Saturation Effect

This library contains fast algorithms written in Cython and python to change the saturation level of an image or textures. This code is using extensively the HSL (Hue, Saturation, Lightness) algorithm in order to change the saturation level. Please see also the project HSL and HSV at the following URLs if you need more details regarding those projects

https://github.com/yoyoberenguer/HSV

https://github.com/yoyoberenguer/HSL

The methods can be used with a large variety of image format such as png, jpg, bmp etc, check pygame image format compatibility for more details. The image format can be either 24-32 bit with or without the transparency channel and works with image containing per-pixel transparency (32 bit). However, this library is not compatible with 8-bit format surface.

These algorithms can be used offline or real time processing for Indy Game such as pygame or Arcade game as long as the game resolution do not exceed 1280x1024. A modern CPU with at least 8 logical processor is required to keep the game running between 30-60 fps.

The algorithms are written using cython with OPENMP capability (multi- processing). This library is build by default with the flag OPENMP, providing the best performance for real time processing. You can also turn off the multi-processing to balance evenly the CPU load between your game and the real time saturation processing. Please refer to the section OPENMP for more details on how to turn the multi-processing on/off.

The saturation effect can be used for various projects such as image processing, 2D light effect, spritesheet, demos and video games, video image processing, Saturation effect for camera

The project is under the MIT license

Saturation effect definition (from wikipedia) :

The saturation of a color is determined by a combination of light intensity and how much it is distributed across the spectrum of different wavelengths. The purest (most saturated) color is achieved by using just one wavelength at a high intensity, such as in laser light. If the intensity drops, then as a result the saturation drops. To desaturate a color of given intensity in a subtractive system (such as watercolor), one can add white, black, gray, or the hue's complement.

HSL and HSV Saturation is also one of three coordinates in the HSL and HSV color spaces. However, in the HSL color space saturation exists independently of lightness. That is, both a very light color and a very dark color can be heavily saturated in HSL; whereas in the previous definitions—as well as in the HSV color space—colors approaching white all feature low saturation.

Excitation purity is the relative distance from the white point. Contours of constant purity can be found by shrinking the spectral locus about the white point. The points along the line segment have the same hue, with pe increasing from 0 to 1 between the white point and position on the spectral locus (position of the color on the horseshoe shape in the diagram) or (as at the saturated end of the line shown in the diagram) position on the line of purples.

image ref : By I, User:adoniscik, CC BY-SA 3.0, https://commons.wikimedia.org/w/index.php?curid=3477910

Installation

check the link for a newest version https://test.pypi.org/project/SaturationEffect/

pip install SaturationEffect
# or version 1.0.2
pip install SaturationEffect==1.0.2

• version installed
• Imported module is case sensitive

>>>from SaturationEffect.saturation import __version__
>>>__version__

Saturation mask

The library contains 4 methods using an optional mask to determine the pixels layer to be changed during the saturation process. The mask is build from a pygame.Surface (image) then converted to a 2d numpy.ndarray shape (width, height) of normalized float values. The image format used by the mask can be a JPG, PNG, BMP, 24 -32 bit with or without alpha channel. Note that the method build_mask2d_alpha using the transparency layer will require a surface compatible 32-bit with per-pixel transparency otherwise an error message will be raised.

You can create 3 different type of masks:

• mask build from the grayscale values of the image
• mask build from the grayscale values of the image and converted to black & white
• mask build from the alpha channel of the image

# Grayscale mask
cpdef inline object build_mask2d_grayscale(object surface_)
# Black and White mask
cpdef inline object build_mask2d_bw(object surface_)
# Alpha mask
cpdef inline object build_mask2d_alpha(object surface_)

Saturation method details

This version includes various methods spread into two category 24-32 bit compatible image format and 32-bit with per-pixel transparency layer. If you wish to process an image without the transparency layer use a method that specify the bitsize 24 (saturation24 for example). On the contrary, if the image contains a transparency layer, use any of method with bitsize 32 such as (saturation32)

Input arguments can be a numpy.ndarray, pygame.Surface or a C -buffer data type. Choose the right method accordingly

# Method using a mask (input can be a surface or a numpy.array)
# Compatible 24 -32 bit
cpdef saturation24_mask(array_, shift_, mask_)
cpdef saturation24_mask1(surface_, shift_, mask_)
# Compatible with 32 bit containing transparency layer
cpdef saturation32_mask(surface_, shift_, mask_)
cpdef saturation32_mask1(rgb_array_, alpha_array_, shift_, mask_)

