pyamasicp 0.2.0

Client for iiyama TV rs232 over lan protocol

iiyama rs232 SICP

Library to control iiama TV over LAN using rs232 serial interface communication protocol.

Supported features depend on the model of the TV.

Commands

Hex Code	Type	Description	Additional Information
0x00		Communication Control	Generic report
0x15	Get	Serial Code
0x18	Set	Power state
0x19	Get	Power state
0x1C	Set	User Input Control
0x1D	Get	User Input Control
0x32	Set	Video parameters
0x33	Get	Video parameters	Brightness, etc.
0x34	Set	Color temperature
0x35	Get	Color temperature
0x36	Set	Color parameters
0x37	Get	Color parameters
0x3A	Set	Picture Format
0x3B	Get	Picture Format
0x42	Set	Audio parameters
0x43	Get	Audio parameters
0x44	Set	Volume
0x45	Get	Volume
0x5A	Set	Scheduling
0x5B	Get	Scheduling
0x70		Auto Adjust	VGA only
0xAC	Set	Input Source
0xAD	Get	Current Source
0xAE	Set	Auto Signal Detecting
0xAF	Get	Auto Signal Detecting
0xA2	Get	Platform and version labels
0xA3		Power state at cold start
0xB1	Get	Pixel Shift
0xB2	Set	Pixel Shift
0xB8	Set	Volume limits
0xC0	Get	Language
0xC1	Set	Language
0xDB		IR Remote
0x0F		Miscellaneous info	Operating hours

IR codes

Hex Code	IR Code
0xA0	Power
0xA1	Menu
0xA2	Input
0xA3	Vol_Up
0xA4	Vol_Down
0xA5	Mute
0xA6	Cursor_Up
0xA7	Cursor_Down
0xA8	Cursor_Left
0xA9	Cursor_Right
0xB1	OK
0xB2	Return
0xC1	Red
0xC2	Green
0xC3	Yellow
0xC4	Blue
0xD1	Format
0xD2	Info
0x00	Btn_0
0x01	Btn_1
0x02	Btn_2
0x03	Btn_3
0x04	Btn_4
0x05	Btn_5
0x06	Btn_6
0x07	Btn_7
0x08	Btn_8
0x09	Btn_9

Input sources

Hex Code	Input Source
0x00	Card DVI-D
0x00	Card OPS
0x00	COMPONENT
0x00	HDMI
0x00	VGA
0x00	VIDEO
0x01	CVI 2 (not applicable)
0x01	Display Port
0x01	DVI-D
0x01	S-VIDEO
0x01	USB
0x01	VIDEO
0x02	S-VIDEO
0x03	COMPONENT
0x03	CVI 2 (not applicable)
0x04	CVI 2 (not applicable)
0x05	VGA
0x06	HDMI 2
0x07	Card DVI-D
0x07	Display Port
0x07	Display Port 2
0x08	Card OPS
0x08	USB
0x08	USB 2
0x09	Card DVI-D
0x09	DVI-D
0x09	HDMI
0x0A	Display Port 1
0x0B	Card OPS
0x0C	USB 1
0x0D	HDMI
0x0d	HDMI 1
0x0E	DVI-D
0x0F	HDMI 3
0x10	BROWSER
0x11	SMARTCMS
0X12	DMS (Digital Media Server)
0x13	INTERNAL STORAGE
0x14	Reserved
0x15	Reserved
0x16	Media Player
0x17	PDF Player
0x18	Custom
0x19	HDMI 4
