TensorSpace-Converter is a TensorSpace preprocess tool for pre-trained model from TensorFlow, Keras, TensorFlow.js. TensorSpace-Converter can extract hidden layer value from a pre-trained model and generate a new multi-output model for TensorSpace 3D visualization. TensorSpace-Converter steeps the learning curve of TensorSpace preprocessing. Using TensorSpace-Converter in development, it is possible to separate the work of model training and model visualization.

Table of Content

• Motivation
• Getting Started
  • Install
  • Usage
• Converter API
• Converter Usage Examples
  • TensorFlow
  • Keras
  • TensorFlow.js
• Contributors
• Contact
• License

Motivation

TensorSpace is a 3D visualization framework for pre-trained deep learning models from TensorFlow, Keras, TensorFlow.js. Before applying TensorSpace, there is an important pipeline —— preprocessing the pre-trained model ( Checkout this article for more information about TensorSpace preprocessing ). TensorSpace-Converter is designed for TensorSpace users to quickly accomplish the TensorSpace Preprocessing.

TensorSpace-Converter out-of-the-box supports preprocessing different formats of pre-trained model from TensorFlow, Keras, TensorFlow.js. It only takes several lines of TensorSpace-Converter codes to preprocess a pre-trained model. Before TensorSpace-Converter, to preprocess a pre-trained model for TensorSpace, developers shall master some frameworks, such as TensorFlow, Keras, tfjs-converter. For example, before TensorSpace-Converter, when preprocessing a Keras model, developers need to prepare a pre-trained Keras model, write some Keras codes to get a new multi-output model, and then use tfjs-converter to convert the multi-output model to a TensorSpace compatible format. By applying TensorSpace-Converter, it just takes 6 lines of TensorSpace-Converter commands to do the same thing.

As a component of TensorSpace ecosystem, TensorSpace-Converter simplify the TensorSpace preprocessing, steeps the learning curve of TensorSpace. As a development tool, TensorSpace-Converter makes it possible to separate the work of backend model training and frontend model visualization.

Fig. 1 - TensorSpace LeNet

Fig. 2 - TensorSpace Preprocess Concept

Getting Started

Install

Install the tensorspacejs pip package:

$ pip install tensorspacejs

If successfully downloading tensorspacejs, you can check the TensorSpace-Converter version in command line:

$ tensorspacejs_converter -v

• Note

TensorSpace-Converter must run under Python 3.6, Node 11.3+. If you have other pre-installed Python version in your local environment, we suggest you to use Conda to create a pure Python 3.6 virtual environment.

$ conda create -n envname python=3.6

Usage

Then we will introduce the usage and workflow of using TensorSpace and TensorSpace-Converter to convert a pre-trained model and visualizing pre-processed model with TensorSpace. And we will preprocess and visualize a MNIST-digit Keras model.

The sample files used in this tutorial includes pre-trained Keras model, TensorSpace-Converter script and TensorSpace visualization code.

Step 1: Use TensorSpace-Converter preprocess pre-trained model

$ tensorspacejs_converter \
    --input_model_from="keras" \
    --input_model_format="topology_weights_combined" \
    --output_layer_names="Conv2D_1,MaxPooling2D_1,Conv2D_2,MaxPooling2D_2,Dense_1,Dense_2,Softmax" \
    ./PATH/TO/MODEL/keras_MNIST_model.h5 \
    ./PATH/TO/SAVE/DIR

Step 2: Load preprocessed into TensorSpace visualization model

model.load({
    type: "keras",
    url: "/PATH/TO/MODEL/model.json"
});

Converter API

Sample TensorSpace-Converter script:

$ tensorspacejs_converter \
    --input_model_from="XXX" \
    --input_model_format="YYY" \
    --output_layer_names="EEE1,EEE2,EEE3" \
    input_path \
    output_path

Arguments explanation:

Converter Usage Examples

This section introduces the usage of TensorSpace-Converter for different types of pre-trained model from TensorFlow, Keras, TensorFlow.js.

TensorFlow

A pre-trained model built with TensorFlow, may be saved as saved model, frozen model, checkpoint model, combined HDF5 model or separated HDF5 model. Use different TensorSpace-Converter commands for different kinds of TensorFlow model formats. A TensorFlow graph may not have layer concept, however, a specific tensor can be corresponding a layer for TensorSpace visualization, collect all these tensor names and set the name list to output_layer_names.

For a TensorFlow saved model. Set input_model_format to be tf_saved_model. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="tensorflow" \
    --input_model_format="tf_saved_model" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    input_path \
    ./PATH/TO/SAVE/DIR

For a TensorFlow frozen model. Set input_model_format to be tf_frozen_model. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="tensorflow" \
    --input_model_format="tf_frozen_model" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    input_path \
    ./PATH/TO/SAVE/DIR

For a TensorFlow checkpoint model. Set input_model_format to be tf_checkpoint_model. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="tensorflow" \
    --input_model_format="tf_checkpoint_model" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    input_path \
    ./PATH/TO/SAVE/DIR

For a combined HDF5 model, topology and weights are saved in a combined HDF5 file xxx.h5. Set input_model_format to be tf_hdf5_model. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="tensorflow" \
    --input_model_format="tf_hdf5_model" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    ./PATH/TO/MODEL/xxx.h5 \
    ./PATH/TO/SAVE/DIR

For a separated HDF5 model, topology and weights are saved in separate files, topology file xxx.json and weights file xxx.hdf5. Set input_model_format to be tf_hdf5_separated_model. In this case, the model have two input files, merge two file's paths and separate them with comma (.json first, .hdf5 last), and then set the combined path to positional argument input_path. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="tensorflow" \
    --input_model_format="tf_hdf5_separated_model" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    ./PATH/TO/MODEL/xxx.json,./PATH/TO/MODEL/eee.hdf5 \
    ./PATH/TO/SAVE/DIR

Checkout this TensorFlow Tutorial for more practical usage of TensorSpace-Converter for TensorFlow models.

Keras

A pre-trained model built with Keras, may have two formats: topology and weights in a combined HDF5 file or topology and weights in separated files. Use different TensorSpace-Converter commands for these two keras model formats.

For a Keras model, topology and weights are saved in a combined HDF5 file xxx.h5. Set input_model_format to be topology_weights_combined. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="keras" \
    --input_model_format="topology_weights_combined" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    ./PATH/TO/MODEL/xxx.h5 \
    ./PATH/TO/SAVE/DIR

For a Keras model, topology and weights are saved in separated files, a topology file xxx.json and a weights file xxx.hdf5. Set input_model_format to be topology_weights_separated, in this case, the model have two input files, merge two file's paths and separate them with comma (.json first, .hdf5 last), and then set the combined path to positional argument input_path. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="keras" \
    --input_model_format="topology_weights_separated" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    ./PATH/TO/MODEL/xxx.json,./PATH/TO/MODEL/eee.hdf5 \
    ./PATH/TO/SAVE/DIR

Checkout this Keras Tutorial for more practical usage of TensorSpace-Converter for Keras models.

TensorFlow.js

A pre-trained model built with TensorFlow.js, may have a topology file xxx.json and a weights file xxx.weight.bin. To converter the model with TensorSpace-Converter, put two files in the same folder and set topology file's path to input_path. Demo converter script:

$ tensorspacejs_converter \
    --input_model_from="tfjs" \
    --output_layer_names="layer1Name,layer2Name,layer3Name" \
    ./PATH/TO/MODEL/xxx.json \
    ./PATH/TO/SAVE/DIR

Checkout this TensorFlow.js tutorial for more practical usage of TensorSpace-Converter for TensorFlow.js models.