# Direct saturation, no mask compatible 24 -32 bit
cpdef inline object saturation24(array_, shift_)
cpdef inline object saturation32(array_, alpha_, shift_)

# Input argument is C-buffer data type, the mask is compulsory, omitting
# the mask will raise an error
cpdef saturation_buffer_mask(buffer_, shift_, mask_array, width_, height_)
cpdef saturation_buffer_mask_inplace(buffer_, shift_, mask_array, width_, height_)

# Inplace method, the changes are applied to the surface directly
cpdef inline object saturation24_inplace(array_, shift_)
cpdef inline object saturation32_inplace(array_, shift_)

Quick example

>>> from SaturationEffect import example

Building cython code

When do you need to compile the cython code ?

Each time you are modifying any of the following files
saturation.pyx, saturation.pxd, or any external C code if applicable

1) open a terminal window
2) Go in the main project directory where (saturation.pyx &
   saturation.pxd files are located)
3) run : python setup_saturation.py build_ext --inplace --force

If you have to compile the code with a specific python
version, make sure to reference the right python version
in (python38 setup_saturation.py build_ext --inplace)

If the compilation fail, refers to the requirement section and
make sure cython and a C-compiler are correctly install on your
 system.
- A compiler such visual studio, MSVC, CGYWIN setup correctly on
  your system.
  - a C compiler for windows (Visual Studio, MinGW etc) install
  on your system and linked to your windows environment.
  Note that some adjustment might be needed once a compiler is
  install on your system, refer to external documentation or
  tutorial in order to setup this process.e.g https://devblogs.
  microsoft.com/python/unable-to-find-vcvarsall-bat/

OPENMP

In the main project directory, locate the file setup_saturation.py. The compilation flag /openmp is used by default. To override the OPENMP feature and disable the multi-processing remove the flag /openmp

setup_saturation.py

ext_modules=cythonize([
        Extension("SaturationEffect.saturation", ["SaturationEffect/saturation.pyx"],
                  extra_compile_args=["/openmp", "/Qpar", "/fp:fast", "/O2", "/Oy", "/Ot"], language="c")]),

Save the change and build the cython code with the following instruction:

python setup_saturation.py build_ext --inplace --force

If the project build successfully, the compilation will end up with the following lines

Generating code
Finished generating code

If you have any compilation error refer to the section Building cython code and make sure your system has the following program & libraries installed. Check also that the code is not running in a different thread.

• Pygame version > 3
• numpy >= 1.18
• cython >=0.29.21 (C extension for python)
• A C compiler for windows (Visual Studio, MinGW etc)

Credit

Yoann Berenguer

Dependencies :

numpy >= 1.18
pygame >=2.0.0
cython >=0.29.21

License :

MIT License

Copyright (c) 2019 Yoann Berenguer

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:

The above copyright notice and this permission notice shall be included in all copies or substantial portions of the Software.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE.

Testing:

>>>import SaturationEffect
>>>from SaturationEffect.tests.test_saturation import run_testsuite
>>>run_testsuite()

Timing :

In the directory tests under the main project path

C:...tests\python profiling.py

TESTING WITH IMAGE 1280x1024 (result in ms)

Performance testing saturation24_mask with mask     per call 0.035846148 overall time 3.58461s for 100 iterations
Performance testing saturation24_mask without mask  per call 0.044081281 overall time 4.40813s for 100
Performance testing saturation32_mask with mask     per call 0.058718479 overall time 5.87185s for 100
Performance testing saturation32_mask without mask  per call 0.056563972 overall time 5.6564s  for 100
Performance testing saturation24                    per call 0.045149282 overall time 4.51493s for 100
Performance testing saturation32                    per call 0.046752571 overall time 4.67526s for 100
Performance testing saturation24_inplace            per call 0.039684722 overall time 3.96847s for 100
Performance testing saturation32_inplace            per call 0.039565034 overall time 3.9565s  for 100
Performance testing saturation_buffer_mask          per call 0.054190551 overall time 5.41906s for 100
Performance testing saturation_buffer_mask_inplace  per call 0.052289168 overall time 5.22892s for 100
