ThermoPack

Thermopack is a thermodynamics library for multi-component and multi-phase thermodynamics developed at SINTEF Energy Research and NTNU Department of Chemistry. Through decades of research, we have developed a software that performs thermodynamic calculations. A large selection of equations of state has been implemented in this software. Most of these equations of state have been developed by other research groups around the world, but some of them have been developed by us. Thermopack has been a much-appreciated in-house powerhouse.

For the full documentation and user guide to ThermoPack, see the ThermoPack homepage. If you are running ThermoPack installed via pip, make sure to check the documentation for the correct version by selecting the version number in the sidebar.

Thermopack is available for everybody, free of charge under the MIT/Apache 2.0 open-source licenses. Thermopack is written in FORTRAN to handle heavy numerical computations associated with process and computational fluid dynamics (CFD) simulations. The thermodynamic framework is easily interfaced from C/C++ and also contains a flexible Python wrapper to make scripting easy.

Table of contents

• Program structure
• Please cite
• Authors and contact persons
• License
• Acknowledgments
• Getting started
  • Initialising an equation of state
• Doing calculations
  • pVT-properties
  • Phase diagrams and equilibria
  • Isolines
  • Critical point
• Advanced usage
  • Interaction parameters
• Component identifiers

Please Cite

Thermopack has been developed through many projects, and have produced many articles. If you are writing academic publications, please cite one or more of the following articles:

• For general usage:
  Thermodynamic Modeling with Equations of State: Present Challenges with Established Methods

• Quantum cubic:
  Accurate quantum-corrected cubic equations of state for helium, neon, hydrogen, deuterium and their mixtures

• SAFT-VR Mie and SAFT-VRQ Mie:
  Equation of state and force fields for Feynman--Hibbs-corrected Mie fluids. I. Application to pure helium, neon, hydrogen, and deuterium
  Equation of state and force fields for Feynman–Hibbs-corrected Mie fluids. II. Application to mixtures of helium, neon, hydrogen, and deuterium
  Choice of reference, the influence of non-additivity and challenges in thermodynamic perturbation theory for mixtures

• CPA, PC-SAFT or cubic models with Wong–Sandler, Huron–Vidal or UNIFAC mixing rules:
  Thermodynamic models to accurately describe the PVTxy-behavior of water/carbon dioxide mixtures

• Using dry-ice and water-ice model or the tc-PR/tc-RK:
  Depressurization of CO₂-N₂ and CO₂-He in a pipe: Experiments and modelling of pressure and temperature dynamics

• Energy-density and entropy-density flashes:
  The influence of CO2 mixture composition and equations of state on simulations of transient pipeline decompression

• Mapping spinodals or critical points:
  The spinodal of single-and multi-component fluids and its role in the development of modern equations of state
  Predicting triggering and consequence of delayed LNG RPT

• Perturbation theories for Lennard-Jones spline fluid:
  Perturbation theories for fluids with short-ranged attractive forces: A case study of the Lennard-Jones spline fluid
  Thermodynamic properties of the 3D Lennard-Jones/spline model

License

Thermopack is distributed under the MIT license and Apache 2.0.

Acknowledgments

A number of colleagues at SINTEF Energy Research and NTNU have contributed to the development of thermopack. We gratefully acknowledge their contributions.

Program structure

The core of ThermoPack is the Fortran module. For more information on that, see the GitHub page. This page contains an introduction to the ThermoPack python-wrapper, which is an object-oriented implementation of a variety of equations of state (EoS), with integrated methods for computing thermodynamic properties.

Each EoS in thermopack is a class, which inherits from the thermopack class found in thermo.py. This class contains all generic methods used to compute thermodynamic properties, phase equilibria, etc. The inheriting classes simply ensure that the correct part of the Fortran-module is linked when performing calculations, and provide some extended functionality for handling EoS parameters and such. See the ThermoPack homepage for more information.

Fluid parameters are compiled into the Fortran-module, and are not directly accessible through the Python-wrapper. The entire fluid parameter database used by thermopack may be found in the /fluids directory in the GitHub repo. In order to model fluids not currently supported in the module available through pip, ThermoPack must be compiled from source with the new parameters. See the ThermoPack homepage for information on how to add new fluids, and a guide on how to compile from source. Please feel free to leave a PR for new parameter sets such that these can be included in future releases of thermopack.

Getting Started

Compatibility

ThermoPack v2.2.0 is completely backwards compatible with v2.1.0, such that all examples in the guide for v2.1.0 will also work with v2.2.0. This guide primarily aims to demonstrate functionality that is new in v2.2.0.

Getting started - Python

This is a short introduction to thermopack. Once you've gotten started, we recommend a look at the Examples in the GitHub repo. Comprehensive documentation for the methods available through the python interface can also be found in the doc page for the thermo class.. For more advanced users, a look at the more advanced page may also be useful.

