sigenergy2mqtt 2025.6.11

Publish Modbus data from Sigenergy to MQTT, with optional Home Assistant Auto-Discovery and PVOutput updating

sigenergy2mqtt is a bridge between the Modbus interface of the Sigenergy energy system and the MQTT lightweight publish/subscribe messaging protocol.

In addition, sigenergy2mqtt has several optional features:

1. It can publish the appropriate messages to allow Home Assistant to automatically discover the Sigenergy devices, simplifying Home Assistant configuration.
2. Production and consumption data can automatically be uploaded to PVOutput.
3. Third-party solar production can be included in the total production and consumption computations, using either custom code or by subscribing to MQTT topics.

sigenergy2mqtt was inspired the Home Assistant integrations developed by TypQxQ.

• Disclaimer
• Installation
  • Home Assistant Add-on
  • Linux
  • Docker
• Configuration
  • Configuration File
    • Configuring Smart-Port Production
  • Command Line Options
  • Environment Variables
• Post-Installation
• Home Assistant Auto-Discovery
• Alternatives

Disclaimer

sigenergy2mqtt was developed for my own use, and as such has only been tested in my single-phase environment without AC or DC chargers. In addition, there has been only cursory testing of the write functions. If you find a problem, please raise an issue.

Installation

Home Assistant Add-on

You need to add my Home Assistant Add-ons repository first, and then you will be able to add the sigenergy2mqtt add-on.

Automatically Add Repository

Manually Add Repository

Follow these steps to get the add-on repository installed on your Home Assistant system:

1. Navigate in your Home Assistant frontend to Settings -> Add-ons -> Add-on store.
2. Click the three vertical dots in the top-right corner and select Repositories.
3. Enter https://github.com/seud0nym/home-assistant-addons and click the ADD button.
4. Close the Repositories window and refresh.

Installation

1. Select the sigenergy2mqtt add-on in the Home Assistant Add-ons Store
2. Enter the configuration details on the Configuration tab, and save.
3. Start the add-on from the Info tab.

Linux

Pre-requisites

• Python 3.11 or later
• An MQTT broker such as Mosquitto, either standalone or installed as an add-on to Home Assistant
• A Linux server (physical hardware, or a virtual machine/container) that runs continuously in which to install sigenergy2mqtt (hardware requirements are minimal: I use a Proxmox LXC with 2 cores and 256MiB RAM to run Mosquitto, ecowitt2mqtt and sigenergy2mqtt)
• A Sigenergy energy solution with Modbus-TCP enabled by your installer

Installation

Install sigenergy2mqtt via pip:

pip install sigenergy2mqtt

Background Service

To run sigenergy2mqtt as a service that starts automatically in the background on system boot, create the file /etc/systemd/system/sigenergy2mqtt.service with your favourite editor, with the following contents:

[Unit]
Description=Publish Modbus data from Sigenergy to MQTT
Documentation=https://github.com/seud0nym/sigenergy2mqtt
After=network.target mosquitto.service

[Service]
Type=simple
User=sigenergy
Group=daemon
ExecStart=/usr/local/bin/sigenergy2mqtt
ExecReload=kill -HUP $MAINPID
KillMode=process
Restart=on-failure
RestartSec=5s

[Install]
WantedBy=multi-user.target

Notes:

• If you are not running sigenergy2mqtt on the same host/container as Mosquitto, remove mosquitto.service from the After= line.

Once that is done, run the following commands:

useradd -m -g 1 sigenergy
systemctl enable sigenergy2mqtt.service

When you are ready to start the service, use this command:

systemctl start sigenergy2mqtt.service

Upgrades

To upgrade to a new release, install using pip with the --upgrade option:

pip install sigenergy2mqtt --upgrade
systemctl restart sigenergy2mqtt.service

Docker

sigenergy2mqtt is available via a Docker image from both Docker Hub and ghcr.io. It can be configured by using the environment variables listed below, or by placing your configuration file in the root of the /data volume,

Running the image is straightforward:

docker run -it \
    -e SIGENERGY2MQTT_MQTT_BROKER=192.168.0.1 \
    -e SIGENERGY2MQTT_MQTT_USERNAME=user \
    -e SIGENERGY2MQTT_MQTT_PASSWORD=password \
    -v /data:/data \
    seud0nym/sigenergy2mqtt:latest

Note that you must provide persistent storage via the -v option to preserve the state of calculated accumulation sensors across executions. You can also place your configuration file in the root of this directory, rather than configuring via environment variables.

docker-compose users can find an example configuration file at docker-compose.yaml.

