Autoscaling GitHub Actions Runners Using Hetzner Cloud
Project description
Autoscaling GitHub Actions Runners Using Hetzner Cloud
The github-runners service program starts and monitors queued up jobs for GitHub Actions workflows. When a new job is queued up, it creates a new Hetzner Cloud server instance that provides an ephemeral GitHub Actions runner. Each server instance is automatically powered off when job completes and then powered off servers are automatically deleted. Both x64 and arm64 runners are supported.
- ❗Warning:
This program is provided on “AS IS” basis without warranties or conditions of any kind. See LICENSE. Use it at your own risk. Manual monitoring is required to make sure server instances are cleaned up properly.
Costs depend on the server type, number of jobs and execution time. For each job a new server instance is created to avoid any cleanup. Server instances are not shared between any jobs.
- ✋ Note:
Currently Hetzner Cloud server instances are billed on hourly basis. So a job that takes 1 min will be billed the same way as for a job that takes 59 minutes. Therefore, the minimal cost for any job is the cost of the server for 1 hour plus the cost for one public IPv4 address.
Features
cost efficient on-demand runners using Hetzner Cloud
supports both x64 and ARM64 runners
supports specifying custom runner types using job labels
simple configuration
Installation
pip3 install testflows.github.runners
Quick Start
Set environment variables corresponding to your GitHub repository and Hetzner Cloud project
export GITHUB_TOKEN=ghp_...
export GITHUB_REPOSITORY=vzakaznikov/github-runners
export HETZNER_TOKEN=GJzdc...
export HETZNER_SSH_KEY_NAME=user@user-node
and then start github-runners program
github-runners
07/22/2023 08:20:37 PM INFO MainThread main 🍀 Logging in to Hetzner Cloud 07/22/2023 08:20:37 PM INFO MainThread main 🍀 Logging in to GitHub 07/22/2023 08:20:37 PM INFO MainThread main 🍀 Getting repository vzakaznikov/github-runners 07/22/2023 08:20:37 PM INFO MainThread main 🍀 Creating scale up service 07/22/2023 08:20:37 PM INFO MainThread main 🍀 Creating scale down service 07/22/2023 08:20:38 PM INFO worker_2 create_server 🍀 Create server ...
or you can pass the required options inline as follows:
github-runners --github-token <GITHUB_TOKEN> --github-repository <GITHUB_REPOSITORY> --hetzner-token <HETZNER_TOKEN> --hetzner-ssh-key <HEZNER_SSH_KEY>
Installation From Sources
For development, you can install from sources as follows:
git clone https://github.com/testflows/Github-Runners.git
./package && ./install
Basic Configuration
By default, the program uses the following environment variables:
GITHUB_TOKEN
GITHUB_REPOSITORY
HETZNER_TOKEN
HETZNER_SSH_KEY
or you can specify these values using the following options:
–github-token
–github-repository
–hetzner-token
–hetzner-ssh-key
Running as a Service
You can run github-runners as a service. For this you will need to install it using the root user or the sudo command.
sudo pip3 install testflows.github.runners
After installation, you can use service install and service uninstall commands to install and uninstall the service.
export GITHUB_TOKEN=ghp_...
export GITHUB_REPOSITORY=testflows/github-runners
export HETZNER_TOKEN=GJzdc...
export HETZNER_SSH_KEY_NAME=user@user-node
sudo github-runners service install
sudo github-runners service uninstall
After installation, you can check the status of the server using the service status command.
sudo github-runners service status
You can start and stop the service using the service start and service stop commands as follows:
sudo github-runners service start
sudo github-runners service stop
or using service system utility
sudo service github-runners start
sudo service github-runners stop
You can get the logs for the service using the service logs command.
sudo github-runners service logs
which is equivalent to the following journalctl command:
journalctl -u github-runners.service -f
Scaling Up Runners
The program scale up runners by looking for any jobs that have queued status. For each such job, a corresponding Hetzner Cloud server instance is created with the following name:
gh-actions-runner-{job.run_id}
The server is configured using default setup and startup scripts. The runner name is set to be the same as the server name so that servers can deleted for any idle runner that for some reason does not pick up a job for which it was created within the max-idle-runner-time period.
