Subfork Python

The Python client for Subfork. Discover nodes, build reusable graphs, publish versions, and run them from your scripts, applications, or agents.

Install

Requires Python 3.8+.

pip install subfork

Connect

Create a key under Account → API keys in Subfork and set SUBFORK_API_KEY in your environment. Grant the permissions your application needs: read, write, run, and/or publish. Keep the key out of source files and graph definitions.

from subfork import Subfork

with Subfork() as client:
    nodes = client.nodes.list()
    graphs = client.graphs.list()

The client reads SUBFORK_API_KEY and connects to subfork.com.

Command line

The package includes a subfork CLI that uses your SUBFORK_API_KEY.

subfork list
subfork export GRAPH_ID --output graph.json
subfork validate graph.json
subfork create graph.json --name "My new graph"
subfork publish GRAPH_ID --version v1
subfork execute GRAPH_ID --version v1
subfork execute GRAPH_ID -o results.json

execute waits for completion and shows progress on stderr. Results are opt-in: use -o results.json to save JSON or -o - to print it to stdout. Add -f / --force to overwrite existing output files with execute or export. Run subfork --help or subfork execute --help for more options.

Create and run a graph

This example creates a text-producing graph, publishes v1, and runs that version. It requires read, write, publish, and run permissions. Graphs are public, and runs use your account's execution quota.

from subfork import Subfork

name = "Python greeting"
definition = {
    "name": name,
    "nodes": [{
        "node_instance_id": "hello",
        "node_id": "n_text_value",
        "node_version": "1.0.0",
        "title": "Hello",
        "params": {"text": "Hello from Python"},
    }],
    "edges": [],
    "graph_outputs": {
        "text": {"node_instance_id": "hello", "output_name": "text"},
    },
}

with Subfork() as client:
    client.graphs.validate(definition)
    graph = client.graphs.create(name=name, definition=definition)
    client.graphs.publish(graph["id"], version="v1")

    execution = client.graphs.execute(graph["id"], version="v1")
    result = client.executions.wait(execution["id"], timeout=120)
    print(result["status"], result.get("outputs"))

To test a draft before publishing, call graphs.execute(graph_id) without a version. To update a draft, use graphs.update() with its name, definition, and description; omitting the description clears it.

Reuse building blocks

Explore published graphs and inspect their versioned interfaces:

with Subfork() as client:
    blocks = client.graphs.published()
    block = client.graphs.published_version(graph_id, "v1")

Replace graph_id with the ID of a graph you want to use. Published graph versions can be composed into larger graphs using the returned composite node manifest. Pin child versions so later publications do not change your graph's behavior.

Handle failures

HTTP failures raise APIError subclasses, including AuthenticationError, PermissionDeniedError, ValidationError, and RateLimitError. These expose status_code and an optional retry_after header.

executions.wait() returns failed and canceled runs as well as successful ones, so check the returned status. An ExecutionTimeout stops polling but does not cancel the remote run; use executions.cancel(execution_id) to request cancellation.

The client does not automatically retry requests. After a TransportError, check remote state before repeating a create, publish, or execute request.

Documentation

See the API and file workflow guide for asset uploads and artifact downloads, and the documentation for installation, Python usage, CLI options, and examples. Browse Subfork Examples and the subfork-examples repository for graphs to learn from and reuse.

Contributing

See CONTRIBUTING.md for development and code-quality checks.

License

BSD-3-Clause.