Configuration

You can configure sigenergy2mqtt via the command line and/or environment variables, but using a persistent configuration file is a better option, as it provides access to all advanced feature configuration.

Configuration File

The complete list of configuration options with associated comments can be found in sigenergy2mqtt.yaml.

Example:

home-assistant:
  enabled: true
mqtt:
  broker: 127.0.0.1
  username: ""
  password: ""
modbus:
  - host: sigenergy.local
    inverters: [ 1 ]
pvoutput:
  enabled: false
  api-key: your_api_key
  system-id: your_system_id
  interval-minutes: 5
  consumption: true

Notes:

• Configure your MQTT broker IP address/host name and Sigenergy IP address/host name as appropriate for your environment.
• The number in square brackets after inverters is the Device ID (slave address) as advised by your installer. It is usually 1. If you have multiple inverters, separate them with commas (e.g. [ 1,2 ])
• If your MQTT broker does not require authentication, add the option anonymous: true under mqtt.
• By default, only entities relating to production, consumption and battery charging/discharging are enabled (all other entities will still appear in Home Assistant, but will be disabled). All other entities are disabled by default. If you want all entities to be initially enabled, set sensors-enabled-by-default to true. This setting only applies the first time that Home Assistant auto-discovers devices and entities; changing this configuration after first discovery will have no effect. Entities can be enabled and disabled through the Home Assistant user interface.
• The default location for sigenergy2mqtt.yaml is in /etc/. However, it will also be found in /data/. You can also use the -c command line option or the SIGENERGY2MQTT_CONFIG environment variable to specify a different location and/or filename.

Configuring Smart-Port Production

Enphase Envoy

This configuration only works with Enphase Envoy firmware versions prefixed with D7 and D8. Add the Envoy host and login details to your sigenergy2mqtt configuration file:

...
modbus:
  - host: your_sigenergy_ip_address
    inverters: [ 1 ]
    log-level: INFO
    smart-port:
      enabled: true
      module:
        name: enphase
        host: your_enphase_envoy_ip_address
        username: your_enphase_enlighten_username
        password: your_enphase_enlighten_password
        pv-power: EnphasePVPower
...

Notes:

1. The module name must be set to enphase.
2. The module pv-power configuration must be set to EnphasePVPower to create the Plant Total PV Power sensor to accumulate the Enphase PV production and Sigenergy PV production.

Any System Already Integrated with Home Assistant

This configuration requires adding the MQTT topics to which sigenergy2mqtt will subscribe to get the third-party PV power production updates, and setting up an automation within Home Assistant to publish the third-party PV power production to MQTT whenever it changes.

1. sigenergy2mqtt Configuration File

...
modbus:
  - host: your_sigenergy_ip_address
    inverters: [ 1 ]
    log-level: INFO
    smart-port:
      enabled: true
      mqtt:
        - topic: sigenergy2mqtt/smartport/envoy_nnnnnnnnnn_current_power_production/state
          gain: 1
...

Notes:

• The topic can be anything meaningful.
• The gain represents the multiplier to convert the state to watts (so if it is provided in kWh, 1000 is the multiplier).
• You can specify multiple MQTT topic/gain pairs in the configuration file (but command line and environment overrides are limited to a single topic).

2. Home Assistant Automation

Create a new automation and enter a YAML configuration similar to this, using the entity_id that contains the current PV power production from your third-party inverter (this example uses Enphase again):

alias: Publish Envoy PV Production
description: "Update sigenergy2mqtt with the current PV production reported by Enphase Envoy"
triggers:
  - trigger: state
    entity_id:
      - sensor.envoy_nnnnnnnnnn_current_power_production
conditions: []
actions:
  - action: mqtt.publish
    data:
      topic: sigenergy2mqtt/smartport/envoy_nnnnnnnnnn_current_power_production/state
      payload: "{{ trigger.to_state.state }}"
mode: queued

Notes:

• The topic(s) must match in both the sigenergy2mqtt configuration and the Home Assistant automation.

Command Line Options

Command line options override both environment variables and the configuration file.

