xeda 0.4.4

Xeda is a cross-platform automation framework for RTL simulation, FPGA synthesis and implementation, and ASIC synthesis and physical design. A single declarative design file can drive commercial and open-source EDA tools without duplicating tool-specific build scripts.

Read the Xeda documentation for the complete design-file, flow, and run-directory references.

Installation

Python 3.11 or newer is required. Xeda orchestrates EDA tools but does not install them; the tools needed by a selected flow must be available locally, in Docker, or on the configured remote host.

For CLI use, the preferred installation is an isolated uv tool environment:

uv tool install --upgrade xeda

pipx is an equivalent alternative:

pipx install --force xeda

To import Xeda as a Python library, install it in your project's virtual environment:

python3 -m pip install -U xeda

Verify the installation with xeda --version.

Development

git clone --recursive https://github.com/XedaHQ/xeda.git
cd xeda
uv sync
uv run pytest tests/

An editable pip installation also works if uv is unavailable.

Usage

The CLI is self-describing. Discover the installed flows and their exact contracts before running one:

xeda list-flows                   # every flow, with its aliases, category and dependencies
xeda list-settings vivado_synth   # every setting of a flow, with type, default and meaning
xeda list-results vivado_synth    # the keys that flow writes to results.json
xeda design-schema                # JSON Schema of a design description file
xeda run vivado_synth sqrt.toml -s clock.period=5.0

Flow names accept snake case, dashes, CamelCase class names, and documented aliases. Setting names are exact; unknown settings fail instead of being silently ignored.

Scripting and coding agents

The query commands above accept --json for machine-readable output. The run, dse, and scrub commands also accept it; tool output and logs then move to stderr so stdout contains one parseable JSON document:

xeda run vivado_synth sqrt.toml --json | jq '.results.Fmax'

Xeda also ships a coding-agent skill whose flow catalog is generated from the installed version:

xeda skill install                # writes ./.claude/skills/xeda/

Design description

A design file describes what to build: sources in compilation order, the top level, parameters, logical clock ports, and an optional testbench. Tool constraints remain per-flow settings. TOML, YAML, and JSON are accepted; paths resolve relative to the design file.

For example, examples/vhdl/sqrt/sqrt.toml:

name = "sqrt"
description = "Iterative computation of square-root of an integer"
language.vhdl.standard = "2008"

[rtl]
sources = ["sqrt.vhdl"]
top = "sqrt"
clock = { port = "clk" }
parameters = { G_IN_WIDTH = 32 }

[tb]
sources = ["tb_sqrt.py"]
cocotb = true

[flows.vivado_synth]
fpga.part = "xc7a100tftg256-2L"
clock.period = 5.0

Use xeda design-schema for the authoritative input schema.

Flows

A flow describes how to build or test a design with one or more tools. Dependencies run automatically. For example, nextpnr runs its yosys_fpga synthesis dependency before place and route. Results, generated scripts, reports, and effective settings are kept under xeda_run/.

Supported Tools and Flows

• AMD-Xilinx Vivado Design Suite
  • vivado_synth: FPGA synthesis and implementation in project mode, run in batch
  • vivado_alt_synth: the same in non-project mode, driving synth_design through route_design from a generated TCL script
  • vivado_project: creates a Vivado project for the design, to work on in Vivado (gui = true opens it)
  • vivado_sim: functional simulation of an RTL design with the Vivado simulator (xsim)
  • vivado_postsynth_sim: post-synthesis and post-implementation simulation of the generated netlist, optionally annotated with timing from an SDF file
  • vivado_power: post-implementation power estimation from the real switching activity of a timing-annotated netlist simulation, rather than a vectorless estimate
• AMD-Xilinx ISE Design Suite
  • ise_synth: FPGA synthesis and implementation for older Xilinx device families
• Bluespec compiler (bsc 2026.07.1 or newer), for designs in Bluespec SystemVerilog (BSV) and Bluespec Classic (BH)
  • bsc: compiles the design to Verilog, and collects the Verilog files its top module needs (including the bsc library modules it instantiates) for any downstream synthesis or simulation flow
  • bsc_sim: compiles a Bluespec testbench and simulates it with Bluesim, or with Verilator, Icarus Verilog or another Verilog simulator through bsc's own Verilog link step
• GHDL VHDL simulator
  • ghdl_sim (alias: ghdl): VHDL simulation
  • ghdl_synth: VHDL elaboration through ghdl --synth; for general-purpose synthesis prefer yosys, which handles VHDL, Verilog and mixed-language designs
• Intel Quartus Prime (Lite/Pro Editions)
  • quartus: FPGA synthesis and implementation flow
• Lattice Diamond
  • diamond_synth: synthesis, place & route and bitstream generation for Lattice devices
• NVC VHDL simulator
  • nvc: VHDL simulation
• Siemens (Mentor) ModelSim
  • modelsim: RTL and gate-level netlist simulation of VHDL, Verilog, SystemVerilog and mixed-language designs, with optional SDF timing annotation
• nextpnr portable FPGA place and route tool
  • nextpnr: places and routes the netlist produced by its yosys_fpga dependency and reports achieved frequency, slack and utilization. Lattice ECP5 is the supported and tested target; other backends are best-effort and report raw per-bel-type counts
  • open_xc7 (alias: openxc7): Xilinx 7-series place and route via nextpnr-xilinx
• openFPGALoader: open-source and multi-platform universal utility for programming FPGAs, compatible with many boards, cables and FPGAs from major manufacturers
  • openfpgaloader: runs the full yosys_fpga -> nextpnr chain, packs the routed design into a bitstream, and loads it onto the board. The only flow that touches real hardware
• OpenROAD: integrated chip physical design flow that takes a design from RTL sources to routed layout
  • openroad: ASIC implementation on top of a yosys synthesis dependency, against the bundled PDKs (xeda list-platforms)
• Synopsys Design Compiler
  • dc: ASIC logic synthesis
• Synopsys VCS simulator
  • vcs: Verilog/SystemVerilog simulation
• Verilator: the fastest (open-source) Verilog/SystemVerilog simulator
  • verilator: compiles the design to C++/SystemC and builds a native executable. Supports cocotb testbenches, plain C++/SystemC harnesses, and VCD/FST waveform tracing
• Yosys Open SYnthesis Suite
  • yosys: ASIC and generic gate/LUT synthesis
  • yosys_fpga: FPGA synthesis; the dependency of nextpnr, open_xc7 and openfpgaloader
  • yosys_sim: simulation with CXXRTL

Run xeda list-flows for the complete list in the installed version; use xeda list-settings <flow> and xeda list-results <flow> for the exact inputs and outputs.
