snntorch 0.9.1

Deep learning with spiking neural networks.

The brain is the perfect place to look for inspiration to develop more efficient neural networks. One of the main differences with modern deep learning is that the brain encodes information in spikes rather than continuous activations. snnTorch is a Python package for performing gradient-based learning with spiking neural networks. It extends the capabilities of PyTorch, taking advantage of its GPU accelerated tensor computation and applying it to networks of spiking neurons. Pre-designed spiking neuron models are seamlessly integrated within the PyTorch framework and can be treated as recurrent activation units.

If you like this project, please consider starring ⭐ this repo as it is the easiest and best way to support it.

If you have issues, comments, or are looking for advice on training spiking neural networks, you can open an issue, a discussion, or chat in our discord channel.

snnTorch Structure

snnTorch contains the following components:

Component	Description
snntorch	a spiking neuron library like torch.nn, deeply integrated with autograd
snntorch.export	enables cross-compatibility with other SNN libraries via NIR
snntorch.functional	common arithmetic operations on spikes, e.g., loss, regularization etc.
snntorch.spikegen	a library for spike generation and data conversion
snntorch.spikeplot	visualization tools for spike-based data using matplotlib and celluloid
snntorch.surrogate	optional surrogate gradient functions
snntorch.utils	dataset utility functions

snnTorch is designed to be intuitively used with PyTorch, as though each spiking neuron were simply another activation in a sequence of layers. It is therefore agnostic to fully-connected layers, convolutional layers, residual connections, etc.

At present, the neuron models are represented by recursive functions which removes the need to store membrane potential traces for all neurons in a system in order to calculate the gradient. The lean requirements of snnTorch enable small and large networks to be viably trained on CPU, where needed. Provided that the network models and tensors are loaded onto CUDA, snnTorch takes advantage of GPU acceleration in the same way as PyTorch.

Citation

If you find snnTorch useful in your work, please cite the following source:

Jason K. Eshraghian, Max Ward, Emre Neftci, Xinxin Wang, Gregor Lenz, Girish Dwivedi, Mohammed Bennamoun, Doo Seok Jeong, and Wei D. Lu “Training Spiking Neural Networks Using Lessons From Deep Learning”. Proceedings of the IEEE, 111(9) September 2023.

@article{eshraghian2021training,
        title   =  {Training spiking neural networks using lessons from deep learning},
        author  =  {Eshraghian, Jason K and Ward, Max and Neftci, Emre and Wang, Xinxin
                    and Lenz, Gregor and Dwivedi, Girish and Bennamoun, Mohammed and
                   Jeong, Doo Seok and Lu, Wei D},
        journal = {Proceedings of the IEEE},
        volume  = {111},
        number  = {9},
        pages   = {1016--1054},
        year    = {2023}
}

Let us know if you are using snnTorch in any interesting work, research or blogs, as we would love to hear more about it! Reach out at [e-mail].

Requirements

The following packages need to be installed to use snnTorch:

• torch >= 1.1.0

• numpy >= 1.17

• pandas

• matplotlib

• math

• nir

• nirtorch

They are automatically installed if snnTorch is installed using the pip command. Ensure the correct version of torch is installed for your system to enable CUDA compatibility.

Installation

Run the following to install:

$ python
$ pip install snntorch

To install snnTorch from source instead:

$ git clone https://github.com/jeshraghian/snnTorch
$ cd snntorch
$ python setup.py install

To install snntorch with conda:

$ conda install -c conda-forge snntorch

To install for an Intelligent Processing Units (IPU) based build using Graphcore’s accelerators:

$ pip install snntorch-ipu

API & Examples

A complete API is available here. Examples, tutorials and Colab notebooks are provided.

Quickstart

Here are a few ways you can get started with snnTorch:

• Quickstart Notebook (Opens in Colab)

• The API Reference

• Examples

• Tutorials

For a quick example to run snnTorch, see the following snippet, or test the quickstart notebook:

import torch, torch.nn as nn
import snntorch as snn
from snntorch import surrogate
from snntorch import utils

num_steps = 25 # number of time steps
batch_size = 1
beta = 0.5  # neuron decay rate
spike_grad = surrogate.fast_sigmoid() # surrogate gradient

net = nn.Sequential(
      nn.Conv2d(1, 8, 5),
      nn.MaxPool2d(2),
      snn.Leaky(beta=beta, init_hidden=True, spike_grad=spike_grad),
      nn.Conv2d(8, 16, 5),
      nn.MaxPool2d(2),
      snn.Leaky(beta=beta, init_hidden=True, spike_grad=spike_grad),
      nn.Flatten(),
      nn.Linear(16 * 4 * 4, 10),
      snn.Leaky(beta=beta, init_hidden=True, spike_grad=spike_grad, output=True)
      )

data_in = torch.rand(num_steps, batch_size, 1, 28, 28) # random input data
spike_recording = [] # record spikes over time
utils.reset(net) # reset/initialize hidden states for all neurons

for step in range(num_steps): # loop over time
    spike, state = net(data_in[step]) # one time step of forward-pass
    spike_recording.append(spike) # record spikes in list

A Deep Dive into SNNs

If you wish to learn all the fundamentals of training spiking neural networks, from neuron models, to the neural code, up to backpropagation, the snnTorch tutorial series is a great place to begin. It consists of interactive notebooks with complete explanations that can get you up to speed.

Tutorial	Title	Colab Link
Tutorial 1	Spike Encoding with snnTorch
Tutorial 2	The Leaky Integrate and Fire Neuron
Tutorial 3	A Feedforward Spiking Neural Network
Tutorial 4	2nd Order Spiking Neuron Models (Optional)
Tutorial 5	Training Spiking Neural Networks with snnTorch
Tutorial 6	Surrogate Gradient Descent in a Convolutional SNN
Tutorial 7	Neuromorphic Datasets with Tonic + snnTorch

Advanced Tutorials	Colab Link
Population Coding
Regression: Part I - Membrane Potential Learning with LIF Neurons
Regression: Part II - Regression-based Classification with Recurrent LIF Neurons
Accelerating snnTorch on IPUs	—

Intelligent Processing Unit (IPU) Acceleration

snnTorch has been optimized for Graphcore’s IPU accelerators. To install an IPU based build of snnTorch:

$ pip install snntorch-ipu

Low-level custom operations for IPU compatibility will be automatically compiled when import snntorch is called for the first time.

When updating the Poplar SDK, these operations may need to be recompiled. This can be done by reinstalling snntorch-ipu, or deleting files in the base directory with an .so extension.

The snntorch.backprop module, and several functions from snntorch.functional and snntorch.surrogate, are incompatible with IPUs, but can be recreated using PyTorch primitives.

Additional requirements include:

• poptorch

• The Poplar SDK

Refer to Graphcore’s documentation for installation instructions of poptorch and the Poplar SDK.

The homepage for the snnTorch IPU project can be found here. A tutorial for training SNNs is provided here.

Contributing

If you’re ready to contribute to snnTorch, instructions to do so can be found here.

Acknowledgments

snnTorch is currently maintained by the UCSC Neuromorphic Computing Group. It was initially developed by Jason K. Eshraghian in the Lu Group (University of Michigan).

Additional contributions were made by Vincent Sun, Peng Zhou, Ridger Zhu, Alexander Henkes, Steven Abreu, Xinxin Wang, Sreyes Venkatesh, gekkom, and Emre Neftci.

License & Copyright

snnTorch source code is published under the terms of the MIT License. snnTorch’s documentation is licensed under a Creative Commons Attribution-Share Alike 3.0 Unported License (CC BY-SA 3.0).