  -h, --help            show this help message and exit
  -c [SIGENERGY2MQTT_CONFIG], --config [SIGENERGY2MQTT_CONFIG]
                        The path to the JSON configuration file (default: /etc/sigenergy2mqtt.yaml)
  -l {DEBUG,INFO,WARNING,ERROR,CRITICAL}, --log-level {DEBUG,INFO,WARNING,ERROR,CRITICAL}
                        Set the log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL. Default is WARNING
                        (warnings, errors and critical failures)
  -d SIGENERGY2MQTT_DEBUG_SENSOR, --debug-sensor SIGENERGY2MQTT_DEBUG_SENSOR
                        Specify a sensor to be debugged using either the full entity id, a partial entity id, the full sensor class name,
                        or a partial sensor class name. For example, specifying 'daily' would match all sensors with daily in their entity
                        name. If specified, --debug-level is also forced to DEBUG
  --hass-enabled        Enable auto-discovery in Home Assistant.
  --hass-discovery-prefix [SIGENERGY2MQTT_HASS_DISCOVERY_PREFIX]
                        The Home Assistant MQTT Discovery topic prefix to use (default: homeassistant)
  --hass-entity-id-prefix [SIGENERGY2MQTT_HASS_ENTITY_ID_PREFIX]
                        The prefix to use for Home Assistant entity IDs. Example: A prefix of 'prefix' will prepend 'prefix_' to entity IDs
                         (default: sigen)
  --hass-unique-id-prefix [SIGENERGY2MQTT_HASS_UNIQUE_ID_PREFIX]
                        The prefix to use for Home Assistant unique IDs. Example: A prefix of 'prefix' will prepend 'prefix_' to unique IDs
                         (default: sigen). Once you have set this, you should NEVER change it, as it will break existing entities in
                         Home Assistant.
  --hass-device-name-prefix [SIGENERGY2MQTT_HASS_DEVICE_NAME_PREFIX]
                        The prefix to use for Home Assistant entity names. Example: A prefix of 'prefix' will prepend 'prefix ' to names
                        (default: '')
  --hass-discovery-only
                        Exit immediately after publishing discovery. Does not read values from the Modbus interface,
                        except to probe for device configuration.
  -b [SIGENERGY2MQTT_MQTT_BROKER], --mqtt-broker [SIGENERGY2MQTT_MQTT_BROKER]
                        The hostname or IP address of an MQTT broker (default: 127.0.0.1)
  --mqtt-port [SIGENERGY2MQTT_MQTT_PORT]
                        The listening port of the MQTT broker (default: 1883)
  --mqtt-anonymous      Connect to MQTT anonymously (i.e. without username/password).
  -u [SIGENERGY2MQTT_MQTT_USERNAME], --mqtt-username [SIGENERGY2MQTT_MQTT_USERNAME]
                        A valid username for the MQTT broker
  -p [SIGENERGY2MQTT_MQTT_PASSWORD], --mqtt-password [SIGENERGY2MQTT_MQTT_PASSWORD]
                        A valid password for the MQTT broker username
  --mqtt-log-level {DEBUG,INFO,WARNING,ERROR,CRITICAL}
                        Set the paho.mqtt log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL.
                        Default is WARNING (warnings, errors and critical failures)
  -m [SIGENERGY2MQTT_MODBUS_HOST], --modbus-host [SIGENERGY2MQTT_MODBUS_HOST]
                        The hostname or IP address of the Sigenergy device
  --modbus-port [SIGENERGY2MQTT_MODBUS_PORT]
                        The Sigenergy device Modbus port number (default: 502)
  --modbus-slave [SIGENERGY2MQTT_MODBUS_INVERTER_SLAVE]
                        The Sigenergy Inverter Modbus Device ID (Slave ID). May be specified multiple times.
  --modbus-accharger-slave [SIGENERGY2MQTT_MODBUS_ACCHARGER_SLAVE]
                        The Sigenergy AC Charger Modbus Device ID (Slave ID).
  --modbus-dccharger-slave [SIGENERGY2MQTT_MODBUS_DCCHARGER_SLAVE]
                        The Sigenergy DC Charger Modbus Device ID (Slave ID).
