qppwg 0.1.2

Quasi-Periodic Parallel WaveGAN implementation

Quasi-Periodic Parallel WaveGAN (QPPWG)

This is official QPPWG PyTorch implementation. QPPWG is a non-autoregressive neural speech generation model developed based on PWG and QP structure.

In this repo, we provide an example to train and test QPPWG as a vocoder for WORLD acoustic features. More details can be found on our Demo page.

News

• 2020/7/22 Release v0.1.2
• 2020/6/27 Release mel-spec feature extraction and the pre-trained models of vcc20 corpus.
• 2020/6/26 Release the pre-trained models of vcc18 corpus.
• 2020/5/20 Release the first version (v0.1.1).

Requirements

This repository is tested on Ubuntu 16.04 with a Titan V GPU.

• Python 3.6+
• Cuda 10.0
• CuDNN 7+
• PyTorch 1.0.1+

Environment setup

The code works with both anaconda and virtualenv. The following example uses anaconda.

$ conda create -n venvQPPWG python=3.6
$ source activate venvQPPWG
$ git clone https://github.com/bigpon/QPPWG.git
$ cd QPPWG
$ pip install -e .

Please refer to the PWG repo for more details.

Folder architecture

• egs: The folder for projects.
• egs/vcc18: The folder of the VCC2018 project.
• egs/vcc18/exp: The folder for trained models.
• egs/vcc18/conf: The folder for configs.
• egs/vcc18/data: The folder for corpus related files (wav, feature, list ...).
• qppwg: The folder of the source codes.

Run

Corpus and path setup

• Modify the corresponding CUDA paths in egs/vcc18/run.py.
• Download the Voice Conversion Challenge 2018 (VCC2018) corpus to run the QPPWG example

$ cd egs/vcc18
# Download training and validation corpus
$ wget -o train.log -O data/wav/train.zip https://datashare.is.ed.ac.uk/bitstream/handle/10283/3061/vcc2018_database_training.zip
# Download evaluation corpus
$ wget -o eval.log -O data/wav/eval.zip https://datashare.is.ed.ac.uk/bitstream/handle/10283/3061/vcc2018_database_evaluation.zip
# unzip corpus
$ unzip data/wav/train.zip -d data/wav/
$ unzip data/wav/eval.zip -d data/wav/

• Training wav lists: data/scp/vcc18_train_22kHz.scp.
• Validation wav lists: data/scp/vcc18_valid_22kHz.scp.
• Testing wav list: data/scp/vcc18_eval_22kHz.scp.

Preprocessing

# Extract WORLD acoustic features and statistics of training and testing data
$ bash run.sh --stage 0 --config PWG_30

• WORLD-related settings can be changed in egs/vcc18/conf/vcc18.PWG_30.yaml.
• If you want to use another corpus, please create a corresponding config and a file including power thresholds and f0 ranges like egs/vcc18/data/pow_f0_dict.yml.
• More details about feature extraction can be found in the QPNet repo.
• The lists of auxiliary features will be automatically generated.
• Training aux lists: data/scp/vcc18_train_22kHz.list.
• Validation aux lists: data/scp/vcc18_valid_22kHz.list.
• Testing aux list: data/scp/vcc18_eval_22kHz.list.

QPPWG/PWG training

# Training a QPPWG model with the 'QPPWGaf_20' config and the 'vcc18_train_22kHz' and 'vcc18_valid_22kHz' sets.
$ bash run.sh --gpu 0 --stage 1 --conf QPPWGaf_20 \
--trainset vcc18_train_22kHz --validset vcc18_valid_22kHz

• The gpu ID can be set by --gpu GPU_ID (default: 0)
• The model architecture can be set by --conf CONFIG (default: PWG_30)
• The trained model resume can be set by --resume NUM (default: None)

QPPWG/PWG testing

# QPPWG/PWG decoding w/ natural acoustic features
$ bash run.sh --gpu 0 --stage 2 --conf QPPWGaf_20 \
--iter 400000 --trainset vcc18_train_22kHz --evalset vcc18_eval_22kHz
# QPPWG/PWG decoding w/ scaled f0 (ex: halved f0).
$ bash run.sh --gpu 0 --stage 3 --conf QPPWGaf_20 --scaled 0.50 \
--iter 400000 --trainset vcc18_train_22kHz --evalset vcc18_eval_22kHz

Monitor training progress

$ tensorboard --logdir exp

• The training time of PWG_30 with a TITAN V is around 3 days.
• The training time of QPPWGaf_20 with a TITAN V is around 5 days.

Inference speed (RTF)

• Vanilla PWG (PWG_30)

# On CPU (Intel(R) Xeon(R) Gold 6142 CPU @ 2.60GHz 32 threads)
[decode]: 100%|███████████| 140/140 [04:50<00:00,  2.08s/it, RTF=0.771]
2020-05-26 12:30:27,273 (decode:156) INFO: Finished generation of 140 utterances (RTF = 0.579).
# On GPU (TITAN V)
[decode]: 100%|███████████| 140/140 [00:09<00:00, 14.89it/s, RTF=0.0155]
2020-05-26 12:32:26,160 (decode:156) INFO: Finished generation of 140 utterances (RTF = 0.016).

