torchsample 0.1.0

Neural network sampling utilities.

Lightweight pytorch functions for neural network featuremap sampling.

WARNING: API is not yet stable. API subject to change!

Introduction

Sampling neural network featuremaps at explicit coordinates has become more and more common with popular developments like:

• Learning Continuous Image Representation with Local Implicit Image Function

• NeRF: Representing Scenes as Neural Radiance Fields for View Synthesis

• PointRend: Image Segmentation as Rendering

PyTorch provides the tools necessary that to sample coordinates, but they result in a large amount of error-prone code. TorchSample intends to make it simple so you can focus on other parts of the model.

Usage

Installation

Requires python >=3.8 Install torchsample via pip:

pip install torchsample

Or, if you want to install the nightly version:

pip install git+https://github.com/BrianPugh/torchsample.git@main

Training

A common scenario is to randomly sample points from a featmap and from the ground truth.

import torchsample as ts

b, c, h, w = batch["image"].shape
coords = ts.coord.rand(b, 4096, 2)  # (b, 4096, 2) where the last dim is (x, y)

featmap = feature_extractor(batch["image"])  # (b, feat, h, w)
sampled = ts.sample(coords, featmap)  # (b, 4096, feat)
gt_sample = ts.sample(coords, batch["gt"])

Inference

During inference, a comprehensive query of the network to form a complete image is common.

import torch
import torchsample as ts

b, c, h, w = batch["image"].shape
coords = ts.coord.full_like(batch["image"])
featmap = encoder(batch["image"])  # (b, feat, h, w)
feat_sampled = ts.sample(coords, featmap)  # (b, h, w, c)
output = model(featmap)  # (b, h, w, pred)
output = output.permute(0, 3, 1, 2)

Positional Encoding

Common positional encoding schemes are available.

import torchsample as ts

coords = ts.coord.rand(b, 4096, 2)
pos_enc = ts.encoding.gamma(coords)

A common task it concatenating the positional encoding to sampled values. You can do this by passing a callable into ts.sample:

import torchsample as ts

encoder = ts.encoding.Gamma()
sampled = ts.sample(coords, featmap, encoder=encoder)

Models

torchsample has some common builtin models:

import torchsample as ts

# Properly handles (..., feat) tensors.
model = ts.models.MLP(256, 256, 512, 512, 1024, 1024, 1)

Design Decisions

• align_corners=False by default (same as Pytorch). You should probably not touch it; explanation here.

• Everything is in normalized coordinates [-1, 1] by default.

• Coordinates are always in order (x, y, ...).

• Whenever a size is given, it will be in (w, h) order; i.e. matches coordinate order. It makes implementation simpler and a consistent rule helps prevent bugs.

• When coords is a function argument, it comes first.

• Simple wrapper functions (like ts.coord.rand) are provided to make the intentions of calling code more clear.

• Try and mimic native pytorch and torchvision interfaces as much as possible.

• Try and make the common-usecase as simple and intuitive as possible.