  --modbus-readonly     Only publish read-only sensors to MQTT. Neither read-write or write-only sensors will be
                        published if specified.
  --modbus-no-remote-ems
                        Do not publish any read-write sensors for remote Energy Management System (EMS) integration to MQTT.
                        Ignored if --modbus-read-only is specified.
  --modbus-log-level {DEBUG,INFO,WARNING,ERROR,CRITICAL}
                        Set the pymodbus log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL.
                        Default is WARNING (warnings, errors and critical failures)
  --scan-interval-low [SIGENERGY2MQTT_SCAN_INTERVAL_LOW]
                        The scan interval in seconds for Modbus registers that are to be scanned at a low frequency. Default is 600 (seconds), and the minimum value is 300.
  --scan-interval-medium [SIGENERGY2MQTT_SCAN_INTERVAL_MEDIUM]
                        The scan interval in seconds for Modbus registers that are to be scanned at a medium frequency. Default is 60 (seconds), and the minimum value is 30.
  --scan-interval-high [SIGENERGY2MQTT_SCAN_INTERVAL_HIGH]
                        The scan interval in seconds for Modbus registers that are to be scanned at a high frequency. Default is 10 (seconds), and the minimum value is 5.
  --scan-interval-realtime [SIGENERGY2MQTT_SCAN_INTERVAL_REALTIME]
                        The scan interval in seconds for Modbus registers that are to be scanned in near-real time. Default is 5 (seconds), and the minimum value is 1.
  --smartport-enabled   Enable interrogation of a third-party device for production data.
  --smartport-module-name [SIGENERGY2MQTT_SMARTPORT_MODULE_NAME]
                        The name of the module which will be used to obtain third-party device production data.
  --smartport-host [SIGENERGY2MQTT_SMARTPORT_HOST]
                        The IP address or hostname of the third-party device.
  --smartport-username [SIGENERGY2MQTT_SMARTPORT_USERNAME]
                        The username to authenticate to the third-party device.
  --smartport-password [SIGENERGY2MQTT_SMARTPORT_PASSWORD]
                        The password to authenticate to the third-party device.
  --smartport-pv-power [SIGENERGY2MQTT_SMARTPORT_PV_POWER]
                        The sensor class to hold the production data obtained from the third-party device.
  --smartport-mqtt-topic [SIGENERGY2MQTT_SMARTPORT_MQTT_TOPIC]
                        The MQTT topic to which to subscribe to obtain the production data for the third-party device.
  --smartport-mqtt-gain [SIGENERGY2MQTT_SMARTPORT_MQTT_GAIN]
                        The gain to be applied to the production data for the third-party device obtained from the MQTT topic.
                        (e.g. 1000 if the data is in kW) Default is 1 (Watts).
  --pvoutput-enabled    Enable status updates to PVOutput.
  --pvoutput-api-key [SIGENERGY2MQTT_PVOUTPUT_API_KEY]
                        The API Key for PVOutput
  --pvoutput-system-id [SIGENERGY2MQTT_PVOUTPUT_SYSTEM_ID]
                        The PVOutput System ID
  --pvoutput-consumption
                        Enable sending consumption status to PVOutput.
  --pvoutput-interval [SIGENERGY2MQTT_PVOUTPUT_INTERVAL]
                        The interval in minutes to send data to PVOutput (default: 5). Valid values are 5, 10 or 15 minutes.
  --pvoutput-log-level {DEBUG,INFO,WARNING,ERROR,CRITICAL}
                        Set the PVOutput log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL. Default is WARNING
                        (warnings, errors and critical failures)
  --clean               Publish empty discovery to delete existing devices, then exits immediately.
  -v, --version         Shows the version number, then exits immediately.

