xtal2txt 0.1.0

Package to encode and decode crystal structures into text representations

xtal2txt

Package to define, convert, encode and decode crystal structures into text representations. xtal2txt is an important part of our MatText framework.

💪 Getting Started

🚀 Installation

The most recent release can be installed from PyPI with:

$ pip install xtal2txt

The most recent code and data can be installed directly from GitHub with:

$ pip install git+https://github.com/lamalab-org/xtal2txt.git

Text Representation with xtal2txt

The TextRep class in xtal2txt.core facilitates the transformation of crystal structures into different text representations. Below is an example of its usage:

from xtal2txt.core import TextRep
from pymatgen.core import Structure


# Load structure from a CIF file
from_file = "InCuS2_p1.cif"
structure = Structure.from_file(from_file, "cif")

# Initialize TextRep Class
text_rep = TextRep.from_input(structure)

requested_reps = [
        "cif_p1",
        "slices",
        "atom_sequences",
        "atom_sequences_plusplus",
        "crystal_text_llm",
        "zmatrix"
]

# Get the requested text representations
requested_text_reps = text_rep.get_requested_text_reps(requested_reps)

Using xtal2txt Tokenizers

By default, the tokenizer is initialized with \[CLS\] and \[SEP\] tokens. For an example, see the SliceTokenizer usage:

from xtal2txt.tokenizer import SliceTokenizer

tokenizer = SliceTokenizer(
                model_max_length=512,
                truncation=True,
                padding="max_length",
                max_length=512
            )
print(tokenizer.cls_token) # returns [CLS]

You can access the \[CLS\] token using the [cls_token]{.title-ref} attribute of the tokenizer. During decoding, you can utilize the [skip_special_tokens]{.title-ref} parameter to skip these special tokens.

Decoding with skipping special tokens:

tokenizer.decode(token_ids, skip_special_tokens=True)

Initializing tokenizers with custom special tokens

In scenarios where the \[CLS\] token is not required, you can initialize the tokenizer with an empty special_tokens dictionary.

Initialization without \[CLS\] and \[SEP\] tokens:

tokenizer = SliceTokenizer(
                model_max_length=512,
                special_tokens={},
                truncation=True,
                padding="max_length",
                max_length=512
            )

All Xtal2txtTokenizer instances inherit from PreTrainedTokenizer and accept arguments compatible with the Hugging Face tokenizer.

Tokenizers with special number tokenization

The special_num_token argument (by default False) can be set to true to tokenize numbers in a special way as designed and implemented by RegressionTransformer.

tokenizer = SliceTokenizer(
                special_num_token=True,
                model_max_length=512,
                special_tokens={},
                truncation=True,
                padding="max_length",
                max_length=512
            )

👐 Contributing

Contributions, whether filing an issue, making a pull request, or forking, are appreciated. See CONTRIBUTING.md for more information on getting involved.

👋 Attribution

⚖️ License

The code in this package is licensed under the MIT License. See the Notice for imported LGPL code.

💰 Funding

This project has been supported by the Carl Zeiss Foundation as well as Intel and Merck.