Equations of State (EoS's) in ThermoPack are classes. To do calculations for a given mixture an EoS object must first be initialized for that mixture, as demonstrated in the Initializing an EoS section. Then, a wide variety of thermodynamic computations can be done, as demonstrated in the remaining sections.

Contents

• Initialising an equation of state
• pVT properties
  • Differentials
• Phase diagrams and equilibria
  • Flash calculations
  • Phase envelopes
    • Tp- and Tv- envelopes
    • pxy- and Txy- envelopes
  • Dew- and bubble points
• Isolines
• Critical point

Initialising an equation of state

An overview of available equations of state can be found here.

An EoS is initialized by passing in the fluid identifiers of the mixture, for example

from thermopack.saftvrmie import saftvrmie
eos = saftvrmie('C1,CO2')

will initialize a SAFT-VR Mie EoS for a mixture of methane and CO2. The complete list of component identifiers is in the Fluid identifiers list. PC-SAFT, SAFT-VRQ Mie and Lee-Kesler EoS are initialized in the same way, as

from thermopack import saftvrmie, saftvrqmie, pcsaft, lee_kesler
svrm = saftvrmie.saftvrmie('AR,KR') # SAFT-VR Mie EoS for Ar/Kr mixture
svrqm = saftvrqmie.saftvrqmie('HE') # SAFT-VRQ Mie EoS for pure He
pcs = pcsaft.pcsaft('BENZENE,NC6,NC12') # PC-SAFT EoS for ternary benzene/hexane/dodecane mixture
lk = lee_kesler.lee_kesler('N2,O2') # Lee-Kesler EoS for nitrogen/oxygen mixture

For PC-SAFT, both the simplified PC-SAFT (SPC-SAFT) and Polar PC-SAFT (PCP-SAFT) are available

from thermopack.pcsaft import SPC_SAFT, PCP_SAFT
spcs = SPC_SAFT('NC6,NC12') # Simplified PC-SAFT
pcps = PCP_SAFT('H2O,MEOH') # Polar PC-SAFT

The cubic equations of state are found in the cubic module. Available cubic EoS's and more information on the individual cubics, mixing rules, etc. can be found on the cubic page.

from thermopack.cubic import SoaveRedlichKwong, RedlichKwong, PengRobinson, PengRobinson78
from thermopack.cubic import SchmidtWensel, PatelTeja, VanDerWaals
srk = SoaveRedlichKwong('NH3,C2') # SRK EoS for ammonia/ethane mixture
rk = RedlichKwong('NC6,CO2,NC12') # Redlich-Kwong EoS
pr = PengRobinson('IC4,NC10') # PR EoS for isobutane/decane mixture
pr78 = PengRobinson78('N2,O2,CO2') # # PR-78 EoS for isobutane/decane mixture
vdw = VanDerWaals('C1,C2,C3,N2,O2') # VdW EoS for methane/ethane/propane/nitrogen/oxygen mixture
sw = SchmidtWensel('R11,R12') # Schmidt-Wensel EoS for FCl3C/F2Cl2C mixture
pt = PatelTeja('PRLN') # Patel-Teja EoS for pure propylene

In addition to these, the Translated-Consisten Peng-Robinson is available as

from thermopack.tcPR import tcPR
tcpr = tcPR('F6S,SO2') # Translated-Consistent PR EoS for SF6/SO2 mixture

For more fine-tuned control of the cubic EoS, the parent class cubic can be initialised directly, to explicitly set mixing rules, alpha-correlation etc.

Cubic-plus association EoS's are available for the SRK and PR EoS through the cpa module as

from thermopack.cpa import SRK_CPA, PR_CPA
srk_cpa = SRK_CPA('H2O,ETOH,PROP1OL') # SRK-CPA EoS for water/ethanol/propanol mixture

Several multiparameter EoS's can interfaced through the multiparameter.multiparam class. The available multiparameter EoS's are NIST-MEOS, MBWR16 and MBWR32. These are initialized as

from thermopack.multiparameter import multiparam
nist = multiparam('C3', 'NIST_MEOS') # NIST-MEOS EoS for propane
mbwr19 = multiparam('C1', 'MBWR19') # MBWR19 EoS for methane
mbwr32 = multiparam('C2', 'MBWR32') # MBWR32 EoS for ethane

please note that not all fluids are supported for multiparameter equations of state, depending on what parameters are available in the fluid database.

Finally, the Extended-corresponding state EoS is available through the extended_csp.ext_csp class as

from thermopack.extended_csp import ext_csp
eos = ext_csp('C1,C2,C3,NC4', sh_eos='SRK', sh_alpha='Classic',
              sh_mixing='vdW', ref_eos='NIST_MEOS', ref_comp='C3')

For more information on the extended-csp EoS please see the Examples and the memo.