Environment Variables

Environment variables override the configuration file, but not command line options.

• SIGENERGY2MQTT_CONFIG :
  • The path to the JSON configuration file (default: /etc/sigenergy2mqtt.yaml)
• SIGENERGY2MQTT_LOG_LEVEL :
  • Set the log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL. Default is WARNING (warnings, errors and critical failures)
• SIGENERGY2MQTT_DEBUG_SENSOR :
  • Specify a sensor to be debugged using either the full entity id, a partial entity id, the full sensor class name, or a partial sensor class name. For example, specifying 'daily' would match all sensors with daily in their entity name. If specified, --debug-level is also forced to DEBUG
• SIGENERGY2MQTT_HASS_ENABLED :
  • Set to 'true' to enable auto-discovery in Home Assistant.
• SIGENERGY2MQTT_HASS_DISCOVERY_PREFIX :
  • The Home Assistant MQTT Discovery topic prefix to use (default: homeassistant)
• SIGENERGY2MQTT_HASS_ENTITY_ID_PREFIX :
  • The prefix to use for Home Assistant entity IDs. Example: A prefix of 'prefix' will prepend 'prefix_' to entity IDs (default: sigen)
• SIGENERGY2MQTT_HASS_UNIQUE_ID_PREFIX :
  • The prefix to use for Home Assistant unique IDs. Example: A prefix of 'prefix' will prepend 'prefix_' to unique IDs (default: sigen). Once you have set this, you should NEVER change it, as it will break existing entities in Home Assistant.
• SIGENERGY2MQTT_HASS_DEVICE_NAME_PREFIX :
  • The prefix to use for Home Assistant entity names. Example: A prefix of 'prefix' will prepend 'prefix ' to names (default: '')
• SIGENERGY2MQTT_HASS_DISCOVERY_ONLY:
  • Set to 'true' to e xit immediately after publishing discovery. Does not read values from the Modbus interface, except to probe for device configuration.
• SIGENERGY2MQTT_MQTT_BROKER :
  • The hostname or IP address of an MQTT broker (default: 127.0.0.1)
• SIGENERGY2MQTT_MQTT_PORT :
  • The listening port of the MQTT broker (default: 1883)
• SIGENERGY2MQTT_MQTT_ANONYMOUS :
  • Set to 'true' to connect to MQTT anonymously (i.e. without username/password).
• SIGENERGY2MQTT_MQTT_USERNAME :
  • A valid username for the MQTT broker
• SIGENERGY2MQTT_MQTT_PASSWORD :
  • A valid password for the MQTT broker username
• SIGENERGY2MQTT_MQTT_LOG_LEVEL :
  • Set the paho.mqtt log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL. Default is WARNING (warnings, errors and critical failures)
• SIGENERGY2MQTT_MODBUS_HOST :
  • The hostname or IP address of the Sigenergy device
• SIGENERGY2MQTT_MODBUS_PORT :
  • The Sigenergy device Modbus port number (default: 502)
• SIGENERGY2MQTT_MODBUS_INVERTER_SLAVE :
  • The Sigenergy device Modbus Device ID (Slave ID). May be specified as a space-separated list (e.g. "1 2"). (default: 1)
• SIGENERGY2MQTT_MODBUS_ACCHARGER_SLAVE :
  • The Sigenergy AC Charger Modbus Device ID (Slave ID).
• SIGENERGY2MQTT_MODBUS_DCCHARGER_SLAVE :
  • The Sigenergy DC Charger Modbus Device ID (Slave ID).
• SIGENERGY2MQTT_MODBUS_NO_REMOTE_EMS:
  • If true, read-write sensors for remote Energy Management System (EMS) integration will NOT be published to MQTT. Default is false. Ignored if SIGENERGY2MQTT_MODBUS_READ_WRITE is false.
• SIGENERGY2MQTT_MODBUS_READ_ONLY :
  • If false, read-only entities will not be published to MQTT. Default is true.
• SIGENERGY2MQTT_MODBUS_READ_WRITE :
  • If false, read-write entities will not be published to MQTT. Default is true.
• SIGENERGY2MQTT_MODBUS_WRITE_ONLY :
  • If false, write-only entities will not be published to MQTT. Default is true.
• SIGENERGY2MQTT_MODBUS_LOG_LEVEL :
  • Set the pymodbus log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL. Default is WARNING (warnings, errors and critical failures)
• SIGENERGY2MQTT_SMARTPORT_ENABLED :
  • Enable interrogation of a third-party device for production data.
• SIGENERGY2MQTT_SMARTPORT_MODULE_NAME :
  • The name of the module which will be used to obtain third-party device production data.
• SIGENERGY2MQTT_SMARTPORT_HOST :
  • The IP address or hostname of the third-party device.
• SIGENERGY2MQTT_SMARTPORT_USERNAME :
  • The username to authenticate to the third-party device.
• SIGENERGY2MQTT_SMARTPORT_PASSWORD :
  • The password to authenticate to the third-party device.
• SIGENERGY2MQTT_SMARTPORT_PV_POWER :
  • The sensor class to hold the production data obtained from the third-party device.
• SIGENERGY2MQTT_SMARTPORT_MQTT_TOPIC :
  • The MQTT topic to which to subscribe to obtain the production data for the third-party device.
• SIGENERGY2MQTT_SMARTPORT_MQTT_GAIN :
  • The gain to be applied to the production data for the third-party device obtained from the MQTT topic. (e.g. 1000 if the data is in kW) Default is 1 (Watts).
• SIGENERGY2MQTT_SCAN_INTERVAL_LOW :
  • The scan interval in seconds for Modbus registers that are to be scanned at a low frequency. Default is 600 (seconds), and the minimum value is 300.
• SIGENERGY2MQTT_SCAN_INTERVAL_MEDIUM :
  • The scan interval in seconds for Modbus registers that are to be scanned at a medium frequency. Default is 60 (seconds), and the minimum value is 30.
• SIGENERGY2MQTT_SCAN_INTERVAL_HIGH :
  • The scan interval in seconds for Modbus registers that are to be scanned at a high frequency. Default is 10 (seconds), and the minimum value is 5.
• SIGENERGY2MQTT_SCAN_INTERVAL_REALTIME :
  • The scan interval in seconds for Modbus registers that are to be scanned in near-real time. Default is 5 (seconds), and the minimum value is 1.
• SIGENERGY2MQTT_PVOUTPUT_ENABLED :
  • Set to 'true' to enable status updates to PVOutput.
• SIGENERGY2MQTT_PVOUTPUT_API_KEY :
  • The API Key for PVOutput
• SIGENERGY2MQTT_PVOUTPUT_SYSTEM_ID :
  • The PVOutput System ID
• SIGENERGY2MQTT_PVOUTPUT_CONSUMPTION :
  • Set to 'true' to enable sending consumption status to PVOutput.
• SIGENERGY2MQTT_PVOUTPUT_INTERVAL :
  • The interval in minutes to send data to PVOutput (default: 5). Valid values are 5, 10 or 15 minutes.
• SIGENERGY2MQTT_PVOUTPUT_LOG_LEVEL :
  • Set the PVOutput log level. Valid values are: DEBUG, INFO, WARNING, ERROR or CRITICAL. Default is WARNING (warnings, errors and critical failures)

