0.03j)
c.addLinha(2, 3, z_ij=0.0125 + 0.025j)

c.calcular_fluxo_pot_nr(erro=0.01, show=False)

c.relatorio(show_tensoes=True, show_correntes=True, show_fluxo=True)

c.perdas()

c.plot_conv(tensao=True, ang=True)

The above example is enough to create a circuit with 3 buses and 4 lines, to calculate the load flow (power flow by newton-raphson method) in it and to show the results with a graphical description.

Interface Gráfica do pySEP -- GUI of the pySEP

import pySEP

pySEP.run_gui()

enter image description here

The same before example can be executed with the GUI of the pySEP. This GUI was developed with theoretical graph.

To use the pySEP GUI, please, download this package in this link.

enter image description here

Built With

All the code in this package uses only three external packages. These are:

  • NumPy - NumPy is the fundamental package for scientific computing with Python.
  • MatPlotLib - Matplotlib is a comprehensive library for creating static, animated, and interactive visualizations in Python.
  • NetworkX - NetworkX is a Python package for the creation, manipulation, and study of the structure, dynamics, and functions of complex networks.

All others libraries used in this code are Python builtins.

Versioning

All versions of this package are "committed" and are available on my GitHub

Author

License

This project is licensed under the Apache License - see the LICENSE.txt file for details