• PWG w/ only 20 blocks (PWG_20)

# On CPU (Intel(R) Xeon(R) Gold 6142 CPU @ 2.60GHz 32 threads)
[decode]: 100%|███████████| 140/140 [03:57<00:00,  1.70s/it, RTF=0.761]
2020-05-30 13:50:20,438 (decode:156) INFO: Finished generation of 140 utterances (RTF = 0.474).
# On GPU (TITAN V)
[decode]: 100%|███████████| 140/140 [00:08<00:00, 16.55it/s, RTF=0.0105]
2020-05-30 13:43:50,793 (decode:156) INFO: Finished generation of 140 utterances (RTF = 0.011).

• QPPWG (QPPWGaf_20)

# On CPU (Intel(R) Xeon(R) Gold 6142 CPU @ 2.60GHz 32 threads)
[decode]: 100%|███████████| 140/140 [04:12<00:00,  1.81s/it, RTF=0.455]
2020-05-26 12:38:15,982 (decode:156) INFO: Finished generation of 140 utterances (RTF = 0.512).
# On GPU (TITAN V)
[decode]: 100%|███████████| 140/140 [00:11<00:00, 12.57it/s, RTF=0.0218]
2020-05-26 12:33:32,469 (decode:156) INFO: Finished generation of 140 utterances (RTF = 0.020).

Models and results

• The pre-trained models and generated utterances are released.
• You can download the whole folder of each corpus and then put it in egs/[corpus] to run speech generations with the pre-trained models.
• You also can only download the [corpus]/data folder and the desired pre-trained model and then put the data folder in egs/[corpus] and the model folder in egs/[corpus]/exp.
• Both models with 100,000 iterations (trained w/ only STFT loss) and 400,000 iterations (trained w/ STFT and GAN losses) are released.
• The generated utterances are in the wav folder of each model’s folder.

Corpus	Lang	Fs [Hz]	Feature	Model	Conf
vcc18	EN	22050	world (uv + f0 + mcep + ap) (shiftms: 5)	PWG_20	link
				PWG_30	link
				QPPWGaf_20	link
vcc20	EN, FI, DE, ZH	24000	melf0h128 (uv + f0 + mel-spc) (hop_size: 128)	PWG_20	link
				PWG_30	link
				QPPWGaf_20	link

Usage of pre-trained models

Analysis-synthesis

The minimum code for performing analysis and synthesis is presented.

# Make sure you have installed `qppwg`
# If not, install it via pip
$ pip install qppwg
# Take "vcc18" corpus as an example
# Download the whole folder of "vcc18"
$ ls vcc18
  data    exp
# Change directory to `vcc18` folder
$ cd vcc18
# Put audio files in `data/wav/` directory
$ ls data/wav/
  sample1.wav    sample2.wav
# Create a list `data/sample.scp` of the audio files
$ tail data/scp/sample.scp
  data/wav/sample1.wav
  data/wav/sample2.wav
# Extract acoustic features
$ qppwg-preprocess \
    --audio data/scp/sample.scp \
    --indir wav \
    --outdir hdf5 \
    --config exp/qppwg_vcc18_train_22kHz_QPPWGaf_20/config.yml
# The extracted features are in `data/hdf5/`
# The feature list `data/sample.list` of the feature files will be automatically generated
$ ls data/hdf5/
  sample1.h5    sample2.h5
$ ls data/scp/
  sample.scp    sample.list
# Synthesis
$ qppwg-decode \
    --eval_feat data/scp/sample.list \
    --stats data/stats/vcc18_train_22kHz.joblib \
    --indir data/hdf5/ \
    --outdir exp/qppwg_vcc18_train_22kHz_QPPWGaf_20/wav/400000/ \
    --checkpoint exp/qppwg_vcc18_train_22kHz_QPPWGaf_20/checkpoint-400000steps.pkl
# Synthesis w/ halved F0
$ qppwg-decode \
    --f0_factor 0.50 \
    --eval_feat data/scp/sample.list \
    --stats data/stats/vcc18_train_22kHz.joblib \
    --indir data/hdf5/ \
    --outdir exp/qppwg_vcc18_train_22kHz_QPPWGaf_20/wav/400000/ \
    --checkpoint exp/qppwg_vcc18_train_22kHz_QPPWGaf_20/checkpoint-400000steps.pkl
# The generated utterances can be found in `exp/[model]/wav/400000/`
$ ls exp/qppwg_vcc18_train_22kHz_QPPWGaf_20/wav/400000/
  sample1.wav    sample1_f0.50.wav    sample2.wav    sample2_f0.50.wav

References

The QPPWG repository is developed based on the following repositories and paper.

• kan-bayashi/ParallelWaveGAN
• bigpon/QPNet
• k2kobayashi/sprocket
• r9y9/wavenet_vocoder
• Parallel WaveGAN

Citation

If you find the code is helpful, please cite the following article.

@article{wu2020qppwg,
title={Quasi-Periodic Parallel WaveGAN Vocoder: A Non-autoregressive Pitch-dependent   Dilated Convolution Model for Parametric Speech Generation},
author={Wu, Yi-Chiao and Hayashi, Tomoki and Okamoto, Takuma and Kawai, Hisashi and Toda, Tomoki},
journal={arXiv preprint arXiv:2005.08654},
year={2020}
}

Authors

Development: Yi-Chiao Wu @ Nagoya University (@bigpon) E-mail: [e-mail]

Advisor: Tomoki Toda @ Nagoya University E-mail: [e-mail]
