repro-catalogue 1.0.0

Tool for reproducible analyses

repro-catalogue

A command line tool to catalogue versions of data, code and results to support reproducibility of research projects.

Contents

• Introduction
• Installation
• Getting started
  • Catalogue overview
  • Available commands
• Example usage
  • Run analysis
  • Check outputs
  • Share outputs
• FAQs
  • Running in the wrong order
  • Intermediary data processing
  • Randomness

Introduction

Research projects are frequently updated - new data are added, and the code undergoes regular changes. Under these circumstances, it's easy to store results, yet lose track of the context in which they were produced.

To ensure reproducibility of any scientific results we need to reliably record:

• what input data was used :floppy_disk:
• what code was run :desktop_computer:
• what outputs were produced :chart_with_upwards_trend:

The catalogue tool aids reproducibility by saving hash values of the input data and the results, along with the git commit hash of the code used to generate those results. The catalogue command line interface then allows the user to easily compare the hash values from different occasions on which the analysis was run so that changes to the input data, code and results can be identified and the impact on reproducibility can be understood.

Hash functions map arbitrary sized data to a binary "word" of a fixed length. The mapping is deterministic and the generated hash values are (for all practical purposes) unique. This means that hashing the same file (or a directory of files) will always produce the same value unless something in the files has changed, in which case the hash function would produce a new value. Because the hash value of a given input is unique, comparing hash values is a quick and easy way to check whether two files are the same.

Installation

git clone https://github.com/alan-turing-institute/repro-catalogue.git
cd repro-catalogue
pip install .

Getting started

Prerequisites

Data and code

To use the tool, we assume you already have a project with some analysis code ready to run on your data. Your project structure might look something like this:

├── data/
│   ├── my_data.csv
├── analysis/
│   ├── my_analysis.py
├── results/

Git

A pre-requisite for using catalogue is that the directory with the analysis code is a git repository. Git is a really useful tool for version control (GitHub sits on top of git).

Command line interface

The tool has a command line interface so you will need to open something like Terminal in macOS or Command Prompt in Windows to use it.

Throughout, the tool will require you to provide paths to some directory or file. Note that the directory path will look different on different operating systems. On Linux and macOS it may look like data/my_data.csv, whereas on Windows it will be data\my_data.csv (i.e., use a \ instead of /).

Catalogue overview

The catalogue tool comes with three commands (engage, disengage, compare) which should be run consecutively:

USAGE
  catalogue [-h] <command> [<arg1>] ... [<argN>]

ARGUMENTS
  <command>       The command to execute
  <arg>           The arguments of the command

GLOBAL OPTIONS
  -h (--help)     Display help message.

AVAILABLE COMMANDS
  engage          Run before an analysis. Saves hashes of `input_data` and `code`.
  disengage       Run after an analysis. Check `input_data` and `code` hashes now
                  are the same as at `engage`. Hash `output_data` and save all
                  hashes to a `TIMESTAMP.json` file.
  compare         Compare hashes.

Note that all arguments have default values which will be used if they are not provided. To see these use:

catalogue <command> -h

Available commands

engage

This command is run before an analysis is conducted:

catalogue engage --input_data <data directory> --code <code directory>

Replace <data directory> and <code directory> with the full or relative path to the data and code directories. In practice, this might look something like this:

catalogue engage --input_data data --code analysis

This will do a series of things. First it will check that the git working tree in our code folder is clean. It gives users a choice:

Working directory contains uncommitted changes.
Do you want to stage and commit all changes? (y/[n])

If we choose to proceed, catalogue will stage and commit all changes in the code directory. Next it will create a temporary file .lock in json format:

//catalogue_results/.lock
{
"timestamp" : {
    "engage": "<timestamp (of catalogue engage)>"
  },
"input_data": {
     "<data_directory>" : "<hash of directory>"
   },
"code" : {
     "<code_directory>": "<latest git commit hash>"
     }
}

Once catalogue is engaged, you can run your analysis.

disengage

The disengage command is run immediately after finishing an analysis to version the results:

catalogue disengage \
  --input_data <data directory> \
  --code <code directory> \
  --output_data <results directory>

Replace all <...>with path to the directory described. In practice, the command might look something like this:

catalogue disengage --input_data data --code analysis --output_data results

This checks that the input_data and code hashes match the hashes in .lock (created during engage). If they do, it will take hashes of the files in output_data and produce the following file:

// catalogue_results/<TIMESTAMP>.json
{
"timestamp" : {
     "engage": "<timestamp (of .lock)>",
     "disengage": "<timestamp (new)>"
   },
"input_data": {
     "<data directory>": "<hash of directory>"
   },
"output_data": {
       "<results directory>":{
           "<output file 1>": "<hash of file>",
           "<output file 2>": "<hash of file>",
           ...
           }
     },
"code" : {
     "<code directory>": "<git commit hash>"
     }
}

Note that the new file is saved in a catalogue_results directory.

compare

The compare command can be used to compare two catalogue output files against each other:

catalogue compare <TIMESTAMP1>.json <TIMESTAMP2>.json

The arguments should be the path to the two files to be compared.