Doing calculations

Now that we have an EoS initialized we can start computing stuff. The primary source on how to use individual methods in thermopack are the specific documentation of the thermo class. Here, a small subset of the functionality is demonstrated.

Note that all input/output is in SI units (moles/kelvin/pascal/cubic meters/joule)

pVT-properties

Specific volume, given temperature, pressure and composition is computed as

from thermopack.saftvrmie import saftvrmie
eos = saftvrmie('NC6,NC10') # Hexane/decane mixture
T = 300 # Kelvin
p = 1e5 # Pascal
x = [0.2, 0.8] # Molar composition
vg, = eos.specific_volume(T, p, x, eos.VAPPH) # Molar volume of gas phase (NB: Notice the comma)
vl, = eos.specific_volume(T, p, x, eos.LIQPH) # Molar volume of liquid phase (NB: Notice the comma)

where eos.VAPPH and eos.LIQPH are phase flags used to identify different phases. The commas are necessary because all output from thermopack methods are as tuples.

Similarly, pressure, internal energy, enthalpy, entropy, etc. and associated differentials can be computed via the methods chemical_potential_tv(T, V, n), internal_energy_tv(T, V, n), enthalpy_tv(T, V, n), helmholtz_tv(T, V, n), entropy_tv(T, V, n). For a full overview of the available property calculations see the TV-property interfaces and the Tp-property interfaces of the thermo class.

Differentials

If we want volume differentials, we use the same method, but set the flags to calculate differentials to True:

# Continued
vg, dvdp = eos.specific_volume(T, p, x, eos.VAPPH, dvdp=True) # Vapour phase molar volume and pressure differential
vl, dvdT = eos.specific_volume(T, p, x, eos.LIQPH, dvdt=True) # Liquid phase molar volume and temperature differential
_, dvdn = eos.specific_volume(T, p, x, eos.LIQPH, dvdn=True) # Liquid phase partial molar volumes

Differentials can be computed as functions of $(T, V, n)$ or as functions of $(T, p, n)$. For an overview of the different methods, see Advanced usage: Different property interfaces. A short example is given here as:

# Continued
n_tot = 15 # Total number of moles
n = n_tot * x
H, dHdn_TV = eos.enthalpy_tv(T, vg, n, dhdn=True) # Compute enthalpy and derivative of enthalpy wrt. mole numbers at constant (T, V)
h_vap, dhvap_dn_Tp = eos.enthalpy(T, p, x, eos.VAPPH, dhdn=True) # Compute molar vapour phase enthalpy and derivative of molar vapour phase enthalpy wrt. mole numbers at constant (T, p)
h_liq, dliq_dn_Tp = eos.enthalpy(T, p, x, eos.LIQPH, dhdn=True) # Compute molar liquid phase enthalpy and derivative of molar liquid phase enthalpy wrt. mole numbers at constant (T, p)
H, dHdn_Tp = eos.enthalpy_tvp(T, vg, n, dhdn=True) # Compute enthalpy and derivative of enthalpy wrt. mole numbers at constant (T, p)

Please note that heat capacities are not available directly, but must be computed as derivatives of enthalpy and internal energy, as

from thermopack.cubic import cubic
eos = cubic('C1,C3,NC6', 'SRK') # SRK EoS for a mixture of methane, propane and n-hexane

T = 300 # Kelvin
p = 1e5 # Pascal
x = [0.2, 0.1, 0.7] # Molar composition
_, Cp_vap = eos.enthalpy(T, p, x, eos.VAPPH, dhdt=True) # Vapour phase heat capacity at constant pressure, computed as (dH/dT)_{p,n}
_, Cp_liq = eos.enthalpy(T, p, x, eos.LIQPH, dhdt=True) # Liquid phase heat capacity at constant pressure, computed as (dH/dT)_{p,n}

vg, = eos.specific_volume(T, p, x, eos.VAPPH) # Computing vapour phase specific volume
vl, = eos.specific_volume(T, p, x, eos.LIQPH) # Liquid phase specific volume

_, Cv_vap = eos.internal_energy_tv(T, vg, x, dedt=True) # Vapour phase heat capacity at constant volume, computed as (dU/dT)_{V,n}
_, Cv_liq = eos.internal_energy_tv(T, vl, x, dedt=True) # Liquid phase heat capacity at constant volume, computed as (dU/dT)_{V,n}

Phase diagrams and Equilibria

As with other calculations, the primary source on how available methods for flash- and equilibria calculations and how to use them is the documentation of the thermo class.. Here we give a short introduction, for more extensive examples see the pyExamples directory.

Flash calculations

Flash calculations of several kinds are handled by the methods twophase_tpflash(), twophase_psflash(), twophase_phflash() and twophase_uvflash().