Post-Installation

If you are using Home Assistant, you can set the current values for the daily and lifetime accumulation sensors from the mySigen app through the MQTT device screen. The screen contains controls for inputting the values. Make sure you enter lifetime values first, because daily sensors use the lifetime numbers as their base.

MQTT Publish and Subscribe Topics

The topics that are published and subscribed to by sigenergy2mqtt can be found here.

Home Assistant Auto-Discovery

For each host defined in the modbus section of the configuration file, an MQTT device will be created in Home Assistant. The first device will be called Sigenergy Plant (plant is the terminology used in the "Sigenergy Modbus Protocol", and is in the context of a power plant). Each plant will have one or more related devices, such as Sigenergy Plant Grid Sensor and if applicable, Sigenergy Plant Smart-Port. Plants will also have associated inverters, and their names will include the model and serial number (e.g. SigenStor CMUxxxxxxxxxx Energy Controller). Each inverter will have an an Energy Storage System device (e.g. SigenStor CMUxxxxxxxxxx ESS) and as many PV String devices as the inverter supports. Chargers will be named Sigenergy AC Charger and Sigenergy DC Charger.

Example:

Sigenergy Plant
   ├─ Sigenergy Plant Grid Sensor
   ├─ SigenStor Plant Smart-Port
   ├─ SigenStor CMUxxxxxxxxxx Energy Controller (ID 1)
   │    ├─ SigenStor CMUxxxxxxxxxx ESS
   │    ├─ SigenStor CMUxxxxxxxxxx PV String 1
   │    ├─ SigenStor CMUxxxxxxxxxx PV String 2
   │    ├─ SigenStor CMUxxxxxxxxxx PV String 3
   │    ├─ SigenStor CMUxxxxxxxxxx PV String 4
   │    └─ Sigenergy DC Charger
   └─ SigenStor CMUyyyyyyyyyy Energy Controller (ID 2)
        ├─ SigenStor CMUyyyyyyyyyy ESS
        ├─ SigenStor CMUyyyyyyyyyy PV String 1
        ├─ SigenStor CMUyyyyyyyyyy PV String 2
        └─ Sigenergy DC Charger

Alternatives

For simple Sigenergy systems, with no integrated legacy solar system or requirement to integrate with PVOutput, the Sigenergy Local Modbus HACS integration may be a better alternative for integration with Home Assistant.

Feature	Sigenergy Local Modbus	sigenergy2mqtt (Linux)	sigenergy2mqtt (HA Add-on)	Comments
Pre-requisites	None	Python, MQTT broker	None
Installation	GUI	Manual	GUI
Configuration	GUI	Edit configuration file	GUI and/or config file
Home Assistant	HACS Integration	Optional MQTT Auto-discovery	MQTT Auto-discovery
PVOutput	No	Optional	Optional
Third-Party Solar included in production and consumption	No	Optional	Optional	Since the V100R001C00SPC108 firmware update, production systems connected to the Sigenergy Gateway Smart-Port are no longer included in the PV Power reported by the Modbus interface. However, this may change in future firmware releases.