For example, I might want to compare results produced on different days to check nothing has changed in this period:

cd catalogue_results
catalogue compare 200510-120000.json 200514-120000.json

If the hashes in the files are the same, this means the same analysis was run on the same data with the same outputs both times. In that case, catalogue will output something like:

results differ in 1 places:
=============================
timestamp

results matched in 3 places:
==============================
input_data
code
output_data

results could not be compared in 0 places:
============================================

If only one input is provided to the compare command, then the input is compared with the current state of the working directory.

Example usage

Imagine that on a central sever we have a data repository

├── Data folder/
│   ├── database release 1/
│   ├── database release 2/
⋮    ⋮
│   └── version index

Elsewhere, in our user directory, perhaps on another computer, things look like this.

├── latest_data/
├── latest_code/
├── results/
│   ├── old_results_with_inputs_1/
│   ├── old_results_with_inputs_2/
│   └── latest_results/
├── catalogue_results/
│   ├── TIMESTAMP1.json
│   ├── TIMESTAMP2.json
│   ├── TIMESTAMP3.json
│   └── TIMESTAMP4.json

Run analysis

We've just made some minor tweaks to our code and now we want to run our analysis. Before we start running any of the scripts in our code folder, we run:

catalogue engage --input_data latest_data --code latest_code

Now we run whatever we need to perform our analysis. Immediately after finishing this we run:

catalogue disengage --input_data latest_data --output_data results/latest_results  --code latest_code

This will produce the following file:

// catalogue_results/TIMESTAMP5.json
{
"timestamp" : {
     "engage": "<timestamp (of .lock)>",
     "disengage": "<timestamp (new)>"
   },
"input_data": {
     "latest_data" : "<hash of directory>"
   },
"output_data": {
       "results/latest results":{
           "summary.txt": "<hash of file>",
           "output.csv": "<hash of file>",
           "metadata.json": "<hash of file>"
           }
     },
"code" : {
     "latest_code": "<git commit hash>"
     }
}

Check outputs

Let's suppose that between TIMESTAMP4 and TIMESTAMP5 we modified the code to output a further file summary.txt, but that otherwise nothing has changed. We would like to check that our file output.csv hasn't changed but oops! We've just overwritten it. Luckily we can compare to the json at TIMESTAMP4.

catalogue compare \
  catalogue_results/TIMESTAMP4.json \
  catalogue_results/TIMESTAMP5.json

Let us also suppose that one of the other files generated by our analysis, metadata.json, includes a timestamp. The diff would look something like this:

results differ in 3 places:
=============================
timestamp
code
results/latest_results/metadata.json

results matched in 2 places:
==============================
input_data
results/latest_results/output.csv

results could not be compared in 1 places:
============================================
results/latest_results/summary.text

Of course this is what we want:

• The code has been updated to produce summary.txt, and the timestamps have changed
• Our data and results have not changed at all
• Our new file summary.txt could not be compared as that file was not present at TIMESTAMP4

Alternatively, let's suppose that our changes to the code had affected our results, so that our output.csv file has changed. In that case catalogue would inform us of the problem without us having to permanently store the output of every analysis we run. The hashes alone would not be enough to recover the original TIMESTAMP4 version. But since we have recorded the timestamp, that information can help us track down the data version, and the git commit digest tells us exactly what version of the code is used, making it easier to try and reproduce those results should we wish to do so.

Share outputs

We can then send a zip file of the results to a colleague along with the hash json produced during the final analysis (TIMESTAMP5.json).

They can rerun the analysis and use catalogue to check that the json they received is the same as their own:

catalogue compare TIMESTAMP4.json

FAQs

Running in the wrong order

The commands catalogue engage and catalogue disengage are meant to be run in that order.

The catalogue engage command will check that a .lock file does not exist. If it does, it will warn:

Already engaged (.lock file exists). To disengage run 'catalogue disengage...
See 'catalogue disengage --help' for details

The catalogue disengage command will check that a .lock file exists. If it doesn't, it will warn:

Not currently engaged (could not find .lock file). To engage run 'catalogue engage...
See 'catalogue engage --help' for details

Intermediary data processing

It is likely that the analysis includes some preprocessing steps. Ideally all of this preprocessing would be run automatically in synchrony with the rest of our code. In that case we consider it output data, and it should be contained in the output_data folder.

Randomness

Comparing two hashes tells you whether the hashed items are the same or different. This process cannot tell you if something is almost the same. If your analysis is non-deterministic, you will get a different hash every time.

There are several ways by which an analysis can be non-deterministic. One of the most common is the user of random numbers. To deal with this, we recommend setting a random seed. Whatever language you're using should be able to provide you with documentation on how to do this - see, for example, the documentation for Python.

Hashing tells you whether something is the same, or different. It cannot tell you if something is almost the same. If your analysis is non-deterministic, you will be getting a different hash every time. To deal with this, we recommend setting a random seed. Whatever language you're using should be able to provide you with documentation on how to do this.
