pybees 0.0.4

A research toolkit for the Bees algorithm in Python

pybees: Python optimization toolkit using the bees algorithm

What is it?

pybees is a Python package for function optimization. It uses the nature inspired bees algorithm, proposed by Pham et al. and is built on top of SciPy. pybees is distributed under the 3-Clause BSD license.

The bees algorithm is a swarm based search algorithm, which mimics the food foraging behaviour of honey bees. The basic algorithm is suitable for both continuous and combinatorial optimization problems, which is demonstrated in the basic examples section.

Main features

• High-level API to optimize continuous functions (training a multilayer perceptron).

• High-level API to optimize discrete functions (traveling salesperson problem).

• Built in single-objective cost functions.

• plotly plotting tools for 2D and 3D (both continuous and discrete).

• Extensible API for developing new ideas.

Where to get it

If all dependencies are already installed, then the easiest way to install pybees is using pip.

pip install pybees

How to use it

Please visit the examples folder to view the demonstration examples. These include.

• Continuous function optimization (levy, drop_wave and michalewicz)
• Combinatorial function optimization (travelling salesperson problem)

Future examples will include

• Multilayer perceptron

Dependencies

pybees requires:

• numpy >= 1.17.4

• scipy >= 1.3.2

• plotly >= 4.4.1

• tqdm >= 4.40.2

• sklearn >= 0.22

• pandas >= 0.25.3


License

BSD 3

Basic Examples

Continuous function optimization

import pybees as pb

sbc = pb.SimpleBeesContinuous(
    n_scout_bees = 50,
    elite_site_params = (15, 40),
    best_site_params = (15, 30),
    bounds = (-10,10),
    n_dim = 2,
    nbhd_radius = 2
)

This operation returns a scipy.optimize.OptimizeResult. fun represents the value of the objective function (lowest point). nit represents the number of iterations taken. x represents the coordinates of the value found for the objective function.

>>> sbc.optimize(pb.levy)
fun: 1.007063464503951e-06
nit: 100
x: array([0.99905553, 0.99967304])

The results may also be visualised by using the following

sbc.plot(global_min = (1, 1))

Combinatorial optimization (e.g. travelling salesperson problem)

import pybees as pb

sbd = pb.SimpleBeesDiscrete(
    n_scout_bees = 50,
    elite_site_params = (15, 40),
    best_site_params = (15, 30),
    coordinates = np.random.randint(10, size=[10, 2])
)

This operation returns a scipy.optimize.OptimizeResult result. res.coordinates represents sbd.coordinates reordered, resulting from the optimization of some objective function. In this example, tour_distance was minimized. As such, coordinates represents the sequence, corresponding to the shortest path between all coordinates (i.e. travelling salesperson problem). fun represents the value of the objective function (shortest distance). nit represents the number of iterations taken. x represents the permutation of the original sequence passed to SimpleBeesDiscrete which gives the shortest distance.

>>> sbd.optimize(pb.tour_distance)
coordinates: array([
       [7., 8.],
       [4., 8.],
       [2., 6.],
       [0., 5.],
       [1., 0.],
       [3., 2.],
       [2., 4.],
       [3., 4.],
       [5., 4.],
       [7., 4.]])
fun: 27.228009718084742
nit: 100
x: array([1., 9., 7., 5., 0., 3., 4., 6., 2., 8.])

The results may also be visualised by using the following

sbd.plot()