- Note:
Given that the server name is fixed and specific for each job.run_id, if multiple github-runners are running in parallel then only 1 server will be created for a given job and any other attempts to create a server with the same name will be rejected by the Hetzner Cloud.
Also,
- Note:
There is no guarantee that a given runner will pick the the job with the exact run_id that caused it to be created. This is expected and because for each queued job a unique runner will be created the number of runners will be equal the number of jobs and therefore under normal conditions all jobs will executed as expected.
Maximum Number of Runners
By default, the maximum number of runners and therefore server instances is not set and therefore is unlimited. You can set the maximum number of runners using the –max-runners option.
New Server
The new server is accessed using SSH. It boots up with the specified OS image and is configured using the setup and startup scripts.
- Server Type:
The default server type is cx11. However, a job server-{hetzner-server-type} label can be used to specify custom server type. Where the {hetzner-server-type} must be a valid Hetzner Cloud server type name such as cx11, cpx21 etc.
For example,
runs-on: [self-hosted, server-cpx21]
- SSH Access:
The server is configured to be accessed using ssh utility and the SSH key specified by name either using the –hetzner-ssh-key option or the HETZNER_SSH_KEY environment variable.
- OS Image:
The server is configured to have the OS image specified by the –hetzner-image option or the HETZNER_IMAGE environment variable.
- Image Configuration:
Each new server instance is configured using setup and startup scripts.
The Setup Script
The setup script created and configures runner user that has sudo privileges.
- Setup:
set -x echo "Create and configure runner user" adduser runner --disabled-password --gecos "" echo "%wheel ALL=(ALL:ALL) NOPASSWD:ALL" >> /etc/sudoers addgroup wheel usermod -aG wheel runner usermod -aG sudo runner
The Start-up Script
The startup script installs GitHub Actions runner. After installation it configures the runner to start in an –ephemeral mode. The –ephemeral mode causes the runner to exit as soon as it completes a job. After the runner exits the server is powered off.
The x64 startup script installs and configures x64 version of the runner.
- x64:
set -x echo "Install runner" cd /home/runner curl -o actions-runner-linux-x64-2.306.0.tar.gz -L https://github.com/actions/runner/releases/download/v2.306.0/actions-runner-linux-x64-2.306.0.tar.gz echo "b0a090336f0d0a439dac7505475a1fb822f61bbb36420c7b3b3fe6b1bdc4dbaa actions-runner-linux-x64-2.306.0.tar.gz" | shasum -a 256 -c tar xzf ./actions-runner-linux-x64-2.306.0.tar.gz echo "Configure runner" ./config.sh --unattended --replace --url https://github.com/${GITHUB_REPOSITORY} --token ${GITHUB_RUNNER_TOKEN} --name "$(hostname)" --runnergroup "${GITHUB_RUNNER_GROUP}" --labels "${GITHUB_RUNNER_LABELS}" --work _work --ephemeral echo "Start runner" bash -c "screen -d -m bash -c './run.sh; sudo poweroff'"
The ARM64 startup script is similar to the x64 script but install an ARM64 version of the runner.
