Generic ETL Pipeline Framework for Apache Spark

Project description

Overview

Goal

There are many public clouds provide managed Apache Spark as service, such as databricks, AWS EMR, Oracle OCI DataFlow, see the table below for a detailed list.

However, the way to deploy Spark application and launch Spark application are incompatible among different cloud Spark platforms.

spark-etl is a python package, provides a standard way for building, deploying and running your Spark application that supports various cloud spark platforms.

Benefit

Your application using spark-etl can be deployed and launched from different cloud spark platforms without changing the source code.

Application

An application is a python program. It contains:

  • A main.py file which contains the application entry
  • A manifest.json file, which specify the metadata of the application.
  • A requirements.txt file, which specify the application dependency.

Application entry signature

In your application's main.py, you shuold have a main function with the following signature:

  • spark is the spark session object
  • input_args a dict, is the argument user specified when running this application.
  • sysops is the system options passed, it is platform specific. Job submitter may inject platform specific object in sysops object.
  • Your main function's return value should be a JSON object, it will be returned from the job submitter to the caller.
def main(spark, input_args, sysops={}):
    # your code here

Here is an application example.

Build your application

etl -a build -c <config-filename> -p <application-name>

Deploy your application

etl -a deploy -c <config-filename> -p <application-name> -f <profile-name>

Run your application

etl -a run -c <config-filename> -p <application-name> -f <profile-name> --run-args <input-filename>

Supported platforms

You setup your own Apache Spark Cluster.
Use PySpark package, fully compatible to other spark platform, allows you to test your pipeline in a single computer.
You host your spark cluster in databricks
You host your spark cluster in Amazon AWS EMR
You host your spark cluster in Google Cloud
You host your spark cluster in Microsoft Azure HDInsight
You host your spark cluster in Oracle Cloud Infrastructure, Data Flow Service
You host your spark cluster in IBM Cloud

Demos

APIs

pydocs for APIs

Job Deployer

For job deployers, please check the wiki .

Job Submitter

For job submitters, please check the wiki
