pybud 0.2.3

A Python tool that generates video visualizations for source code debugging.

PyBud

PyBud is a Python debugging and profiling tool that generates videos of step-by-step code execution.

Here's a PyBud video output from debugging the usage example below!

Installation

Use the package manager pip to install PyBud.

pip install pybud

Usage Example

Usage

Once installed, running pybud --help will give you an overview of how to use PyBud.

Here's the help output:

$ pybud -h
usage: pybud [-h] [-t] [-d FILE] [-f FUNCTION [FUNCTION ...]] [-o FILE] [-v [FILE]] [-c CONFIG] [-p [FILE]]

A Python debugger for analyzing and profiling functions. Created by Eastan Giebler.

optional arguments:
  -h, --help            show this help message and exit
  -t, --test            Test PyBud on a suite of sorting, searching, and similar algorithms. Outputs a PyBud JSON for each function in the
                        'pybud/test/test_logs' package.

Debugging:
  Debug a python function and generate an output log.

  -d FILE, --debug FILE
                        Path to the Python file you wish to debug.
  -f FUNCTION [FUNCTION ...], --function FUNCTION [FUNCTION ...]
                        The function in the Python file you wish to debug, along with the arguments you wish to pass. Defaults to the main
                        function if argument not used. EXAMPLE: '--function test 2 4' will call 'test(2,4)'.
  -o FILE, --output FILE
                        Optional: Path to write the json log file to. Defaults to output.pybud if argument not used.
  -v [FILE], --video [FILE]
                        Generate a video rendering for the PyBud debug steps of the program flow. Optional: provide a filepath to output to,
                        mp4 is the only supported format, defaults to output.mp4.
  -c CONFIG, --video-cfg CONFIG
                        Path to the YAML video config file you wish to use, default configuration will be loaded if not specified.

Parsing and Analysis:
  Parse a PyBud JSON output and display in human-readable form.

  -p [FILE], --parse [FILE]
                        Path to the json log you wish to parse into human-readable form. Defaults to output.pybud if a file is not specified.
  -v [FILE], --video [FILE]
                        Generate a video rendering for the PyBud debug steps of the program flow. Optional: provide a filepath to output to,
                        mp4 is the only supported format, defaults to output.mp4.
  -c CONFIG, --video-cfg CONFIG
                        Path to the YAML video config file you wish to use, default configuration will be loaded if not specified.

Contributing

Pull requests are welcome. For major changes, please open an issue first to discuss what you would like to change.

License

MIT