See the Flash interfaces in the documentation of the thermo class for the specifics on the different flash routines.

The result of a flash calculation is returned in a FlashResult struct. The specific results of the calculation are accessed through the attributes of this object.

An example calculation using twophase_tpflash() may be done as

from thermopack.saftvrqmie import saftvrqmie
# SAFT-VRQ Mie for Hydrogen/Helium/Neon mixture
eos = saftvrqmie('H2,HE,NE', minimum_temperature=20) # NB: Set minimum temperature low enough when working at very low temperatures
T = 35 # Kelvin
p = 3e6 # Pascal (30 bar)
z = [0.1, 0.25, 0.65] # Molar composition
flsh = eos.two_phase_tpflash(T, p, z) # flsh is a FlashResult object
print(flsh)
### Output: ###
# FlashResult object for Tp-flash
# Containing the attributes (description, name, value):
#   	Flash type                     flash_type : Tp
#   	Total composition              z     : [0.1, 0.25, 0.65]
#   	Temperature [K]                T     : 35
#   	pressure [Pa]                  p     : 3000000.0
#   	Liquid phase composition       x     : [0.05407302 0.03859287 0.90733411]
#   	Vapour phase composition       y     : [0.14642524 0.46370066 0.3898741 ]
#   	Vapour fraction                betaV : 0.497302408174766
#   	Liquid fraction                betaL : 0.5026975918252341
#   	Phase indentifier index        phase : 0

the result of the flash is accessed from the attributes of the FlashResult object, found in utils.py, as

# Continued
x = flsh.x # Liquid composition
y = flsh.y # Vapour composition
betaL = flsh.betaL #
# ... etc

The FlashResult object returned by the different flash routines all contain the same attributes.

Phase envelopes

ThermoPack has interfaces to trace (T,p)-, (T,v)-, (p,x,y)- and (T, x, y)- phase envelopes. For the full documentation, see the docs of the thermo class. For more comprehensive examples, see the Examples.

Tp- and Tv- phase envelopes

Phase envelopes can be generated directly with the method get_envelope_twophase() as

# Continued
T, p = eos.get_envelope_twophase(1e5, x) # arrays of temperature and pressure for phase envelope, starting at 1 bar.
plt.plot(p, T) # Tp-projection of phase envelope

T, p, v = eos.get_envelope_twophase(1e5, x, calc_v=True) # Also return the specific volume at each point along the phase envelope
plt.plot(1 / v, T) # rho-T projection of the phase envelope

pxy- and txy- phase envelopes

To compute pxy-type phase envelopes, we use the get_binary_pxy() method. This method returns a XYDiagram struct, which holds the composition and pressure / temperature of each equilibrium phase.

The XYDiagram struct has the attributes lle, l1ve and l2ve, where

• lle holds the composition and pressure / temperature of the Liquid 1 - Liquid 2 equilibria
  • lle.x1 is the composition of Liquid 1 (mole fraction of species 1)
  • lle.x2 is the composition of Liquid 2 (mole fraction of species 1)
  • lle.p / lle.T is the pressure / temperature along the phase boundary
• l1ve holds the composition and pressure / temperature of the Liquid 1 - Vapour equilibria
  • l1ve.x is the composition of Liquid 1 (mole fraction of species 1)
  • l1ve.y is the composition of the vapour (mole fraction of species 1)
  • l1ve.p / l1ve.T is the pressure / temperature along the phase boundary
• l2ve holds the composition and pressure / temperature of the Liquid 2 - Vapour equilibria
  • l2ve.x is the composition of Liquid 2 (mole fraction of species 1)
  • l2ve.y is the composition of the vapour (mole fraction of species 1)
  • l2ve.p / l2ve.T is the pressure / temperature along the phase boundary

We get the phase diagram as

from thermopack.cpa import SRK_CPA

eos = SRK_CPA('NC6,H2O')  # CPA-SRK eos for Hexane/water mixture
T = 350
pxy = eos.get_binary_pxy(T)  # Returns a XYDiagram struct
print(pxy)
# Result:
# XYDiagram object with attributes (name : description)
# lle  : Liquid 1 - Liquid 2 Equilibrium
# 	PxyEquilibrium object with attributes (description, name, value)
# 		Type of equilibrium                   type : lle
# 		Liquid 1 mole fraction, species 1     x1   : [4.278e-07 ... 4.145e-07], len(x1) = 457
# 		Liquid 2 mole fraction, species 1     x2   : [9.969e-01 ... 9.974e-01], len(x2) = 457
# 		Pressure                              p    : [1.648e+05 ... 1.500e+07], len(p) = 457
#
# l1ve : Liquid 1 - Vapour Equilibrium
# 	PxyEquilibrium object with attributes (description, name, value)
# 		Type of equilibrium                   type : lve
# 		Liquid mole fraction, species 1       x    : [4.278e-07 ... 2.197e-07], len(x) = 66
# 		Vapour mole fraction, species 1       y    : [7.880e-01 ... 6.461e-01], len(y) = 66
# 		Pressure                              p    : [1.648e+05 ... 1.000e+05], len(p) = 66
#
# l2ve : Liquid 2 - Vapour Equilibrium
# 	PxyEquilibrium object with attributes (description, name, value)
# 		Type of equilibrium                   type : lve
# 		Liquid mole fraction, species 1       x    : [9.969e-01 ... 1.000e+00], len(x) = 100
# 		Vapour mole fraction, species 1       y    : [7.880e-01 ... 1.000e+00], len(y) = 100
# 		Pressure                              p    : [1.648e+05 ... 1.289e+05], len(p) = 100

