titiler 0.19.1

A modern dynamic tile server built on top of FastAPI and Rasterio/GDAL.

A modern dynamic tile server built on top of FastAPI and Rasterio/GDAL.

---

Documentation: https://devseed.com/titiler/

Source Code: https://github.com/developmentseed/titiler

---

Titiler, pronounced tee-tiler (ti is the diminutive version of the french petit which means small), is a set of python modules that focus on creating FastAPI application for dynamic tiling.

Note: This project is the descendant of cogeo-tiler and cogeo-mosaic-tiler.

Features

• Built on top of FastAPI
• Cloud Optimized GeoTIFF support
• SpatioTemporal Asset Catalog support
• Multiple projections support (see TileMatrixSets) via morecantile.
• MultiDimensional dataset support via Xarray
• JPEG / JP2 / PNG / WEBP / GTIFF / NumpyTile output format support
• OGC WMTS support
• Automatic OpenAPI documentation (FastAPI builtin)
• Virtual mosaic support (via MosaicJSON)
• Example of AWS Lambda / ECS deployment (via CDK)

Packages

Starting with version 0.3.0, the TiTiler python module has been split into a set of python namespace packages: titiler.{package}.

Package	Version	Description
titiler.core		The Core package contains libraries to help create a dynamic tiler for COG and STAC
titiler.xarray		The xarray package contains libraries to help create a dynamic tiler for Zarr/NetCDF datasets
titiler.extensions		TiTiler's extensions package. Contains extensions for Tiler Factories.
titiler.mosaic		The mosaic package contains libraries to help create a dynamic tiler for MosaicJSON (adds cogeo-mosaic requirement)
titiler.application		TiTiler's demo package. Contains a FastAPI application with full support of COG, STAC and MosaicJSON

Installation

To install from PyPI and run:

# Make sure you have pip up to date
python -m pip install -U pip

python -m pip  install titiler.{package}
# e.g.,
# python -m pip  install titiler.core
# python -m pip  install titiler.xarray
# python -m pip  install titiler.extensions
# python -m pip  install titiler.mosaic
# python -m pip  install titiler.application (also installs core, extensions and mosaic)

# Install uvicorn to run the FastAPI application locally
python -m pip install uvicorn

# Launch application locally
uvicorn titiler.application.main:app

To install from sources and run for development:

git clone https://github.com/developmentseed/titiler.git
cd titiler

python -m pip install -U pip
python -m pip install -e src/titiler/core -e src/titiler/xarray -e src/titiler/extensions -e src/titiler/mosaic -e src/titiler/application
python -m pip install uvicorn

uvicorn titiler.application.main:app --reload

Docker

Ready to use/deploy images can be found on Github registry.

• https://github.com/developmentseed/titiler/pkgs/container/titiler

docker run --name titiler \
    -p 8000:8000 \
    --env PORT=8000 \
    --env WORKERS_PER_CORE=1 \
    --rm -it ghcr.io/developmentseed/titiler:latest

• Built the docker locally

git clone https://github.com/developmentseed/titiler.git
cd titiler

docker compose up --build titiler  # or titiler-uvicorn

Some options can be set via environment variables, see: https://github.com/tiangolo/uvicorn-gunicorn-docker#advanced-usage

Project structure

src/titiler/                     - titiler modules.
 ├── application/                - Titiler's `Application` package
 ├── extensions/                 - Titiler's `Extensions` package
 ├── xarray/                     - Titiler's `Xarray` package
 ├── core/                       - Titiler's `Core` package
 └── mosaic/                     - Titiler's `Mosaic` package

Contribution & Development

See CONTRIBUTING.md

License

See LICENSE

Authors

Created by Development Seed

See contributors for a listing of individual contributors.

Changes

See CHANGES.md.
