Overview

Pyrandwalk is an educational tool for simulating random walks, calculating the probability of given state sequences, etc. Random walk is a representation of the discrete-time, discrete-value Markov chain model used in stochastic processes.

PyPI Counter
Github Stars

Branch	master	dev
CI

Installation

Source code

• Download Version 1.1 or Latest Source
• Run pip install -r requirements.txt or pip3 install -r requirements.txt (Need root access)
• Run python3 setup.py install or python setup.py install (Need root access)

PyPI

• Check Python Packaging User Guide
• Run pip install pyrandwalk or pip3 install pyrandwalk (Need root access)

Usage

>>> from pyrandwalk import *
>>> import numpy as np
>>> states = [0, 1, 2, 3, 4]
>>> trans = np.array([[1,    0, 0,    0, 0],
...                   [0.25, 0, 0.75, 0, 0],
...                   [0, 0.25, 0, 0.75, 0],
...                   [0, 0, 0.25, 0, 0.75],
...                   [0, 0,    0, 1,    0]])
>>> rw = RandomWalk(states, trans)

We are simulating random walks on the above graph (weights are probabilities):

Probability of A Sequence

Imagine you want to calculate probability which you start from state 2, go to state 1 and stuck in state 0. What's the probability of these walk sequences?

>>> rw.prob_sec([2, 1, 0])
0.0125

Initial probability distribution is assumed to be uniform by default but you can change it by passing optional argument initial_dist:

>>> rw.prob_sec([2, 1, 0], initial_dist=[0, 0, 1, 0, 0])
0.0625

Run a random walk

You can start a random walk on given markov chain and see the result:

>>> states, probs = rw.run()
>>> states
[4, 3, 4, 3, 4, 3, 4, 3, 2, 3, 4]
>>> probs
[0.2, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.25, 0.75, 0.75]

By default your random walk will contain 10 steps, but you can change it by passing optional argument ntimes:

>>> states, probs = rw.run(ntimes=20)
>>> states
[3, 4, 3, 4, 3, 2, 1, 2, 3, 4, 3, 4, 3, 4, 3, 4, 3, 4, 3, 2, 3]
>>> probs
[0.2, 0.75, 1.0, 0.75, 1.0, 0.25, 0.25, 0.75, 0.75, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.25, 0.75]

And if you want to see what's going on down there during the simulation you can set the show flag:

>>> states, probs = rw.run(ntimes=30, show=True)
1 --> 2  (p = 0.750)
2 --> 3  (p = 0.750)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 2  (p = 0.250)
2 --> 1  (p = 0.250)
1 --> 2  (p = 0.750)
2 --> 3  (p = 0.750)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 4  (p = 0.750)
4 --> 3  (p = 1.000)
3 --> 2  (p = 0.250)
2 --> 3  (p = 0.750)
>>> states
[1, 2, 3, 4, 3, 4, 3, 4, 3, 4, 3, 4, 3, 4, 3, 2, 1, 2, 3, 4, 3, 4, 3, 4, 3, 4, 3, 4, 3, 2, 3]
>>> probs
[0.2, 0.75, 0.75, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.25, 0.25, 0.75, 0.75, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.75, 1.0, 0.25, 0.75]

Final Probability Distribution

You can easily find out the final probability distribution of you random walk by:

>>> rw.final_dist()
array([1., 0., 0., 0., 0.])

Which implies that the walk will in state 0 for sure as time goes on.

Is it irreducible?

You can check if your Markov chain is irreducible to lower rank ones or not by:

>>> rw.is_irreducible()
False

nth transition matrix

If you want to see what's the probability of moving from state i to j with n steps, you can easily calculate the nth transition matrix by:

>>> rw.trans_power(2)
array([[1.    , 0.    , 0.    , 0.    , 0.    ],
       [0.25  , 0.1875, 0.    , 0.5625, 0.    ],
       [0.0625, 0.    , 0.375 , 0.    , 0.5625],
       [0.    , 0.0625, 0.    , 0.9375, 0.    ],
       [0.    , 0.    , 0.25  , 0.    , 0.75  ]])

Graph edges

You can have your final graph edges in a list containing tuples like (from, to, probability) for each edge by:

>>> rw.get_edges()
[(0, 0, 1.0), (1, 0, 0.25), (1, 2, 0.75), (2, 1, 0.25), (2, 3, 0.75), (3, 2, 0.25), (3, 4, 0.75), (4, 3, 1.0)]

Graph

Making a networkx graph object from your random walk process is also token care of by this library:

>>> rw_graph = rw.get_graph()

Colors of Nodes [will be removed]

Until now we could not show graphs with self-loops using networkx so as far as this feature being added to networkx, we're using blue color for ordinary states and red color for states with self-loop.

>>> rw.get_colormap()
['red', 'blue', 'blue', 'blue', 'blue']

Type of Classes

For knowing which class is recurrent or transient you can use above method, you can also have reduced transition matrix for each set.

>>> rw_class_types = rw.get_typeof_classes()
>>> rw_class_types['recurrent']
([0], array([[1.]]))
>>> rw_class_types['transient'][0]
[1, 2, 3, 4]
>>> rw_class_types['transient'][1]
array([[0.  , 0.75, 0.  , 0.  ],
       [0.25, 0.  , 0.75, 0.  ],
       [0.  , 0.25, 0.  , 0.75],
       [0.  , 0.  , 1.  , 0.  ]])

The Best Policy Problems

For making the best policy problems for your random walk you can easily:

>>> states = [0, 1, 2]
>>> trans = np.array([[1, 0, 0], [1/2, 0, 1/2], [0, 1, 0]])
>>> rw = RandomWalk(states, trans, payoff=[0, 1, 4], cost=[1, 0, 2], discount=0.5)
>>> rw.best_policy()
{'continue': [], 'stop': [0, 1, 2]}

References

1- Lawler, Gregory F. Introduction to stochastic processes. Chapman and Hall/CRC, 2018.