For ease of use, the XYDiagram struct is iterable, such that we can unpack it efficiently as

lle, l1ve, l2ve = pxy

Now, we can plot the phase diagram as

# Continued
import matplotlib.pyplot as plt

# Liquid-liquid phase boundaries
# pxy.lle holds the composition and pressure of the liquid phases
plt.plot(pxy.lle.x1, pxy.lle.p, label='Liquid 1 composition') # lle.x1 is the mole fraction of component 1 (NC12) in Liquid 1 along the phase boundary
plt.plot(pxy.lle.x2, pxy.lle.p, label='Liquid 2 composition') # lle.x2 is the mole fraction of component 1 (NC12) in Liquid 2 along the phase boundary

# Liquid 1-vapour phase boundaries
# pxy.l2ve holds composition and pressure along the Liquid 1 - Vapour phase boundary
plt.plot(pxy.l1ve.x, pxy.l1ve.p, label='Liquid 1 bubble line') # l1ve.x is the mole fraction of component 1 (NC12) in Liquid 1 along the Liquid 1 - Vapour phase boundary
plt.plot(pxy.l1ve.y, pxy.l1ve.p, label='Liquid 1 dew line') # l1ve.y is the mole fraction of component 1 (NC12) in the Vapour phase along the Liquid 1 - Vapour phase boundary

# Liquid 2-vapour phase boundaries
# L2VE[2] is the pressure along the Liquid 2 - Vapour phase boundary
plt.plot(pxy.l2ve.x, pxy.l2ve.p, label='Liquid 2 bubble line') # l2ve.x is the mole fraction of component 1 (NC12) in Liquid 2 along the Liquid 2 - Vapour phase boundary
plt.plot(pxy.l2ve.y, pxy.l2ve.p, label='Liquid 2 dew line') # l2ve.y is the mole fraction of component 1 (NC12) in the Vapour phase along the Liquid 2 - Vapour phase boundary

plt.ylabel('Pressure [Pa]') # The third element in each tuple is the pressure along the phase boundary
plt.xlabel('Molar composition')

The method get_binary_txy works in the same way, only replacing the p attribute with T, such that we can compute

p = 1e5
lle, l1ve, l2ve = eos.get_binary_txy(p) # Unpacking the XYDiagram

# Liquid-liquid phase boundaries
# l1ve holds the composition and pressure of Liquid 1 and Vapour along the phase boundary
plt.plot(l1ve.x, l1ve.T, label='Liquid 1 composition') # l1ve.x is the mole fraction of component 1 (NC12) in Liquid 1 along the phase boundary
plt.plot(l1ve.y, l1ve.T, label='Vapour composition') # l1ve.y is the mole fraction of component 1 (NC12) in Vapour along the phase boundary

# ... etc ...

In the same way as for v2.1.0, the arrays of values are set to None if an equilibrium is not found, such that we may need to check for the presence of an equilibrium before plotting.

Dew- and bubble points

We can also compute the bubble-temperature, pressure etc. directly using the methods bubble_temperature(p, z), bubble_pressure(T, z), dew_temperature(p, z) and dew_pressure(T, z), where z is the composition of the mixture, as

eos = cubic('CO2,C1', 'SRK')
x = [0.5, 0.5] # Total composition of the mixture
p_dew, y_dew = eos.dew_pressure(250, x) # Calculates dew pressure and dew composition at 250 K
T_dew, y_dew = eos.dew_temperature(1e5, x) # Calculates dew temperature and dew composition at 1 bar
p_bub, x_bub = eos.bubble_pressure(230, x) # Calculates bubble pressure and bubble composition at 230 K
T_bub, x_bub = eos.bubble_temperature(1e5, x) # Calculates bubble temperature and bubble composition at 1 bar

Isolines

Various isolines can be computed using the methods get_isotherm, get_isobar, get_isentrope and get_isenthalp. In the following code snippet, the default values of the keyword arguments are indicated.