- ARM64:
set -x echo "Install runner" cd /home/runner curl -o actions-runner-linux-arm64-2.306.0.tar.gz -L https://github.com/actions/runner/releases/download/v2.306.0/actions-runner-linux-arm64-2.306.0.tar.gz# Optional: Validate the hash echo "842a9046af8439aa9bcabfe096aacd998fc3af82b9afe2434ddd77b96f872a83 actions-runner-linux-arm64-2.306.0.tar.gz" | shasum -a 256 -c# Extract the installer tar xzf ./actions-runner-linux-arm64-2.306.0.tar.gz echo "Configure runner" ./config.sh --unattended --replace --url https://github.com/${GITHUB_REPOSITORY} --token ${GITHUB_RUNNER_TOKEN} --name "$(hostname)" --runnergroup "${GITHUB_RUNNER_GROUP}" --labels "${GITHUB_RUNNER_LABELS}" --work _work --ephemeral echo "Start runner" bash -c "screen -d -m bash -c './run.sh; sudo poweroff'"
Scaling Down Runners
Powered Off Servers
The program scales down runners by first cleaning up powered off servers. The scale down service relies on the fact that the startup script starts an ephemeral runner which will pick up only 1 job and then will power itself off after the job is complete.
The powered off servers are deleted after the max-powered-off-time interval which can be specified using the –max-powered-off-time option which by default is set to 20 sec.
Idle Runners
The scale down service also monitors all the runners that have idle status and tries to delete any servers associated with such runners if the runner is idle for more than the max-idle-runner-time period. This is needed in case a runner never gets a job assigned to it and the server will stay in the power on state. This cycle relies on the fact that the runner’s name is the same as server’s name. The max-idle-runner-time can be specified using the –max-idle-runner-time option which by default is set to 120 sec.
Zombie Servers
The scale down service will delete any zombie servers. A zombie server is defined as as any server that fails to register its runner within the max-runner-registration-time. The max-runner-registration-time can be specified using the –max-runner-registration-time option which by default is set to 60 sec.
Handling Failing Conditions
The program is designed to handle the following failing conditions:
- Server Never Registers a Runner:
The server will remain in running state and should be reclaimed by the scale down service when it checks the actual runners registered for current servers. If it finds a server that is running but no runner is active for it it will be deleted after the max-runner-registration-time period.
- The ./config.sh Command Fails:
The behavior will be the same as for the Server Never Registers a Runner case above.
- The ./run.sh Command Fails:
The server will be powered off by the startup script and will be deleted by the scale down service.
- Creating Server For Queued Job Fails:
If creation of the server fails for some reason then the scale up service will retry the operation in the next interval as the job’s status will remain queued.
- Runner Never Gets a Job Assigned:
If the runner never gets a job assigned, then the scale down service will remove the runner and delete its server after the max-idle-runner-time period.
- Runner Created With a Mismatched Labels:
The behavior will be the same as for the Runner Never Gets a Job Assigned case above.
Program Options
The following options are supported:
-h, –help show this help message and exit
-v, –version show program’s version number and exit
–license show program’s license and exit
–github-token GITHUB_TOKEN GitHub token, default: $GITHUB_TOKEN environment variable
–github-repository GITHUB_REPOSITORY GitHub repository, default: $GITHUB_REPOSITORY environment variable
–hetzner-token HETZNER_TOKEN Hetzner Cloud token, default: $HETZNER_TOKEN environment variable
–ssh-key HETZNER_SSH_KEY Hetzner Cloud SSH key name, default: $HETZNER_SSH_KEY environment variable
–image HETZNER_IMAGE Hetzner Cloud server image name, default: ubuntu-20.04
-m count, –max-runners count maximum number of active runners, default: unlimited
-w count, –workers count number of concurrent workers, default: 10
–logger-config path custom logger configuration file
–setup-script path path to custom server setup script
–startup-x64-script path path to custom server startup script
–startup-arm64-script path path to custom ARM64 server startup script
–max-powered-off-time sec maximum time after which a powered off server is deleted, default: 20 sec
–max-idle-runner-time sec maximum time after which an idle runner is removed and its server deleted, default: 120 sec
–max-runner-registration-time maximum time after which the server will be deleted if its runner is not registered with GitHub, default: 60 sec
–scale-up-interval sec scale up service interval, default: 10 sec
–scale-down-interval sec scale down service interval, default: 10 sec
–debug enable debugging mode, default: False
commands:
command
service service commands
install install service
uninstall uninstall service
status get service status
logs get service logs
start start service
stop stop service
