Spectral Clustering

# Spectral Clustering

## Overview

This is a Python re-implementation of the spectral clustering algorithm in the paper Speaker Diarization with LSTM.

## Disclaimer

This is not the original implementation used by the paper.

Specifically, in this implementation, we use the K-Means from scikit-learn, which does NOT support customized distance measure like cosine distance.

• numpy
• scipy
• scikit-learn

## Installation

Install the package by:

```pip3 install spectralcluster
```

or

```python3 -m pip install spectralcluster
```

## Tutorial

Simply use the `predict()` method of class `SpectralClusterer` to perform spectral clustering:

```from spectralcluster import SpectralClusterer

clusterer = SpectralClusterer(
min_clusters=2,
max_clusters=100,
p_percentile=0.95,
gaussian_blur_sigma=1)

labels = clusterer.predict(X)
```

The input `X` is a numpy array of shape `(n_samples, n_features)`, and the returned `labels` is a numpy array of shape `(n_samples,)`.

For the complete list of parameters of the clusterer, see `spectralcluster/spectral_clusterer.py`.

## Citations

Our paper is cited as:

``````@inproceedings{wang2018speaker,
title={Speaker diarization with lstm},
author={Wang, Quan and Downey, Carlton and Wan, Li and Mansfield, Philip Andrew and Moreno, Ignacio Lopz},
booktitle={2018 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP)},
pages={5239--5243},
year={2018},
organization={IEEE}
}
``````

## FAQs

### Laplacian matrix

Question: Why are you performing eigen-decomposition directly on the similarity matrix instead of its Laplacian matrix? (source)

Answer: No, we are not performing eigen-decomposition directly on the similarity matrix. In the sequence of refinement operations, the first operation is `CropDiagonal`, which replaces each diagonal element of the similarity matrix by the max non-diagonal value of the row. After this operation, the matrix has similar properties to a standard Laplacian matrix.

Question: Why don't you just use the standard Laplacian matrix?

Answer: Our Laplacian matrix is less sensitive (thus more robust) to the Gaussian blur operation.

### Cosine vs. Euclidean distance

Question: Your paper says the K-Means should be based on Cosine distance, but this repository is using Euclidean distance. Do you have a Cosine distance version?

Answer: You can find a variant of this repository using Cosine distance for K-means instead of Euclidean distance here: FlorianKrey/DNC

## Misc

Our new speaker diarization systems are now fully supervised, powered by uis-rnn. Check this Google AI Blog.