from thermopack.pcsaft import pcsaft
eos = pcsaft('NC6,NC12')
x = [0.2, 0.8]

# Calculate pressure, specific volume, specific entropy and specific enthalpy along the isotherm at 300 K
# from p = minimum_pressure to p = maximum_pressure. Compute at most nmax points.
p_iso_T, v_iso_T, s_iso_T, h_iso_T = eos.get_isotherm(300, x, minimum_pressure=1e5, maximum_pressure=1.5e7, nmax=100)

# Calculate temperature, specific volume, specific entropy and specific enthalpy along the isobar at 1 bar
# from T = minimum_temperature to T = maximum_temperature. Compute at most nmax points.
T_iso_p, v_iso_p, s_iso_p, h_iso_p = eos.get_isobar(1e5, x, minimum_temperature=200, maximum_temperature=500, nmax=100)

# Calculate temperature, pressure, specific volume and specific entropy along the isenthalp at 1 kJ / mol
# Start at the upper of (minimum_pressure, minimum_temperature)
# End at the lower of (maximum_pressure, maximum_temperature)
T_iso_h, p_iso_h, v_iso_h, s_iso_h = eos.get_isenthalp(1e3, x, minimum_pressure=1e5, maximum_pressure=1.5e7,
                                                            minimum_temperature=200, maximum_temperature=500,
                                                            nmax=100)

# Calculate temperature, pressure, specific volume and specific enthalpy along the isentrope at 5 J / mol K
# Start at the upper of (minimum_pressure, minimum_temperature)
# End at the lower of (maximum_pressure, maximum_temperature)
T_iso_s, p_iso_s, v_iso_s, h_iso_s = eos.get_isentrope(5, x, minimum_pressure=1e5, maximum_pressure=1.5e7,
                                                            minimum_temperature=200, maximum_temperature=500,
                                                            nmax=100)

In addition to these, we can trace isentropes and isotherms in the metastable region using the methods map_meta_isentrope and map_meta_isotherm.

Critical point

Thermopack has a critical point solver, which is called as

eos = saftvrqmie('HE,NE') # Use FH-corrected Mie potentials for Helium calculations!
n = [5, 10]
Tc, Vc, pc = eos.critical(n) # Compute the critical temperature, pressure and volume given mole numbers
vc = Vc / sum(n) # Critical specific volume computed from critical volume and mole numbers.

The solver accepts initial guesses for the critical values through the kwargs temp, and v. The error tolerance can be set via the tol kwarg (default is tol=1e-7).

To compute only the critical pressure, temperature or molar volume, we can use the methods [critical_pressure]

Metastable region

Methods for computing properties in the metastable region are found in the documentation for stability interfaces.

We can trace the spinodal curve as

import matplotlib.pyplot as plt
from thermopack.tcPR import tcPR

eos = tcPR('CO2,C1')
z = [0.2, 0.8]
Ts, vs, ps = eos.spinodal(z) # Trace the spinodal
Te, pe, ve = eos.get_envelope_twophase(1e3, z, calc_v=True) # Trace the phase envelope
plt.plot(Ts, ps, label='Spinodal')
plt.plot(Te, pe, label='Phase envelope')
plt.xlabel('T [K]')
plt.ylabel('p [Pa]')
plt.show()

plt.plot(1 / vs, Ts, label='Spinodal')
plt.plot(1 / ve, Te, label='Phase envelope')
plt.xlabel(r'$\rho$ [mol m$^{-3}$]')
plt.ylabel('T [K]')
plt.show()

We can also find specific points on the spinodal using the spinodal_point method.

For density solvers that can be used in the metastable region, refer to the documentation for stability interfaces.

For methods to trace isolines in the metastable region, refer to the section on isolines.

More advanced usage

Interaction parameters

In thermopack we're able to both set and get a wide array of coefficients and parameters depending on the models we are utilizing.

Cubic equations of state

Setting and getting the attractive energy interaction parameter $k_{ij}$ and co-volume interaction parameter $l_{ij}$

Starting with the attractive energy interaction parameter (kij). The parameter can be set using the function set_kij after initialising the equation and state. The function requires that you first write in the number of the components and subsequently the new interaction parameter i.e. (component number 1, component number 2, new kij value). If we're curious as to what parameter the EOS is already using we can see this by using the function get_kij which returns the value as a float given the component numbers as input i.e. (component number 1, component number 2).

cs = cubic('CO2,N2',"SRK","Classic","Classic")
#We set the interaction parameter to be -0.032
cs.set_kij(1,2,-0.032)
#We want to see what the interaction parameter is which returns that kij = -0.032
kij = cs.get_kij(1,2)

The procedure for setting and getting co-volume interaction parameters is analogous to the getting and setting of attractive energy parameters. Simply use the functions set_lij and get_lij instead.

#We set the parameter to be -0.032
cs.set_lij(1,2,-0.032)
#We want to see what the parameter is which returns that lij = -0.032
lij = cs.get_lij(1,2)

Tuning Cubics

Cubic Equations of state implemented in ThermoPack can be accessed through the generic cubic class. This class also offers a variety of methods to tune the alpha-function, mixing rules etc. See the documentation for the cubic class for more information.

The different property interfaces (TV-) (Tp-) and (TVp-)

Property calculations in ThermoPack can be done either through the TV-interfaces, the Tp-interfaces or the TVp-interfaces.

The difference between the TV- and Tp- interface is only what variables the properties are computed as functions of, and what variables are held constant in the derivatives. TV-interface methods compute properties as functions of $(T, V, n)$, while Tp-interface methods compute properties as functions of $(T, p, n)$.

The TVp-interface methods on the other hand take $(T, V, n)$ as arguments, and evaluate derivatives as functions of $(T, p, n)$. To demonstrate with an example:

import numpy as np
from thermopack.cubic import cubic

eos = cubic('O2,N2', 'PR') # PR EoS for O2/N2 mixture

T = 300 # Kelvin
p = 1e5 # Pascal
x = np.array([0.21, 0.79]) # Molar composition (of air)
n_tot = 10 # Total number of moles
n = n_tot * x # Vector of mole numbers

v, = eos.specific_volume(T, p, x, eos.VAPPH) # Compute specific volume of vapour phase
V = v * n_tot # Total volume


# Computing the TOTAL Enthalpy (J), given (T, V, n)
# The differentials are computed for H = H(T, V, n), with
# "subscripts" indicating the variables held constant
H_tvn, dHdT_Vn, dHdn_TV = eos.enthalpy_tv(T, V, n, dhdt=True, dhdn=True)

# Computing the SPECIFIC VAPOUR phase enthalpy (J / mol), given (T, p, n)
# The differentials are computed for h_vap = h_vap(T, p, n), with the
# "subscripts" indicating the variables held constant
h_vap_tpn, dh_vap_dt_pn, dh_vap_dn_Tp = eos.enthalpy(T, p, n, eos.VAPPH, dhdt=True, dhdn=True)

# Computing the SPECIFIC LIQUID phase enthalpy (J / mol), given (T, p, n)
# The differentials are computed for h_liq = h_liq(T, p, n), with the
# "subscripts" indicating the variables held constant
h_liq_tpn, dh_liq_dt_pn, dh_liq_dn_Tp = eos.enthalpy(T, p, n, eos.LIQPH, dhdt=True, dhdn=True)

# Computing the TOTAL Enthalpy (J), given (T, V, n)
# NOTE : The differentials are computed for H = H(T, p, n)
#        NOT for H = H(T, V, n)
H_tpn, dHdt_pn, dHdn_Tp = eos.enthalpy_tvp(T, V, n, dhdt=True, dhdn=True)

Besides enthalpy_tvp, there are currently available TVp-interfaces for entropy_tvp and thermo_tvp (logarithm of fugacity coefficients).

Component identifiers

Fluid name to fluid identifier mapping



In order to specify fluids in Thermopack you need to use fluid identifiers as shown in the table below. The 'SAFT-VR', 'PC-SAFT' and 'CPA' columns indicate which fluids SAFT-EoS and CPA parameters are available for.

  You may have to scroll right to view the whole table.

Fluid name	CAS Number	Fluid identifyer	SAFT-VR	PC-SAFT	CPA
1,1,1,2-Tetrafluoroethane	811-97-2	R134a
1,1,1-Trifluoroethane	420-46-2	R143a
1,1-Difluoroethane	75-37-6	R152a
1,1-Difluoroethylene	75-38-7	R1132a
1,2-Dichlorotetrafluoroethane	76-14-2	R114
1,3-Butadiene	106-99-0	13BD
1-Butanol	71-36-3	BUT1OL		✔	✔
1-Chloro-1,1,2,2-tetrafluoroethane	354-25-6	R124a
1-Chloro-1,1-difluoroethane	75-68-3	R142b
1-Hexanol	111-27-3	HEX1OL		✔	✔
1-Pentanol	71-41-0	PENT1OL		✔	✔
1-Propanol	71-23-8	PROP1OL		✔	✔
2,3,3,3-Tetrafluoropropene	754-12-1	R1234yf
2-Chloro-1,1,1,2-tetrafluoroethane	2837-89-0	R124
2-Methylhexane	591-76-4	2MHX
3-Methylpentane	96-14-0	3MP
Acetone	67-64-1	ACETONE		✔
Acetylene	74-86-2	ACETYLENE		✔
Ammonia	7664-41-7	NH3	✔	✔	✔
Argon	7440-37-1	AR	✔	✔
Benzene	71-43-2	BENZENE		✔
Butanal	123-72-8	BUTANAL		✔
Carbon dioxide	124-38-9	CO2	✔	✔	✔
Carbon monoxide	630-08-0	CO
Carbon tetrafluoride	75-73-0	R14
Chlorine	7782-50-5	CL2		✔
Chlorodifluoromethane	75-45-6	R22
Chloropentafluoroethane	76-15-3	R115
Chlorotrifluoromethane	75-72-9	R13
Chlorotrifluorosilane	14049-36-6	ClF3Si
Cyclohexane	110-82-7	CYCLOHEX		✔
Cyclopropane	75-19-4	C3_1
Deuterium	7782-39-0	D2	✔
Di-methyl ether	115-10-6	DME		✔
Di-n-hexyl ether	112-58-3	S434
Dichlorodifluoromethane	75-71-8	R12
Dichlorofluoromethane	75-43-4	R21
Difluoromethane	75-10-5	R32
Dinitrogen tetroxide	10544-72-6	N2O4
Equilibrium-hydrogen	1333-74-0	E-H2
Ethane	74-84-0	C2	✔	✔
Ethanol	64-17-5	ETOH	✔	✔	✔
Ethylbenzene	100-41-4	EBZN
Ethylene glycol	107-21-1	MEG
Ethylene	74-85-1	C2_1		✔
Helium-4	7440-59-7	HE	✔
Hexafluoroethane	76-16-4	R116
Hydrazine	302-01-2	N2H4	✔
Hydrogen peroxide	7722-84-1	H2O2
Hydrogen sulfide	7783-06-4	H2S	✔	✔
Hydrogen	1333-74-0	H2	✔
Isobutane	75-28-5	IC4		✔
Isopentane	78-78-4	IC5		✔
Krypton	7439-90-9	KR	✔	✔
Lennard-jones_fluid		LJF	✔
Methane	74-82-8	C1	✔	✔
Methanol	67-56-1	MEOH	✔	✔	✔
Methyl fluoride	593-53-3	R41
Methylcyclopentane	96-37-7	MTC5
Neon	7440-01-9	NE	✔
Nitric oxide	10102-43-9	NO
Nitrogen	7727-37-9	N2	✔	✔
Nitrous oxide	10024-97-2	N2O
Octafluoropropane	76-19-7	R218
Ortho-hydrogen	1333-74-0	O-H2	✔
Oxygen	7782-44-7	O2	✔	✔
Para-hydrogen	1333-74-0	P-H2	✔
Pentafluoroethane	354-33-6	R125
Propadiene	463-49-0	ALLENE
Propane	74-98-6	C3	✔	✔	✔
Propylene	115-07-1	PRLN
Pseudo	XXX	PSEUDO
Sulfur dioxide	7446-09-5	SO2
Sulfur hexafluoride	2551-62-4	F6S
Tetrafluoroethylene	116-14-3	R1114
Tetrafluorohydrazine	10036-47-2	F4N2
Toluene	108-88-3	TOLU		✔
Trans-1,3,3,3-tetrafluoropropene	29118-24-9	R1234ze
Trichlorofluoromethane	75-69-4	R11
Trifluoroamine oxide	13847-65-9	F3NO
Trifluoromethane	75-46-7	R23
Water	7732-18	H2O	✔	✔	✔
Xenon	7440-63-3	XE	✔
m-Xylene	108-38-3	MXYL
n-Butane	106-97-8	NC4	✔	✔	✔
n-Decane	124-18-5	NC10	✔	✔	✔
n-Docosane	629-97-0	NC22	✔	✔
n-Dodecane	112-40-3	NC12		✔
n-Eicosane	112-95-8	NC20	✔	✔
n-Heneicosane	629-94-7	NC21		✔
n-Heptadecane	629-78-7	NC17		✔
n-Heptane	142-82-5	NC7	✔	✔	✔
n-Hexadecane	544-76-3	NC16		✔
n-Hexane	110-54-3	NC6	✔	✔	✔
n-Hydrogen	1333-74-0	N-H2
n-Nonadecane	629-92-5	NC19		✔
n-Nonane	111-84-2	NC9	✔	✔	✔
n-Octadecane	593-45-3	NC18		✔
n-Octane	111-65-9	NC8	✔	✔	✔
n-Pentacosane	629-99-2	NC25		✔
n-Pentadecane	629-62-9	NC15	✔	✔
n-Pentan	109-66-0	NC5	✔	✔	✔
n-Tetracosane	646-31-1	NC24		✔
n-Tetradecane	629-59-4	NC14		✔
n-Tricosane	638-67-5	NC23		✔
n-Tridecane	629-50-5	NC13		✔
n-Undecane	1120-21-4	NC11		✔
o-Xylene	95-47-6	OXYL
p-Xylene	106-42-3	PXYL
